Programming the unit

There are four TAPPETS on your timing dial, two red and
two blue:
the red tappets are the ON switches
the blue tappets are the OFF switches
Tappets
1 If you have not already done so, remove the dial cover
2 Hold the black & silver knob with one hand and move
the red tappet marked 'A' clockwise to the time you
want your HEATING/HOT WATER to switch on in the
morning.
NB. you may fi nd the tappets quite stiff, so you may
have to push them quite fi rmly to move them.
3 Hold the black knob with one hand and move the blue
tappet marked 'B' to the time you want your HEATING/
HOT WATER to switch off in the morning.
4 You can set your other two tappets in the same way
to set your HEATING/HOT WATER for the afternoon
or evening.
!
For latest prices and delivery to your door visit MyTub Ltd - 0845 303 8383 - www.mytub.co.uk - info@mytub.co.uk
DO NOT switch the programmer on and off
with the mains switch as this will stop the
clock/timer and affect the timed programme.
Tappets
17
