symboLs useD in
saueR-Danfoss
LiteRatuRe
6
Series 45 G Frame Open Circuit Axial Piston Pumps
Service Manual
Introduction
These symbols are in the illustrations and text of this manual. They communicate helpful
information at the point where it is most useful to the reader.
In most instances, the appearance of the symbol itself denotes its meaning. The legend
below defines the symbol and explains its purpose.

WARNING may result in injury

CAUTION may result in damage to
product or property

Reusable part

Non-reusable part, use a new part

Non-removable item

Option – either part may exist

Superseded – parts are not
interchangeable

Measurement required

Flatness specification

Parallelism specification

External hex head

Internal hex head

Torx head

O-ring boss port
520L0605 • Rev AB • December 2010

Tip, helpful suggestion

Lubricate with hydraulic fluid

Apply grease / petroleum jelly

Apply locking compound

Inspect for wear or damage

Clean area or part

Be careful not to scratch or damage

Note correct orientation

Mark orientation for reinstallation

Torque specification

Press in – press fit

Pull out with tool – press fit

Cover splines with installation
sleeve

Pressure measurement / gauge
location or specification
