Specifications - General AUG18FBAB Service Manual

SPECIFICATIONS

TYPE
INDOOR UNIT
OUTDOOR UNIT
COOLING CAPACITY
ELECTRICAL DATA
POWER SOURCE
RUNNING CURRENT
INPUT WATTS
E.E.R.
MOISTURE REMOVAL
AIR CIRCULATION-HIGH
FAN MOTOR
DISCRIMINATION
HIGH-SPEED
INDOOR
UNIT
MED-SPEED
LOW-SPEED
DISCRIMINATION
OUTDOOR
HIGH-SPEED
UNIT
LOW-SPEED
DIMENSIONS
INDOOR UNIT
H x W x D
OUTDOOR UNIT H x W x D
GRILLE H x W x D
WEIGHT
INDOOR UNIT Net / Gross
OUTDOOR UNIT Net / Gross
GRILLE Net / Gross
REFRIGERANT CHARGE (R410A)
COMPRESSOR TYPE
DISCRIMINATION
Pipe Length 7.5 m
10 m
FULL CHARGE
15 m
20 m
ADDITIONAL CHARGE
MAXIMUM PIPE HEIGHT
MAXIMUM PIPE LENGTH
2006.03.23
COOL
AUG18FBAB
AOG18FNCKL AOG18FNCNL
5.00 kW
230 V 50 Hz
8.5 A
1.90 kW
2.63 kW/kW
2.1 L/hr
620 m /hr
3
MFA-18GTT
800 r.p.m.
700 r.p.m.
600 r.p.m.
MFB-24JTBT MFB-24JTS
780 r.p.m.
400 r.p.m.
235 x 580 x 580 +70 mm
650 x 830 x 320 mm
35 x 650 x 650 mm
18 kg / 23 kg
47 kg / 51 kg
2.2 kg / 4.3 kg
Hermetic type, Rotary
5KS225DAC
800 g
850 g
950 g
1,050 g
20 g/m
8 m
20 m
TYPE
INDOOR UNIT
OUTDOOR UNIT
COOLING CAPACITY
HEATING CAPACITY
ELECTRICAL DATA
POWER SOURCE
COOLING
RUNNING
CURRENT
HEATING
COOLING
INPUT WATTS
HEATING
COOLING
E.E.R.
HEATING
MOISTURE REMOVAL
AIR CIRCULATION-HIGH
FAN MOTOR
DISCRIMINATION
HIGH-SPEED
INDOOR
UNIT
MED-SPEED
LOW-SPEED
DISCRIMINATION
OUTDOOR
HIGH-SPEED
UNIT
LOW-SPEED
DIMENSIONS
INDOOR UNIT H x W x D
OUTDOOR UNIT H x W x D
GRILLE H x W x D
WEIGHT
INDOOR UNIT Net / Gross
OUTDOOR UNIT Net / Gross
GRILLE Net / Gross
REFRIGERANT CHARGE (R410A)
COMPRESSOR TYPE
DISCRIMINATION
Pipe Length
FULL CHARGE
ADDITIONAL CHARGE
MAXIMUM PIPE HEIGHT
MAXIMUM PIPE LENGTH
1
COOL & HEAT
AUG18UBAB
AOG18UNCKL AOG18UNCNL
4.85 kW
5.40 kW
230 V 50 Hz
8.2 A
9.2 A
1.85 kW
2.00 kW
2.62 kW/kW
2.70 kW/kW
2.1 L/hr
620 m 3 /hr
MFA-18GTBT
800 r.p.m.
700 r.p.m.
600 r.p.m.
MFB-24JTBT MFB-24JTBS
780 r.p.m.
400 r.p.m.
235 x 580 x 580 +70 mm
650 x 830 x 320 mm
35 x 650 x 650 mm
18 kg / 23 kg
52 kg / 56 kg
2.2 kg / 4.3 kg
Hermetic type, Rotary
5KS225DAC
1,250 g
7.5 m
1,300 g
10 m
1,400 g
15 m
1,500 g
20 m
20 g/m
8 m
20 m
