User Manual

VIDEO DOOR PHONE CDV-73BE
Thank you for purchasing COMMAX products.
Thank you for purchasing COMMAX products.
Please carefully read this User's Guide (in particular, precautions for safety) before using a product and follow
Please carefully read this User's Guide (in particular, precautions for safety) before using a product and follow
instructions to use a product exactly.
instructions to use a product exactly.
The company is not responsible for any safety accidents caused by abnormal operation of the product.
The company is not responsible for any safety accidents caused by abnormal operation of the product.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CDV-73BE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Commax CDV-73BE

Summary of Contents for Commax CDV-73BE

  • Page 1: User Manual

    User Manual VIDEO DOOR PHONE CDV-73BE Thank you for purchasing COMMAX products. Thank you for purchasing COMMAX products. Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow instructions to use a product exactly.

  • Page 2: Table Of Contents

    Table of Contents Table of Contents ..............1 Warnings and caution ..............2 1. Product overview ..............4 2. Product characters & key features ........5 3. Operation ................5 4. Display adjustment ..............6 5. Name of parts ................7 6. Wiring Diagram ..............7 7. Installation method ..............8 8.

  • Page 3: Table Of Contents

    9. Specification ITEM Details Wiring CAMERA 4wires(polarized), INTERPHONE 4wires Power source 100-240V~, 50/60Hz Communication way Simultaneous Conversation way (Hand-set) Display 7 TFT-LCD Digital Entrance(individual entrance): electronic chime 2 times, Call sound Interphone: electronic sound Stand-by : 4.5 W(Max.) Power consumption On operation : 12 W(Max.) Wire Pie 0.5mm 0.65mm 0.8mm...

  • Page 4: Warnings And Caution

    Warnings and caution Make sure to follow the instructions to prevent any danger or property losses. It indicates prohibition. It indicates prohibition of disassembly. Warning Death or serious It indicates prohibition of contact. injury is expected. It indicates dos and don’ts. It indicates that the plug should be pulled out from the socket.
  • Page 5 Install the product in a flat and Pull the plug if the product is If the product generates strange stable place. not used for a long time. sound, make sure to pull the plug immediately and contact Otherwise, it may not function Commax service center. properly.

  • Page 6: Product Overview

    1. Product overview Name Details Handset Handset On/Off & Display LED Indicates On/Off & Display status No available Volume control button Control the call volume Monitoring button(MONITOR) View image from door camera and can talk Interphone button(INTERPHONE) Intercommunication between the rooms Door release button Open the door during talk Direction button...

  • Page 7: Product Characters & Key Features

    2. Product characters & key features 7” Wide Digital TFT-LCD ● Surface mounted type installation ● Free voltage power ● Call and talk with 2 door cameras ● Call and talk with interphone ● Door release function ● 3. Operation ☞When Power switch ON after done installation, you can use it with LCD screen On.

  • Page 8: Display Adjustment

    2. Interphone function ☞With pick up the handset, if press INTERPHONE button, the connected interphone will be called. If not press interphone button, there will be no more ringing tone chimed, so you must press continually. On this stage, if pick up the handset of other party’s interphone, users can talk each other.

  • Page 9: Name Of Parts

    5. Name of parts SCREW T4X18(2EA) User manual Wall Mount Bracket Fixing Screw Video phone & Handset wired Connector 4P (2EA) 6. Wiring Diagram • When CAMERA 2 port is used with connecting 2nd camera, the jump-cap is no needed, but it is covered in factory release status.

  • Page 10: Installation Method

    7. Installation method Installation method of monitor SCREW T4 X 18(2EA) SCREW M3 X 6(2EA) Caution during installation Avoid installation on place with magnetism, lots of moisture, directed light, and also closed ● location from heating apparatus due to harmful effect. Its standard height from floor is 1450~1500mm to be installed.

  • Page 11: Trouble Shooting

    8. Trouble shooting If you think that the product has trouble, please first check below contents before you ask a repair. Troubles Check Point Actions 1. Please connect the 1.The power supply The power supply is ● power supply cord code is missing or not.

  • Page 12: Specification

    513-11, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea Int’l Business Dept. Tel. : +82-31-7393-540~550 Fax. : +82-31-745-2133 Web site : www.commax.com PM0773BE0010 Printed In Korea / 2011.03.104...
