- Page 1 Ireland ALEZIO EVOLUTION EASYLIFE User Manual Reversible air / water "Split Inverter" heat pump ALEZIO EVOLUTION AWHP-V200 MIV-4/E 4–8 V200 MIV-4/E 11–16 V200 MIV-4/H 4–8 V200 MIV-4/H 11–16 V200...
- Page 2 Dear Customer, Thank you very much for buying this appliance. Please read through the manual carefully before using the product, and keep it in a safe place for later reference. In order to ensure continued safe and efficient operation we recommend that the product is serviced regularly. Our service and customer service organisation can assist with this.
-
Page 3: Table Of Contents
Contents Contents Safety ................... . 5 General safety instructions . - Page 4 Contents Troubleshooting ..................52 Error messages .
-
Page 5: Safety
1 Safety Safety General safety instructions Danger This appliance can be used by children aged 8 years and above and by persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge when they have been given supervision or instruction concerning the safe use of the device and understand the result... - Page 6 1 Safety Important Insulate the pipes to reduce heat losses to a mini mum. Caution The system must satisfy each point in the rules in force in the country that govern works and inter ventions in individual homes, blocks of flats or other buildings.
- Page 7 1 Safety Caution The appliance is intended to be permanently con nected to the domestic water mains network. Caution Respect the minimum and maximum water inlet pressure to ensure correct operation of the appli ance: refer to the chapter Technical Specifica tions.
- Page 8 1 Safety Caution There must be no cut-off devices between the safety valve or unit and the domestic hot water tank. Electrical safety Caution A disconnection device must be fitted to the per manent pipes in accordance with installation rules. Caution If a power cord comes with the appliance and it turns out to be damaged, it must be replaced by...
-
Page 9: Recommendations
1 Safety Important The Installation Manual for the appliance is also available on our internet site. Recommendations Caution Install the heat pump's indoor module in a frost- free location. Note Only qualified persons are authorised to assem ble, install and maintain the installation. Caution Maintenance work must be carried out by a quali... - Page 10 1 Safety Important Remove the casing only to perform maintenance and repair work. Put the casing back in place af ter maintenance and repair work. Caution Give preference to the mode rather than switching off the system to leave the following functions running: Anti blocking of pumps Frost Protection...
-
Page 11: Specific Safety Instructions
1 Safety Specific safety instructions Warning Refrigerant fluid and pipes: Use only R410A refrigerant fluid to fill the instal lation. Use tools and pipe components especially de signed for use with R410A refrigerant fluid. Use copper pipes deoxidised with phosphorus to carry the refrigerant fluid. - Page 12 1 Safety Tab.2 Precautions for use First aid If inhaled: Evacuate the subject from the contaminated area and take him into the open air. If feeling unwell: call a doctor. In the event of contact with the skin: Treat frost injuries like burns. Rinse with copious amounts of tepid water, do not remove clothing (risk of adhesion to the skin).
-
Page 13: Liabilities
1 Safety Personal protection Respiratory protection: If ventilation is insufficient: AX type cartridge mask. In confined spaces: self-contained breathing apparatus. Hand protection: protective gloves in leather or nitrile rubber. Eye protection: safety glasses with side protection. Skin protection: clothing made principally of cotton Industrial hygiene: do not drink, eat or smoke at the place of work. -
Page 14: User's Liability
1 Safety Carry out initial commissioning and any checks neces sary. Explain the installation to the user. If maintenance is necessary, warn the user of the obli gation to check the appliance and keep it in good working order. Give all the instruction manuals to the user. 1.4.3 User's liability To guarantee optimum operation of the system, you... -
Page 15: About This Manual
2 About this manual About this manual General This manual is intended for the user of a MIV-4 heat pump. Symbols used 2.2.1 Symbols used in the manual This manual uses various danger levels to draw attention to special in structions. - Page 16 2 About this manual Fig.3 Symbols used on the connection la 1 Sensor cable - low voltage 2 Power cord 230 V / 400 V 3 Heating circuit flow 4 Circuit B flow 5 Heating circuit return 6 Circuit B return (optional) G1"...
-
Page 17: Technical Specifications
3 Technical specifications Technical specifications Homologations 3.1.1 Directives This product complies with the requirements of the following European Di rectives and Standards: Pressure Equipment Directive 97/23/EC, Article 3, paragraph 3 Low Voltage Directive 2014/35/EU Generic standard: EN 60335-1 Relevant standards: EN 60335-2-21, EN 60335-2-40 Electromagnetic Compatibility Directive 2014/30/EU Generic standards: EN 61000-6-3, EN 61000-6-1 Relevant Standard: EN 55014... - Page 18 3 Technical specifications Measure Unit AWHP 4 AWHP 4.5 AWHP 6 AWHP 8 AWHP 11 AWHP 11 AWHP 16 AWHP 16 ment type MR-2 MR-2 MR-2 TR-2 MR-2 TR-2 AWHP 6 MR-3 Nominal 0.68 0.80 1.00 1.36 1.96 1.96 2.53 2.53 /hour water flow...
-
Page 19: Domestic Hot Water Tank
3 Technical specifications Measure Unit AWHP 4 AWHP AWHP 6 AWHP 6 AWHP 8 AWHP 11 AWHP 11 AWHP 16 AWHP 16 ment 4.5 MR MR-2 MR-3 MR-2 MR-2 TR-2 MR-2 TR-2 type Power voltage of the out door unit Start-up amper... -
Page 20: Heat Pump Weight
3 Technical specifications Specification Unit Value Minimum operating temperature °C Maximum operating pressure MPa (bar) 0.3 (3.0) Exchanger capacity Litres 11.3 Exchange surface m² Tab.9 Technical specifications secondary circuit (domestic water) Specification Unit Value Maximum operating temperature °C Minimum operating temperature °C Maximum operating pressure MPa (bar) -
Page 21: Combination Heaters With Medium-Temperature Heat Pump
3 Technical specifications 3.2.4 Combination heaters with medium-temperature heat pump Tab.13 Technical parameters for heat pump combination heaters (parameters declared for medium-temperature application) Product name MIV-4 MIV-4 MIV-4 AWHP 4 MR AWHP 4.5 MR AWHP 6 MR-2 AWHP 6 MR-3 Air-to-water heat pump Water-to-water heat pump Brine-to-water heat pump... - Page 22 3 Technical specifications Product name MIV-4 MIV-4 MIV-4 AWHP 4 MR AWHP 4.5 MR AWHP 6 MR-2 AWHP 6 MR-3 Off mode 0.009 0.009 0.009 Thermostat-off mode 0.049 0.049 0.049 Stand-by 0.016 0.016 0.015 Crankcase heater mode 0.055 0.000 0.055 Supplementary heater Psup Rated heat output...
- Page 23 3 Technical specifications Product name MIV-4 MIV-4 MIV-4 AWHP 8 MR-2 AWHP 11 MR-2 AWHP 16 MR-2 = -7°C = +2°C 11.9 = +7°C 12.9 = +12°C 10.1 15.4 = bivalent temperature = operation limit temperature Bivalent temperature °C Degradation coefficient —...
-
Page 24: Circulating Pump
3 Technical specifications Product name MIV-4 MIV-4 MIV-4 AWHP 8 MR-2 AWHP 11 MR-2 AWHP 16 MR-2 Annual energy consumption under warmer condi 1904 2580 4120 tions Rated air flow rate, outdoors for air-to-water heat — 3300 6000 6000 pumps Declared load profile Daily electricity consumption 4.816... -
Page 25: Description Of The Product
4 Description of the product Description of the product General description The MIV-4 heat pump comprises: an indoor module, including a domestic hot water tank and a control panel. A reversible outdoor unit for energy production in heating or cooling mode. -
Page 26: Main Components
4 Description of the product Fig.4 General operating principle MW-6000391-1 1 Evaporator (fin battery in the outdoor unit) 5 Electrical energy 2 Compressor 6 Heating water 3 Condenser (plate exchanger in the indoor module) 7 Energy flow 4 Electronic expansion valve 8 Heat recovered from the environment Main components Fig.5... -
Page 27: Control Panel Description
4 Description of the product Control panel description 4.4.1 Description of the keys Fig.6 : back to the previous level without saving the modifications made : manual reset : accessing the heating parameters : lowering the value : accessing the domestic hot water parameters : raising the value : MODE display : accessing the menu selected or confirming the value modifi... - Page 28 4 Description of the product Hydraulic pressure in the system The display alternates between the hydraulic pressure for the system and the measured flow temperature. Fig.11 Steady symbol: displayed when indicating the system's hydraulic pressure value Flashing symbol: pressure in the system too low XXX Pressure value in the system (in bar) or flow temperature (in °C) Cooling mode Fig.12...
- Page 29 4 Description of the product Fig.17 Additional PCB SCB–04: 2 circuit ...SCB / 04- / B... COUNTERS / TIME PROG / Sub-Menus CLOCK Fig.18 COUNTERS sub-menu (CNT) TIME PROG sub-menu: Timer programming dedicated to heat ing and domestic hot water production (CIRC A, CIRC B, ECS) Timer program for Monday Timer program for Tuesday Timer program for Wednesday...
-
Page 30: Operation
5 Operation Operation Use of the control panel 5.1.1 Browsing in the menus Press any key to turn on the backlight for the control panel screen. Important If no key is pressed within 3 minutes, the backlight will go out. Fig.21 Press the 2 right-hand keys together to access the different menus: Tab.15... -
Page 31: Shutdown
5 Operation Shutdown 5.3.1 Switching off the heating Note Heating mode can be managed via the TIME PROG sub-menu dedicated to timer programming. Note If the heating function is shut off, then the cooling will also be shut off. Fig.25 1. -
Page 32: Stopping Domestic Hot Water Production
5 Operation 5.3.2 Stopping domestic hot water production Note Domestic hot water production can be managed via the TIME PROG sub-menu dedicated to timer programming. Fig.28 1. Go to stop mode by pressing the key. MW-5000135-3 Fig.29 2. Select domestic hot water production mode pressing the key. - Page 33 5 Operation If the water temperature is lower than 5°C, the circulating pump starts If the water temperature is lower than 3°C, the back-up starts up. If the water temperature is higher than 10°C, the back-up shuts down and the circulating pump continues to run for a short time. The radiator valves in rooms where there is a risk of frost must be fully open.
-
Page 34: Settings
6 Settings Settings List of parameters 6.1.1 User menu Fig.31 MW-2000435-1 1 Sub-menu available 3 Setting parameters 2 Name of the PCB or circuit Tab.16 List of User sub-menus Sub-menu Description Name of the PCB or cir cuit Main heating circuit Additional heating circuit B Domestic hot water circuit Central unit PCB EHC-02... - Page 35 6 Settings Parameter Description Factory setting Factory setting Set point cooling activity zone 2 25°C 25°C Can be set from 20 to 30°C Do not modify this setting. 25°C 25°C Do not modify this setting. 25°C 25°C Do not modify this setting. 25°C 25°C Do not modify this setting.
-
Page 36: Menus
6 Settings Tab.19 List of parameters in the / sub-menus of the User menu Parameter Description Factory setting Factory setting Cooling mode operation: not available = off = on Central heating operation: not available = off (no heating or cooling) = on Domestic hot water tank operation: not available... - Page 37 6 Settings Parameter Description Factory setting Setting the LANGUAGE = no language = French = Dutch = English = German = Spanish = Italian = Polish = Portuguese Setting the CONTRAST Can be set from 0 to 3 Selecting the UNIT = °C = °F Applying summer/winter time...
- Page 38 6 Settings Tab.24 List of hour run meters available (X) in the sub-menu Parameter Description Unit Number of hours' operation hours Number of hours' compressor operation since the hours last service Number of hours' operation since the last service hours Number of compressor start-ups since the last service Consumption in heating mode...
-
Page 39: Setting The Parameters
6 Settings Tab.26 List of parameters in the sub-menu of the menu Parameter Unit HOURS Can be set from 0 to 23 available MINUTE Can be set from 0 to 59 available DATE Can be set from 1 to 31 available MONTH Can be set from 1 to 12... -
Page 40: Setting The Domestic Hot Water Temperature
6 Settings Fig.35 3. Confirm by pressing the key. The name of the circuit and the heating water temperature set point are displayed alternately. 4. Access setting of the heating water temperature set point by press ing the key. 5. Set the heating water temperature set point by pressing the key. -
Page 41: Activating Manual Forcing For Heating
6 Settings Fig.38 2. Open Forcing of the cooling function by pressing the key. MW-5000402-2 Fig.39 3. Activate Forcing of the cooling function by pressing the key. MW-5000403-2 Fig.40 4. Confirm Forcing of the cooling function by pressing the key. 5. -
Page 42: Setting The Timer Programming
6 Settings 6.2.6 Setting the timer programming Fig.43 1. Access the COUNTERS / TIME PROG menus CLOCK Important The COUNTERS / TIME PROG / CLOCK menus can only be ac cessed when the icon flashes. Important When using a programmable room thermostat, this menu is not displayed. -
Page 43: Reading Out Measured Values
6 Settings Fig.47 7. Set the start time for the period by pressing the key. 8. Confirm the selection by pressing the key. MW-5000142-2 Fig.48 9. Select the status that correspond to the period by pressing keys. Status for periods Description comfort mode reduced mode... - Page 44 6 Settings Tab.28 List of sub-menus for an installation with an additional PCB Sub-menu Description Name of the PCB or circuit Central unit PCB EHC-02 Additional PCB SCB-04 Control panel HMI Tab.29 Values available (X) in the , sub-menus Parameter Description Unit Pump rotation speed...
-
Page 45: Control System Sequence
6 Settings Parameter Description Unit Domestic hot water production mode: = programming = manual = frost protection mode Heat pump flow temperature °C Heat pump return temperature °C System flow temperature. °C Heating temperature set point °C Software version for the selected PCB Parameter version for the selected PCB Tab.30 Values available (X) in the... - Page 46 6 Settings Status (parameter Sub-status (parameter = operating in heating mode = normal operation The compressor or the back-ups are running. = internal set point limited If the heating set point on the heat pump differs from the system set point. = pump post-operation Heat pump and back-up shut-down, system pump operation.
- Page 47 6 Settings Status (parameter Sub-status (parameter = controlled compressor shut-down = off: the heating or cooling set point has been reached = anti-short cycle The heating set point has been reached. The compressor is not authorised to restart. = pump post-operation Heat pump and back-up shut-down, system pump post-operation.
- Page 48 6 Settings Status (parameter Sub-status (parameter = forced operation in heating mode = normal operation. The compressor or the back-ups are running. = internal set point limited If the heating set point on the heat pump differs from the system set point. = pump post-operation Heat pump and back-up shut-down, system pump post-operation.
- Page 49 6 Settings Status (parameter Sub-status (parameter = venting = normal operation The compressor or the back-ups are running. = internal set point limited If the heating set point on the heat pump differs from the system set point. = pump post-operation Heat pump and back-up shut-down.
-
Page 50: Maintenance
7 Maintenance Maintenance General Maintenance operations are important for the following reasons: To guarantee optimum performance. To extend the life of the equipment. To provide an installation which offers the user optimum comfort over time. Caution Maintenance work must be carried out by a qualified professional. Danger Before any work, switch off the mains electricity to the heat pump and the hydraulic or electrical back-up if connected. -
Page 51: Cleaning The Casing
7 Maintenance Cleaning the casing 1. Clean the outside of the appliance using a damp cloth and a mild detergent. 7623755 - v05 - 27042017 MIV-4... -
Page 52: Troubleshooting
8 Troubleshooting Troubleshooting Error messages Fig.49 Resetting the control panel allows the appliance to be restarted. The message appears when a fault code is detected. After resolving the problem, pressing the key resets the appliance's functions and thus eradicates the fault. If several faults occur, they are displayed one after the other. -
Page 53: Fault Codes
8 Troubleshooting Error code Message Description H02.04 PARAMETER ERROR H02.05 Memory error H02.07 WATPRESSURE Insufficient water pressure ERROR Check the hydraulic pressure in the heating circuit. H02.09 PARTIAL BLOCK BL input on the central unit PCB terminal block open H02.10 FULL BLOCK BL input on the central unit PCB terminal block open H02.23... -
Page 54: Troubleshooting
8 Troubleshooting Fig.51 1. Access the menus by pressing the two keys on the right simultane ously. MW-2000369-1 Fig.52 2. Select the Malfunction menu by pressing the key. Fig.53 3. Select the PCB by pressing the keys. The icon appears. Confirm the PCB selection by pressing the key: the PCB name appears. - Page 55 8 Troubleshooting Problems Probable causes Corrections There is no domestic The domestic hot water Increase the value of parameter hot water. set point temperature is too low. The domestic hot water Activate the domestic hot water mode. mode is deactivated. The appliance is in re...
-
Page 56: Decommissioning
9 Decommissioning Decommissioning Decommissioning procedure To decommission the heat pump temporarily or permanently: 1. Contact the installer. MIV-4 7623755 - v05 - 27042017... -
Page 57: 10 Disposal
10 Disposal 10 Disposal 10.1 Disposal and Recycling Fig.55 Recycling Warning Removal and disposal of the heat pump must be carried out by a qualified professional in accordance with prevailing local and na tional regulations. MW-3000179-03 7623755 - v05 - 27042017 MIV-4... -
Page 58: 11 Environmental
11 Environmental 11 Environmental 11.1 Energy savings Energy-saving advice: Do not block ventilation outlets. Do not cover the radiators. Do not hang curtains in front of the radiators. Install reflective panels behind the radiators to prevent heat losses. Insulate the pipes in rooms that are not heated (cellars and lofts). Close the radiators in rooms not in use. -
Page 59: 12 Warranty
12 Warranty 12 Warranty 12.1 General We would like to thank you for buying one of our appliances and for your trust in our product. In order to ensure continued safe and efficient operation, we recommend that the product is regularly inspected and maintained. Your installer and our service department can assist with this. -
Page 60: 13 Appendix
13 Appendix 13 Appendix 13.1 Product fiche Tab.35 Product sheet for heat pump combination heaters MIV-4 MIV-4 MIV-4 AWHP 4 MR AWHP 4.5 AWHP 6 MR-2 AWHP 6 MR-3 Space heating - Temperature application Medium Medium Medium Water heating - Declared load profile Seasonal space heating energy efficiency class under average climate conditions Water heating energy efficiency class under average climate... -
Page 61: Product Fiche - Temperature Controls
13 Appendix MIV-4 MIV-4 MIV-4 AWHP 8 MR-2 AWHP 11 AWHP 16 MR-2 MR-2 Water heating energy efficiency class under average climate conditions (Prated or Rated heat output under average climate conditions Psup) Space heating - Annual energy consumption under average cli 3316 3783 5184... - Page 62 13 Appendix Fig.56 Package fiche for medium-temperature heat pumps indicating the space heating energy efficiency of the package Seasonal space heating energy effi ciency of heat pump ‘I’ Temperature control Class I = 1%, Class II = 2%, Class III = 1.5%, Class IV = 2%, Class V = 3%, Class VI = 4%, from fi...
- Page 63 13 Appendix Tab.38 Weighting of medium temperature heat pumps Prated / (Prated + Psup) II, package without hot water storage tank II, package with hot water storage tank (1)(2) 1.00 1.00 0.70 0.63 0.45 0.30 0.25 0.15 0.15 0.06 0.05 0.02 0.02 ≥...
-
Page 64: Package Fiche - Combination Heaters (Boilers Or Heat Pumps)
13 Appendix 13.4 Package fiche - Combination heaters (boilers or heat pumps) Fig.57 Package fiche for combination heaters (boilers or heat pumps) indicating the water heating energy efficiency of the package Water heating energy effi ciency of combination heater ‘I’ Declared load profi... - Page 65 13 Appendix 7623755 - v05 - 27042017 MIV-4...
- Page 66 13 Appendix MIV-4 7623755 - v05 - 27042017...
- Page 67 © Copyright All technical and technological information contained in these technical instructions, as well as any drawings and technical de scriptions supplied, remain our property and shall not be multiplied without our prior consent in writing. Subject to alterations.
- Page 68 Зубарев переулок, д. 15/1 +49 (0)25 72 / 9161-0 Бизнес-центр «Чайка Плаза», +49 (0)25 72 / 9161-102 офис 309 info@remeha.de 8 800 333-17-18 info@dedietrich.ru DE DIETRICH THERMIQUE Iberia S.L.U. DE DIETRICH SERVICE www.dedietrich-calefaccion.es www.dedietrich-heiztechnik.com Freecall 0800 / 201608 C/Salvador Espriu, 11 08908 L’HOSPITALET de LLOBREGAT...
