KMC Controls STE-6000 Series Installation Manual

Mounting
STE-6014 STE-6017/6019
Interface
Features
Model
Number
Override
Button
Indicator
STE-6014
STE-6017 X
STE-6019 X
STE-6018 X
STE-6020 X
All dimensions are in inches
2.250
2.438
R .187 R 3.094
Location and Cover Removal
Install the sensor on an inside wall where it can sense
the average room temperature and be away from
direct sunlight, heat sources, windows, air vents,
and air circulation obstructions (curtains, furniture,
etc.). It can be mounted on a hollow wall or (with
an HMO-6036/6036W universal backplate) to a 2 x 4
inch electrical (handy) box.
The cover is held to the black base by three, small,
round pegs that fit in the holes of the cover. The
STE-6014/6017/6018/6019/6020 Room Temperature Sensors
Room Temperature Sensors (with Rotary Dials)
Installation Guide
STE-6018/6020
Cable
Connections
LED Screw
RJ-45
Status Clamp
Connector
Terminals
X
X
X
X X
X X
.643
.422
Clamp
(Screw-type)
Terminals
STE-6019/6020 STE-6014/6017/6018
bottom peg is on a tab, which snaps into the center
bottom hole.
1. With a small Phillips screwdriver or hex wrench,
press in and hold the plastic tab button that
snaps into the center hole on the bottom of the
cover. Do not use excessive force and deform or
break the tab.
2. Carefully pull the cover from the black base.
Electrical Box Installation (Recommended)
EIA-485
Data
1. Mount an HMO-6036 or
Port
HMO-6036W universal
X
backplate to the handy
X
box using the two screws
provided.
X
2. Remove the cover from
the black base (see the
Location and Cover
Removal section).
3. With the plastic tab
.475
max. button on the bottom, attach the base to the
universal backplate using the two screws
provided.
Modular
4. Connect the wiring (see the Wiring section).
RJ-45
Jack
5. Reinstall the cover.
Four-pin
Hollow Wall Installation
EIA-485
PC Data
Port
1. Remove the cover from the black base (see the
Location and Cover Removal section).
2. Using the base as a template, drill two holes
for mounting screws (7/64 inches or 3 mm in
diameter and 1.4 inches, 1-13/32 inches, or 35.6
mm apart) and cut a center hole (size needed is
dependent on model) for the terminal block or
jack.
3. Attach the base to the wall using two #6
self-threading screws. (Plastic anchors are
recommended, and the size of the holes will then
need adjusting.)
4. Connect the wiring (see the Wiring section).
5. Reinstall the cover.
1
STE-6014/6017/6018/6019/6020
Installation Guide
