Mode / Function Operation Instructions
Function Button Function
Single tap Panning Mode / Lock Mode
Double tap Panning and Tilting Mode
Triple tap Rotate 180°in horizontal
Quadruple tap Reset
Long press until
Standby
the red light
flashes quickly

4. Firmware Upgrade

(1) Option 1: connect the gimbal with PC via micro USB cable, and then upgrade the firmware.
Please visit the official website
USB driver, firmware upgrade software and product firmware,and install the relevant software, decompress the
firmware files for standby application.
(2) Option 2: connect the gimbal with Smarphone via bluetooth, and then upgrade the firmware.
Feiyu ON

5. Gimbal initialization

You can initialize your gimbal when:
（1） when camera is not level
（2） if not used for a long period of time
（3） in case of extreme temperature variations
Adjusting steps:
Red light
flashes
press and hold press and hold
1

6. Parameters

Titling Angle
Rolling Angle
Panning Angle
Adaption
Weight
D I S C L A I M E R
Prohibit any user for any illegal purpose. Users will be responsible for
all behaviors of purchase and use products.
The Company assumes no liability for any risks related to or resulting
from the debug and use of this product (including the direct, indirect
or third-party losses).
For any unknown sources of using, we will not be at any services.
The updating and changes of product firmware and program may
cause changes in function descriptions in this user manual, please
read the instructions carefully before upgrading the firmware and use
the corresponding user manual.
You can get the latest user manual from the official website:
www.feiyu-tech.com
Feiyu Tech reserves the right to amend this manual and the terms
and conditions of use the product at any time.
For more information, please visit our official website: www.feiyu-tech.com
Support Email: service@feiyu-tech.com
Due to software and hardware improvements, your actual product might
differ from the descriptions and pictures in this user manual. You can get
the latest user manual from the official website.
Explanation
Single tap to switch between panning mode and lock mode
Under panning and tilting mode, single tap to switch to lock mode
Make the lens rotate 180 °
Reset the tilting axis of the gimbal to initial orientation and initial mode
Single tap again to awake the gimbal, or triple tap to initialize the gimbal
www.feiyu-tech.com to download the relevant programs for upgrading, including
micro USB
Firmware upgrade
new firmware is available,
do you want to upgrade?
Yes No
×
Blue light
is on
Triple tap Triple tap
2
320°
320°
360°
iPhone 7 Plus/7/6s Plus/6s/6 Plus/6/SE/5c/5s/5
350g （
not including battery and smartphone
Upgrade........
PC
Stands on table
Blue light flash
three times quickly
Initialization
successful
3
Titling Increments
Panning Increments
Usage time
）
Attention
Please correctly assemble the gimbal in
accordance with the diagram.
Please install the iPhone before powering
on the gimbal.
When the gimbal is not in use or placed on
the table, please ensure it is powered off.
min 2°/s max 75°/s
min 3°/s max 150°/s
7 Hours
