Mic Unit - Icom IC-M25 Service Manual

[MIC UNIT]

REF PARTS
NO. NO.
C410 4030017620 S.CER C1005 CH 1H 100C-T
C411 4030017420 S.CER C1005 CH 1H 470J-T
J250 6450002460 CON HSJ1594-010160
J607 6510025142 S.CON 10FLT-SM2-TB(LF)(SN)(M)
J608 6510009351 CON B2B-ZR(LF)(SN)
S250 2260001900 SWI SW-149 (SKHLLDA010)
W1 8900014801 CAB OPC-1573-1(P0.5N10L50) <TJM>
EP4 6910018460 S.BEA MMZ1005Y102C-T
EP5 6910024660 S.BEA MPZ2012S102AT
EP6 6910018460 S.BEA MMZ1005Y102C-T
EP7 6910024660 S.BEA MPZ2012S102AT
EP8 6910018460 S.BEA MMZ1005Y102C-T1
Eqv.= This component is equivalent to the REF No. component listed above, and
may be substituted on parts orders and repairs.
DESCRIPTION M.
LOCATION
B
B
B
B
B
B
B
B
H/V
11.7/20.7
11.6/11.9
11.2/8.1
14.5/11.4
11.7/14.1
8.2/11.9
13.9/19.9
9.9/5.2
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
7-4
S.=Surface mount
