1.14.2 TRAY SHIFT SENSORS AND TRAY RELEASE SENSOR

1. Tray 1 covers (
2. Gear disk [A] (
3. Tray shift sensors [B] (
4. Tray release sensor [C] (

1.14.3 TRAY 1 SHIFT MOTOR

1. Tray 1 covers (
2. Motor bracket [A] (
3. Tray 1 shift motor [B] (

1.14.4 BACK FENCE LOCK CLUTCH

1. Tray 1 covers (
2. Back fence lock clutch [A] (
x1)
SM
1.14.1)
x1)
x1 each).
x1)
1.14.1)
x3, x1)
x3, belt x1)
[A]
1.14.1)
x1,
11
TRAY 1 INTERIOR
[B]
[C]
[A]
[B]
[A]
[B]
B352R210.WMF
B352R209.WMF
B352R211.WMF
G838
