IHR Series Manual
Chart 1.1 • Clearance to Combustibles in Inches (see Figure 1.1)
Model No.
IHR 30
IHR 60
IHR 90
IHR 130
IHR 160
* This clearance is 80 in. when the heater is fitted with a parabolic reflector.
NOTE: If the heater is mounted beneath a non-combustible surface, a 24 in. minimum top clearance must
be maintained from the top of the heater to prevent overheating the controls.
Figure 1.1 • Clearance to Combustibles
Side
Mount Heater Level
- Side to Side -
FRONT VIEW
Sides
30
32
48
48
50
Top
Side
Front
5
1.0 Safety
Back
18
18
30
30
32
20° - 35°
SIDE VIEW
• Clearance to Combustibles
Top Below/Front
28 72
40 72*
42 98
52 120
60 132
Back
Manifold or
Control End
Below
