- Page 1 Installation and Operation Manual TRAILERED OVENS Stone Hearth Oven Gas-Fired and Gas/Wood Combination Models MT. ADAMS WS-MS-5-RFG-(IR)-(W)-LP-TR BISTRO 4355 WS-BL-4355-RFG-(W)-LP-TR WOOD STONE CORPORATION Toll Free 800.988.8103 1801 W. Bakerview Rd. Tel 360.650.1111 Bellingham, WA 98226 USA Fax 360.650.1166 www.woodstone-corp.com DOC NO M0055.03...
-
Page 2: Table Of Contents
FUEL WOOD FACTS � � � � � � � � � � � � � � � � � � � � � � � �33 LIMITED WARRANTY � � � � � � � � � � � � � � � � � � � � � � �34 Wood Stone Corporation Toll Free 800.988.8103 1801 W. -
Page 3: Trailered Ovens
TRAILERED OVENS Trailered Ovens Installation and Operation Manual INSTALLATION AND OPERATION MANUAL FOR THE WOOD STONE TRAILER OVENS STONE HEARTH COOKING EQUIPMENT TRAILER MOUNTED GAS-FIRED OVEN WS-MS-5-RFG-(IR)-(W)-LP-TR MODELS (INCLUDES NAPLES MODELS) WS-BL-4355-RFG-(W)-LP-TR ADDITIONAL COPIES AVAILABLE UPON REQUEST WS-MS-5-RFG-IR-TR-LP WS-BL-4355-RFG-TR-LP Wood Stone Corporation Toll Free 800.988.8103... -
Page 4: Cautions And Warnings
CAUTIONS AND WARNINGS Trailered Ovens Installation and Operation Manual INSTALLATION AND OPERATION MANUAL FOR WOOD STONE TRAILERED OVENS PROPANE (LP) FUELED STONE HEARTH OVEN RETAIN THIS MANUAL FOR FUTURE REFERENCE Additional copies of this manual at woodstone-corp�com� For prompt responses to service/maintenance questions, call us at @ 1-800-988-8103�... - Page 5 à son installation ou entretien. SAVE THE INSTRUCTIONS Wood Stone’s Gas-Fired ovens have been tested and approved by Intertek Testing Services and are ETL listed to ANSI Z83.11:2016 Ed. 4 / CSA 1.8:2016 Ed. 4, ULC Subject 1482-M1990, UL Subject 2162, ULC-S627-00, UL 737, CSA 2.17-M91...
-
Page 6: Specifications
E INFORMATION CONTAINED IN THIS DRAWING IS THE Revised December 2016. Doc no: M0055.06 120 VAC, 2 A NEMA L5-15 THOUT THE WRITTEN PERMISSION OF WOOD STONE IS Due To Loading, Tire Pressure, and Due To Loading, Tire Pressure, and SOLE PROPERTY OF WOOD STONE CORPORATION... -
Page 7: Bl-4355 Specifications
An ongoing program of product improvement may require us to change Power Cord Receptacle AN ONGOING PROGRAM OF PRODUCT IMPROVEMENT WITHOUT THE WRITTEN PERMISSION OF WOOD STONE IS AN ONGOING PROGRAM OF PRODUCT IMPROVEMENT info@woodstone-corp.com or visit woodstone-corp.com 120 VAC, 2 A NEMA L5-15 specifications without notice. -
Page 8: Venting
Flue extended and Flue collapsed. Flue collapsed and locked. locked. Wood Stone Corporation Toll Free 800.988.8103 1801 W. Bakerview Rd. Tel 360.650.1111 Bellingham, WA 98226 USA Fax 360.650.1166 An ongoing program of product improvement may require us to change info@woodstone-corp.com or visit woodstone-corp.com... -
Page 9: Installation Clearances
CLEARANCES The Wood Stone gas-fired oven must have a minimum 1" clearance to combustibles from all sides, 14" clearance to combustibles from the top and O" clearance to non-combustible materials� WARNING: Do not pack required air spaces with insulation or other materials. -
Page 10: Propane System
If any components are damaged, they must be replaced before using the appliance� Use only the regulator, hose and hose assemblies supplied by Wood Stone� If a regulator or hose needs to be replaced, replace only with a part of equal size and ratings�... -
Page 11: Gas Specifications
9" WS-BL-4355-TR-LP 68,000 Wood Stone recommends that inspection and maintenance of the burners and gas piping connections of this appliance be performed at regularly scheduled intervals and only by professional gas appliance service agencies� GAS CODE LIMITATIONS The installation of this appliance must conform with local codes, or in the absence of local codes, with the National Fuel Gas Code, ANSI Z223�1 or the Natural Gas installation Code CAN/CGA-B149�1 as applicable�... -
Page 12: Electrical Specifications
Electrical grounding: This appliance must be electrically grounded in accordance with local codes, or in the absence of local codes, with the National Electrical code, ANSI/NFPA 70 or the Canadian Electrical Code, CSA C22�1, as applicable� Wood Stone Corporation Toll Free 800.988.8103 1801 W. -
Page 13: Controller
WAIT 5 MINUTES BEFORE RELIGHTING and Celsius temperature ATTENDRE 5 MINUTES AVANT DE RÉALLUMER scales in display screens 1-800-988-8103 www.woodstone-corp.com Wood Stone Corporation Toll Free 800.988.8103 1801 W. Bakerview Rd. Tel 360.650.1111 Bellingham, WA 98226 USA Fax 360.650.1166 An ongoing program of product improvement may require us to change info@woodstone-corp.com or visit woodstone-corp.com... -
Page 14: Initial Start
MS-5 MT ADAMS MODEL INITIAL OVEN START-UP NOTE: The ceramic materials used in the construction of your Wood Stone oven will absorb moisture if exposed to high humidity or damp conditions during shipment from the factory or extended periods of storage before installation� Occasionally, through the course of the initial start-up, as the oven heats up it is possible that you will see some water dripping from the sides of the oven as moisture is driven out of the ceramic�... -
Page 15: Daily Operation
Use a natural fiber brush—always brushing away from the radiant burner well� For deeper cleaning, use a brass bristled brush� The oven floor can be then cleaned with a damp rag wrapped around the brass bristled brush head� (Wood Stone offers an assortment of oven brushes available through your dealer�... -
Page 16: Wood Burning
“green” wood, will cause a build-up of creosote residue throughout the exhaust system� (See the FUELWOOD FACTS section of this manual, or consult Wood Stone for information on what types of wood can be used for oven fuel�) The fire should be ignited a couple of hours before the oven needs to be at cooking temperature�... - Page 17 The interior floor and dome of the oven do not require creosote or soot removal� The oven flue and exhaust system will require inspection and cleaning� The exhaust system must be inspected and cleaned per the manufacturer’s and or local code official’s recommendations� Wood Stone recommends cleaning and inspection at least monthly on any ventilation system serving solid fuel equipment.
-
Page 18: Bl-4355 Controller
1" below the hearth oven on and off� surface� Display will read “LO” when the temperature is below 100 °F� Wood Stone Corporation Toll Free 800.988.8103 1801 W. Bakerview Rd. Tel 360.650.1111 Bellingham, WA 98226 USA Fax 360.650.1166 An ongoing program of product improvement may require us to change info@woodstone-corp.com or visit woodstone-corp.com... -
Page 19: Bl-4355 Initial Start
BL-4355 INITIAL OVEN START-UP NOTE: The ceramic materials used in the construction of your Wood Stone oven will absorb moisture if exposed to high humidity or damp conditions during shipment from the factory or extended periods of storage before installation� Occasionally, through the course of the initial start-up, as the oven heats up it is possible that you will see some water dripping from the sides of the oven as moisture is driven out of the ceramic�... -
Page 20: Bl-4355 Daily Operation
Use a natural fiber brush—always brushing away from the radiant burner well� For deeper cleaning, use a brass bristled brush� The oven floor can be then cleaned with a damp rag wrapped around the brass bristled brush head� (Wood Stone offers an assortment of oven brushes available through your dealer�... -
Page 21: Bl-4355 Wood Burning
“green” wood, will cause a build-up of creosote residue throughout the exhaust system� (See the FUELWOOD FACTS section of this manual, or consult Wood Stone for information on what types of wood can be used for oven fuel�) The fire should be ignited a couple of hours before the oven needs to be at cooking temperature�... - Page 22 The interior floor and dome of the oven do not require creosote or soot removal� The oven flue and exhaust system will require inspection and cleaning� The exhaust system must be inspected and cleaned per the manufacturer’s and or local code official’s recommendations� Wood Stone recommends cleaning and inspection at least monthly on any ventilation system serving solid fuel equipment.
-
Page 23: Flame Height Control
For more information regarding Flame Height Flame Height Index Scale Control, go to the Resource Center section of our web site at: Flame Height Control Knob www.woodstone-corp.com Wood Stone Corporation Toll Free 800.988.8103 1801 W. Bakerview Rd. Tel 360.650.1111 Bellingham, WA 98226 USA Fax 360.650.1166 An ongoing program of product improvement may require us to change info@woodstone-corp.com or visit woodstone-corp.com... -
Page 24: Cleaning
The oven floor can be then cleaned with a damp (not wet) rag wrapped around the brush head� Wood Stone offers an assortment of oven brushes available through your dealer� Specification sheets may be viewed on the Wood Stone website under Tools &... -
Page 25: Periodic Thermal Cleaning
THERMAL CLEANING If a Wood Stone gas-fired oven is operated at low temperatures (below 450 °F), it is possible that grease from food could condense on the walls and ceiling of the oven� To remove the grease that has accumulated on the walls and ceiling of the oven, simply turn the radiant flame to its highest setting�... -
Page 26: Troubleshooting
2. Damaged thermocouple� Contact Wood Stone for assistance� Please contact Wood Stone at 1-800-988-8103 should service be necessary, or if you have any questions about your oven. Our service hours are 8am to 4:30pm Pacific Standard Time. Follow the recorded instructions for Emergency Service if you require assistance during non-business hours. -
Page 27: Operational Sequence
Amber light comes on or, on touchpad-style controllers, dome light comes on� Burner remains on until oven control is turned off� Wood Stone Corporation Toll Free 800.988.8103 1801 W. Bakerview Rd. Tel 360.650.1111 Bellingham, WA 98226 USA Fax 360.650.1166 An ongoing program of product improvement may require us to change info@woodstone-corp.com or visit woodstone-corp.com... - Page 28 “chec”� lights� Floor reaches the Hearth Set Point temperature–Controller turns off power to SV-1� Underfloor burner shuts off� Wood Stone Corporation Toll Free 800.988.8103 1801 W. Bakerview Rd. Tel 360.650.1111 Bellingham, WA 98226 USA Fax 360.650.1166 An ongoing program of product improvement may require us to change info@woodstone-corp.com or visit woodstone-corp.com...
-
Page 29: Bl-4355 Operational Sequence
SV-2 senses pilot flame� Igniter off–SV-2 opens� Burner lights� Radiant burner remains on until oven controller is turned off� Wood Stone Corporation Toll Free 800.988.8103 1801 W. Bakerview Rd. Tel 360.650.1111 Bellingham, WA 98226 USA Fax 360.650.1166 An ongoing program of product improvement may require us to change info@woodstone-corp.com or visit woodstone-corp.com... -
Page 30: Electrical Diagram
DIAG #: WD070 Rev. 0 Bellingham, WA +1(360)650-1111 www.woodstone-corp.com DATE: 11/14/2014 See equipment data plate for correct voltage of your oven� Wood Stone Corporation Toll Free 800.988.8103 1801 W. Bakerview Rd. Tel 360.650.1111 Bellingham, WA 98226 USA Fax 360.650.1166 An ongoing program of product improvement may require us to change info@woodstone-corp.com or visit woodstone-corp.com... - Page 31 DIAG #: WD064 Rev. 0 Bellingham, WA +1(360)650-1111 www.woodstone-corp.com DATE: 3/28/2014 See equipment data plate for correct voltage of your oven� Wood Stone Corporation Toll Free 800.988.8103 1801 W. Bakerview Rd. Tel 360.650.1111 Bellingham, WA 98226 USA Fax 360.650.1166 An ongoing program of product improvement may require us to change info@woodstone-corp.com or visit woodstone-corp.com...
-
Page 32: Bl-4355 Electrical Diagram
DIAG #: WD070 Rev. 0 Bellingham, WA +1(360)650-1111 www.woodstone-corp.com DATE: 11/14/2014 See equipment data plate for correct voltage of your oven� Wood Stone Corporation Toll Free 800.988.8103 1801 W. Bakerview Rd. Tel 360.650.1111 Bellingham, WA 98226 USA Fax 360.650.1166 An ongoing program of product improvement may require us to change info@woodstone-corp.com or visit woodstone-corp.com... -
Page 33: Fuelwood Facts
Wet wood is the most common operational difficulty associated with wood-fired cooking equipment� Wood Stone’s optional Mini-Ligno E Wood Moisture Meter can save you from paying for water when you thought you were paying for wood (see the Tools &... -
Page 34: Limited Warranty
LIMITATIONS OF LIABILITY In the event of warranty claim or otherwise, the sole obligation of Wood Stone shall be the repair and/or replacement, at the option of Wood Stone, of the appliance or component or part thereof� Such repair or replacement shall be at the expense of Wood Stone with the exception of travel over 100 miles or two hours, overtime, and holiday charges which shall be at the expense of the purchaser�... - Page 36 WOOD STONE CORPORATION Toll Free 800.988.8103 1801 W. Bakerview Rd. Tel 360.650.1111 Bellingham, WA 98226 USA Fax 360.650.1166 www.woodstone-corp.com An ongoing program of product improvement may require us to change specifications without notice.
