4.0 Meet the StudioLive RM32AI and RM16AI

Rear

15
POWER
14
14. Power switch
15. Power inlet
16. MIDI input and output
17. Digital option-card slot
18. Mix outputs (mirror of front panel mix outputs)
5.0

Wired Ethernet Control Setup

100-230V , 50-60 Hz. 120W
WER
Your StudioLive RM32AI and RM16AI can be set up for control with a wired Ethernet connection in seconds.
Simply connect the included Ethernet cable to the Ethernet control port on the back of the mixer and to a
network router that is also connected to your computer or iPad.
When you launch UC-Surface with the computer and StudioLive RM32AI or RM16AI connected to the same
network, the software should automatically see the mixer.
