Icom IC-M25 Service Manual page 16

[MAIN UNIT]
REF PARTS
NO. NO.
R171 7030009140 S.RES ERJ2GEJ 272 X (2.7K)
R172 7030005000 S.RES ERJ2GEJ 471 X (470)
R173 7030005030 S.RES ERJ2GEJ 152 X (1.5K)
R174 7030005230 S.RES ERJ2GEJ 334 X (330K)
R175 7030005600 S.RES ERJ2GEJ 273 X (27K)
R176 7030005120 S.RES ERJ2GEJ 102 X (1K)
R192 7030009280 S.RES ERJ2GEJ 391 X
R193 7030005000 S.RES ERJ2GEJ 471 X (470)
R194 7030005090 S.RES ERJ2GEJ 104 X (100K)
R201 7030007290 S.RES ERJ2GEJ 222 X (2.2K)
R202 7030005090 S.RES ERJ2GEJ 104 X (100K)
R203 7030005110 S.RES ERJ2GEJ 224 X (220K)
R204 7030005040 S.RES ERJ2GEJ 472 X (4.7K)
R206 7030008290 S.RES ERJ2GEJ 183 X (18K)
R207 7030007350 S.RES ERJ2GEJ 393 X (39K)
R212 7030005030 S.RES ERJ2GEJ 152 X (1.5K)
R213 7030005100 S.RES ERJ2GEJ 154 X (150K)
R214 7030007340 S.RES ERJ2GEJ 153 X (15K)
R226 7030005040 S.RES ERJ2GEJ 472 X (4.7K)
R227 7030005050 S.RES ERJ2GEJ 103 X (10K)
R228 7030008300 S.RES ERJ2GEJ 184 X (180K)
R230 7030005230 S.RES ERJ2GEJ 334 X (330K)
R231 7030007280 S.RES ERJ2GEJ 331 X (330)
R235 7030010010 S.RES ERJ2RKF 334 X (330K)
R236 7030010020 S.RES ERJ2RKF 1503X (150K)
R240 7030004990 S.RES ERJ2GEJ 221 X (220)
R242 7410001270 S.ARR EXB28V821JX
R251 7030008280 S.RES ERJ2GEJ 271 X (270)
R252 7030005060 S.RES ERJ2GEJ 333 X (33K)
R253 7030007300 S.RES ERJ2GEJ 332 X (3.3K)
R255 7030005700 S.RES ERJ2GEJ 274 X (270K)
R256 7030008290 S.RES ERJ2GEJ 183 X (18K)
R257 7030005040 S.RES ERJ2GEJ 472 X (4.7K)
R258 7030005040 S.RES ERJ2GEJ 472 X (4.7K)
R260 7030005110 S.RES ERJ2GEJ 224 X (220K)
R261 7030005720 S.RES ERJ2GEJ 563 X (56K)
R262 7030005240 S.RES ERJ2GEJ 473 X (47K)
R263 7030008290 S.RES ERJ2GEJ 183 X (18K)
R264 7030005090 S.RES ERJ2GEJ 104 X (100K)
R265 7030005090 S.RES ERJ2GEJ 104 X (100K)
R270 7030005120 S.RES ERJ2GEJ 102 X (1K)
R271 7030011650 S.RES ERJ2GEJ 243X (24K)
R272 7030005090 S.RES ERJ2GEJ 104 X (100K)
R273 7030005220 S.RES ERJ2GEJ 223 X (22K)
R276 7030008300 S.RES ERJ2GEJ 184 X (180K)
R277 7030005090 S.RES ERJ2GEJ 104 X (100K)
R278 7030005120 S.RES ERJ2GEJ 102 X (1K)
R279 7030005030 S.RES ERJ2GEJ 152 X (1.5K)
R283 7030005090 S.RES ERJ2GEJ 104 X (100K)
R286 7030008010 S.RES ERJ2GEJ 123 X (12K)
R290 7030007060 S.RES ERJ2GEJ 684X (680K)
R291 7030005090 S.RES ERJ2GEJ 104 X (100K)
R292 7030005090 S.RES ERJ2GEJ 104 X (100K)
R293 7030008010 S.RES ERJ2GEJ 123 X (12K)
R294 7030005040 S.RES ERJ2GEJ 472 X (4.7K)
R295 7030005040 S.RES ERJ2GEJ 472 X (4.7K)
R300 7030005290 S.RES ERJ2GEJ 682 X (6.8K)
R340 7030005090 S.RES ERJ2GEJ 104 X (100K)
R341 7030005050 S.RES ERJ2GEJ 103 X (10K)
R343 7030005050 S.RES ERJ2GEJ 103 X (10K)
R351 7030005120 S.RES ERJ2GEJ 102 X (1K)
R352 7030007340 S.RES ERJ2GEJ 153 X (15K)
R353 7030005120 S.RES ERJ2GEJ 102 X (1K)
R361 7410001130 S.ARR EXB28V102JX
R371 7030005170 S.RES ERJ2GEJ 474 X (470K)
R372 7030007310 S.RES ERJ2GEJ 155 X (1.5M)
R373 7030005160 S.RES ERJ2GEJ 105 X (1M)
R374 7030006610 S.RES ERJ2GEJ 394 X (390K)
R376 7030005090 S.RES ERJ2GEJ 104 X (100K)
R377 7030005080 S.RES ERJ2GEJ 823 X (82K)
R378 7030005080 S.RES ERJ2GEJ 823 X (82K)
R379 7030005080 S.RES ERJ2GEJ 823 X (82K)
R380 7030005050 S.RES ERJ2GEJ 103 X (10K)
R381 7030005050 S.RES ERJ2GEJ 103 X (10K)
R382 7030009140 S.RES ERJ2GEJ 272 X (2.7K)
R383 7030008010 S.RES ERJ2GEJ 123 X (12K)
R384 7030007290 S.RES ERJ2GEJ 222 X (2.2K)
R386 7030005050 S.RES ERJ2GEJ 103 X (10K)
R387 7030005090 S.RES ERJ2GEJ 104 X (100K)
R388 7030005170 S.RES ERJ2GEJ 474 X (470K)
R391 7030005240 S.RES ERJ2GEJ 473 X (47K)
R392 7030007340 S.RES ERJ2GEJ 153 X (15K)
R393 7030007290 S.RES ERJ2GEJ 222 X (2.2K)
R395 7030005090 S.RES ERJ2GEJ 104 X (100K)
R396 7030005050 S.RES ERJ2GEJ 103 X (10K)
R397 7030005700 S.RES ERJ2GEJ 274 X (270K)
R398 7030005050 S.RES ERJ2GEJ 103 X (10K)
R401 7030005090 S.RES ERJ2GEJ 104 X (100K)
R402 7030005060 S.RES ERJ2GEJ 333 X (33K)
R403 7030005050 S.RES ERJ2GEJ 103 X (10K)
R404 7030004980 S.RES ERJ2GEJ 101 X (100)
R410 7030005120 S.RES ERJ2GEJ 102 X (1K)
R411 7030005120 S.RES ERJ2GEJ 102 X (1K)
R412 7030005050 S.RES ERJ2GEJ 103 X (10K)
R413 7030005050 S.RES ERJ2GEJ 103 X (10K)
R414 7030005050 S.RES ERJ2GEJ 103 X (10K)
R415 7030005240 S.RES ERJ2GEJ 473 X (47K)
R430 7030005700 S.RES ERJ2GEJ 274 X (270K)
R431 7030005120 S.RES ERJ2GEJ 102 X (1K)
R432 7030005040 S.RES ERJ2GEJ 472 X (4.7K)
R433 7030005090 S.RES ERJ2GEJ 104 X (100K)
R434 7030005080 S.RES ERJ2GEJ 823 X (82K)
R435 7030008010 S.RES ERJ2GEJ 123 X (12K)
R450 7030007280 S.RES ERJ2GEJ 331 X (330)
R451 7030005040 S.RES ERJ2GEJ 472 X (4.7K)
Eqv.= This component is equivalent to the REF No. component listed above, and
may be substituted on parts orders and repairs.
DESCRIPTION M.
LOCATION
B
B
B
B
B
B
B
B
B
B
B
B
B
T
B
T
T
T
B
B
B
B
B
B
B
T
B
B
B
B
B
B
B
B
T
T
T
T
B
T
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
T
B
B
B
B
B
B
T
T
T
T
T
T
B
B
B
B
T
T
T
T
T
B
T
B
B
B
B
T
B
B
T
B
B
B
T
T
B
B
B
B
B
B
B
B
B
B
B
B
[MAIN UNIT]
H/V REF PARTS
NO. NO.
23.2/10.5 R452 7030007290 S.RES ERJ2GEJ 222 X (2.2K)
21.0/11.9 R457 7030005050 S.RES ERJ2GEJ 103 X (10K)
16.3/5.6 R458 7030005040 S.RES ERJ2GEJ 472 X (4.7K)
14.6/11.9 R459 7030005040 S.RES ERJ2GEJ 472 X (4.7K)
16.7/12.4 R460 7030004970 S.RES ERJ2GEJ 470 X (47)
17.9/13.1 R461 7030004990 S.RES ERJ2GEJ 221 X (220)
48.2/32.7 R462 7030010040 S.RES ERJ2GEJ-JPW
44.8/29.7 R463 7030004980 S.RES ERJ2GEJ 101 X (100)
47.7/31.4 R464 7030004980 S.RES ERJ2GEJ 101 X (100)
14.1/41.4 R465 7030003320 S.RES ERJ3GEYJ 101 V (100)
15.3/39.8 R466 7030005050 S.RES ERJ2GEJ 103 X (10K)
12.8/41.6 R467 7030005720 S.RES ERJ2GEJ 563 X (56K)
11.9/42.5 R468 7030004990 S.RES ERJ2GEJ 221 X (220)
9.4/41.1 R477 7030005050 S.RES ERJ2GEJ 103 X (10K)
11.2/41.6 R478 7030005050 S.RES ERJ2GEJ 103 X (10K)
7.9/39.9 R479 7030007340 S.RES ERJ2GEJ 153 X (15K)
7.9/38.3 R607 7030014270 S.RES ERJ2RKF3300X (330)
6.7/37.7 R608 7030014260 S.RES ERJ2RKF1801X
54.3/40.8 R609 7030005050 S.RES ERJ2GEJ 103 X (10K)
57.9/46.6 R634 7030005050 S.RES ERJ2GEJ 103 X (10K)
53.9/44.5 R641 7030010010 S.RES ERJ2RKF 334 X (330K)
46.7/44.0 R642 7030010020 S.RES ERJ2RKF 1503X (150K)
45.8/44.0 R647 7030005050 S.RES ERJ2GEJ 103 X (10K)
64.2/43.0 R650 7030005160 S.RES ERJ2GEJ 105 X (1M)
64.0/45.4 R659 7030004980 S.RES ERJ2GEJ 101 X (100)
94.7/27.2
54.8/32.7
80.9/43.2 C2 4030017460 S.CER C1005 JB 1H 102K-T
41.2/44.3 C3 4030017440 S.CER C1005 CH 1H 221J-T
16.9/37.4 C4 4030017640 S.CER C1005 CH 1H 150J-T
15.1/36.5 C5 4030017670 S.CER C1005 CH 1H 390J-T
15.4/38.6 C6 4030017460 S.CER C1005 JB 1H 102K-T
16.9/35.6 C7 4030018860 S.CER C1005 JB 0J 105K-T
18.1/36.0 C8 4030017350 S.CER C1005 CH 1H 020B-T
11.6/39.7 C9 4030017350 S.CER C1005 CH 1H 020B-T
12.5/39.7 C11 4550007480 S.TAN
12.5/40.9 C12 4030017460 S.CER C1005 JB 1H 102K-T
35.8/36.5 C13 4030016930 S.CER C1005 JB 1A 104K-T
31.4/39.9 C15 4030016790 S.CER C1005 JB 1E 103K-T
36.1/37.9 C18 4030016930 S.CER C1005 JB 1A 104K-T
41.2/45.2 C19 4030017650 S.CER C1005 CH 1H 270J-T
33.0/38.3 C20 4030017460 S.CER C1005 JB 1H 102K-T
35.7/39.4 C21 4030017610 S.CER C1005 CH 1H 090C-T
35.7/38.5 C22 4030017610 S.CER C1005 CH 1H 090C-T
38.7/36.6 C24 4550008150 S.TAN
38.3/35.3 C25 4030017460 S.CER C1005 JB 1H 102K-T
37.1/39.1 C26 4030018070 S.CER C1005 CH 1H 300J-T
38.0/39.1 C27 4030017660 S.CER C1005 CH 1H 330J-T
48.0/48.0 C28 4030017460 S.CER C1005 JB 1H 102K-T
39.3/38.5 C30 4030017460 S.CER C1005 JB 1H 102K-T
40.9/36.9 C31 4030017460 S.CER C1005 JB 1H 102K-T
39.5/34.5 C32 4030017550 S.CER C1005 CH 1H 1R5B-T
44.5/38.4 C33 4030017440 S.CER C1005 CH 1H 221J-T
46.6/41.0 C34 4030017550 S.CER C1005 CH 1H 1R5B-T
48.2/40.9 C35 4030017460 S.CER C1005 JB 1H 102K-T
49.2/42.1 C36 4030017460 S.CER C1005 JB 1H 102K-T
9.9/38.3 C37 4030017340 S.CER C1005 CH 1H 010B-T
106.3/29.8 C38 4030017460 S.CER C1005 JB 1H 102K-T
106.3/28.9 C39 4030017630 S.CER C1005 CH 1H 120J-T
105.7/36.3 C40 4030017640 S.CER C1005 CH 1H 150J-T
89.8/34.0 C41 4030017460 S.CER C1005 JB 1H 102K-T
93.3/31.5 C42 4030017380 S.CER C1005 CH 1H 050B-T
93.3/30.6 C43 4030017400 S.CER C1005 CH 1H 220J-T
115.7/31.8 C44 4030017460 S.CER C1005 JB 1H 102K-T
103.1/45.5 C50 4030017460 S.CER C1005 JB 1H 102K-T
106.3/45.5 C51 4030017620 S.CER C1005 CH 1H 100C-T
104.7/45.5 C52 4030017460 S.CER C1005 JB 1H 102K-T
104.0/44.1 C53 4030017460 S.CER C1005 JB 1H 102K-T
10.7/40.6 C54 4030017640 S.CER C1005 CH 1H 150J-T
9.1/41.9 C55 4030017650 S.CER C1005 CH 1H 270J-T
7.4/41.9 C56 4030016790 S.CER C1005 JB 1E 103K-T
6.4/39.8 C57 4030016790 S.CER C1005 JB 1E 103K-T
98.0/10.5 C58 4030016930 S.CER C1005 JB 1A 104K-T
101.4/19.0 C59 4030017730 S.CER C1005 JB 1H 471K-T
100.5/19.0 C60 4030017460 S.CER C1005 JB 1H 102K-T
101.0/20.2 C61 4030019560 S.CER GRM21BB31C106KE15L
105.4/18.5 C62 4030017460 S.CER C1005 JB 1H 102K-T
107.8/22.7 C63 4030016790 S.CER C1005 JB 1E 103K-T
86.5/45.3 C65 4030017420 S.CER C1005 CH 1H 470J-T
30.6/36.3 C67 4030017730 S.CER C1005 JB 1H 471K-T
5.5/40.6 C68 4030017420 S.CER C1005 CH 1H 470J-T
84.7/44.0 C69 4030017420 S.CER C1005 CH 1H 470J-T
85.4/42.4 C70 4030018020 S.CER C1608 CH 1H 910J-T
90.5/31.4 C71 4030007060 S.CER C1608 CH 1H 270J-T
115.7/35.4 C72 4030006860 S.CER C1608 JB 1H 102K-T ATEX
69.1/42.3 C73 4030017460 S.CER C1005 JB 1H 102K-T
67.9/43.0 C74 4030017460 S.CER C1005 JB 1H 102K-T
102.6/21.8 C77 4030016930 S.CER C1005 JB 1A 104K-T
43.3/40.3 C78 4030016930 S.CER C1005 JB 1A 104K-T
42.2/39.1 C80 4030017460 S.CER C1005 JB 1H 102K-T
41.3/39.1 C81 4030017390 S.CER C1005 CH 1H 180J-T
99.3/17.8 C82 4030017390 S.CER C1005 CH 1H 180J-T
100.9/17.8 C83 4030017400 S.CER C1005 CH 1H 220J-T
5.2/36.9 C84 4030018120 S.CER C1005 CH 1H 110J-T
6.4/36.5 C85 4030017410 S.CER C1005 CH 1H 240J-T
6.4/38.2 C86 4030017610 S.CER C1005 CH 1H 090C-T
5.2/36.0 C89 4030017590 S.CER C1005 CH 1H 070C-T
47.7/46.4 C90 4030017610 S.CER C1005 CH 1H 090C-T
47.7/44.8 C91 4030017620 S.CER C1005 CH 1H 100C-T
44.5/39.3 C94 4030017380 S.CER C1005 CH 1H 050B-T
38.2/33.7 C95 4030017400 S.CER C1005 CH 1H 220J-T
37.0/33.6 C96 4030016790 S.CER C1005 JB 1E 103K-T
35.4/33.6 C97 4030017350 S.CER C1005 CH 1H 020B-T
43.5/45.2 C98 4030017350 S.CER C1005 CH 1H 020B-T
46.8/47.7 C99 4030017650 S.CER C1005 CH 1H 270J-T
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
7-2
DESCRIPTION M.
B
B
B
B
B
B
B
B
B
B
B
B
T
T
B
B
T
T
T
T
T
T
B
B
B
B
B
B
B
B
B
T
T
F930J106MAABMA B
T
B
T
B
B
B
B
B
F921V224MAA B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
T
T
T
T
T
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
S.=Surface mount
H/V
LOCATION
43.9/46.4
32.2/34.0
32.2/35.6
31.3/35.6
38.7/15.0
61.2/11.5
61.2/9.7
75.9/13.4
75.5/18.6
91.0/13.9
75.0/17.4
73.8/17.0
94.7/26.3
102.8/17.8
41.6/46.4
99.9/10.5
17.5/38.3
19.1/38.3
28.5/38.7
115.1/37.5
28.3/40.3
28.3/41.9
60.2/39.1
79.7/43.3
3.4/29.8
31.0/12.1
33.1/11.0
31.9/10.6
35.9/8.3
53.3/16.3
39.9/14.6
26.6/5.1
22.2/5.1
36.7/5.2
20.8/5.6
40.3/7.6
38.5/7.3
41.5/7.1
35.4/9.8
48.6/22.2
49.5/22.2
50.4/22.2
43.3/5.5
49.3/7.4
49.4/12.1
48.2/12.1
48.5/15.8
48.6/18.6
60.1/17.8
56.6/13.6
59.9/14.6
58.6/9.9
61.1/14.6
56.5/17.7
56.1/15.5
58.2/22.0
57.3/22.0
60.7/19.3
54.8/21.8
56.1/21.8
51.0/19.9
56.5/26.8
71.4/23.5
68.2/21.2
67.0/21.2
67.0/20.3
71.2/18.2
70.0/17.1
102.3/20.6
106.0/22.5
102.3/19.0
107.3/19.4
105.0/16.4
67.6/36.8
77.1/21.4
68.9/8.7
72.5/11.2
81.7/13.4
82.9/13.0
69.8/8.7
87.6/8.1
92.9/7.9
95.8/8.5
103.5/11.9
102.8/7.5
67.0/17.3
74.7/6.7
107.9/9.4
96.7/7.0
101.6/7.1
108.3/8.1
108.8/11.0
112.8/11.0
113.7/12.6
112.8/12.6
106.3/9.4
105.9/15.5
103.9/17.9
100.6/19.9
102.7/21.3
103.5/16.7
101.2/18.7
99.7/19.6
