USB-2416-4AO User's Guide
Do not connect to terminal block pins labeled "NC."
Pin Signal name
1 NC
2 CH0H
3 CH0L
4 NC
5 IC0
6 CH1H
7 CH1L
8 4WC1
9 IC1
10 CH2H
11 CH2L
12 4WC2
13 IC2
14 CH3H
15 CH3L
16 4WC3
17 IC3
18 GND
19 CH4H
20 CH4L
21 4WC4
22 IC4
23 CH5H
24 CH5L
25 4WC5
26 IC5
27 CH6H
28 CH6L
29 4WC6
30 IC6
31 CH7H
32 CH7L
33 4WC7
34 IC7
35 +5V
36 GND
37 VDAC0
38 VDAC1
39 GND
40 VDAC2
41 VDAC3
42 GND
43 CTR0
44 GND
45 CTR1
46 GND
47 NC
48 NC
Table 37. 32-channel single-ended mode pin out
Pin description
No connect
Channel 0
Channel 16
No connect
No connect
Channel 1
Channel 17
No connect
No connect
Channel 2
Channel 18
No connect
No connect
Channel 3
Channel 19
No connect
No connect
Analog ground
Channel 4
Channel 20
No connect
No connect
Channel 5
Channel 21
No connect
No connect
Channel 6
Channel 22
No connect
No connect
Channel 7
Channel 23
No connect
No connect
+5V output
Analog ground
Analog output Ch0
Analog output Ch1
Analog ground
Analog output Ch2
Analog output Ch3
Analog ground
Counter input Ch0
Analog ground
Counter input Ch1
Analog ground
No connect
No connect
43
Pin Signal name
49 NC
50 CH15L
51 CH15H
52 IC14
53 4WC14
54 CH14L
55 CH14H
56 IC13
57 4WC13
58 CH13L
59 CH13H
60 IC12
61 4WC12
62 CH12L
63 CH12H
64 IC11
65 4WC11
66 GND
67 CH11L
68 CH11H
69 IC10
70 4WC10
71 CH10L
72 CH10H
73 IC9
74 4WC9
75 CH9L
76 CH9H
77 IC8
78 4WC8
79 CH8L
80 CH8H
81 GND
82 NC
83 NC
84 GND
85 DIO7
86 DIO6
87 DIO5
88 DIO4
89 DIO3
90 DIO2
91 DIO1
92 DIO0
93 DGND
94 DGND
95 NC
96 NC
Specifications
Pin description
No connect
Channel 31
Channel 15
No connect
No connect
Channel 30
Channel 14
No connect
No connect
Channel 29
Channel 13
No connect
No connect
Channel 28
Channel 12
No connect
No connect
Analog ground
Channel 27
Channel 11
No connect
No connect
Channel 26
Channel 10
No connect
No connect
Channel 25
Channel 9
No connect
No connect
Channel 24
Channel 8
Analog ground
No connect
No connect
Analog ground
Digital input/output
Digital input/output
Digital input/output
Digital input/output
Digital input/output
Digital input/output
Digital input/output
Digital input/output
Digital I/O ground
Digital I/O ground
No connect
No connect
