General ABG14FBBJ Service Manual

Room air conditioner

Hide thumbs

www.enindel.com

SPLIT TYPE

ROOM AIR CONDITIONER

F L O O R C O N S O L E /

U N D E R C E IL IN G

DUA L

Models

Indoor unit

ABG14FBBJ

ABG14UBBJ

ABG18FBBJ

ABG18UBBJ

ABG24FBBJ

ABG24UBBJ

CO NT ENT S

SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

OUTLINE AND DIMENSIONS . . . . . . . . . . . . . . . . . . . . 3

REFRIGERANT SYSTEM DIAGRAM . . . . . . . . . . . . . 5

CIRCUIT DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

ERROR DISPLAY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

PCB CIRCUIT DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . 13

DISASSEMBLY ILLUSTRATION (Indoor Unit) . . . . . 15

DISASSEMBLY ILLUSTRATION (Outdoor Unit) . . . . 22

PARTS LIST (Indoor Unit) . . . . . . . . . . . . . . . . . . . . . . . . 31

PARTS LIST (Outdoor Unit) . . . . . . . . . . . . . . . . . . . . . . 33

t y pe

Outdoor unit

AOG14FSDJ

AOG14USDJL

AOG18FNBK

AOG18UNBKL

AOG24FNBK

AOG24UNBKL

Table of Contents

Need help?

Do you have a question about the ABG14FBBJ and is the answer not in the manual?

Questions and answers

Summary of Contents for General ABG14FBBJ

Page 1: Table Of Contents
F L O O R C O N S O L E / U N D E R C E IL IN G DUA L t y pe Models Indoor unit Outdoor unit ABG14FBBJ AOG14FSDJ ABG14UBBJ AOG14USDJL ABG18FBBJ AOG18FNBK ABG18UBBJ...
Page 2: Specifications
SPECIF I CAT IO NS TYPE Cool ABG14FBBJ ABG18FBBJ ABG24FBBJ INDOOR UNIT AOG14FSDJ AOG18FNBK AOG24FNBK OUTDOOR UNIT COOLING CAPACITY (kW) 4.20 5.40 6.50 ELECTRICAL DATA POWER SOURCE FREQUENCY (Hz) 11.0 RUNNING CURRENT INPUT WATTS (kW) 1.39 1.92 2.45 E.E.R. (kW/kW) 3.02...
Page 3 TYPE Cool and Heat INDOOR UNIT ABG14UBBJ ABG18UBBJ ABG24UBBL OUTDOOR UNIT AOG18UNBKL AOG14USDJL AOG24UNBKL COOLING CAPACITY (kW) 4.00 5.40 6.50 HEATING CAPACITY (kW) 4.70 6.00 7.40 ELECTRICAL DATA POWER SOURCE FREQUENCY (Hz) RUNNING CURRENT (Cool) 10.8 RUNNING CURRENT (Heat) 10.3 INPUT WATTS (Cool) (kW) 1.42...
Page 4: Outline And Dimensions
OUT L IN E AN D D IM E NS I O NS Unit : mm INDOOR UNIT Models : ABG14FBBJ ABG18FBBJ ABG24FBBJ ABG14UBBJ ABG18UBBJ ABG24UBBJ 2003.12.29 PRELIMINARY www.enindel.com...
Page 5 www.enindel.com...
Page 6: Refrigerant System Diagram
REFRIGER A NT S YS T EM DIA G RAM Models : ABG14FBBJ / AOG14FSDJ INDOOR UNIT OUTDOOR UNIT Refrigerant pipe 6.35 mm (1/4") Capillary tube Strainer Condenser Evaporator Refrigerant pipe 12.7 mm (1/2") Charging valve Compressor Models : ABG14UBBJ / AOG14USDJL...
Page 7 Models : ABG18FBBJ / AOG18FNBK INDOOR UNIT OUTDOOR UNIT Refrigerant pipe 9.52 mm (3/8") Capillary tube Strainer Condenser Evaporator Refrigerant pipe 15.88 mm (5/8") Charging valve Compressor Models : ABG24FBBJ / AOG24FNBK INDOOR UNIT OUTDOOR UNIT Refrigerant pipe 9.52 mm (3/8") Capillary tube Strainer Evaporator...
Page 8 Models : ABG18UBBJ / AOG18UNBKL INDOOR UNIT OUTDOOR UNIT Capillary tube Strainer Refrigerant pipe 9.52mm(3/8") Compressor Evaporator Condenser Refrigerant pipe 15.88mm(5/8") 4-Way valve Charging valve Models : ABG24UBBJ / AOG24UNBKL INDOOR UNIT OUTDOOR UNIT Capillary Strainer tube Refrigerant pipe 9.52mm(3/8") Compressor Evaporator Accumulator...
Page 9: Circuit Diagram
CIRCUIT DI AGR A M Models : ABG14FBBJ / AOG14FSDJ INDOOR UNIT OUTDOOR UNIT www.enindel.com 2003.01.06 PRELIMINARY...
Page 10 Models : ABG14UBBJ / AOG14USDJL INDOOR UNIT OUTDOOR UNIT 2003.01.06 PRELIMINARY www.enindel.com...
Page 11 Models : ABG18FBBJ / AOG18FNBK ABG24FBBJ / AOG24FNBK INDOOR UNIT OUTDOOR UNIT www.enindel.com 2003.01.06 PRELIMINARY...
Page 12 Models : ABG18UBBJ / AOG18UNBKL ABG24UBBJ / AOG24UNBKL INDOOR UNIT OUTDOOR UNIT 2003.01.06 PRELIMINARY www.enindel.com...
Page 13: Error Display
ERR OR D ISP L A Y The OPERATION, TIMER and SWING lamps operate as follows according to the error contents. Fast flashing Slow flashing Error display Error contents OPERATION TIMER SWING (RED) (GREEN) (ORANGE) Indoor unit circuit board error Indoor unit room temperature sensor wire 2 times opened...
Page 14: Pcb Circuit Diagram
INDOOR P R INT ED CIR CUI T BOA RD CIRCUIT DIAG RA M CONTROLLERPCB ASSEMBLY ( MAIN PCB ) ABG14FBBJ : EZ-001LWSE-F Models : ABG14FBBJ ABG18FBBJ : EZ-002YWSE-F ABG18FBBJ ABG24FBBJ : EZ-002TWSE-F ABG24FBBJ R15 - R17 ROOM TEMPERATURE THERMISTOR...
Page 15 Models : ABG14UBBJ ABG18UBBJ ABG24UBBJ CONTROLLER PCB ASSEMBLY ( MAIN PCB ) ABG14UBBJ : EZ-00312HSE-F ABG18UBBJ : EZ-00211HSE-F ABG24UBBJ : EZ-00210HSE-F R15 - R17 B2B-XASK-1-A ROOM TEMPERATURE THERMISTOR WHITE 10K <1/10W> x 3 R5 62K CN8-1 BLACK 4700P <2W> R18 1.0K <1/10W> CN8-2 NOT USED BLACK...
Page 16: Disassembly Illustration (Indoor Unit)
DISASSEM BL Y A S SEMB LY Models : ABG14FBBJ, ABG14UBBJ ABG18FBBJ, ABG18UBBJ ABG24FBBJ, ABG24UBBJ 365-2 653-2 365-1 870-1 365-2 870-1 653-2 365-1 2003.01.05 PRELIMINARY www.enindel.com...
Page 17 870-2 196-1 574-2 588-2 184-1 574-1 588-1 2003.01.05 PRELIMINARY www.enindel.com...
Page 18 653-1 2003.01.05 PRELIMINARY www.enindel.com...
Page 19 2003.01.05 PRELIMINARY www.enindel.com...
Page 20 652-1 BYPASS PIPE AS BYPASS COUPLING PIPE B PIPE AS DISTRIBUTOR AS 652-1 BYPASS PIPE AS COUPLING PIPE AS DISTRIBUTOR AS 2003.01.05 PRELIMINARY www.enindel.com...
Page 21 187-1 824-3 731-2 629-1 36-2 2003.01.05 PRELIMINARY www.enindel.com...
Page 22 2003.01.05 PRELIMINARY www.enindel.com...
Page 23: Disassembly Illustration (Outdoor Unit)
Models : AOG14FSDJ AOG14USDJL 2003.01.05 PRELIMINARY www.enindel.com...
Page 24 2003.01.05 PRELIMINARY www.enindel.com...
Page 25 Model : AOG14USDJL Model : AOG14FSDJ 2003.01.05 PRELIMINARY www.enindel.com...
Page 26 www.enindel.com...
Page 27 www.enindel.com...
Page 28 www.enindel.com...
Page 29 www.enindel.com...
Page 30 www.enindel.com...
Page 31 www.enindel.com...
Page 32: Parts List (Indoor Unit)
When you order parts, please make a photocopy of this page INDOOR UNIT and fill the number of the parts in the "Order" column. Ref. Ord. Part No. Description Q'ty ABG14FBBJ ABG14UBBJ ABG18FBBJ ABG18UBBJ ABG24FBBJ ABG24UBBJ Air Filter 9358567029 9358567029...
Page 33 When you order parts, please make a photocopy of this page INDOOR UNIT (Continued) and fill the number of the parts in the "Order" column. Ref. Ord. Part No. Description ABG14FBBJ ABG14UBBJ ABG18FBBJ ABG18UBBJ ABG24FBBJ ABG24UBBJ Q'ty Clamp NK-10N 9359183006...
Page 34: Parts List (Outdoor Unit)
OUTDOOR UNIT When you order parts, please make a photocopy of this page and fill the number of the parts in the "Order" column. Ref. Ord. Part No. Description AOG14FSDJ AOG14USDJL Q'ty Fan Cover 9304109006 9304109006 Emblem-R ear (AOY Model) 9351355005 9351355005 Emblem-R ear (AOG Model)
Page 35 When you order parts, please make a photocopy of this page OUTDOOR UNIT (Continued) and fill the number of the parts in the "Order" column. Part No. Part No. Ref. Ord. Ref. Ord. Description Description Q'ty Q'ty AOG18UNBKL AOG24UNBKL AOG18FNBK AOG24FNBK Fan Guard 9371187013...
Page 36: Standard Accessories
STANDARD ACCESSORIES The following installation parts are furnished. Use them as required. INDOOR UNIT ACCESSORIES Name and Shape Q'ty Application Name and Shape Q'ty Application Cover plate (left) Drain hose Cover plate (right) Insulation (drain hose) Adhesive type 70 x 230 T apping screw 4x10) VT wire...
Page 37 0401G2479 www.enindel.com...
