c. Clamp the QR lever to fully 'closed' position in line with the fork.
The QR lever should start to feel tight at 90 degrees as you close
– if it is too tight or too loose you can adjust by holding lever
'open' again and turning nut.
Check front wheel is correctly installed by lifting the handlebar and
holding the wheel at the fork. Firmly push from side to side. If
there is no movement the wheel is fitted correctly.
Creig 24 / Creig 26
Step 4 of 6
Pedal installation
a. Left pedal
Tighten
Left pedal – rotate pedal axle clockwise towards front of bike.
a.
b.
Right pedal – rotate axle anti-clockwise towards front of bike.
Tighten max. 30Nm
Please ensure you identify the left and right pedals
before installing.
E-mail: techsupport@islabikes.co.uk
b. Right pedal
Tighten
Telephone: +44 (0)1584 856881
