- Page 1 User Guide Reversible air / water "Split Inverter" heat pump ALEZIO EVOLUTION AWHP-2 MIV-3...
- Page 2 Dear customer, Thank you for purchasing this appliance. Please read this manual carefully before using the product and keep it in a safe place for future reference. In order to ensure continued safe and efficient operation we recommend that the product is regularly maintained. Our Service and After Sales organization can assist with this.
-
Page 3: Table Of Contents
Decommissioning procedure ................32 7611973 - v04 - 07032016 AWHP-2 MIV-3... - Page 4 13.3 Package fiche - Medium-temperature heat pumps ........... . 37 AWHP-2 MIV-3...
-
Page 5: Safety
Take precautions with the domestic hot water. De pending on the heat pump settings, the domestic hot water temperature may exceed 65°C. 7611973 - v04 - 07032016 AWHP-2 MIV-3... - Page 6 AWHP-2 MIV-3 7611973 - v04 - 07032016...
-
Page 7: Recommendations
1.3 Liabilities 1.3.1 Manufacturer's liability Our products are manufactured in compliance with the re quirements of the various Directives applicable. They are 7611973 - v04 - 07032016 AWHP-2 MIV-3... -
Page 8: Installer's Liability
Liquefied gas: contact with the liquid may cause serious frost burn and eye injuries. Product classification: this product is not classified as a "hazardous preparation" according to European Union reg ulations. AWHP-2 MIV-3 7611973 - v04 - 07032016... - Page 9 Cleaning / decontamination: allow any residual product to evaporate. In the event of contact with the eyes: Rinse immediately with water, holding the eyelids well apart (for at least 15 minutes). Consult an ophthalmologist immediately. 7611973 - v04 - 07032016 AWHP-2 MIV-3...
- Page 10 Product waste: consult the manufacturer or the supplier for information on recovery or recycling. Soiled packaging: reuse or recycle after decontamination. Destroy in au thorised installations. Regulation European Regulation No. EC 842/2006: fluorinated greenhouse gases un der the Kyoto Protocol. AWHP-2 MIV-3 7611973 - v04 - 07032016...
-
Page 11: About This Manual
2 About this manual About this manual General This manual is intended for the user of a AWHP-2 MIV-3 heat pump. This manual can also be found on our internet site. Symbols used 2.2.1 Symbols used in the manual This manual uses various danger levels to draw attention to special in... -
Page 12: Technical Specifications
14.46 Energy efficien 4.83 4.09 3.99 4.75 4.75 3.96 3.96 cy ratio Absorbed elec 0.72 1.15 2.00 2.35 2.35 3.65 3.65 trical power Nominal am 3.40 5.43 9.40 11.05 3.68 17.15 5.71 perage AWHP-2 MIV-3 7611973 - v04 - 07032016... -
Page 13: Other Technical Parameters
(2) at 5 m from the appliance, free field 3.1.1 Other technical parameters Tab.8 Technical parameters for heat pump space heaters (parameters declared for medium-temperature application) AWHP-2 MIV-3 AWHP 4 MR AWHP 6 MR-2 AWHP 8 MR-2 Air-to-water heat pump... - Page 14 3 Technical specifications AWHP-2 MIV-3 AWHP 4 MR AWHP 6 MR-2 AWHP 8 MR-2 Declared capacity for heating for part load at in door temperature 20 °C and outdoor temperature = -7 °C = +2 °C = +7 °C = +12 °C...
- Page 15 3 Technical specifications Tab.9 Technical parameters for heat pump space heaters (parameters declared for medium-temperature application) AWHP-2 MIV-3 AWHP 11 MR-2 AWHP 16 MR-2 AWHP 11 TR-2 AWHP 16 TR-2 Air-to-water heat pump Water-to-water heat pump Brine-to-water heat pump Low-temperature heat pump...
-
Page 16: Sensor Characteristics
3 Technical specifications AWHP-2 MIV-3 AWHP 11 MR-2 AWHP 16 MR-2 AWHP 11 TR-2 AWHP 16 TR-2 Sound power level, indoors - outdoors dB (A) 53 - 69 53 - 69 Annual energy consumption under average conditions 3783 5184 Annual energy consumption under colder conditions... -
Page 17: Description Of The Product
In optimised energy cost mode, the control system chooses the cheap est generator according to the coefficient of performance of the heat pump and according to energy cost. 7611973 - v04 - 07032016 AWHP-2 MIV-3... -
Page 18: Control Panel Description
MW-M002227-1 Other Information: : Fault active : Adjusting the set point temperatures : A manual venting cycle is running / Permanent display of the information menu / The screed drying function is active. AWHP-2 MIV-3 7611973 - v04 - 07032016... -
Page 19: Operation
When the outside temperature drops too low, the appliance's protection system starts up. Frost protection is handled by the back-up. The back-up is tripped automatically to handle frost protection under the following con ditions: 7611973 - v04 - 07032016 AWHP-2 MIV-3... - Page 20 Tab.12 Frost protection conditions Frost protection Conditions Heating circuit Outside temperature: < 3°C Heating flow temperature: < 6°C Protection of the domestic hot wa Outside temperature: < 3°C ter tank Domestic hot water temperature: < 4°C AWHP-2 MIV-3 7611973 - v04 - 07032016...
-
Page 21: Settings
Fossil energy tariff for the hydraulic back-up 0.01 to 2.50 0.01 Gas boiler: Tariff per m of gas. Example: €/m Oil boiler: Tariff per litre of oil. Example: €/litre (1) Only available if 7611973 - v04 - 07032016 AWHP-2 MIV-3... -
Page 22: User Settings
Heating and domestic hot water Heating Domestic hot water Cooling and domestic hot water Cooling Shut-down/Frost Protection mode Swimming pool Swimming pool and domestic hot water 4. Press the key to confirm and exit the menu. AWHP-2 MIV-3 7611973 - v04 - 07032016... -
Page 23: Forcing The Back-Up
°C 3. Press the key to confirm and exit the menu. Note M002241-B When a room thermostat is connected, set it to a value 2 K higher than the room temperature set point 7611973 - v04 - 07032016 AWHP-2 MIV-3... -
Page 24: Configuring The Hybrid Operating Mode
Adjustment Increment Factory set range ting Domestic hot wa from 40 to 1 °C 50 °C ter set point tem 65°C perature 3. Press the key to confirm and exit the menu. M002244-B AWHP-2 MIV-3 7611973 - v04 - 07032016... -
Page 25: Reading Out Measured Values
In cooling mode: Cooling set point temperature In swimming pool mode: Swimming pool set point temperature Measured flow temperature °C Measured domestic hot water temperature °C Measured outside temperature °C Water flow rate litres/minute 7611973 - v04 - 07032016 AWHP-2 MIV-3... -
Page 26: Energy Consumption Display
C004233-B Fig.22 Unit 100 kWh The displayed value is 12300 kWh. The unit is 100 kWh. The first dig it indicates the scale x 100. Only the first 3 digits are displayed. MW-C004234-1 AWHP-2 MIV-3 7611973 - v04 - 07032016... - Page 27 Display example Description Fig.23 Unit 1000 kWh The displayed value is 123000 kWh. The unit is 1000 kWh. The first digit indicates the scale x 1000. Only the first 3 digits are displayed. MW-C004235-1 7611973 - v04 - 07032016 AWHP-2 MIV-3...
-
Page 28: Maintenance
7.4.1 Manual venting 1. Open the valves on all radiators connected to the heating system. 2. Put the heat pump in shut-down/frost protection mode. AWHP-2 MIV-3 7611973 - v04 - 07032016... -
Page 29: Automatic Venting
An automatic venting cycle begins. The word stops flashing. 2. Press the key to stop the venting cycle. Caution After venting, check whether the pressure in the installation is still sufficient. Add more water to the installation if necessary. 7611973 - v04 - 07032016 AWHP-2 MIV-3... -
Page 30: Troubleshooting
For AWHP 8 MR-2, set 8°C. For AWHP 11 MR-2 : set 10°C. For AWHP 11 TR-2: set 10°C. For AWHP 16 MR-2 : set to 13°C. For AWHP 16 TR-2: set 13°C. AWHP-2 MIV-3 7611973 - v04 - 07032016... -
Page 31: Troubleshooting
Significant water leak The pipes on the heat Contact the installer. underneath or in the pump or the central heat vicinity of the heat ing are damaged. pump. 7611973 - v04 - 07032016 AWHP-2 MIV-3... -
Page 32: Decommissioning Procedure
9 Decommissioning procedure Decommissioning procedure To decommission the heat pump temporarily or permanently: 1. Contact the installer. AWHP-2 MIV-3 7611973 - v04 - 07032016... -
Page 33: Environmental
60°C and 80°C respectively) when an ON/OFF thermostat is used. When clock thermostats and programmable thermostats are to be set, do not forget to take any holidays and days when no one is at home into account. 7611973 - v04 - 07032016 AWHP-2 MIV-3... -
Page 34: Disposal/Recycling
11 Disposal/recycling 11.1 Disposal and Recycling Fig.26 Recycling Warning Removal and disposal of the heat pump must be carried out by a qualified professional in accordance with prevailing local and na tional regulations. MW-3000179-03 AWHP-2 MIV-3 7611973 - v04 - 07032016... -
Page 35: Warranty
The rights established in European Directive 99/44/EEC, implemented by legal decree No. 24 of 2 February 2002 and published in Official Journal No. 57 of 8 March 2002, remain in force. 7611973 - v04 - 07032016 AWHP-2 MIV-3... -
Page 36: Appendix
For specific precautions about assembling, installing and main taining: See Safety Instructions 13.2 Product fiche - Temperature Controls Tab.20 Product fiche for the temperature controls Regulator Class Contribution to space heating energy efficiency AWHP-2 MIV-3 7611973 - v04 - 07032016... -
Page 37: Package Fiche - Medium-Temperature Heat Pumps
The value of the mathematical expression: 294/(11 · Prated), whereby ‘Prated’ is related to the preferential space heater. The value of the mathematical expression 115/(11 · Prated), whereby ‘Prated’ is related to the preferential space heater. 7611973 - v04 - 07032016 AWHP-2 MIV-3... - Page 38 Seasonal space heating energy efficiency of package Tab.23 Package efficiency AWHP 11 MR-2 AWHP 16 MR-2 AWHP 11 TR-2 AWHP 16 TR-2 Seasonal space heating energy efficiency Temperature control Seasonal space heating energy efficiency of package AWHP-2 MIV-3 7611973 - v04 - 07032016...
- Page 39 © Copyright All technical and technological information contained in these technical instructions, as well as any drawings and technical de scriptions supplied, remain our property and shall not be multiplied without our prior consent in writing. Subject to alterations.
