SPLIT TYPE
AIR CONDITIONER
DUCT
Models
Indoor unit
ARG36UUAN
CO NTE NT S
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
DIMENSIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
REFRIGERANT SYSTEM DIAGRAM . . . . . . . . . . . . . 4
CIRCUIT DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
INDOOR PCB CIRCUIT DIAGRAM . . . . . . . . . . . . . .
ERROR CONTENTS . . . . . . . . . . . . . . . . . . . . . . . . . . .
DISASSEMBLY ILLUSTRATION . . . . . . . . . . . . . . . . . . 9
PARTS LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
STANDARD ACCESSORIES . . . . . . . . . . . . . . . . . . . 18
(50Hz)
type
Outdoor unit
AOG36UMAXL
6
. . . . . . . . . . . . 7
8
Advertisement
Table of Contents
Related Manuals for General ARG36UUAN
Summary of Contents for General ARG36UUAN
-
Page 1: Table Of Contents
Models Indoor unit Outdoor unit ARG36UUAN AOG36UMAXL CO NTE NT S SPECIFICATIONS ......1 DIMENSIONS . -
Page 2: Specifications
SPECIFIC ATIONS WEIGHT COOLING & HEATING 50 / 43 kg TYPE INDOOR UNIT GROSS / NET ARG36UUAN INDOOR UNIT 105 / 98 kg OUTDOOR UNIT GROSS / NET AOG36UMAXL OUTDOOR UNIT COOLING CAPACITY 10.5 kW NOISE LEVEL HEATING CAPACITY 12.7 kW... -
Page 3: Dimensions
DIM EN SIO NS INDOOR UNIT Model : ARG36UUAN (Unit : mm) 1,177 1,015 1,135 www.enindel.com 2006.01.19... - Page 4 OUTDOOR UNIT Model : AOG36UMAXL (Unit : mm) Air Flow www.enindel.com 2006.01.19...
-
Page 5: Refrigerant System Diagram
REF RIGE R ANT SYST EM DI AG RA M Models : ARG36UUAN / AOG36UMAXL INDOOR UNIT OUTDOOR UNIT Pressure Refrigerant Pipe Check Valve 15.88mm (5/8") High Pressure Switch Charging Valve Muffler 4-way Valve Evaporator Condenser Muffler Accumulator Compressor Expansion... -
Page 6: Circuit Diagram
CIRC UIT D IA GR AM Model : ARG36UUAN THERMISTOR TRANSFORMER (ROOM TEMP.) GRAY GRAY GRAY GRAY THERMISTOR (PIPE TEMP.) GRAY GRAY CN103 CN104 GRAY GRAY GRAY POWER PCB CN109 CN107 CN108 GRAY GRAY GRAY GRAY Use T3. 15A - 250V... -
Page 7: Indoor Pcb Circuit Diagram
INDOO R PCB C IR CU IT DI A G RA M Model : ARG36UUAN POWER SUPPLY PCB CONTROLLER PCB ASSEMBLY ( MAIN PCB ) K04CW-0400HSE-P0 K03BZ-0409HSE-C1 CN104 CN105 R15 - R17 B2B-XARK-1-A 5V 12V 14V B04B-PASK-1 DC SUPPLY 10K <1/10W> x 3... -
Page 8: Outdoor Pcb Circuit Diagram
OUTDOOR PC B CI RCU IT DIAG RA M CONTROLLER PCB ASSEMBL Model : AOG36UMAXL K04DF-0500HUE-C1 www.enindel.com 2006.01.19... -
Page 9: Disassembly Illustration
DISA S SEM B L Y I LL UST RAT I O N Model : ARG36UUAN Insulation Control Box Insulation Insulation www.enindel.com 2006.01.19... - Page 10 Model : ARG36UUAN www.enindel.com 2006.01.19...
- Page 11 Model : ARG36UUAN www.enindel.com 2006.01.19...
- Page 12 Model : AOG36UMAXL www.enindel.com 2006.01.19...
- Page 13 Model : AOG36UMAXL www.enindel.com 2006.01.19...
- Page 14 Model : AOG36UMAXL www.enindel.com 2006.01.19...
- Page 15 Model : AOG36UMAXL Fuse 250V 5A www.enindel.com 2006.01.19...
-
Page 16: Parts List
P ART S L IST INDOOR UNIT Part No. Ref. Ord. Description Q'ty ARG36UUAN Control Cover-A Sub Assy 9374516018 Motor Mount 9374281015 Bracket Motor Assy 9374230013 Sirocco Fan Assy 9356531022 Rubber 313659068604 Cabinet-L Sub Assy 9374509010 Cabinet-R Sub Assy 9374508013... - Page 17 OUTDOOR UNIT Part No. Ref. Ord. Description AOG36UMAXL Q'ty Top Panel Sub Assy 9374417018 Front Panel 9374094042 Fan Guard 9374330010 Side Grip 9374173013 Service Panel Sub Assy 9374415021 Right Panel Sub Assy 9374416028 Motor Bracket Sub Assy 9374418022 Propeller Fan Assy 9366378013 Motor, Induction 9601671060...
-
Page 18: Standard Accessories
STAND ARD ACCESSO RI ES INDOOR UNIT ACCESSORIES Name and Shape Q'ty Application Name and Shape Application Q'ty Hanger For suspending the indoor Binder For fixing the drain hose unit from ceiling (large) For fixing the remote controller cord (small) Special nut A For suspending the indoor Remote... - Page 19 0512G2960 www.enindel.com...
