SPLIT TYPE
AIR CONDITIONER
DUCT
Models
C O N T E N T S
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
OUTLINE AND DIMENSIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
CIRCUIT DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
REFRIGERANT SYSTEM DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
ERROR CONTENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
INDOOR PRINTED CIRCUIT BOARD CIRCUIT DIAGRAM . . . . . .
OUTDOOR PRINTED CIRCUIT BOARD CIRCUIT DIAGRAM. . . . .
DISASSEMBLY ILLUSTRATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
PARTS LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
type
Indoor unit
Outdoor unit
ARG25FUAA
AOG25FNAKL
ARG25UUAA
AOG25UNAKL
(50Hz)
8
9
11
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for General ARG25FUAA
Summary of Contents for General ARG25FUAA
-
Page 1: Table Of Contents
(50Hz) DUCT type Models Indoor unit Outdoor unit ARG25FUAA AOG25FNAKL ARG25UUAA AOG25UNAKL preliminary C O N T E N T S SPECIFICATIONS ..........1 OUTLINE AND DIMENSIONS . -
Page 2: Specifications
S P E C I F I C A T I O N S TYPE COOLING COOLING & HEATING INDOOR UNIT ARG25FUAA ARG25UUAA OUTDOOR UNIT AOG25FNAKL AOG25UNAKL COOLING CAPACITY (kW) 7.05 7.00 HEATING CAPACITY (kW) ------ 7.70 ELECTRICAL DATA POWER SOURCE... - Page 3 TYPE COOLING COOLING & HEATING INDOOR UNIT ARG25FUAA ARG25UUAA OUTDOOR UNIT AOG25FNAKL AOG25UNAKL NOISE LEVEL (dB) HI-SPEED (dB) INDOOR UNIT MED-SPEED (dB) LO-SPEED (dB) OUTDOOR UNIT COOL 53 / HEAT 54 Note : Static pressure : 100Pa Duct length : Inlet 1m, Outlet 2m REFRIGERANT CHARGE 7.5 m...
- Page 4 D I M E N S I O N S INDOOR UNIT Models : ARG25FUAA ARG25UUAA Unit : mm 1,177 1,063 1,135 www.enindel.com 2004.08.02...
- Page 5 OUTDOOR UNIT Models : AOG25FNAKL AOG25UNAKL Unit : (mm) Air flow Bottom www.enindel.com 2004.08.02...
-
Page 6: Circuit Diagram
C I R C U I T D I A G R A M Model : ARG25FUAA Model : AOG25FNAKL www.enindel.com 2004.08.02... - Page 7 Model : ARG25UUAA Model : AOG25UNAKL www.enindel.com 2004.08.02...
-
Page 8: Refrigerant System Diagram
R E F R I G E R A N T S Y S T E M D I A G R A M Models : ARG25FUAA / AOG25FNAKL INDOOR UNIT OUTDOOR UNIT Refrigerant pipe 9.52 mm (3/8") Capillary tube... - Page 9 C I R C U I T B O A R D C I R C U I T D I A G R A M POWER SUPPLY PCB Model : ARG25FUAA CONTROLLER PCB ASSEMBLY ( MAIN PCB ) K03CA-0401WSE-P0 K03BZ-0403WSE-C1 TRANS ( SEC )
- Page 10 Model : ARG25UUAA POWER SUPPLY PCB CONTROLLER PCB ASSEMBLY ( MAIN PCB ) K03CA-0400HSE-P0 K03BZ-0402HSE-C1 TRANS ( SEC ) CN105 CN104 R15 - R17 B04B-PASK-1 B2B-XARK-1-A DC SUPPLY 10K <1/10W> x 3 WHITE UL1430 AWG22 UL1430 AWG26 GRAY R18 - R20 UL1430 AWG22 UL1430 AWG26 GRAY...
- Page 11 O U T D O O R P R I N T E D C I R C U I T B O A R D C I R C U I T D I A G R A M CONTROLLER PCB ASSEMBLY ( MAIN PCB ) Model : AOG25UNAKL R33 10K...
-
Page 12: Disassembly Illustration
D I S A S S E M B LY I L L U S T R A T I O N Models : ARG25FUAA ARG25UUAA 2004.08.02 www.enindel.com... - Page 13 Models : ARG25FUAA ARG25UUAA 2004.08.02 www.enindel.com...
- Page 14 Models : ARG25FUAA ARG25UUAA 2004.08.02 www.enindel.com...
- Page 15 www.enindel.com...
- Page 16 www.enindel.com...
- Page 17 Model : AOG25FNAKL 47-1 735-3 178-2 13-2 13-1 348-1 2004.08.02 www.enindel.com...
- Page 18 Model : AOG25UNAKL 735-3 20-1 13-2 13-1 20-2 178-2 2004.08.02 www.enindel.com...
- Page 19 Model : AOG25FNAKL 823-2 824-4 218-3 989-1 989-2 Model : AOG25UNAKL 32-2 218-4 989-1 989-2 2004.08.02 www.enindel.com...
-
Page 20: Parts List
When you order parts, please make a photocopy of this page INDOOR UNIT and fill the number of the parts in the "Order" column. Part No. Ref. Ord. Description Q'ty ARG25FUAA ARG25UUAA Capacitor (Fan Motor) 9900230012 9900230012 36-2 Cord Holder Metal 9356362008... - Page 21 OUTDOOR UNIT Part No. Part No. Ref. Ord. Ref. Ord. Description Description Q'ty Q'ty AOG25FNAKL AOG25UNAKL Fan Guard 9371187013 Fan Guard 9371187013 Emblem-R ear 9372171011 Emblem-R ear 9372171011 Front Panel Ptd 9371924014 Front Panel Ptd 9371924014 Connector Cover (Cabinet) 9366398004 Connector Cover (Cabinet) 9366398004 Wire Assy (Comp)
- Page 22 STANDARD ACCESSORIES INDOOR UNIT ACCESSORIES Part No. Name and Shape Q'ty Application ARG25FUAA ARG25UUAA For positioning the indoor Installation unit template 9357036007 9357036007 Hanger For suspending the indoor unit from ceiling 9356563009 9356563009 Special nut A For suspending the indoor...
- Page 23 0406G2612 www.enindel.com...
