USB-2416-4AO User's Guide
Installing the USB-2416-4AO
Screw terminal pin out – single-ended
Figure 5. 32-channel single-ended mode pin out
Figure 6. DSUB37 expansion connector pinout
The AI-EXP32 expansion port is intended to interface directly with the USB-2416-4AO. Do not attempt to use
any of the expansion port pins for any other purpose.
Power-down the USB-2416-4AO before you connect it the AI-EXP32 expansion board.
11
