STE-6000 Series Room Temperature Sensors
Applications Guide
STE-6012/6016
2.250
2.438
STE-6012/6013/6019/6020
All dimensions are in inches
Room Temperature Sensors
STE-6014
.643
.149 for
6012/6013;
.422 for
6019/6020
(Screw-type)
Clamp
(Screw-type)
Terminals
STE-6011
STE-6000 Series
STE-6017/6019
.450
.475
max.
Modular
RJ-45
Jack
Clamp
Terminals
Four-pin
EIA-485
PC Data
Port
STE-6010/6014/6015/6016/6017/6018
STE-6018/6020
Applications Guide
