- Page 1 Electronic Code Locks SL2000B v1.4 and SL2000S1K v1.3 Document version: Rev. C Roger Sp.j.
-
Page 2: Functional Description
(Disable USER Codes When in Armed Mode). Open collector outputs The Bistable (Switch in SL2000B) and BELL outputs of SL2000 lock are an open collector transistor type. Some care must be taken in order to protect them from damage. When transistor output is switched off it remains in high impedance state, when switched on it shorts connected to it potential with supply minus. - Page 3 Electronic Code Locks SL2000B v1.4 and SL200S1K v1.3 EN Rev.C.doc 2011-11-16 Bistable/Switch output Enter the master code each time switches output in the opposite state. This mode is dedicated to control some device or system which requires bistable (latch) control, usually it can be used to control arming mode of the alarm zone or entire alarm system.
-
Page 4: Special Options
Electronic Code Locks SL2000B v1.4 and SL200S1K v1.3 EN Rev.C.doc 2011-11-16 Note: If you are not going to use a door open sensor leave the Door Contact input unconnected. Without a door open sensor the SL2000 will not signal the Door Alarm. - Page 5 Electronic Code Locks SL2000B v1.4 and SL200S1K v1.3 EN Rev.C.doc 2011-11-16 Commands Commands can be entered during normal working time of a SL2000 and doesn’t require entry to the programming mode. [USER Code] [#] Whenever a valid USER code is entered the code lock generates two beeps (**) and then starts count C1C2 time delay.
- Page 6 Electronic Code Locks SL2000B v1.4 and SL200S1K v1.3 EN Rev.C.doc 2011-11-16 Configuring the SL2000 — Memory Reset In order to configure the SL2000 you must perform the Memory Reset procedure and then enroll sequentially 10 digits (C1,C2..C10) which will configure the unit for the individual installation.
-
Page 7: Default Settings
Electronic Code Locks SL2000B v1.4 and SL200S1K v1.3 EN Rev.C.doc 2011-11-16 C8: Enabling and disabling special options, enter 0-3 (default: 0). Option 2: Disable USER Codes When Option 1: Timed Lock-out in Armed Mode Disabled Disabled Enabled Disabled Disabled Enabled... -
Page 8: Installation
The SL2000 code lock should be mounted near the supervised door on a vertical piece of supporting structure. The SL2000S1k can be installed either indoor or outdoor location, SL2000B can be installed in indoor location only. Assure that the surface beneath of the controller’s rear panel is flat and smooth. - Page 9 Electronic Code Locks SL2000B v1.4 and SL200S1K v1.3 EN Rev.C.doc 2011-11-16 Strona 9 z 13...
- Page 10 Electronic Code Locks SL2000B v1.4 and SL200S1K v1.3 EN Rev.C.doc 2011-11-16 Strona 10 z 13...
- Page 11 Electronic Code Locks SL2000B v1.4 and SL200S1K v1.3 EN Rev.C.doc 2011-11-16 Strona 11 z 13...
-
Page 12: Connection Assignments
Electronic Code Locks SL2000B v1.4 and SL200S1K v1.3 EN Rev.C.doc 2011-11-16 Connection assignments Label Description +12V Supply input plus Supply input minus TAMPER Tamper contact, NC max. 50mA/24V DC/AC Exit Button input, NO type Door Contact input, NO type, 1.5A/24V DC/AC... -
Page 13: Product History
Electronic Code Locks SL2000B v1.4 and SL200S1K v1.3 EN Rev.C.doc 2011-11-16 Product History Version Firmware Date Description SL2000B v1.4 07/2011 SL2000S1K v1.3 06/2011 The symbol of a crossed-through waste bin on wheels means that the product must be disposed of at a separate collection point. This also applies to the product and all accessories marked with this symbol.
