Control Buttons
CONTROL BUTTONS
Press the Enter button repeatedly to view:
• Cooling Setpoint
• Heating Setpoint
• Mode (Heat, Cool, Auto, Off, or Emergency
Heat)
• Fan (Auto or Constant On)
While viewing a menu item:
• Press the Up or Down button to change the
setting if desired
• Press the Enter button to continue
(A Level 1 password might be required to
access this menu. If needed, contact the
installer.)
Up
Enter
Down
Quick Reference Guide
STE-9000 Series Digital Room Sensors
PM
OCCUPANCY MODE
The icon shows the current mode (according
to the schedule, sensed motion, or button
activation):
• Person in house = Occupied
• Empty house = Standby
• OVR = Override (activated by motion or ad-
justing setpoint during unoccupied times on
a schedule)
• None of the icons = Unoccupied
Current Temperature
Occupancy Mode
Time (and Optional
CO
or Humidity)
2
Opt. Motion Sensor
