- Page 1 Sunstrip Pro RGB ORDERCODE 42566...
- Page 2 For more information: iwant@showtec.info You can get some of the best quality, best priced products on the market from Showtec. So next time, turn to Showtec for more great lighting equipment. Always get the best -- with Showtec ! Thank you!
-
Page 3: Table Of Contents
Showtec Showtec Sunstrip Pro RGB Product Guide ™ Warning.................…...……………..…………………………….………..… Safety-instructions……………………………………………………………………………………………………….. Operating Determinations.……………………………………………………………………………………………. Rigging.………………………………………………………………………………………………………………….… Return Procedure……………………………………………………………………..........Claims……………………………………………………………………..............Description...................………..…..………….….….………………………. Features and Overview ..……………………………...…...….……………….…………………...….…………….. Backside…………………………………………………...…...….……………….…………………...….…………….. Installation................…...………………………………………………….…. Set Up and Operation..............……..…………………………………………….. Control Modes…………………………………………………………………………………………………………… One Sunstrip Pro RGB (Built-in Programs)…………………………………………….……………………….. One Sunstrip Pro RGB (Sound Control)…………………………………………………………………………... -
Page 4: Warning
Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: • LED Sunstrip Pro RGB with cable 1,25m. • 2X Quick-lock • User manual LED Expected Lifespan LEDs gradually decline in brightness over time. - Page 5 If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Showtec dealer for service.
-
Page 6: Operating Determinations
The Sunstrip Pro RGB can be placed on a flat stage floor or mounted to any kind of truss by a clamp. Improper installation can cause serious damage to people and property ! Connection with the mains Connect the device to the mains with the power-plug. -
Page 7: Return Procedure
Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility. Call Highlite 0031-455667723 or mail aftersales@highlite.nl and request an RMA prior to shipping the fixture. -
Page 8: Description
Description of the device Features Sunstrip Pro RGB is a LED system from Showtec. • Voltage : AC 110V/60Hz or 220V/50Hz (CE) • Power consumption: Max. 110W • Fuse: 250V / T2A • Audio trigger: Built-in Mic • DMX Input : 3-pin XLR Male/Female connector •... -
Page 9: Installation
1.Plug the end of the electric mains power cord into a proper electric power supply socket. Turn on the music. If the device is set to Sound Program [1-16], then the sunstrip Pro RGB will react to the beat of the music. -
Page 10: Multiple Sunstrips Pro Rgb (Dmx Control)
DMX signal. Maximum recommended DMX data link distance: 100 meters Maximum recommended number of Sunstrip Pro RGB on a DMX data link: 30 fixtures Maximum recommended number of Sunstrip Pro RGB on a IEC link: 8 fixtures Data Cabling To link fixtures together you must obtain data cables. -
Page 11: Control Panel
Control Panel When the red LED indicator light is on, means the Sunstrip Pro RGB is working. When the green LED indicator light is on, means the Sunstrip Pro RGB is receiving a DMX signal. Fig. 5 A. LED Display E. -
Page 12: Menu Overview
MENU OVERVIEW... -
Page 13: System Mode
Press the MODE button to scroll through 4 options of the menu: Only shown at Start-up !!!! Version Number V1.0 System Mode (Page 12) Moto Mode (Page 14) System Setup (Page 15) System Mode... -
Page 14: Autoc Mode
System Mode Press the Up/Down button in the main menu until the display shows: Use the Up/Down buttons to change between Autoc, Sound, DMX or Slave : 1. Autoc Mode 2. Sound Mode 3. DMX Mode 4. Slave ID Mode 1. -
Page 15: Sound Mode
2. Sound Mode Enter the Sound menu by pressing the FUN button. Press the MENU button to go one step back. You can adjust the desired Sound Program from 01-16 by using the UP/DOWN buttons. When you press the Fun Button a second time you can change the sensitivty of each Sound Program. Use the UP/DOWN buttons to change the value from 01-99. -
Page 16: Moto Mode
Moto Mode Press the MODE button until the display shows: use the Up/Down buttons to change between Autom or Keep: 1. Moto Automatic Enter the Autom menu by pressing the FUN button. Press the MENU button to back one step back. Use the FUN button to scroll through these 3 options (P1, P2, Speed) . -
Page 17: System Setup
System Setup Press the MODE button until the display shows: Use the Up/Down buttons to change between Slave number, Wait Time, Backlight or Set Software : 1. Slave Number Enter the Slave Number menu by pressing the FUN button. Press the MENU button to go one step back. You can adjust the Slave Number from 00-30 by using the UP/DOWN buttons. -
Page 18: Dmx Modes
DMX Modes 8 DMX Channels (Mode 1) Channel 1 - Vertical movement (Tilt) Push the fadder, up in order to move the Sunstrip vertically (TILT). Gradual head adjustment from one end of the slider to the other (0-255, 128-center). The Sunstrip can be turned by 270°and stopped at any position you wish. Channel 2 –... -
Page 19: Dmx Channels (Mode 2) Leds Divided In 4 Sections
15 DMX Channels (Mode 2) LEDs divided in 4 sections Section 1 Section 2 Section 3 Section 4 Channel 1 - Vertical movement (Tilt) Push the fadder, up in order to move the Sunstrip vertically (TILT). Gradual head adjustment from one end of the slider to the other (0-255, 128-center). The Sunstrip can be turned by 270°and stopped at any position you wish. -
Page 20: 111 Dmx Channels (Mode 3) 36 Leds, Each One Controlled Separately
111 DMX Channels (Mode 3) 36 LEDs, each one controlled separately Channel 1 - Vertical movement (Tilt) Push the fadder, up in order to move the Sunstrip vertically (TILT). Gradual head adjustment from one end of the slider to the other (0-255, 128-center). The Sunstrip can be turned by 270°and stopped at any position you wish. - Page 21 Channel 104 – LED 34 Green 0-255 Gradual adjustment Blue from 0 – 100% Channel 105 – LED 34 Blue 0-255 Gradual adjustment Red from 0 – 100% Channel 106 – LED 35 Red 0-255 Gradual adjustment Green from 0 – 100% Channel 107 –...
-
Page 22: Connection Cables
4. The electric power supply cables must not show any damages or material fatigue. The Sunstrip Pro RGB requires almost no maintenance. However, you should keep the unit clean. Disconnect the mains power supply, and then wipe the cover with a damp cloth. Do not immerse in liquid. -
Page 23: Troubleshooting
3. If all of the above appears to be O.K., plug the unit in again. 4. If you are unable to determine the cause of the problem, do not open the Sunstrip Pro RGB, as this may damage the unit and the warranty will become void. - Page 24 Problem Probable cause(s) Remedy No power to the fixture · Check that power is switched on One or more and cables are plugged in. fixtures are Primary fuse blown. · Replace fuse. completely dead. Fixtures reset The controller is not connected. ·...
-
Page 25: Product Specifications
Product Specification Model: Showtec Sunstrip Pro RGB Voltage : AC 110V/60Hz or 220V/50Hz (CE) Power consumption: Max. 110W Fuse: 250V / T2A Audio trigger: Built-in Mic DMX Input : 3-pin XLR Male connector DMX Output : 3-pin XLR Female connector Tilt 270°...
