Channel Strip Area; Flex Master Channel Strip - PRESONUS StudioLive RM32AI Visual Quickstart Manual

11.0

Channel Strip Area

11.0 Channel Strip Area
1
2
3
4
5
6
7
8
9

12.0 Flex Master Channel Strip

1
2
3
4
5
6
7
8
9
This area displays the input channels and fader levels for the selected mix.
EQ micro view. Selects the associated channel and brings up the
1.
Fat Channel.
2. Solo
3. Mute
4. Pan
5. Channel fader. Controls the channel level for the selected mix.
6. Input meter
7. Compressor gain-reduction meter
8. Gate gain-reduction meter
Channel number, name, and type icon. Selects the associated channel and
9.
brings up the Fat Channel.
The Flex Master channel strip shows the master channel for the selected mix. For
example, when Mix 3 is selected, the Flex Master is the main output for Mix 3.
EQ micro view. Selects the associated Mix master and brings up the Fat Channel.
1.
2. Solo
3. Mute
GEQ or FX Edit. Opens the associated graphic EQ or effects editor in the Fat
4.
Channel area.
5. Mix fader
6. Output meter
7. Compressor gain-reduction meter
8. Gate gain-reduction meter
Mix number, name, and type icon. Selects the associated Mix master and
9.
brings up the Fat Channel.
PreSonus StudioLive RM32AI/RM16AI
® ™
Visual Quick Start Guide
11
