Table of Contents

Advertisement

Quick Links

Download this manual
G188/G189
SERVICE MANUAL
004261MIU

Advertisement

Table of Contents
loading

Related Manuals for Ricoh G188

Summary of Contents for Ricoh G188

  • Page 1 G188/G189 SERVICE MANUAL 004261MIU...
  • Page 5 G188/G189 SERVICE MANUAL 004261MIU...
  • Page 7 It is the reader's responsibility when discussing the information contained within this document to maintain a level of confidentiality that is in the best interest of Ricoh Americas Corporation and its member companies. NO PART OF THIS DOCUMENT MAY BE REPRODUCED IN ANY FASHION AND DISTRIBUTED WITHOUT THE PRIOR PERMISSION OF RICOH AMERICAS CORPORATION.
  • Page 9 Ricoh Technical Training Program. Untrained uncertified users utilizing information contained in this service manual to repair or modify Ricoh equipment risk personal injury, damage to property or loss of warranty protection. Ricoh Americas Corporation...
  • Page 11 LEGEND PRODUCT COMPANY CODE GESTETNER LANIER RICOH SAVIN G188 C8140ND LP540C SP C820DN CLP340D G189 C8150ND LP550C SP C821DN CLP350D DOCUMENTATION HISTORY REV. NO. DATE COMMENTS 02/2009 Original Printing...

  • Page 13: Table Of Contents

    G188/G189 TABLE OF CONTENTS PRODUCT INFORMATION 1. PRODUCT INFORMATION............1-1 1.1 SPECIFICATIONS..................1-1 1.2 MACHINE CONFIGURATION ..............1-2 1.3 OVERVIEW ....................1-5 1.3.1 COMPONENT LAYOUT..............1-5 1.3.2 PAPER PATH..................1-6 1.3.3 DRIVE LAYOUT ................1-7 1.4 GUIDANCE FOR THOSE WHO ARE FAMILIAR WITH PREDECESSOR PRODUCTS .....................1-9 INSTALLATION 2.
  • Page 14 SD CARD APPLI MOVE ............2-66 Overview.....................2-66 Outline of SD Card Appli Move ............2-66 Move Exec ..................2-67 Undo Exec ..................2-67 PREVENTIVE MAINTENANCE 3. PREVENTIVE MAINTENANCE............ 3-1 3.1 MAINTENANCE ITEMS................3-1 REPLACEMENT AND ADJUSTMENT 4. REPLACEMENT AND ADJUSTMENT ........4-1 4.1 BEFOREHAND...................4-1 G188/G189...
  • Page 15 4.6.3 THIRD DUCT FAN ................4-25 When reinstalling the third duct fan.............4-26 4.6.4 TONER PUMP UNIT ...............4-26 When you install the new toner pump unit ..........4-29 4.6.5 TONER END SENSOR ..............4-31 4.7 IMAGE TRANSFER..................4-33 4.7.1 IMAGE TRANSFER BELT UNIT .............4-33 G188/G189...
  • Page 16 When re-installing the pressure roller ..........4-76 4.10.7 HEATING ROLLER THERMISTOR ...........4-77 4.10.8 PRESSURE ROLLER THERMOSTAT ........4-78 4.10.9 PRESSURE ROLLER THERMISTOR ........4-78 4.10.10 BEARING GEAR AND IDLE GEAR ........4-79 4.10.11 FUSING FAN................4-79 When installing the fusing fan .............4-80 4.10.12 PAPER EXIT FAN ..............4-80 G188/G189...
  • Page 17 When installing the new BCU ............4-107 4.13.6 PSU ..................4-108 PSU bracket..................4-108 PSU board ..................4-108 4.13.7 ITB POWER SUPPLY BOARD ..........4-109 4.13.8 HIGH VOLTAGE SUPPLY BOARD .........4-109 4.13.9 HIGH VOLTAGE SUPPLY BOARD BRACKET .......4-110 4.13.10 IH INVERTER...............4-110 4.13.11 CONTROLLER BOARD ............4-111 G188/G189...
  • Page 18 5.5.2 RETRIEVING THE DEBUG LOG FROM THE HDD......5-16 5.5.3 DEBUG LOG CODES ..............5-16 SP5857-015 Copy SD Card-to-SD Card: Any Desired Key ....5-16 SP5857-016 Create a File on HDD to Store a Log ......5-16 SP5857-017 Create a File on SD Card to Store a Log .......5-17 G188/G189...
  • Page 19 6.3.1 IMAGE PROBLEMS ................6-3 Stain on the outputs ................6-3 6.4 JAM DETECTION..................6-4 6.5 ELECTRICAL COMPONENT DEFECTS............6-5 G188/G189 APPENDICES SEE APPENDIX SECTION FOR DETAILED TABLE OF CONTENTS B793 BOOKLET FINISHER SR3000 SEE SECTION B793 FOR DETAILED TABLE OF CONTENTS B804/B805 BOOKLET FINISHER SR3020/SR3030...
  • Page 21 Read This First Important Safety Notices Prevention of Physical Injury Before disassembling or assembling parts of the printer and peripherals, make sure that the printer power cord is unplugged. The wall outlet should be near the printer and easily accessible. If any adjustment or operation check has to be made with exterior covers off or open while the main switch is turned on, keep hands away from electrified or mechanically driven components.
  • Page 22 recommended by the manufacturer. Do not recharge or burn the batteries. Used batteries must be handled in accordance with local regulations. Safety and Ecological Notes for Disposal Do not incinerate toner bottles or used toner. Toner dust may ignite suddenly when exposed to an open flame.
  • Page 23 Trademarks ® ® ® Microsoft , Windows , and MS-DOS are registered trademarks of Microsoft Corporation in the United States and /or other countries. ® PostScript is a registered trademark of Adobe Systems, Incorporated. ® is a registered trademark of Hewlett-Packard Company. ®...
  • Page 25 PRODUCT INFORMATION APPENDIX: SPECIFICATIONS INSTALLATION APPENDIX: PREVENTIVE MAINTENANCE PAPER FEED UNIT PB3040 D351 PAPER FEED UNIT PB3080 D387 PREVENTIVE MAINTENANCE APPENDIX: SERVICE CALL CONDITIONS LCIT PB3050 D352 REPLACEMENT AND ADJUSTMENT APPENDIX: PROCESS CONTROL ERROR CONDITIONS BOOKLET FINISHER SR3000 B793 BOOKLET FINISHER SR3020/SR3030 B804/B805 MAIL BIN TYPE C820 G835 SYSTEM MAINTENANCE REFERENCE APPENDIX: TROUBLESHOOTING GUIDE...

  • Page 27: Product Information

    PRODUCT INFORMATION...

  • Page 29: Specifications

    Specifications 1. PRODUCT INFORMATION 1.1 SPECIFICATIONS See "Appendices" for the following information: Mainframe Specifications Printer Specifications Supported Paper Sizes Software Accessories Optional Equipment G188/G189...

  • Page 30: Machine Configuration

    Machine Configuration 1.2 MACHINE CONFIGURATION Machine Call Item Remarks Code Mainframe G188/G189 Mail Bin G835 One from [C] and [D] D352-57/-67 One from the three and [D] + [E] Two-tray paper feed unit D351-57 Paper tray unit (one tray) D387-17 One from [F] and [G];...
  • Page 31 - Punch unit: 3/2 holes B807-17 Requires [G] - Punch unit: 4/2 holes B807-27 Requires [G] - Punch unit: 4 holes B807-30 Requires [G] Bridge unit D386 Machine Call Item Remark code USB 2.0: Standard USB Host Standard Ethernet: Standard G188/G189...
  • Page 32 (IEEE 802.11 g) Bluetooth B826 Gigabit Ethernet D377-21 Standard for G189 Hard Disk Drive M354-05 Option for G188 Data Overwrite Security Unit M354-21 NetWare printing M354-19 One from the five in SD slot 1 at a time. Data Storage Card...

  • Page 33: Overview

    4. Paper transfer roller 12. Image transfer belt cleaning unit 5. Registration roller 13. Image transfer belt unit 6. By-pass feed table 14. Toner bottle (4 colors) 7. Tray 2 15. ID sensor 8. Tray 1 16. IH coil unit G188/G189...

  • Page 34: Paper Path

    12. Finisher upper tray (Optional) 7. Tray 2 feed 13. Finisher proof tray (Optional) The 3000-sheet finisher and 1000-sheet booklet finisher require the bridge unit (D386) and one from the two-tray paper feed unit (D351) or the LCT (D352). G188/G189...

  • Page 35: Drive Layout

    Drives the color drum unit and development unit (K, Y, M, motor (K, Y, M, C) 6. Paper feed clutch Switches the drive power between the tray 1 and tray 2. Drives the paper feed mechanisms (tray 1/tray 2/by-pass 7. Paper feed motor: tray). G188/G189...
  • Page 36 Moves the paper transfer roller in contact with the image motor: transfer belt. 12. ITB drive motor: Drives the image transfer belt unit. Drives the duplex inverter rollers and duplex transport 13. Duplex inverter motor rollers. 14. Fusing/paper exit motor: Drives the fusing unit and paper exit section. G188/G189...

  • Page 37: Guidance For Those Who Are Familiar With Predecessor Products

    Guidance for Those Who are Familiar with Predecessor Products 1.4 GUIDANCE FOR THOSE WHO ARE FAMILIAR WITH PREDECESSOR PRODUCTS Machine G188/G189 is a successor model to Machine G133. If you have experience with the predecessor product, the following information will be of help when you read this manual.

  • Page 39: Installation

    INSTALLATION...

  • Page 41: Installation Requirements

    Install the machine on a strong, level base. (Inclination on any side must be no more than 5 mm.) Do not install the machine in areas that get strong vibrations. 2.1.2 MACHINE LEVEL Front to back: Within 5 mm (0.2") Right to left: Within 5 mm (0.2") G188/G189...

  • Page 42: Machine Space Requirements

    Ground the machine. Input voltage level: 120 V, 60 Hz: More than 12 A 220 V to 240 V, 50 Hz/60 Hz: More than 7 A Permissible voltage fluctuation: ±10 % Do not put things on the power cord. G188/G189...

  • Page 43: Optional Unit Combinations

    *: Child options (Child options require a parent option.) For details about installation procedures for the user installation options, see "Hardware Guide" of this model. 2.2.2 CONTROLLER OPTIONS U: User installation, C: CE installation Options Remarks Bluetooth One from the three (I/F Slot) G188/G189...
  • Page 44 Optional Unit Combinations IEEE802.11a/g, g IEEE 1284 Gigabit Ethernet Type B Gigabit Ethernet Slot Option only for G188 PictBridge Option Data Storage Card Type A One from the two (SD card slot 1) NetWare printing Type A Data Overwrite Security Unit...

  • Page 45: Printer Installation

    Printer Installation 2.3 PRINTER INSTALLATION 2.3.1 POWER SOCKET FOR PERIPHERAL Rating voltage for peripheral. Make sure to plug the cable into the correct socket. 2.3.2 INSTALLATION FLOW CHART This flow chart shows the best procedure for installation. G188/G189...
  • Page 46 You need the two-tray paper feed unit (D351-57) or the LCT (D352-57/-67) if you want to install the finisher (B793 or B805). The punch unit "B702" is for the 3000-sheet finisher (B805). The punch unit "B807" is for the 1000-sheet booklet finisher (B793). G188/G189...

  • Page 47: Installation Procedure

    Unpacking When lifting the machine, use the handle and grips on both sides of the machine. If not, the machine could be dropped. This may cause an injury and may damage the machine. Pull out the handle [A]. G188/G189...
  • Page 48 Lift the machine with four people by using the handle and grips on both sides of the machine. Do not remove the tapes before placing the machine. Lower the machine slowly and carefully, so as not to pinch your hands. Push back the handle into the machine. Remove the tape [B]. G188/G189...
  • Page 49 Push up the lever [C] on the right door, and then open the right door. Keep pushing the lever [D], and then remove the securing pin [E] by pulling the wire with the red tag. Close the right door. G188/G189...
  • Page 50 Open the drum positioning plate [H]. Remove and pull out the four tapes horizontally from all PCUs. Make sure that all tapes are removed. Close the drum positioning plate. Turn the green levers clockwise to lock the levers. G188/G189 2-10...

  • Page 51: Installing The Toner

    Printer Installation Installing the Toner Shake the toner bottle up and down five or six times before installing. Insert the each toner bottle into the machine with the label facing up. Close the front door. Loading Paper 2-11 G188/G189...
  • Page 52 Take out the contents from tray 1. Adjust the end plate [B] to A4 LEF/Letter LEF size. Load paper in tray 1, and then close tray 1. Attach the tray number decal "1" to the handle [C] of tray 1. G188/G189 2-12...

  • Page 53: Turning Power On

    Pull out the feeler [D] for the output-tray-full detection mechanism. Turning Power On Turn off the power switch whenever you plug in and unplug the power cord. Make sure that the power switch is set to " " (Off). Plug in the machine. 2-13 G188/G189...

  • Page 54: Selecting The Panel Display Language

    Press the "Enter" key. “Menu” shows on the panel display. Press the "Menu" key. “Ready” shows on the panel display. Printing the Test Page You can check if the printer works correctly by printing a test page such as the G188/G189 2-14...

  • Page 55: Settings Relevant To The Service Contract

    ID2: A01______23456789 = serial No. A0123456789) The following settings must be correctly programmed. Proxy server IP address (SP5816-063) Proxy server Port number (SP5816-064) Proxy User ID (SP5816-065) Proxy Password (SP5816-066) Get a Request Number Execute the @Remote Settings Enter the SP mode. 2-15 G188/G189...
  • Page 56 Center GUI. 10. Press "EXECUTE" key to execute the registration with SP5816-206. 11. Check the registration result with SP5816-207. Value Meaning Solution/ Workaround Succeeded Request number error Check the request number again. Already registered Check the registration status. G188/G189 2-16...
  • Page 57 Make sure that "Remote prohibited. The device has an Service" in User Tools is Embedded RC gate-related set to "Do not prohibit". problem. -12006 A confirmation request was made after the confirmation Execute registration. had been already completed. 2-17 G188/G189...
  • Page 58 -2394 Mainframe not managed Box ID for external RCG is -2395 illegal. Mainframe ID for external RCG -2396 is illegal. Check the ID2 of the -2397 Incorrect ID2 format mainframe. Incorrect request number -2398 Check the Request No. format G188/G189 2-18...

  • Page 59: Meter Click Charge

    The counter cannot be displayed or printed by the customer. To check the counter, the technician must print the SMC report (SP 5-990). You must select one of the counter methods (developments/prints) in accordance with the contract ( SP5-045-001). 2-19 G188/G189...
  • Page 60 If this SP is enabled, an alert "1": No alert Fusing Unit message is displayed when the fusing unit needs to be replaced. Specifies if the counting method Counter SP5-045-001 used in meter charge mode is “1”: Prints method based on developments or prints. G188/G189 2-20...

  • Page 61: Moving The Machine

    2) Then do the "Forced Line Position Adj. Mode a" (SP2-111-1). To check if SP 2-111-1 was successful, watch the screen during the process. A message is displayed at the end. Also, you can check the result with SP 2-194-10 to -12. 2-21 G188/G189...

  • Page 62: Bridge Unit (D386)

    Screw Knob screw Long Knob Screw Holder bracket Guide 2.4.2 INSTALLATION PROCEDURE Unplug the printer power cord before starting the following procedure. If you will install a finisher (B793 or B805) in the machine, install the finisher after G188/G189 2-22...
  • Page 63 (D386). Remove all tapes. If the sensor feeler [A] is out, fold it into the machine. Remove the connection cover [A] ( x 1). Remove the inner tray [A]. Remove the connector cover [B] ( x 1). 2-23 G188/G189...
  • Page 64 Holder bracket [A] is used in the installation procedure of the finisher (B793 or B805). At this time, do not install it yet. 13. Turn on the main power switch of the machine. 14. Check the bridge unit operation. G188/G189 2-24...

  • Page 65: 1000-Sheet Booklet Finisher (B793)

    Check the quantity and condition of the accessories against the following list. Description Q’ty Rear Joint Bracket Front Joint Bracket Grounding Plate Upper Output Tray Cushion Lower Output Tray Short Knob Screw Long Knob Screw Screw (M3 x 8) Screw (M4 x 14) 2-25 G188/G189...

  • Page 66: Installation Procedure

    Unplug the main machine power cord before starting the following procedure. The bridge unit (D386) and optional paper feed unit (D351 or D352) must be installed before installing this finisher (B793). Unpack the finisher and remove all tapes and packing materials from the finisher. G188/G189 2-26...
  • Page 67 Attach the cushions [C] to the finisher. Make sure that the cushions are placed within 0 to 1 mm [D] from the edge of the cover or frame. Install the ground plate [E] on the finisher ( x 2; M3 x 8). 2-27 G188/G189...
  • Page 68 [J] [K] go into their slots. 10. Push the lock lever [I], and then secure it (Long knob screw x 1). 11. Close the front door of the finisher. 12. Connect the finisher connector [L] to the machine. G188/G189 2-28...
  • Page 69 1000-Sheet Booklet Finisher (B793) 13. Install the upper output tray [M] (Short knob screw x 1). 14. Install the lower output tray [N]. 15. Turn on the main power switch of the machine. 16. Check the 1000-sheet booklet finisher operation. 2-29 G188/G189...

  • Page 70: Punch Unit (B807)

    Check the quantity and condition of the components against the following list. Description Q’ty Punch Unit Punch Drive Motor Hopper Full Sensor Arm Sub-scan Registration Sensor Unit Punch Unit Stay Sub-scan Registration Sensor Guide Hopper Screw Step Screw Spring G188/G189 2-30...

  • Page 71: Installation Procedure

    If the finisher is connected to the machine, disconnect it. Open the top cover [A] and then release the guide arm [B] ( x 1). Open the front door [C]. Pull the hook [D] up then remove the knob [E]. 2-31 G188/G189...
  • Page 72 Punch Unit (B807) Timing belt cover [F]. Rear cover of the 1000-sheet booklet finisher [G] ( x 2). Cover bracket [H] ( x 1) Remove the paper guide plate [I] from the rear side ( x 4). G188/G189 2-32...
  • Page 73 11. Remove the bracket [L] from the punch unit ( x 1). 12. Install the punch unit [M] along the punch unit stay from the rear side. 13. Make sure to put the punch unit stay pin [N] through the hole [O]. 2-33 G188/G189...
  • Page 74 18. Connect the home position sensor harness [U] (yellow connector) from the punch unit to the home position sensor [V]. 19. Install the sub-scan registration sensor unit [W] from the rear side ( x 2). 20. Route and connect the harnesses as shown ( x 2). G188/G189 2-34...
  • Page 75 25. Reinstall the rear cover ( x 2). 26. Close the front door and top cover. 27. Install the 1000-sheet booklet finisher on the mainframe. 28. Plug in and turn on the main power switch. 29. Check the 1000-sheet booklet finisher operation. 2-35 G188/G189...

  • Page 76: 3000-Sheet Finisher (B805)

    Rear joint bracket Front joint bracket Ground (earth) plate Tapping screws - M4 x14 Tapping screws - M3 x 8 Tapping screws - M3 x 6 Upper output tray Support Tray Cushion (with double-sided tape) Small ground (earth) plate G188/G189 2-36...

  • Page 77: Installation Procedure

    Unplug the main machine power cord before starting the following procedure. The bridge unit (D386) and optional paper feed unit (D351 or D352) must be installed before installing this finisher. Unpack the finisher and remove all tapes and packing materials from the finisher. 2-37 G188/G189...
  • Page 78 Make sure that the cushion is placed within 0 to 1 mm from the edge of the cover. Install the ground plate [C] to the finisher ( x 2; M3 x 6). Install the small ground plates [D] to the finisher ( x 2; M3 x 6 each). G188/G189 2-38...
  • Page 79 [E] [F] go into their slots. 11. Push the lock lever [H], and then secure it ( x 1). 12. Close the front door of the finisher. 13. Connect the finisher connector [I] to the machine. 2-39 G188/G189...

  • Page 80: Support Tray Installation

    If a stack problem occurs several times on the upper output tray [A], put the support tray [B] on the tray as shown. Keep this tray in the manual pocket if this tray does not need to be installed. G188/G189 2-40...

  • Page 81: Punch Unit (B702)

    Check the quantity and condition of the components against the following list. Description Q’ty Punchout Waste Unit Slide Drive Unit Punch Waste Hopper Screws (M3 x 6) Side-to-Side Detection Unit Punching Unit 2.8.2 INSTALLATION PROCEDURE Unplug the main machine power cord before starting the following 2-41 G188/G189...
  • Page 82 Move the punch unit [D] along its rails into the finisher. Make sure that the pin engages correctly at the front and rear. Connect the cables [E] of the finisher to the connectors (CN601 and CN602) on the G188/G189 2-42...
  • Page 83 10. Attach the side-to-side detection unit and connect it at the rear ( x 2, x 1, 11. Pull the short connector out of the connector [H] then connect the cable of the finisher x 1). 2-43 G188/G189...
  • Page 84 17. Set the hopper [L] in its holder. 18. Reassemble the finisher, and then install it on the main machine. 19. Connect the power cord to the outlet, and then turn the main power switch on. 20. Check the punch unit operation. G188/G189 2-44...

  • Page 85: Output Jogger Unit (B703)

    1. Jogger Unit 2. Tapping Screws M3x6 2.9.2 INSTALLATION The Output Jogger Unit B703 is installed only on the 3000-Sheet Finisher (B805). Always switch the machine off and unplug the machine before doing any of the following procedures 2-45 G188/G189...
  • Page 86 [A] into the holes in the left and right side of the finisher frame. Connect connector [B] to the socket ( x 1). Attach the jogger unit [C] to the finisher ( x 2). Reattach the jogger unit cover [D] to the jogger unit ( x 2). G188/G189 2-46...

  • Page 87: Mail Bin (G835)

    Check the quantity and condition of the components against the following list. Description Q’ty Tray Rear Hold Bracket Front Hold Bracket Mail Bin Right Stay Guide Bracket Mail Bin Solenoid Harness Clamp (Not used) Screw: M3x8 Screw: M4x10 Screw: M3x6 Step Screw Decal Sheet 2-47 G188/G189...

  • Page 88: Installation Procedure

    Mail Bin (G835) 2.10.2 INSTALLATION PROCEDURE Open the right door. Remove the following: Connection cover [A] ( x 1) Operation panel [B] ( x 1, x 1) G188/G189 2-48...
  • Page 89 Remove the following: Screw caps [A] Top right cover [B] ( x 2) Top rear cover [C] ( x 2) Remove the paper exit cover [A] ( x 1). Remove the top right stay [B] ( x 3). 2-49 G188/G189...
  • Page 90 Connect the harness [B] and then clamp the harness with the four clamps. Reinstall the top right stay [A] ( x 3). Install the guide plate [B] ( x 2: M3x6). 10. Install the two step screws [C]. G188/G189 2-50...
  • Page 91 The front cover is connected to the mail bin unit with the harnesses. It is not necessary to disconnect the harnesses from the front cover. However, take care not to break or disconnect the harnesses during this installation procedure. 14. Install the mail bin unit [A] on the printer as shown above. 2-51 G188/G189...
  • Page 92 16. Release the harness [A] from the printer ( x 5). 17. Connect the harness [A] to the main board of the mail box unit ( x 1). 18. Reinstall the top rear cover ( x 2) 19. Install the right stay [A] ( x 1). G188/G189 2-52...
  • Page 93 1 each). 22. Close the right door. 23. Install the tray [A] in each bin of the mail bin unit [B]. 24. Plug in and turn on the printer. 25. Check the operation of the mail bin unit. 2-53 G188/G189...

  • Page 94: Tray Heater (Standard Tray)

    Connect the connector [B] of the heater to the connector of the main machine. Install the heater [C] inside the machine ( x 1) Reassemble the machine. Attach the on/standby decal [D] to the right-hand side of the main power switch. G188/G189 2-54...

  • Page 95: Tray Heater (Optional Tray)

    Description Q’ty Tray heater 1 (-90) or On-standby decal 2 (-91) Harness 2 (For D387) Harness 1 (For D351/D352) Screw M4 x 10 Installation procedure 2.12.2 INSTALLATION PROCEDURE Unplug the machine power cord before starting the following procedure. 2-55 G188/G189...

  • Page 96: For Installing The Tray Heater In The D351 (Two-Tray Paper Feed Unit)

    Install the tray heater [A] in the optional paper feed unit ( x 1). Remove the two securing brackets [B] ( x 1 each), and then the rear cover [C] of the optional paper feed unit ( x 2). Remove the harness cover bracket [D] ( x 1). G188/G189 2-56...
  • Page 97 Connect the harness [H] to the connector [I] of the tray heater. Route the harness [H] as shown and clamp it with four clamps ( x 4). 10. Connect the harness [H] to the connector [J] of the mainframe. 11. Reassemble the mainframe and optional paper feed unit. 2-57 G188/G189...

  • Page 98: For Installing The Tray Heater In The D352 (Lct)

    Pull out the LCT drawer. If the right tray comes out with the left tray, push the right tray into the LCT. Left tray [A] ( x 2) Remove the right tray [B] while pressing down the stopper [C]. G188/G189 2-58...
  • Page 99 Install the tray heater [D] in the optional LCT ( x 1). Remove the two securing brackets [E] ( x 1 each), and then the rear cover [F] of the optional LCT ( x 2). Remove the harness cover bracket [G] ( x 1). 2-59 G188/G189...
  • Page 100 10. Connect the harness [K] to the connector [L] of the tray heater. 11. Route the harness [K] as shown and clamp it with four clamps ( x 4). 12. Connect the harness [K] to the connector [M] of the mainframe. 13. Reassemble the mainframe and optional LCT. G188/G189 2-60...

  • Page 101: For Installing The Tray Heater In The D387 (Paper Tray Unit)

    For installing the tray heater in the D387 (Paper tray unit) Remove the rear cover of the mainframe ( x 6). Pull out the tray from the optional paper tray. Install the tray heater [A] in the optional paper tray ( x 1). 2-61 G188/G189...
  • Page 102 10. Connect one harness [K] of the two-way harness to the connector [L] of the mainframe. Connect [K] to the connector on the mainframe. The harness of connector [K] has two binders. The harness of the other connector [M] has one binder, and this is for another optional paper feed unit. G188/G189 2-62...
  • Page 103 14. Pass the harness from the lower paper feed unit through the hole [Q], and then connect it to the harness [R]. Make sure that the harness is clamped, with the bind [S] placed at the right hand side of the clamp [T]. 2-63 G188/G189...
  • Page 104 Tray Heater (Optional Tray) 15. Reassemble the mainframe and optional paper tray. 16. Attach the on/standby decal [U] to the right-hand side of the main power switch. G188/G189 2-64...

  • Page 105: Controller Options

    Slot 1 is used for one of the optional applications: Data Overwrite Security Unit, NetWare, PictBridge, Data Storage Card. Slot 2 is used for installing the VM card, HDD Encryption Unit, or for service only (for example, updating the firmware). 2-65 G188/G189...

  • Page 106: Sd Card Appli Move

    The data necessary for authentication is transferred with the application program from an SD card to another SD card. Authentication fails if you try to use the SD card after you copy the application program from one card to another card. G188/G189 2-66...

  • Page 107: Move Exec

    Do not turn ON the write protect switch of an application SD card on the machine. If the write protect switch is ON, a download error (e.g. Error Code 44) occurs during a firmware upgrade or application merge. 2-67 G188/G189...
  • Page 108 Remove the SD card from SD card slot 2. This step assumes that the application programs in the SD card are used by the machine. 10. Turn the main switch on. 11. Check that the application programs run normally. G188/G189 2-68...

  • Page 109: Preventive Maintenance

    PREVENTIVE MAINTENANCE...

  • Page 111: Maintenance Items

    Maintenance Items 3. PREVENTIVE MAINTENANCE 3.1 MAINTENANCE ITEMS See "Appendices" for the following information: User Maintenance Items Service Maintenance Items G188/G189...

  • Page 113: Replacement And Adjustment

    REPLACEMENT AND ADJUSTMENT...

  • Page 115: Beforehand

    4.1 BEFOREHAND Before installing options, please do the following: If there are printer jobs in the machine, print out all jobs in the printer buffer. Turn off the main switch and disconnect the power cord and the network cable. G188/G189...

  • Page 116: Special Tools

    PCMCIA Card Adapter B645 6830 USB Reader/Writer VSSM9000 Digital Multimeter – FLUKE87 C401 9503 20X Magnification Scope A257 9300 Grease Barrierta – S552R 5203 9502 Silicone Grease G-501 B679 5100 Plug - IEEE1284 Type C B132 9700 Lubricant Powder G188/G189...

  • Page 117: Image Adjustment

    The registration in both main- and sub-scan directions can change within the following tolerance. Sub-scan direction: 0 ± 9 mm Main-scan direction: 0.5 ± 4 mm Adjustment Procedure Enter SP2-109-003. Select the test pattern (14: 1-dot trimming pattern) with SP2-109-003. G188/G189...

  • Page 118: Erase Margin Adjustment

    Adjust the erase margin C and D only if the registration (main scan and sub scan) cannot be adjusted within the standard values. Do the registration adjustment after adjusting the erase margin C and D, and then adjust the erase margin A and B. G188/G189...

  • Page 119: Color Registration

    1) First do SP2-111-3. 2) Then do SP2-111-1. To check if SP 2-111-1 was successful, watch the screen during the process. A message is displayed at the end. Also, you can check the result with SP 2-194-10 to -12. G188/G189...

  • Page 120: Gamma Adjustment

    Adjust the CMY gradation scale at the top of the chart by balancing the density of the C, M, and Y gradation scales – the CMY gray scale should change smoothly from minimum to maximum. There should be no coloration. Examine this color adjustment sheet: G188/G189...

  • Page 121: Adjustment Procedure

    The NVRAM holds three sets of controller gamma settings: Those saved this time: Controller SP1-101 "ToneCtlSet" - "Tone (Current)" Those saved in the previous adjustment: Controller SP1-101 "ToneCtlSet - Tone (Prev)" The factory settings: Controller SP1-101 "ToneCtlSet - "Tone (Factory)". Adjustment Procedure Enter the controller service mode. G188/G189...
  • Page 122 Set Black 15 Default Value 240 Set Cyan 1 ∼ 15 See Set Black 1 ∼ 15 Set Magenta 1 ∼ 15 See Set Black 1 ∼ 15 Set Yellow 1 ∼ 15 See Set Black 1 ∼ 15 G188/G189...
  • Page 123 12. Use Controller SP1-105 “ToneCtlSave” in the controller service menu, to store the new settings in the controller. 13. Reset the controller (press the [Reset] key when the machine is off line”) to use the new settings. You must reset the controller to keep the new settings in the controller NVRAM. G188/G189...

  • Page 124: Exterior Covers

    Exterior Covers 4.4 EXTERIOR COVERS 4.4.1 FRONT DOOR Open the front door [A]. Remove the two pins [B], and then remove the front cover. G188/G189 4-10...

  • Page 125: Left Cover

    Exterior Covers 4.4.2 LEFT COVER Left cover [A] ( x 6) 4.4.3 REAR COVER Rear cover [A] ( x 6) 4-11 G188/G189...

  • Page 126: Top Right And Rear Cover

    Remove the screw caps [A]. Top right cover [B] ( x 2) Top rear cover [C] ( x 2) 4.4.5 RIGHT REAR COVER Rear cover [A] ( x 6) Open the right door [B]. Right rear cover [C] ( x 4) G188/G189 4-12...

  • Page 127: Operation Panel

    Paper exit cover [A] ( x 1) 4.4.8 OUTPUT TRAY Top right cover and top rear cover( Section: Top Right and Rear Cover 4-12) Operation panel cover ( Section: Operation Panel 4-13) Left cover ( Section: Left Cover 4-11) 4-13 G188/G189...

  • Page 128: Ozone Filter

    2) 10. Output tray [E] 4.4.9 OZONE FILTER Ozone filter for charge unit Top right cover ( Section: Top Right and Rear Cover 4-12) Top rear cover ( Section: Top Right and Rear Cover 4-12) Ozone filter [A] G188/G189 4-14...

  • Page 129: Ozone Filter For Ih Inverter

    Exterior Covers Ozone filter for IH inverter IH inverter fan cover [A] (hook) Filter [B] Ozone filter [C] 4-15 G188/G189...

  • Page 130: Laser Optics

    (the correct time is stated in the manual). This bracket protects a capacitor on the unit. If the bracket is removed too early, you could break the capacitor on the corner of the main frame when you install the new unit. G188/G189 4-16...

  • Page 131: Preparing The New Laser Optics Housing Unit

    Turn off the main power switch and disconnect the power cord of the copier. Remove the left cover and harness cover bracket (see the following "Removing the old laser optics housing unit") 4-17 G188/G189...

  • Page 132: Removing The Old Laser Optics Housing Unit

    Do steps 1 to 7 of "Before removing the old laser optics housing unit". Connect the harness [A] and reinstall the harness bracket and left cover. Plug in and turn on the main power switch. Removing the old laser optics housing unit Left cover [A] ( x 6) G188/G189 4-18...

  • Page 133: Installing A New Laser Optics Housing Unit

    Push the new laser optics housing unit [A] slowly into the copier until the bracket [B] bumps against the frame of the copier. Remove the bracket [B], and then push the new laser optics housing unit fully into the copier ( x 2, All x 3). Reassemble the machine. 4-19 G188/G189...

  • Page 134: After Installing The New Laser Optics Housing Unit

    The value [B] is different for each laser optics housing unit. Print the test pattern (14: 1-dot trimming pattern in the SP2-109-003). Check that the left trim margin is within 2 ± 1 mm. If not, change the registration G188/G189 4-20...

  • Page 135: Polygon Mirror Motor And Drive Board

    After you replace the housing unit, do the adjustments in the following section of the manual: Image Adjustment – Registration. 4.5.3 POLYGON MIRROR MOTOR AND DRIVE BOARD Laser optics housing unit [A] ( Section: Laser Optics Housing Unit4-16) Polygon mirror motor cover [A] of the laser optics housing unit ( x 4) 4-21 G188/G189...
  • Page 136 To check if SP 2-111-1 was successful, watch the screen during the process. A message is displayed at the end. Also, you can check the result with SP 2-194-10 to -12. After you replace the motor, do the adjustments in the following section of the manual: Image Adjustment – Registration. G188/G189 4-22...

  • Page 137: Image Creation

    Open the front door. Turn the drum positioning plate lever [A] and the image transfer unit lock lever [B] counter-clockwise. Open the drum positioning plate [C]. Pull out the PCU (hold the grip while you pull it out) [A]. 4-23 G188/G189...

  • Page 138: Second Duct Fan

    Top rear cover ( Section: Top Right and Rear Cover 4-12) Open the controller box ( Section: Controller Box 4-104) Second duct [A] ( x 2, x 1, x 3) Split the second duct (2 hooks). Second duct fan [A] G188/G189 4-24...

  • Page 139: When Reinstalling The Second Duct Fan

    Top rear cover ( Section: Top Right and Rear Cover 4-12) Open the controller box ( Section: Controller Box 4-104). PSU bracket ( Section: PSU) Third duct fan cover [A] ( x 1, x 1, hook x 3) Third duct fan [A] (hook x 1) 4-25 G188/G189...

  • Page 140: When Reinstalling The Third Duct Fan

    Put some sheets of paper on the floor before doing this procedure. Toner may fall on the floor. Front door ( Section: Front Door 4-10) Image transfer belt unit ( Section: Image Transfer Belt Unit 4-33) All PCUs ( Section: PCU 4-23) G188/G189 4-26...
  • Page 141 Release the harness [A] from the clamp ( x 1 for YCM, x 2 for K) and hook, and then disconnect the harness. Avoid touching these spring terminals [B]. Release the toner supply tube [C]. Remove the toner pump unit [A] ( x 2) 4-27 G188/G189...
  • Page 142 Slowly remove the toner supply tube [A] from the toner pump unit by pulling the tube right and left. Turn up the openings of the toner pump unit and toner supply tube just after removing the tube. If not, the toner may scatter and fall. G188/G189 4-28...

  • Page 143: When You Install The New Toner Pump Unit

    11. Keep the opening [A] of the toner supply tube up, and then clip the opening of the toner supply. When you install the new toner pump unit Before installing the new toner pump unit, mask the opening of the old toner pump unit with tape. Dispose of it following local rules. 4-29 G188/G189...
  • Page 144 Connect the harness [A] to the connector of the machine. On the above picture, the magnified picture of the connector shows the easiest way to connect it. Clamp the harness [A] ( x 1 for YCM, x 3 for K). G188/G189 4-30...

  • Page 145: Toner End Sensor

    Be careful when you lift the edge of the holder, because the holder is easily broken. Insert the toner pump unit [A] into the rear frame of the machine ( x 2). 4.6.5 TONER END SENSOR Rear cover ( Section: Rear Cover 4-11) Open the controller box ( Section: Controller Box 4-104) 4-31 G188/G189...
  • Page 146 Image Creation Toner end sensor [A] ( x 1, 2 hooks each) G188/G189 4-32...

  • Page 147: Image Transfer

    Pull out the image transfer belt unit [B] halfway. Grasp the handles [A], and then pull out the image transfer belt unit fully. 4.7.2 IMAGE TRANSFER BELT CLEANING UNIT If you will install a new belt cleaning unit, then set SP 3902-015 to 1. 4-33 G188/G189...

  • Page 148: Image Transfer Belt

    4.7.3 IMAGE TRANSFER BELT Image transfer belt cleaning unit ( Section: Image Transfer Belt Cleaning Unit 4-33) Image transfer belt unit ( Section: Image Transfer Belt Unit 4-33) Turn the image transfer unit contact lever counterclockwise (as seen from the rear). G188/G189 4-34...
  • Page 149 Image Transfer Gear [A] (hook x 1) Turn the gear cover [B] clockwise (as seen from the rear) ( x 1). Remove the top covers [A] ( x 6). Three stays [A] ( x 6) 4-35 G188/G189...
  • Page 150 Guide plate [A] (as seen from the right side of the machine) ( x 2) Remove the two screws and then the rear holder bracket [A] (as seen from the rear). 10. Remove the two screws and then the front holder bracket [A] (as seen from the front). G188/G189 4-36...

  • Page 151: When Reinstalling The Image Transfer Belt

    11. Put the front side of the image transfer belt unit on a corner of the table or a box as shown. 12. Pull the tension roller [A] as shown. 13. Image transfer belt [A] When reinstalling the image transfer belt Clean all rollers with dry cloth before installing the image transfer belt. 4-37 G188/G189...
  • Page 152 This belt must be installed the correct way around. When you reinstall the image transfer belt unit, install it with the number [A] on the belt at the rear side of the unit. Put "Lubricant Powder" (B132 9700) on the surface of the image transfer belt [A], while G188/G189 4-38...
  • Page 153 Lubricant powder prevents the image transfer cleaning blade from turning up. Do not put the lubricant powder at the right side of the image transfer belt unit (the above picture is taken from the rear). Otherwise, lubricant powder may damage the encoder sensor. 4-39 G188/G189...

  • Page 154: Paper Transfer

    If you do this, then the machine will reset the PM counter for the paper transfer unit automatically, after you turn the power on again. Open the right door. Release the white hook. Paper transfer roller unit [A] 4.8.2 PAPER TRANSFER UNIT Turn off the main power switch. Open the duplex door [A]. G188/G189 4-40...

  • Page 155: High Voltage Supply Board - Discharge Plate

    Section: Paper Transfer Roller Unit4-40) Right door inner cover [A] ( x 1) Pivot bracket [A] ( x 1) Paper transfer unit [B] ( x 1, 2 springs) 4.8.3 HIGH VOLTAGE SUPPLY BOARD – DISCHARGE PLATE Open the right door. 4-41 G188/G189...

  • Page 156: Id Sensor Board

    1, ground cable x 1) 4.8.4 ID SENSOR BOARD K PCU ( Section: PCU 4-23) Open the right door. Fusing unit ( Section: Fusing Unit 4-66) Image transfer belt unit ( Section: Image Transfer Belt Unit 4-33) G188/G189 4-42...

  • Page 157: Cleaning For Id Sensors

    ID sensor board [A] ( x 6) Cleaning for ID sensors ID sensors must be cleaned when you visit the customer to service the machine. Do the following steps for ID sensor cleaning. K PCU ( Section: PCU4-23) 4-43 G188/G189...

  • Page 158: After Installing A New Id Sensor Unit/Board

    For example, input "1.00" with SP3-362-013. Exit the SP mode. 4.8.5 TEMPERATURE AND HUMIDITY SENSOR Rear cover ( Section: Rear Cover 4-11) Right rear cover ( Section: Top Right and Rear Cover4-12) Temperature and humidity sensor [A] ( x 1, x 1) G188/G189 4-44...

  • Page 159: Drive Unit

    There are some motors and clutches that are not shown in the above drawing: Tray lift motor 1 and 2 Junction gate 1 motor Duplex inverter motor Shutter motor Duplex/By-pass Motor By-pass clutch 4.9.1 GEAR UNIT All PCU's Image transfer belt unit. 4-45 G188/G189...
  • Page 160 Third duct ( Section: Third Duct Fan4-25) Left cover ( Section: Left Cover4-11) PSU bracket ( Section: PSU Bracket4-108) Remove the rear stay [A] ( x 3). Remove ten clamps (blue arrows). 10. Release seven clamps and turn each harness aside. G188/G189 4-46...
  • Page 161 12. Disconnect two connectors (red arrows) and put these harnesses inside the machine. 13. Disconnect each connector (red circles) from the drum/development drive motors ( x 1, x 1 each). 14. Disconnect each connector (blue circles) from the development clutches ( each). 4-47 G188/G189...
  • Page 162 Drive Unit 15. Cover [A] ( x 2) 16. Disconnect eight connectors from the high voltage supply board ( x 8, x 2). 17. Release four clamps (red circles) and turn the harnesses aside. G188/G189 4-48...
  • Page 163 Drive Unit 18. Disconnect five connectors (red circles) ( x 5). 19. Toner transport motor [A] ( x 3) 20. Pulley [A] (timing belt) 21. Gear unit [A] ( x 8) 4-49 G188/G189...

  • Page 164: When Installing The Drive Unit

    Check that the gear unit is installed correctly. Exit the SP mode. 4.9.2 REGISTRATION MOTOR Rear cover ( Section: Rear Cover4-11) Right rear cover ( Section: Right Rear Cover4-12) Ventilation duct ( Section: PSU4-108) Turn the harnesses aside ( x 5) G188/G189 4-50...

  • Page 165: Paper Feed Motor

    Registration motor assembly [B] ( x 3, x 1) Registration motor [C] ( x 2, timing belt) 4.9.3 PAPER FEED MOTOR Rear cover ( Section: Rear Cover4-11) Right rear cover ( Section: Right Rear Cover4-12) Release the two clamps ( x 2) 4-51 G188/G189...

  • Page 166: Drum/Development Motors For M, C, And Y

    PSU bracket ( Section: PSU) Open the controller box. Drum/Development motors (three motors, one each for MCY) [A] ( x 4, each) 4.9.5 DRUM/DEVELOPMENT MOTOR-K Rear cover ( Section: Rear Cover4-11) PSU bracket ( Section: PSU) Controller box ( Section:Controller Box4-104) G188/G189 4-52...

  • Page 167: Itb Drive Motor

    4.9.6 ITB DRIVE MOTOR Rear cover ( Section: Rear Cover4-11) Controller box ( Section: Controller Box4-104) ITB drive motor [A] ( x 4, x 1) 4.9.7 FUSING/PAPER EXIT MOTOR Rear cover ( Section: Rear Cover4-11) Controller box ( Section: Controller Box4-104) 4-53 G188/G189...

  • Page 168: Image Transfer Belt Contact Motor

    Rear cover ( Section: Rear Cover4-11) Controller box ( Section: Controller Box) Transfer belt contact motor [A] ( x 2, x 2, x 1) 4.9.9 DUPLEX INVERTER MOTOR Open the right door. Right door cover ( Section: By-pass Bottom Tray) G188/G189 4-54...
  • Page 169 Duplex inverter motor bracket cover [A] ( x 2, x 2) Duplex inverter motor bracket [A] ( x 3, x 1, x 2, spring x 1) Gear [A] ( x 1, belt x 1) Duplex inverter motor [B] ( x 4) 4-55 G188/G189...

  • Page 170: Pressure Roller Contact Motor

    Pressure roller contact motor [A] ( x 4) 4.9.11 DUPLEX/BY-PASS MOTOR Rear cover ( Section: Rear Cover4-11) Right rear cover ( Section: Right Rear Cover4-12) Open the controller box ( Section: Controller Box4-104). Pressure roller contact motor ( Section: Pressure Roller Contact Motor4-56) G188/G189 4-56...
  • Page 171 Drive Unit Disconnect the connector [A] ( x 1, x 1) Duplex/by-pass motor bracket [A] ( x 2) Duplex/by-pass motor [A] ( x 4, belt x 1) 4-57 G188/G189...

  • Page 172: Paper Transfer Contact Motor

    Open the controller box ( Section: Controller Box4-104). Stay [A] ( x 4) Pressure roller contact motor ( Section: Pressure Roller Contact Motor4-56) Duplex/by-pass motor bracket ( Section: Duplex/by-pass Motor) Disconnect the connector [A] ( x 1) Paper transfer contact motor [A] ( x 2) G188/G189 4-58...

  • Page 173: Toner Transport Motor

    Toner transport motor [A] ( x 3, x 1) 4.9.14 TONER COLLECTION UNIT Remove all PCUs ( Section: PCU). Image transfer belt unit ( Section: Image Transfer Belt Unit) Rear cover ( Section: Rear Cover) Controller box ( Section: Controller Box) 4-59 G188/G189...

  • Page 174: Paper Feed Clutches

    High voltage power supply board bracket ( Section: High Voltage Supply Board Bracket4-110) Gear unit ( Section: Gear Unit 4-45) 10. Toner collection unit [A] ( x 6, x 1) 4.9.15 PAPER FEED CLUTCHES Rear cover ( Section: Rear Cover4-11) PSU bracket ( Section: PSU) G188/G189 4-60...
  • Page 175 Drive Unit Release five clamps, and then turn the harness [A] aside. Paper feed clutch 1 bracket [A] ( x 2, x 1, x 1) 4-61 G188/G189...
  • Page 176 Drive Unit Paper feed clutch 1 [A] Paper feed clutch 2 bracket [A] ( x 2, x 1, x 1) Paper feed clutch 2 [A] G188/G189 4-62...

  • Page 177: Development Clutch-Y

    Rear cover ( Section: Rear Cover4-11) PSU bracket ( Section: PSU) Open the controller box. ( Section: Controller Box4-104). Drum/development motor-Y ( Section: Drum/Development Motors for M,C, and Y4-52) Disconnect the connector [A] ( x 1). Remove the pulley and bushing [A]. 4-63 G188/G189...

  • Page 178: Development Clutches For M And C

    Drum/development motors for M and C ( Section: Drum/Development Motors for M,C, and Y) Disconnect the connector for each development clutch ( x 1). Turn the development clutch unit [A] counter-clockwise and then pull it out ( x 1). Development clutches for M and C [B] ( x 1) G188/G189 4-64...

  • Page 179: Development Clutch-K

    PSU bracket ( Section: PSU) Controller box. ( Section: Controller Box) Drum/development motor-K ( Section: Drum/Development Motor-K) Turn the development clutch unit [A] counter-clockwise and then pull it out ( x 1). Development clutch-K [A] ( x 1) 4-65 G188/G189...

  • Page 180: Fusing

    Turn off the main switch and wait until the fusing unit cools down before beginning any of the procedures in this section. The fusing unit can cause serious burns. Open the right door. Stoppers [A] (knob screw x 1 each). Release the lock levers [A]. Pull out the fusing unit [B]. G188/G189 4-66...

  • Page 181: Heating Roller And Heating Roller Bearing

    Fusing 4.10.2 HEATING ROLLER AND HEATING ROLLER BEARING Fusing unit ( Section: Fusing Unit) Front and rear fusing covers [A] ( x 2 each; Stepped screws) Fusing right cover [A] ( x 2; Stepped screws) 4-67 G188/G189...
  • Page 182 Turn both pressure levers [A] [B], and pull out pins [C] [D]. If the pins [C] [D] are not pulled out in this step, the fusing unit frames may become bent. Front bracket [A] ( x 4) Rear bracket [B] ( x 4) G188/G189 4-68...
  • Page 183 Fusing Top stay [A] ( x 5) Stripper plate [A] (two springs) 10. Heating roller bearing [A] at the front side (c-ring x 1) 4-69 G188/G189...
  • Page 184 12. Heating roller bearing [A] at the rear side 13. Heating roller [A] The surface of the heating roller is fragile, so the heating roller must be covered with a sheet of paper when it is placed on a table or floor. G188/G189 4-70...

  • Page 185: When Re-Installing The Heating Roller

    Do not wipe off the grease of the new idle gear when replacing the idle gear [A]. (The actual idle gear [A] is white.) 4.10.3 FUSING CLEANING FELT Fusing unit ( Section: Fusing Unit) Heating roller ( Section: Heating Roller and Heating Roller Bearing) 4-71 G188/G189...

  • Page 186: When Attaching A New Fusing Cleaning Felt

    Otherwise, dust from the IH coil unit may fall on the paper in the fusing unit and the output becomes dirty. 4.10.4 FUSING LAMP Fusing unit ( Section: Fusing Unit) Front bracket ( Section: Heating Roller and Heating Roller Bearing) Rear bracket ( Section: Heating Roller and Heating Roller Bearing) G188/G189 4-72...
  • Page 187 Rear terminal of the fusing lamp ( x 1, x 3) Fusing lamp rear bracket [A] ( x 1) Fusing lamp [A] Remove the fusing lamp without touching the glass part [B]. Pay attention to the direction of the fusing lamp during the re-installation. 4-73 G188/G189...

  • Page 188: Fusing Drive Gear

    Fusing drive gear [A] (c-ring x 1) 4.10.6 PRESSURE ROLLER AND PRESSURE ROLLER BEARING Heating roller ( Section: Heating Roller and Heating Roller Bearing) Fusing lamp ( Section: Fusing Lamp) Pressure roller gear [A] at the rear side (c-ring x 1) G188/G189 4-74...
  • Page 189 Fusing Pressure roller bearing [A] at the rear side Front terminal [A] ( x 1) Lamp holder front bracket [A] ( x 1) Pressure roller bracket [B] at the front side ( x 2, binding screw x 1) 4-75 G188/G189...

  • Page 190: When Re-Installing The Pressure Roller

    [A], and to the rear shaft of the pressure roller at 2 mm from the edge [B]. (Apply the lubricant to half of the circumference of the pressure roller, as shown in the lower of the three above diagrams.) G188/G189 4-76...

  • Page 191: Heating Roller Thermistor

    4.10.7 HEATING ROLLER THERMISTOR Fusing unit ( Section: Fusing Unit) Fusing right cover ( Section: Heating Roller and Heating Roller Bearing) Fusing bottom cover [A] ( x 5) Heating roller thermistor with bracket [A] ( x 1, x 1) 4-77 G188/G189...

  • Page 192: Pressure Roller Thermostat

    Pressure roller thermostats [A] ( x 4) 4.10.9 PRESSURE ROLLER THERMISTOR Fusing unit ( Section: Fusing Unit) Fusing right cover ( Section: Heating Roller and Heating Roller Bearing) Fusing bottom cover ( Section: Heating Roller Thermistor) G188/G189 4-78...

  • Page 193: Bearing Gear And Idle Gear

    Rear bracket ( Section: Heating Roller and Heating Roller Bearing) Fusing lamp rear bracket ( Section: Fusing Lamp) Bearing gear [A] (c-ring x 1) and idle gear [B] 4.10.11 FUSING FAN Rear cover ( Section: Rear Cover) Right rear cover ( Section: Right Rear Cover) 4-79 G188/G189...

  • Page 194: When Installing The Fusing Fan

    Make sure that the fusing fan is installed with its decal facing the right side of the machine. 4.10.12 PAPER EXIT FAN Open the right door. Operation panel cover ( Section: Operation Panel) Paper exit fan [A] ( x 1, x 1, hook x 2) G188/G189 4-80...

  • Page 195: When Installing The Paper Exit Fan

    Make sure that the IH inverter fan is installed with its decal facing the upper side of the machine. 4.10.14 THERMOPILE Open the right door. Operation panel ( Section: Operation Panel) Pull out trays 1 and 2. Image transfer belt unit ( Section: Image Transfer Belt Unit) 4-81 G188/G189...
  • Page 196 Right front cover [A] and front inner cover [B] Bracket [A] ( Fusing unit ( Section: Fusing Unit) Paper exit unit ( Section: Paper Exit Unit) Thermopile bracket [A] ( x 2, x 1, x 2) 10. Thermopile ( x 2) G188/G189 4-82...

  • Page 197: When Cleaning The Lens Of The Thermopile

    In that case, the IH coil unit must be replaced. Fusing unit ( Section: Fusing Unit) Push the cotton swab [A] into the special cleaning tool [B] until it clicks. This special cleaning tool is provided with the fusing maintenance kit. 4-83 G188/G189...

  • Page 198: Pressure Roller Hp Sensor

    Rotate the special cleaning tool [A] 10 times while pushing in to clean the lens inside of the printer. 4.10.15 PRESSURE ROLLER HP SENSOR Rear cover ( Section: Rear Cover) Open the controller box ( Section: Controller Box) Pressure roller HP sensor bracket [A] ( x 1, x 1) G188/G189 4-84...

  • Page 199: Ih Coil Fan

    HP sensor bracket. 4.10.16 IH COIL FAN Open the right door. Operation panel cover ( Section: Operation Panel) Pull out trays 1 and 2, and the image transfer belt unit. Right front cover and front inner cover ( Section: Thermopile) 4-85 G188/G189...

  • Page 200: Ih Coil Unit

    Fusing unit ( Section: Fusing Unit) Rear cover ( Section: Rear Cover) Right rear cover ( Section: Right Rear Cover) Open the controller box ( Section: Controller Box). Fusing duct ( Section: Fusing Fan) IH inverter ( Section: IH Inverter) G188/G189 4-86...
  • Page 201 Fusing IH inverter bracket [A] ( x 3) Ground cable [B] ( x 1, x 1) Disconnect the connector [A]. 10. Pull the Harness [A] in the arrow direction. 4-87 G188/G189...
  • Page 202 Fusing 11. Bracket [A] ( x 1) 12. IH coil unit [A] (First, release the front side of the IH coil unit.) G188/G189 4-88...

  • Page 203: Paper Feed

    Rear cover ( Section: Rear Cover) Right rear cover ( Section: Right Rear Cover) Duplex unit ( Section: Duplex Unit) Pull out tray 1 and tray 2. Paper guide plate [A] (hook x 2) Harness cover [A] ( x 1) 4-89 G188/G189...

  • Page 204: Pick-Up, Feed And Separation Rollers

    Separation roller [D] and torque limiter [E] ( x 1) 4.11.3 TRAY LIFT MOTOR Rear cover ( Section: Rear Cover) PSU bracket ( Section: PSU Bracket) High voltage supply board bracket ( Section: High Voltage Supply Board Bracket) G188/G189 4-90...

  • Page 205: Vertical Transport, Paper Overflow, Paper End And Paper Feed Sensors

    Paper end feeler [B] and paper end sensor [C] (hook, x 1 each) Vertical transport sensor bracket [D] ( x 1, x 1) Vertical transport sensor [E] ( x 1, hook) Paper feed sensor bracket [F] ( x 1) Paper feed sensor [G] ( x 1, hook) 4-91 G188/G189...

  • Page 206: Registration Sensor

    2 each) Registration sensor [C] ( x 1, hook) 4.11.6 BY-PASS PAPER SIZE SENSOR AND BY-PASS PAPER LENGTH SENSOR Open the by-pass tray [A]. Move the side fences to the center. By-pass tray cover [B] ( x 4) G188/G189 4-92...

  • Page 207: When Reinstalling This Switch

    Plug in and turn on the main power switch. Check this sensor operation with SP5803-011 (By-pass paper size < Input Check). - Display on the LCD - Paper Size Display Paper Size Display A3 SEF 00001110 A5 SEF 00001011 B4 SEF 00001100 B6 SEF 00000011 4-93 G188/G189...

  • Page 208: By-Pass Bottom Tray

    Open the right door. By-pass tray cover ( Section: By-pass Paper Size Sensor and By-pass Paper Length Sensor) Open the duplex door [A]. Right door cover [B] ( x 4) Right door rear cover [A] ( x 3) G188/G189 4-94...
  • Page 209 Paper Feed Remove the screw at the front side ( x 1). Remove the cover [A] (2 hooks). Remove the screw at the rear side. 4-95 G188/G189...

  • Page 210: By-Pass Paper End Sensor

    1 each). 10. By-pass Bottom Tray [A] 4.11.8 BY-PASS PAPER END SENSOR Right door cover ( Section: By-pass Bottom Tray) By-pass feed unit cover [A] ( x 2). By-pass paper end sensor [B] ( x 1, hook) G188/G189 4-96...

  • Page 211: By-Pass Pick-Up, Feed And Separation Roller, Torque Limiter

    Right door cover ( Section: By-pass Bottom Tray) By-pass pick-up roller [A] (hook) By-pass feed roller [A] ( x 1) By-pass feed unit cover ( Section: By-pass Paper End Sensor) By-pass separation roller [A] ( x 1) Torque limiter [B] 4-97 G188/G189...

  • Page 212: By-Pass Feed Clutch

    Image transfer belt unit ( Section: Image Transfer Belt Unit) Rear cover ( Section: Rear Cover) Right rear cover ( Section: Right Rear Cover) Fusing duct [A] ( x 1, x 1) Paper exit cover [B] ( x 1) Top right stay [C] ( x 3) G188/G189 4-98...

  • Page 213: Fusing Exit, Paper Overflow, Junction Paper Jam And Paper Exit Sensors

    Fusing exit sensor [B] ( x 1) Paper overflow sensor [C] ( x 1, hook) Sensor bracket [D] ( x 1) Junction paper jam sensor [E] ( x 1, hook) Paper exit sensor [F] ( x 1, hook) 4-99 G188/G189...

  • Page 214: Duplex Unit

    Open the lower door [A] of the duplex unit. Release the tab [B] and remove the lower door (spring x 2). Open the right door. Release the front link [A] ( x 1). Keep the right door fully open. G188/G189 4-100...

  • Page 215: Duplex Door Sensor

    Wire [A] ( x 1) 10. Duplex unit [B] ( x 1, Stud screw x 1, x 1, x 4, ground cable x 1) 4.12.2 DUPLEX DOOR SENSOR Right door cover ( Section: Duplex Unit) Open the right door. 4-101 G188/G189...

  • Page 216: Duplex Entrance Sensor

    Open the right door. Duplex entrance guide [A] ( x1, stepped screw x 2) Duplex entrance sensor bracket [B] ( x 1, x 1) Duplex entrance sensor [C] (hook) 4.12.4 DUPLEX EXIT SENSOR Paper transfer unit ( Section:Paper Transfer Unit) G188/G189 4-102...
  • Page 217 Duplex Unit Guide plate [A] (two hooks) Duplex exit sensor [B] ( x 1, hook) 4-103 G188/G189...

  • Page 218: Electrical Components

    Controller unit [A] (knob screw x 5) 4.13.2 CONTROLLER BOX RIGHT COVER Rear cover ( Section: Rear Cover) Controller box right cover [A] ( x 9) 4.13.3 CONTROLLER BOX When opening the controller box Rear cover ( Section: Rear Cover) G188/G189 4-104...

  • Page 219: When Removing The Controller Box

    When removing the controller box Rear cover ( Section: Rear Cover) Right rear cover ( Section: Right Rear Cover) Controller box right cover ( Section: Controller Box Right Cover) Remove the controller box stay [A] ( x 4). 4-105 G188/G189...

  • Page 220: Iob (In/Out Board)

    If you do not open the controller box, the second fan duct prevents you from removing the controller box. Lift up the controller box [A], and then remove it. 4.13.4 IOB (IN/OUT BOARD) Rear cover ( Section: Rear Cover) Controller box right cover ( Section: Controller Box Right Cover) G188/G189 4-106...

  • Page 221: Bcu

    Make sure the NVRAM is correctly installed on the BCU. Insert the NVRAM in the NVRAM slot with the "half-moon" pointing [B] to the upward side. When installing the new BCU Remove the NVRAM from the old BCU. 4-107 G188/G189...

  • Page 222: Psu

    4.13.6 PSU PSU bracket Rear cover ( Section: Rear Cover) Ventilation duct [A] ( x 2) PSU bracket [B] ( x 6, all s, all PSU board Rear cover ( Section: Rear Cover) Ventilation duct ( Section: PSU) G188/G189 4-108...

  • Page 223: Itb Power Supply Board

    Top rear cover ( Section: Top Right and Rear Cover) ITB power supply board [A] ( x 5, x 6, x 3) 4.13.8 HIGH VOLTAGE SUPPLY BOARD Rear cover ( Section: Rear Cover) PSU bracket ( Section:PSU Bracket4-108) 4-109 G188/G189...

  • Page 224: High Voltage Supply Board Bracket

    PSU bracket ( Section: PSU Bracket) High voltage supply board bracket [A] ( x 3, All x 2) 4.13.10 IH INVERTER Rear cover ( Section: Rear Cover) Right rear cover ( Section: Right Rear Cover) Fusing duct ( Section: Fusing Fan) G188/G189 4-110...
  • Page 225 Electrical Components IH inverter [A] ( x 6, x 5) 4.13.11 CONTROLLER BOARD Controller unit ( Section: Controller Unit) Controller board [A] ( x 7, x 1) 4-111 G188/G189...

  • Page 226: When Installing The New Controller Board

    Re-install the NetWare option if new NVRAM is installed when replacing the controller board. Keep NVRAMs away from any objects that can cause static electricity. Static electricity can damage NVRAM data. Make sure the NVRAM is correctly installed on the controller board. G188/G189 4-112...

  • Page 227: Hdd Fan

    Make sure that the HDD fan is installed with its decal facing the right side of the machine. 4.13.13 HDD The HDD is an option for G188 model. The HDD is a standard for G189 model. Controller unit ( Section: Controller Unit)

  • Page 228: Disposal Of Hdd Units

    Turn the main switch off. Install an SD card into SD card slot 2. Then turn the main power on. Copy the NVRAM data to an SD card ( SP5-824-001) if possible. Turn off the main switch. Then unplug the power cord. G188/G189 4-114...

  • Page 229: Nvram On The Controller

    Install a New NVRAM on the controller. Then reassemble the machine. Turn the main switch on. SC995-02 occurs. Turn the machine off and on. Do the process control self-check. Re-install the NetWare option if it has been installed. 4-115 G188/G189...

  • Page 230: Controller Board

    Boot-up from Flash Boot-up from SD card Memory Factory Use Only: Do not change the switch 2 to 8 settings. 4.14.2 BCU BOARD DIP SW No. Factory Use Only: Do not change the switch 1 and 2 settings. G188/G189 4-116...

  • Page 231: System Maintenance Reference

    SYSTEM MAINTENANCE REFERENCE...

  • Page 233: System Maintenance Reference

    End: Exit service mode To select an item, press the “OK” key. Then the sub-menu appears. Scroll through the sub menu items using the “ / ” keys. To go back to a higher level, press the “Escape” key. G188/G189...

  • Page 234: Inputting A Value Or Setting For A Service Program

    MTH: Middle thick paper bottom) TH: Thick paper B: By-pass table Color Mode [Color] [K]: Black in B&W mode [Y], [M], or [C]: Yellow, Magenta, or Cyan in Full Color mode [YMC]: Only for Yellow, Magenta, and Cyan [FC]: Full Color mode G188/G189...

  • Page 235: Others

    5.1.4 BIT SWITCH PROGRAMMING Do not change the bit switches unless you are told to do this by the manufacturer. Start the SP mode. Select the “Service” menu with " / " keys. Press the "OK" key three times. G188/G189...
  • Page 236 [Escape]: Goes out of the program without saving changes. [OK]: Goes out of the program and saves changes. Push the "Escape" key one or more times until the menu “SP mode (Service)” is shown. Select “End” and push the OK key. G188/G189...

  • Page 237: Firmware Update

    The firmware-update program for this machine searches the folder romdata for necessary firmware. When you save the firmware in an SD card, make the folder ‘romdata’. You must not make the folder ‘romdata’ in another folder. Do not make another firmware-update program folder in the folder ‘romdata’. G188/G189...

  • Page 238: Update Procedure

    Remove the slot cover from the slot 2 ( x 1). Do not use the slot 1. The slot 1 is for customer use. Turn the SD card face to the rear side of the printer, and insert it into the slot 2. G188/G189...
  • Page 239 17. Attach the slot cover to the SD card slot 2 ( x 1). 18. Connect the printer to the network physically. 19. Turn on the main power switch. 20. Print the Configuration Page to check that the every firmware is correctly updated: Menu > List/Test Print > Config. Page G188/G189...

  • Page 240: Error Handling

    HDD connection incorrect or replace hard disks. data download Insert the SD card with the remaining data Data incorrect for continuous required for the download, the re-start the download procedure. Data incorrect after download Execute the recovery procedure for the intended G188/G189...
  • Page 241 Controller module download SD card and tray again, or replace controller failed board. SD update data is incorrect. The data on the SD Electronic confirmation check card is for another machine. Acquire correct failed update data then install again. G188/G189...

  • Page 242: Controller Self-Diagnostics

    Power-on self-diagnostics: The machine automatically starts the self-diagnostics just after the power has been turned on. SC detection: The machine automatically detects SC conditions at power-on or during operation. The following shows the workflow of the power-on and detailed self-diagnostics. G188/G189 5-10...

  • Page 243: Nvram Data Upload/Download

    Turn off the main power switch. Insert an SD card into the SD card slot 2. 10. Turn on the main power switch. 11. Start the SP mode. 12. Select SP5-824-001(NVRAM Upload). 13. Push the "OK" key. The upload starts. 5-11 G188/G189...

  • Page 244: Downloading Nvram Data

    11. Install the SD slot cover to the SD card slot 2. 12. Turn on the main power switch. 13. Check that the NVRAM data is correctly downloaded. This procedure does not download the following data to the NVRAM: Total Count Serial Number G188/G189 5-12...

  • Page 245: Using The Debug Log

    Select “3 SD Card” to save the debug information directly to the SD card if it is inserted in the service slot. Now select “SP5858” and specify the events that you want to record in the debug log. SP5858 (Debug Save When) provides the following items for selection. 5-13 G188/G189...
  • Page 246 Refer to the two tables below for the 4-digit numbers to enter for each key. The following keys can be set with the corresponding numbers. (The initials in parentheses indicate the names of the modules.) 4-Digit Entries for Keys 1 to 10 Key No. Printer 2222 (SCS) 14000 (SRM) G188/G189 5-14...
  • Page 247 The machine is now set to record the debugging information automatically on the HDD (the target selected with SP5857-002) for the events that you selected with SP5858 and the memory modules selected with SP5859. Please keep the following important points in mind when you do this setting: 5-15 G188/G189...

  • Page 248: Retrieving The Debug Log From The Hdd

    SD card. Use a card reader to copy the file and send it for analysis to your local Ricoh representative by email. You can also send the SD card by regular mail if you want.

  • Page 249: Sp5857-017 Create A File On Sd Card To Store A Log

    SD card. With the file already created on the SD card for the log file, the data only needs to be recorded; a new log file does not require creation. To create a new log file, do SP5857-012 to delete the debug log data from the SD card. Then do SP5857-017. 5-17 G188/G189...

  • Page 251: Troubleshooting

    TROUBLESHOOTING...

  • Page 253: Service Call Conditions

    Service Call Conditions 6. TROUBLESHOOTING 6.1 SERVICE CALL CONDITIONS See the "Appendices" for the following information: SC Tables G188/G189...

  • Page 254: Process Control Error Conditions

    Process Control Error Conditions 6.2 PROCESS CONTROL ERROR CONDITIONS See the "Appendices" for the following information: Developer Initialization Result Process Control Self-Check Result Line Position Adjustment Result G188/G189...

  • Page 255: Troubleshooting Guide

    If a stain appears at the edge of the output, do the following procedure. Execute the fusing cleaning mode with SP1123-002. It takes 160 seconds to complete the fusing cleaning mode. Print a sample page, and then check if a stain appears on the output. G188/G189...

  • Page 256: Jam Detection

    Jam Detection 6.4 JAM DETECTION See the "Appendices" for the following information: Paper Jam Display Jam Codes and Display Codes G188/G189...

  • Page 257: Electrical Component Defects

    Electrical Component Defects 6.5 ELECTRICAL COMPONENT DEFECTS See the "Appendices" for the following information: Sensors Blown Fuse Conditions G188/G189...
  • Page 259 G188/G189 SERVICE MANUAL APPENDICES...
  • Page 261 G188/G189 APPENDICES TABLE OF CONTENTS 1. APPENDIX: SPECIFICATIONS ........... 1-1 1.1 GENERAL SPECIFICATIONS ..............1-1 1.1.1 MAIN FRAME ................... 1-1 1.2 PRINTER ....................1-4 1.3 SUPPORTED PAPER SIZES ..............1-6 1.3.1 PAPER FEED ................... 1-6 1.3.2 PAPER EXIT..................1-8 3000 Sheet Finisher (B805)..............1-8 1000-Sheet Booklet Finisher (B793) ..........
  • Page 262 4.1.3 LINE POSITION ADJUSTMENT RESULT........4-5 5. APPENDIX: TROUBLESHOOTING GUIDE ........ 5-1 5.1 TROUBLESHOOTING GUIDE..............5-1 5.1.1 IMAGE QUALITY ................5-1 5.1.2 LINE POSITION ADJUSTMENT............5-2 Test ...................... 5-3 Countermeasure list for color registration errors ........5-3 G188/G189 SM Appendix...
  • Page 263 Table 3: Paper Size (By-pass Table)..........8-299 1000-Sheet Booklet Finisher (B793) ..........8-300 3000-Sheet Finisher (B805) ............. 8-303 Mail Bin (G835) ................8-306 Bridge Unit (D386)................8-307 One or Two-Tray PFU (D387/D351)/ LCIT 2000 (D352) ....8-308 SM Appendix G188/G189...
  • Page 264 8.2.3 OUTPUT CHECK TABLE ............. 8-308 Printer....................8-308 1000-Sheet Booklet Finisher (B793) ..........8-316 3000-Sheet Finisher ................. 8-318 Bridge Unit (D386)................8-320 One or Two-Tray PFU (D387/D351)/ LCIT 2000 (D352) ....8-320 8.2.4 TEST PATTERN PRINTING ............8-322 G188/G189 SM Appendix...

  • Page 265: Appendix: Specifications

    APPENDIX: SPECIFICATIONS...

  • Page 267: General Specifications

    Black & white: 9 seconds or less (A4/LT LEF) First print: Color: 7 seconds or less (A4/LT LEF) Black & white: 8 seconds or less (A4/LT LEF) Warm-up time: EU/ASIA: 34 seconds or less (23°C, 50%) NA: 35 seconds or less (23°C, 50%) SM Appendix G188/G189...
  • Page 268 Mail bin unit: 125 sheets x 4 Up to 4,000 sheets total capacity *1: T6200, A4 LEF Standard: 512 MB Memory: Maximum: 1024 MB (+ Option) Power Source: 120 V, 60 Hz: More than 12A (for North America) G188/G189 SM Appendix...
  • Page 269 Dimensions (W x D x H): Printer: 670 x 670 x 640 mm (26.4" x 26.4" x 25.2") Printer + PFU or LCT: 670 x 670 x 1020 mm (26.4" x26.4" x 40.2") Weight: Less than 97 kg (213.4 lb.) SM Appendix G188/G189...

  • Page 270: Printer

    P2d: 50 ppm (color/black and white) in Plain/Middle Thick mode x25/ 17.5 ppm in Thick/OHP mode (depending on paper type) PCL 6/5c (Standard): 35 Intelli fonts Resident Fonts: 10 TrueType fonts 13 International fonts Adobe PostScript 3: G188/G189 SM Appendix...
  • Page 271 USB Host I/F: Standard Ethernet (100 Base-TX/10 Base-T): Standard Host Interfaces: IEEE1284 parallel x 1: Optional IEEE802.11a/b/g (Wireless LAN): Optional Bluetooth (Wireless): Optional Gigabit Ethernet: Optional TCP/IP (IPv4, IPv6), SMB, AppleTalk (Auto Switching): Standard Network Protocols: IPX/SPX: Optional SM Appendix G188/G189...

  • Page 272: Supported Paper Sizes

    A5 SEF 210mm 210 x A5 LEF 148mm 105 x A6 SEF 148mm 257 x B4 SEF 364mm 182 x B5 SEF 257mm 257 x B5 LEF 182mm 128 x B6 SEF 182mm Ledger 11" x 17" G188/G189 SM Appendix...
  • Page 273 7.25" F SEF 8" x 13" Foolscap 8.5" x 13" 8.25" x 13" 11" x 15" Folio SEF 10" x 14" 8" x 10" 267 x 390mm 195 x 16K SEF 267mm 267 x 16K LEF 195mm SM Appendix G188/G189...

  • Page 274: Paper Exit

    3000 Sheet Finisher (B805) MF: Main Frame, Prf: Proof, Clr: Clear, Shf: Shift, Stp: Staple, 2P: 2 Holes Punch, N2P: North Europe 2 Holes, 3P: 3 Holes Punch, Punch 4 P: 4 Holes Punch, N4P: North Europe 4 Holes Punch G188/G189 SM Appendix...
  • Page 275 257 x B4 SEF 364 mm 182 x B5 SEF 257 mm 257 x B5 LEF 182 mm 128 x B6 SEF 182 mm Ledger 11" x 17" 8.5" x Letter SEF 11" Letter LEF 11" x SM Appendix G188/G189...
  • Page 276 F SEF 8" x 13" Foolscap 8.5" x 13" 8.25" x 13" 11" x 15" Folio SEF 10" x 14" 8" x 10" 267 x 390 mm 195 x 16K SEF 267 mm 16K LEF 267 x G188/G189 1-10 SM Appendix...
  • Page 277 Longer paper (feed length) than DLT (432 mm) is not guaranteed in this mode. *3: Minimum 100 mm for 2P, 230 mm for 3P, 255 mm for 4P, 125 mm for N4P *4: Corner stapling is not available in this mode. SM Appendix 1-11 G188/G189...

  • Page 278: 1000-Sheet Booklet Finisher (B793)

    Letter SEF 8.5" x 11" Letter LEF 11" x 8.5" Legal SEF 8.5" x 14" Government 8.25" x 14" Legal SEF Half Letter SEF 5.5" x 8.5" Executive SEF 7.25" x 10.5" Executive LEF 10.5" x 7.25" G188/G189 1-12 SM Appendix...
  • Page 279 C6 Env. 114 x 162 mm C5 Env. 162 x 229 mm DL Env. 110 x 220 mm Remarks: Supported Output up to 10 sheets Output up to 30 sheets Output up to 50 sheets Not supported SM Appendix 1-13 G188/G189...

  • Page 280: Software Accessories

    1.4.2 UTILITY SOFTWARE Software Description A font management utility with screen fonts for the Font Manager 2000 printer (Win9x/ME, 2000/XP/2003, NT4) This is provided on the printer drivers CD-ROM SmartDeviceMonitor for Admin A printer management utility for network G188/G189 1-14 SM Appendix...
  • Page 281 DeskTopBinder Lite itself can be used as personal document management software and can manage DeskTopBinder Lite both image data converted from paper documents (Win9x/ME, 2000/XP/2003, NT4) and application files saved in each client’s PC. This is provided on the scanner drivers CD-ROM SM Appendix 1-15 G188/G189...

  • Page 282: Optional Equipment

    Power Consumption: Less than 50 W (Max.)/ Less than 35 W (Ave,) Dimensions (W x D x H): 580 mm x 620 mm x 260 mm (22.8" x 24.4" x 10.2") Weight: 25 kg (55 lb.) G188/G189 1-16 SM Appendix...

  • Page 283: Large Capacity Tray

    50 sheets: B4, 8.5” x 14 or larger Proof Tray A5-A3 SEF, B6 SEF, A6 SEF Paper Size 5.5” x 8.5”-11” x 17” SEF, 12” x 18” SEF Paper Weight 60 g/m - 163 g/m (14 lb. - 43 lb.) SM Appendix 1-17 G188/G189...
  • Page 284 (same size) 20 - 50 pages 150 - 60 sets A4 LEF, 8.5” x 11” LEF 2 - 19 pages 150 sets A4 SEF, B5, 8.5” x 11” 15 - 50 pages 100 - 30 sets G188/G189 1-18 SM Appendix...

  • Page 285: Punch Unit For 3000-Sheet Finisher

    A5 to A4, 5.5" x 8.5" , 8.5" x 11” A3, B4, 11” x 17” NA 3-holes A4, B5, 8.5" x 11” A5 to A3, 5.5" x 8.5" to 11” x 17” EU 2-holes A5 to A4, 5.5" x 8.5", 8.5" x 11” SM Appendix 1-19 G188/G189...

  • Page 286: 1000-Sheet Booklet Finisher & Punch Unit

    (14 to 43 lb.) Staple mode: 64 to 90 g/m (17 to 24 lb.) Label/Thick paper/OHP cannot be stapled [Proof tray] Tray Capacity: 100 sheets: A4, 8.5" x 11" or less 50 sheets: B4, 8.5" x 14" or more G188/G189 1-20 SM Appendix...

  • Page 287: Bridge Unit

    , 16 lb. to 78 lb. Power Source: DC 24 V, 5 V (form the copier/printer) Dimensions (W x D x H): 415 mm x 412 mm x 111 mm (16.3" x 16.2" x 4.4") Weight 5 kg (11 lb.) SM Appendix 1-21 G188/G189...

  • Page 288: Mail Bin

    1.5.8 MAIL BIN Paper size A5(LEF)-11"x17"(SEF)/A3 Paper weight 60-128g/m , Bond 16-34lb Paper capacity More than 125 x 4 (80g/m Dimensions 435 x 475 x 375 mm (17.2"x18.7"x14.8") Weight Approximately 10kg (22lb) Power consumption Approximately 17 W G188/G189 1-22 SM Appendix...
  • Page 289 APPENDIX: PREVENTIVE MAINTENANCE...

  • Page 291: Appendix: Preventive Maintenance Tables

    An error message shows when a maintenance counter gets to the value in the PM table when the machine’s default settings are used. It is not necessary to reset counters for each part. The machine detects new components automatically and resets the necessary counters. SM Appendix G188/G189...

  • Page 292: Service Maintenance Items

    Paper Feed Unit PB3040 (D351) LCIT PB3050 (D352) Item Remarks Feed Roller Dry cloth Separation Roller Dry cloth Pick-up Roller Dry cloth Paper Feed Sensor Dry cloth Relay Sensor Dry cloth Relay Roller Damp cloth Bottom Plate Pad Damp cloth G188/G189 SM Appendix...

  • Page 293: 1000/3000-Sheet (Booklet) Finisher

    Service Maintenance Items 1000/3000-Sheet (Booklet) Finisher Items Remarks Rollers Damp cloth Discharge Brush Dry cloth Sensors Blower brush 1000/3000-Sheet (Booklet) Finisher Punch Kit Items Remarks Punch Chads Discard chads. SM Appendix G188/G189...

  • Page 295: Service Call Conditions

    APPENDIX SERVICE CALL CONDITIONS...
  • Page 297 You can reset the machine by turning the main Turn the main power switch or power switch or main switch off main power switch off and on. and on. If the error occurs again, the same SC code is displayed. SM Appendix G188/G189...

  • Page 298: Sc Code Classification

    Unique for a specific model 290 - Shutter 300 - Charge 330 - Drum potential Image development 1 350 - Development 380 - Unique for a specific model Image development 2 400 - Image transfer 420 - Paper separation G188/G189 SM Appendix...
  • Page 299 650 - Network 670 - Internal data processing 680 - Unique for a specific model 700 - Not used in this model Peripherals 720 - Finisher: Shift/Staple 740 - Finisher: Staple/Punch Controller 800 - Error after ready condition SM Appendix G188/G189...

  • Page 300: Service Call Tables - 1

    SC 2xx: Exposure Type Details (Symptom, Possible Cause, Troubleshooting Procedures) Polygon motor error 1: ON timeout The polygon mirror motor does not reach the targeted operating speed within the specified time after turning on or changing speed G188/G189 SM Appendix...
  • Page 301 Polygon motor error 3: XSCRDY signal error The SCRDY_N signal goes HIGH (inactive) while the laser diode is firing. Disconnected or defective harness to polygon motor driver board Defective polygon motor Defective polygon motor driver board See SC 202 for troubleshooting details. SM Appendix G188/G189...
  • Page 302 Laser synchronizing detection error: start position [Y]: LD2 Laser synchronizing detection error: start position [M]: LD1 Laser synchronizing detection error: start position [M]: LD2 Laser synchronizing detection error: start position [C]: LD1 Laser synchronizing detection error: start position [C]: LD2 G188/G189 SM Appendix...
  • Page 303 FGATE OFF error: Bk The PFGATE ON signal still asserts within 5 seconds after processing the image in normal job or MUSIC for end position [K]. The PFGATE ON signal still asserts when the next job starts. SM Appendix G188/G189...
  • Page 304 FGATE OFF error: M The PFGATE ON signal still asserts within 5 seconds after processing the image in normal job or MUSIC for end position [M]. The PFGATE ON signal still asserts when the next job starts. G188/G189 SM Appendix...
  • Page 305 LD error: M LD error: C The BCU detects LDB error a few times consecutively when LDB unit turns on after LDB initialization. Worn-out LD Disconnected or broken harness of the LD Replace the harness of the LD. SM Appendix G188/G189...
  • Page 306 Check and reinstall the image transfer belt unit and PCUs. Check if each toner bottle has enough toner. Replace the ID sensor. Replace the image transfer belt unit. Replace the PCU(s). Replace the laser optics housing unit. G188/G189 3-10 SM Appendix...
  • Page 307 The Vt value of the black, magenta, cyan, or yellow TD sensor exceeds the specified value (default: 4.7V) with SP3020-002 for twenty counts. The [Vt - Vtref] value of the black, magenta, cyan, or yellow TD sensor exceeds the specified value (default: 5.0V) with SP3020-001. SM Appendix 3-11 G188/G189...
  • Page 308 Check the black, magenta, cyan, or yellow TD sensor connector and harness between the TD sensor and PCU for damage. Check the drawer connector. Replace the defective PCU. Type Details (Symptom, Possible Cause, Troubleshooting Procedures) TD sensor adjustment error: K G188/G189 3-12 SM Appendix...
  • Page 309 The machine does not detect the drum position signal for 3 seconds at the drum phase adjustment. Dirty or defective drum gear position sensor Clean the drum gear position sensor. Check the harness connection. Replace the drum gear position sensor. Replace the PCU. SM Appendix 3-13 G188/G189...

  • Page 310: Service Call Tables - 3

    The Vsg error counter counts "1" when the Vsg detected by ID sensor is more than the value (default: 4.5V) specified with SP3324-005 or less than the value (default: 3.5V) specified with SP3324-006. Dirty or defective ID sensor Defective ID sensor shutter Check the harness of the ID sensor. G188/G189 3-14 SM Appendix...
  • Page 311 Replace the IOB. Type Details (Symptom, Possible Cause, Troubleshooting Procedures) Image transfer belt contact motor error The image transfer belt contact sensor does not detect the movement of actuator at the sensor while the polygon motor rotates. SM Appendix 3-15 G188/G189...
  • Page 312 The paper transfer unit contact sensor does not detect the movement of actuator at the sensor while the polygon motor rotates. Defective paper transfer unit contact sensor Defective paper transfer unit contact motor Broken +24V fuse on PSU Defective IOB G188/G189 3-16 SM Appendix...
  • Page 313 The LOCK signal is not detected for 2 seconds when the transport motor turns on. Toner transport motor overload Disconnected or broken harness Defective toner transport motor Opened +24V fuse on the PSU Defective interlock switch Check or replace the harness. Replace the toner transport motor. SM Appendix 3-17 G188/G189...
  • Page 314 Broken harness Defective image transfer belt unit or paper transfer unit Defective high voltage supply unit Check or replace the harness. Replace the image transfer belt unit or paper transfer unit. Replace the high voltage supply unit. G188/G189 3-18 SM Appendix...
  • Page 315 SC is generated and the machine detects that the humidity is "50%". Temperature and humidity sensor harness disconnected, loose, defective Temperature and humidity sensor defective Check the connector and harness. Replace the temperature/humidity sensor. SM Appendix 3-19 G188/G189...

  • Page 316: Service Call Tables - 4

    When the tray lift motor is turned on, the upper limit is not detected within 10 seconds For the LCT: SC 503-01 occurs if the upper or lower limit is not detected within 8 seconds when the tray lift motor is turned on to lift or lower the tray. G188/G189 3-20 SM Appendix...
  • Page 317 If the upper limit does not go off for 1.5 seconds even the tray lift motor turns on to lower the tray after the upper limit has been detected at power on. SM Appendix 3-21 G188/G189...
  • Page 318 Defective tray lift motor or connector disconnection Defective lift sensor or connector disconnection Check the cable connections. Check and/or replace the defective component. Type Details (Symptom, Possible Cause, Troubleshooting Procedures) Tray 4 error (Paper Feed Unit or LCT) G188/G189 3-22 SM Appendix...
  • Page 319 When the tray lift motor is turned on, the upper limit is not detected within 10 seconds. Defective tray lift motor or connector disconnection Defective lift sensor or connector disconnection Check the cable connections. Check and/or replace the defective component. SM Appendix 3-23 G188/G189...
  • Page 320 Ventilation fan (at the left side of the machine) motor-front/rear error The IOB does not receive the lock signal for 2 seconds after turning on the ventilation fan motor-front/rear. Defective ventilation fan motor-front or rear Defective IOB G188/G189 3-24 SM Appendix...
  • Page 321 IH inverter fan turns on. Disconnected harness Overload on the IH inverter fan motor Defective IH inverter fan motor Defective IOB Check or replace the harness. Replace the IH inverter fan. Replace the IOB. SM Appendix 3-25 G188/G189...
  • Page 322 Replace the paper exit fan. Replace the IOB. Type Details (Symptom, Possible Cause, Troubleshooting Procedures) Third duct fan error The motor lock signal error is detected for 10 seconds after the motor lock signal was first detected. G188/G189 3-26 SM Appendix...
  • Page 323 The temperature measured by the heating roller thermopile does not reach 0°C for 6 seconds. Loose connection of the heating roller thermopile Defective heating roller thermopile Defective thermopile Check if the heating roller thermopile is firmly connected. Replace the heating roller thermopile. SM Appendix 3-27 G188/G189...
  • Page 324 Replace the IOB. Replace the BCU. Type Details (Symptom, Possible Cause, Troubleshooting Procedures) Heating roller overheat 1 (hardware error) During stand-by mode or a print job, the temperature detected by the heating roller thermopile reaches 250 °C. G188/G189 3-28 SM Appendix...
  • Page 325 Check the power supply source. Replace the +24V fuse on the PSU. Replace the PSU Type Details (Symptom, Possible Cause, Troubleshooting Procedures) Fusing unit rotation error The heating roller rotation sensor does not detect change in the SM Appendix 3-29 G188/G189...
  • Page 326 The heating roller temperature does not reach the ready temperature for 90 seconds after the heating lamp on. The heating roller temperature does not reach 80°C for 20 seconds after the IH inverter on. Defective heating roller thermistor G188/G189 3-30 SM Appendix...
  • Page 327 Details (Symptom, Possible Cause, Troubleshooting Procedures) Heating roller overheat (hardware error) The heating roller thermistor detects 250°C or more. Defective PSU Defective IOB Defective BCU Defective fusing control system Replace the PSU. Replace the IOB. Replace the BCU. SM Appendix 3-31 G188/G189...
  • Page 328 The temperature detected by the pressure roller thermistor does not reach 0 °C for 37 seconds. Loose connection of the pressure roller thermistor Defective pressure roller thermistor Check if the pressure roller thermistor is firmly connected. Replace the pressure roller thermistor. G188/G189 3-32 SM Appendix...
  • Page 329 Defective PSU Defective IOB Defective BCU Replace the PSU. Replace the IOB. Replace the BCU. Type Details (Symptom, Possible Cause, Troubleshooting Procedures) Pressure roller overheat 3 (hardware error) The pressure roller thermistor detects 220°C or more. SM Appendix 3-33 G188/G189...
  • Page 330 Pressure roller contact sensor does not detect the pressure roller position three times. Broken or defective pressure roller contact sensor Deformed or broken pressure roller contact sensor feeler Defective pressure roller contact motor Defective fusing unit G188/G189 3-34 SM Appendix...
  • Page 331 Disconnected power input terminal 1 and 2 Defective IH inverter Defective IH coil unit Defective fusing unit Check the power input terminals 1 and 2. Replace the IH inverter. Replace the IH coil unit. Replace the fusing unit. SM Appendix 3-35 G188/G189...

  • Page 332: Sc6Xx: Device Communication

    The machine detects the mechanical counter error when SP5987-001 is set to "1". Disconnected mechanical counter Defective mechanical counter Check or replace the mechanical counter. Type Details (Symptom, Possible Cause, Troubleshooting Procedures) Finisher/ Mail Bin communication error G188/G189 3-36 SM Appendix...
  • Page 333 The upper unit cannot communicate with the lower unit after the upper unit has detected the lower unit. The upper unit detects an error signal from the lower unit after the upper unit has detected the lower unit. Disconnected connector Check and/ or connect the connector. SM Appendix 3-37 G188/G189...
  • Page 334 Details (Symptom, Possible Cause, Troubleshooting Procedures) BICU control data transfer abnormal A sampling of the control data sent from the BICU reveals an abnormality. Defective controller board External noise Defective BCU Replace the controller board. Replace the BCU. G188/G189 3-38 SM Appendix...
  • Page 335 Details (Symptom, Possible Cause, Troubleshooting Procedures) Engine board mismatch error Engine board and controller mismatch detected. Wrong engine board installed. Wrong controller board installed. Check the type of engine board and controller board. Replace the BCU. Replace the controller board. SM Appendix 3-39 G188/G189...
  • Page 336 No memory chip on the development unit Noise Replace the PCU. Type Details (Symptom, Possible Cause, Troubleshooting Procedures) RFID: Unit check error The machine gets RFID communication error even the toner cartridges have not been installed in the machine. Caused by noise G188/G189 3-40 SM Appendix...
  • Page 337 The I2C bus communication is not established due to an error other than a buffer shortage. Loose connection Defective BCU Defective LD controller board Turn the main switch off and on. Check the cable connection. Replace the laser optics-housing unit. Replace the BCU. SM Appendix 3-41 G188/G189...

  • Page 338: Sc7Xx: Peripherals

    Stack feed-out HP sensor does not turn off 200 ms after the stack feed-out belt has moved from its home position. The 1st detection failure issues a jam error, and the 2nd failure issues this SC code. Defective stack feed-out HP sensor G188/G189 3-42 SM Appendix...
  • Page 339 Guide plate position sensor disconnected, defective Check the connections and cables for the components mentioned above. Check for blockages in the guide plate motor mechanism. Replace the guide plate position sensor and/or guide plate motor. Replace the finisher main board. SM Appendix 3-43 G188/G189...
  • Page 340 The HP sensor of the staple unit detects the home position after the staple unit moves from its home position. The 1st detection failure issues a jam error, and the 2nd failure issues this SC code. G188/G189 3-44 SM Appendix...
  • Page 341 For the 1000-sheet booklet finisher The stapler HP sensor is not activated within the specified time after the stapler motor turned on. The 1st detection failure issues a jam error, and the 2nd failure issues this SC code. SM Appendix 3-45 G188/G189...
  • Page 342 Check for blockages in the stack feed motor mechanism. Replace the stack feed HP sensor and/or stack feed motor Replace the finisher main board. Type Details (Symptom, Possible Cause, Troubleshooting Procedures) 1000/3000-sheet (booklet) finisher: Tray lift motor error G188/G189 3-46 SM Appendix...
  • Page 343 The 1st detection failure issues a jam error, and the 2nd failure issues this SC code. Punch HP sensor disconnected, defective Punch motor disconnected or defective Punch motor overload due to obstruction SM Appendix 3-47 G188/G189...
  • Page 344 The punch unit moves but is not detected at the home position within the specified time. The 1st detection failure issues a jam error, and the 2nd failure issues this SC code. Motor harness disconnected, loose, defective Defective motor Check the connections to the punch movement motor. G188/G189 3-48 SM Appendix...
  • Page 345 The sponge roller moves but is not detected at the home position within the specified time. The 1st detection failure issues a jam error, and the 2nd failure issues this SC code. Motor harness disconnected, loose, defective SM Appendix 3-49 G188/G189...
  • Page 346 Broken harness Check the connections between the bridge unit and the machine. Install a new bridge unit. Type Details (Symptom, Possible Cause, Troubleshooting Procedures) Finisher error The machine does not recognize the finisher, but recognizes the bridge G188/G189 3-50 SM Appendix...

  • Page 347: Sc8Xx: Peripherals

    File or module on the system SD card is illegal Make sure that the system SD card is the one designed for the machine Replace controller board. Type Details (Symptom, Possible Cause, Troubleshooting Procedures) Fatal error Process error [696E] System completely down SM Appendix 3-51 G188/G189...
  • Page 348 [4361] CPU cache error Replace the controller. Kernel stop error An error in the operation system (An error message is output.) Defective CPU Defective memory Defective flash memory Incorrect software Replace the memory. Replace the controller. G188/G189 3-52 SM Appendix...
  • Page 349 CPU/Memory Error System firmware problem [0702] Defective RAM-DIMM [0709] Defective controller [070A] Reinstall the controller system software. Replace the RAM-DIMM. Replace the controller. Type Details (Symptom, Possible Cause, Troubleshooting Procedures) Self-diagnostics error: ASIC [XXXX]: Detailed error code SM Appendix 3-53 G188/G189...
  • Page 350 CPU timer. If the ASIC timer does not function in the specified range, this SC code is displayed. System firmware problem [0D05] Defective RAM-DIMM Defective controller Reinstall the controller system firmware. Replace the RAM-DIMM. Replace the controller board. G188/G189 3-54 SM Appendix...
  • Page 351 Defective standard NVRAM Defective controller board Worn-out battery in the NVRAM Check the standard NVRAM is firmly inserted into the socket. Replace the NVRAM. Replace the controller board. Type Details (Symptom, Possible Cause, Troubleshooting Procedures) [15FF] SM Appendix 3-55 G188/G189...
  • Page 352 Replace the SDRAM DIMM. Replace the controller. Resident memory error The SPD values in all RAM DIMM are incorrect or unreadable. Defective RAM DIMM [0202] Defective SPD ROM on RAM DIMM Defective 12C bus Replace the RAM DIMM. G188/G189 3-56 SM Appendix...
  • Page 353 The result of checking the composition data of the optional RAM in Slot 1 on the controller is incorrect. Not specified RAM DIMM installed Defective RAM DIMM Turn the main switch off and on. Replace the RAM DIMM. Replace the controller board. SM Appendix 3-57 G188/G189...
  • Page 354 Replace the controller board. Type Details (Symptom, Possible Cause, Troubleshooting Procedures) Wireless LAN/Bluetooth card not detected The wireless LAN/Bluetooth card is not detected before communication is established, though the wireless LAN/Bluetooth board is detected. Loose connection Check the connection. G188/G189 3-58 SM Appendix...
  • Page 355 Defective USB driver Loose connection Check the connection. Replace the USB board. Type Details (Symptom, Possible Cause, Troubleshooting Procedures) HDD Encryption unit error 1 A serious error occurs when data is encrypted to update an encryption SM Appendix 3-59 G188/G189...
  • Page 356 Same as SC991 Type Details (Symptom, Possible Cause, Troubleshooting Procedures) HDD Encryption unit error 2 A serious error occurs when the HDD data is encrypted to update an encryption key with the HDD encryption unit. HDD check error: G188/G189 3-60 SM Appendix...
  • Page 357 HDD not initialized Defective HDD Reformat the HDD. Replace the HDD. Type Details (Symptom, Possible Cause, Troubleshooting Procedures) HDD: Reboot error The HDD does not become ready within 30 seconds after the power is supplied to the HDD. SM Appendix 3-61 G188/G189...
  • Page 358 Details (Symptom, Possible Cause, Troubleshooting Procedures) HDD: CRC error While reading data from the HDD or storing data in the HDD, data transmission fails. Defective HDD Replace the HDD. Type Details (Symptom, Possible Cause, Troubleshooting Procedures) HDD: Access error G188/G189 3-62 SM Appendix...
  • Page 359 An error is detected in the SD card. For a file system error, format the SD card on your PC. For a device error, turn the mains switch off and on. Replace the SD card. Replace the controller board. SM Appendix 3-63 G188/G189...
  • Page 360 Details (Symptom, Possible Cause, Troubleshooting Procedures) HDD mail transmission data error An error is detected in the HDD at machine initialization. Defective HDD Power failure during an access to the HDD Initialize the HDD partition (SP5-832-008). Replace the HDD. G188/G189 3-64 SM Appendix...
  • Page 361 This can be caused by switching the machine off while it is operating. Log Data Error 1 -001 Damaged log data file in the HDD Initialize the HDD with SP5832-004. -002 Log Data Error 2 An encryption module not installed SM Appendix 3-65 G188/G189...
  • Page 362 The 'all delete' function cannot be executed but the Data Overwrite Security Unit (M354) is installed and activated. Defective SD card (M354) SD card (M354) not installed Replace the NVRAM and then install the new SD card (M354). Check and reinstall the SD card (M354). G188/G189 3-66 SM Appendix...
  • Page 363 An error is detected in the printer application program. Defective software Unexpected hardware resource (e.g., memory shortage) Software defective; switch off/on, or change the controller firmware if the problem is not solved Install an optional memory. SM Appendix 3-67 G188/G189...
  • Page 364 The software has attempted to perform an unexpected operation. However, unlike SC 990, the object of the error is continuity of the software. Software program error Internal parameter incorrect, insufficient working memory. This SC is not displayed on the LCD (logging only). G188/G189 3-68 SM Appendix...
  • Page 365 Replace the controller board with the correct type. Incorrect model controller installed. -004 Replace the controller board with the correct model. Type Details (Symptom, Possible Cause, Troubleshooting Procedures) Application start error No applications start within 60 seconds after the power is turned on. SM Appendix 3-69 G188/G189...
  • Page 366 SMC - Logging (SP5-990-004) Printer driver settings used when the problem occurs All data displayed on the screen (SC code, error code, and program address where the problem is logged.) Image file which causes the problem, if possible G188/G189 3-70 SM Appendix...

  • Page 367: Appendix: Process Control Error Conditions

    APPENDIX: PROCESS CONTROL ERROR CONDITIONS...

  • Page 369: Process Control Error Conditions

    Vcnt is 4.3V. Defective TD sensor Vcnt is less than 4.7V Defective TD sensor Vt target settings are not correct. Vcnt error 1 when Vcnt is Vt target ±0.2V. Toner density error SM Appendix G188/G189...

  • Page 370: Process Control Self-Check Result

    Vt error minimum error is Replace the development unit. detected. Replace the IOB board. Vt minimum error: Replace the development unit. Replace the IOB board. ID sensor Not enough data can Solid image is not sufficient density: G188/G189 SM Appendix...
  • Page 371 Vk is out of range. Background dirty Minimum Vk < –150 Hardware defective Same as 53 Sampling data Not enough data can ID sensor pattern density is too high error during be sampled during the or low. SM Appendix G188/G189...

  • Page 372: Vsg Adjustment Result

    Replace the ID sensor. Check the connection. Replace the IOB board. ID sensor output Defective ID sensor is more than Poor connection ID sensor "Voffset Defective IOB output error Threshold" Replace the ID sensor. (SP3-324-004) Check the connection. G188/G189 SM Appendix...

  • Page 373: Line Position Adjustment Result

    ID sensors have correctly detected the patterns adjustment for line position adjustment, but a shift of See Note range patterns is out of adjustable range. Not used For details, see the "Troubleshooting Guide - Line Position Adjustment" section. SM Appendix G188/G189...
  • Page 375 APPENDIX: TROUBLESHOOTING GUIDE...

  • Page 377: Appendix: Troubleshooting Guide

    Troubleshooting Guide 5. APPENDIX: TROUBLESHOOTING GUIDE 5.1 TROUBLESHOOTING GUIDE 5.1.1 IMAGE QUALITY The following work-flow shows the basic troubleshooting steps for the image quality problems on this product. SM Appendix G188/G189...

  • Page 378: Line Position Adjustment

    Troubleshooting Guide 5.1.2 LINE POSITION ADJUSTMENT When there are color registration errors on the output, do the line position adjustment as follows. Use A3/DLT size paper for this adjustment. G188/G189 SM Appendix...

  • Page 379: Test

    Replace the high voltage power supply unit. Do the forced process control (SP3-011-001) or supply some toner (SP3-015-xxx). Replace the BICU. Defective ID sensor shutter Normal image, but with color Defective ID sensor registration errors Defective BCU SM Appendix G188/G189...
  • Page 380 Defective laser optics housing unit The skew for M, C, Y is more Defective BCU than ±0.75 mm from the main Reinstall or replace the PCU. scan registration of K Replace the laser optics housing unit. Replace the BCU. G188/G189 SM Appendix...
  • Page 381 Replace the high voltage power supply unit. Do the forced process control (SP3-011-001) or supply some toner (SP3-015-xxx). Replace the BCU. Defective ID sensor shutter Normal image, but with color Defective ID sensor registration errors Defective BCU Replace the ID sensor shutter solenoid. SM Appendix G188/G189...
  • Page 382 Deformed center area on the image transfer belt shifted by more than ±0.66 mm, Defective BCU but only at the central area of the Replace the ID sensor. image on the output. Replace the image transfer belt. Replace the BCU. G188/G189 SM Appendix...
  • Page 383 Result: "0" in SP2-194-007 Result: Color registration errors in SP2-194-010, -011, -012 Test pattern check Possible cause/Countermeasure Low pattern density Low image density on the output Do the forced process control (SP3-011-001) or supply some toner (SP3-015-xxx). SM Appendix G188/G189...
  • Page 384 The skew of M, C, Y is different. Reinstall or replace the PCU. Replace the laser optics housing unit. Replace the IOB. The sub scan lines are shifted. Defective PCU Shifted lines appear cyclically. Defective drive unit G188/G189 SM Appendix...
  • Page 385 Test pattern check Possible cause/Countermeasure Drum phase adjustment error Do SP1-902-001 (Drum phase adjustment); see Replacement and Adjustment – Drive Unit – Gear Unit for details. Reinstall or replace the PCU. Check or replace the drive unit. SM Appendix G188/G189...

  • Page 387: Appendix: Jam Detection

    APPENDIX: JAM DETECTION...

  • Page 389: Paper Jam Display

    Paper is not fed from tray 3 (LCT). 7504 6 Tray 4: ON Paper is not fed from tray 4. 7504 7 Tray 5: ON Paper is not fed from tray 5. 7504 8 Bypass: ON Paper is not fed from the by-pass tray. SM Appendix G188/G189...
  • Page 390 Junction Gate Feed: Junction gate jam sensor does not 7504 24 detect paper. Duplex exit sensor does not detect 7504 25 Duplex Exit: ON paper. Duplex Entrance: ON Duplex entrance sensor does not detect 7504 26 (In) paper. G188/G189 SM Appendix...
  • Page 391 Duplex exit sensor does not turn off. Duplex Entrance: OFF Duplex entrance sensor does not turn 7504 66 (In) off. Duplex Entrance: OFF Duplex entrance sensor does not turn 7504 67 (Out) off after paper has passed this sensor. SM Appendix G188/G189...
  • Page 392 (B793) Fold unit exit sensor does not turn off after it has turned on. Finisher Guide Motor Exit guide plate HP sensor does not turn 7504 137 R1-R3 (B793) off after the exit guide plate has opened. G188/G189 SM Appendix...
  • Page 393 Shift motor HP sensor does not turn off Finisher Shift Roller after the shift roller has moved from its 7504 142 R1-R3 Motor (B793) home position. Shift motor HP sensor does not turn on SM Appendix G188/G189...
  • Page 394 Lower clamp roller HP sensor does not Finisher Stack 2 turn off after the lower clamp roller has R7-R11 7504 147 Release Motor (B793) moved from its home position. Lower clamp roller HP sensor does not G188/G189 SM Appendix...
  • Page 395 Finisher Exit: EUP 7504 195 R8-R12 (B805) Upper tray exit sensor does not turn off after the stack feed-out belt has returned to its home position. 7504 196 Finisher Staple: EUP Not used SM Appendix G188/G189...
  • Page 396 R5-R8 Stapler rotation HP sensor does not turn (B805) on/off after the corner stapler rotation motor has turned on. Finisher Staple Motor: Corner stapler does not finish stapling 7504 203 R5-R8 EUP (B805) after a specified time. G188/G189 SM Appendix...
  • Page 397 MBX P. Feed 2: ON not turn off. Finisher Exit No The machine does not get a paper exit 7504 230 Response signal from the finisher. Finisher The machine does not detect the 7504 231 Communication Error finisher. SM Appendix G188/G189...

  • Page 398: Paper Size Code

    Size Code Paper Size Size Code Paper Size A4 LEF B4 SEF A5 LEF B5 SEF B5 LEF DLT SEF LT LEF LG SEF HLT LEF LT SEF A3 SEF HLT SEF A4 SEF Others A5 SEF G188/G189 6-10 SM Appendix...

  • Page 399: Sensor Locations

    Jam Detection Sensor Locations SM Appendix 6-11 G188/G189...

  • Page 401: Appendix: Electrical Component Defects

    APPENDIX: ELECTRICAL COMPONENT DEFECTS...
  • Page 403 ID Sensor: M 7, 11 Shorted CN211/ Open/ SC400 ID Sensor: C 8, 12 Shorted CN211/ Open/ ID Sensor: Y 9, 13 Shorted Open/ ID Sensor: Front CN211/1 SC258 Shorted ID Sensor: Center CN211/2 Open/ SC400 / SC258 SM Appendix G188/G189...
  • Page 404 Jam A (Jam3, 11) Vertical Transport CN230/A7 Sensor 1 Shorted Jam A, B (Jam1) Paper end is not Paper End CN230/ detected when there is Open Sensor 1, 2 A10, B10 no paper in the paper tray. G188/G189 SM Appendix...
  • Page 405 Shorted tray 1 is not set. CN232/ By-pass Paper Size Open/ B16, B17, Paper size error Sensor Shorted B19, B20 Paper on the by-pass By-pass Paper CN232/ Open tray is not detected Detection when paper is set. SM Appendix G188/G189...
  • Page 406 Open/ TD Sensor - Y SC375 Shorted Open Jam C (Jam 19) Fusing Exit Sensor CN204/12 Shorted Jam C (Jam 1) Waste toner near full Waste Toner Sensor CN224/A5 Open indicated when it is not near full. G188/G189 SM Appendix...
  • Page 407 Open/ Thermopile CN209/16 SC541 Shorted Thermistor Open/ CN212/22 SC551 - Heating Roller Shorted Thermistor Open/ CN212/18 SC561 - Pressure Roller Shorted Paper Exit Sensor CN204/9 Open Jam C (Jam 20) SM Appendix G188/G189...

  • Page 408: Blown Fuse Conditions

    R: This means that it is possible to replace in the field (for example: Tube fuse). Rating Symptom when turning on the main Fuse Remark 220V - switch 115V 240V No response. (The main power to the PSU is 15A/125V 8A/250V not supplied.) G188/G189 SM Appendix...

  • Page 409: Ih Inverter

    5A/250V 5V power to the BCU not supplied. IH Inverter Rating Fuse Symptom when turning on the main switch 115V 220V - 240V 15V power to the IH coil unit is not supplied. 15A/125V 8A/250V SC689 occurs. SM Appendix G188/G189...
  • Page 410 220V - 240V 115°C No response 115°C No response 15V power to the IH coil unit is not supplied. 1A/250V SC689 occurs. For continued protection against risk of fire, replace only with same type and rating of fuse. G188/G189 SM Appendix...

  • Page 411: Appendix: Sp Mode Tables

    APPENDIX: SP MODE TABLES...

  • Page 413: Service Mode

    7 [RPCS,PCL]: Printable area frame border 0: Disable 1: Enable Enable: The machine prints all RPCS and PCL jobs with a border on the edges of the printable area. 1001 Bit Switch 002 Bit Switch 2 SM Appendix G188/G189...
  • Page 414 [PCL5e/c]: Legacy HP compatibility 0: Disable 1: Enable Enable: Uses the same left margin as older HP models such as HP4000/HP8000. In other words, the left margin defined in the job (usually "<ESC>*r0A") will be changed to "<ESC>*r1A" bit 3 G188/G189 SM Appendix...
  • Page 415 PS data or not. Pattern3: includes most PS commands. Pattern1: A small number of PS tags and headers bit 4 Increase max number of the stored jobs Disable Enable (1000) (100) to 1000 jobs. SM Appendix G188/G189...
  • Page 416 Bit Switch Bit Switch 8 bit 0 bit 1 bit 2 bit 3 [PCL,PS]: Allow BW jobs to print without Disable Enable requiring User Code Enable: BW jobs submitted without a user code will be printed even if G188/G189 SM Appendix...
  • Page 417 Enables or disables the display for information on each supply. 1007 001 Development *CTL [0 or 1 / 1 / 1 /step] 0: OFF, 1: ON 1007 002 *CTL 1007 003 Transfer *CTL 1007 004 Int. Transfer *CTL SM Appendix G188/G189...
  • Page 418 1103 002 ColorChart [ToneCtlValue] 1104 Adjusts the printer gamma for the mode selected in the Mode Selection menu. 1104 001 Set Black 1 *CTL [0 to 255 / 16 / 1/step] G188/G189 SM Appendix...
  • Page 419 1104 065 Set Yellow 5 *CTL 1104 006 Set Black 6 *CTL 1104 026 Set Cyan 6 *CTL [0 to 255 / 96 / 1/step] 1104 046 Set Magenta 6 *CTL 1104 066 Set Yellow 6 *CTL SM Appendix G188/G189...
  • Page 420 1104 051 Set Magenta 11 *CTL 1104 071 Set Yellow 11 *CTL 1104 012 Set Black 12 *CTL [0 to 255 / 192 / 1/step] 1104 032 Set Cyan 12 *CTL 1104 052 Set Magenta 12 *CTL G188/G189 SM Appendix...
  • Page 421 “current setting” to the “previous setting” memory-storage location. [Toner Limit Value] 1106 Adjusts the maximum toner amount for image development. 1106 001 TonerLimitValue *CTL [100 to 400 / 260 / 1%/step] 1108 [Ext. Toner Save] SM Appendix G188/G189...
  • Page 422 Mode 1: Text 1108 002 Mode 2: Text 1108 003 Mode 1: Image 1108 004 Mode 2: Image 1108 005 Mode 1: Line 1108 006 Mode 2: Line 1108 007 Mode 1: Paint 1108 008 Mode 2: Paint G188/G189 8-10 SM Appendix...

  • Page 423: Engine Service Mode

    010 By-pass: Thick 2 *ENG 011 By-pass: Thick 3 *ENG 013 Duplex: Plain *ENG 014 Duplex: Middle Thick *ENG 015 Duplex: Thick 1 *ENG 016 Tray: Thick 3 *ENG 017 Tray: Plain:1200 *ENG 018 Tray: Middle Thick:1200 *ENG SM Appendix 8-11 G188/G189...
  • Page 424 Adjusts the amount of paper buckle at the registration roller by changing the paper feed timing. 002 Paper Tray1: Plain *ENG [–9 to 5 / -2 / 1 mm/step] 003 Tray1: Middle Thick *ENG [–9 to 5 / -1 / 1 mm/step] G188/G189 8-12 SM Appendix...
  • Page 425 029 By-pass: Thick 1: 1200 *ENG 030 Duplex: Plain: 1200 *ENG [–9 to 5 / 0 / 1 mm/step] 031 Duplex: Middle Thick: 1200 *ENG 032 Duplex: Thick 1: 1200 *ENG [–9 to 5 / -2 / 1 mm/step] SM Appendix 8-13 G188/G189...
  • Page 426 Feed or Fusing Temp: Heating Roller Temperature 1104 Specifies the threshold temperature for the paper feed waiting in each mode. The machine does not feed paper until the temperature of the pressure or heating roller reaches temperatures specified by the following SPs. G188/G189 8-14 SM Appendix...
  • Page 427 [0 to 100 / 5 / 1 deg/step] *ENG Ready: Offset Feed: Middle Thick: *ENG Standby: Offset Feed: Thick: Ready: *ENG [0 to 100 / 100 / 1 deg/step] Offset Feed: Thick: Standby: *ENG [0 to 100 / 5 / 1 deg/step] Offset SM Appendix 8-15 G188/G189...
  • Page 428 033 Offset: Feed Start: Glossy *ENG 1bin: Paper Feed: *ENG [20 to 120 / 90 / 1 deg/step] Pressure Temp Specifies the threshold of the pressure roller for the paper feed to the 1bin tray G188/G189 8-16 SM Appendix...
  • Page 429 Sets the upper limit temperature of the heating roller at the end of the heating roller. This value is one of the thresholds to determine if the machine is at the heating roller target temperature during warm-up. 012 Stand-By: Pressure * ENG [60 to 130 / 90 / 1 deg/step] SM Appendix 8-17 G188/G189...
  • Page 430 *ENG [140 to 190 / 160 / 1 deg /step] 056 OHP: FC: Simplex *ENG 057 OHP: BW: Simplex *ENG 058 Special 1: FC: Simplex *ENG [120 to 190 / P2c: 165, P2d: 170 / 1 G188/G189 8-18 SM Appendix...
  • Page 431 093 Envelop: FC *ENG 094 Envelop: BW *ENG Middle Thick: Middle [120 to 170 / 165 / 1 deg /step] *ENG Speed: FC: Simplex Middle Thick: Middle *ENG Speed: FC: Duplex Middle Thick: Middle *ENG Speed: BW: Simplex SM Appendix 8-19 G188/G189...
  • Page 432 [120 to 170 / 150 / 1 deg/step] 141 F: Thick1: BW: Simplex *ENG 142 Glossy: Plain1 *ENG [120 to 170 / 135 / 1 deg/step] 144 Glossy: Plain2 *ENG [120 to 170 / 140 / 1 deg/step] G188/G189 8-20 SM Appendix...
  • Page 433 *ENG [10 to 32 / 17 / 1 deg/step] 006 Auto Off Timer *ENG [0 to 255 / 0 / 1 min/step] [7 to 60 / P2c: 14.0, P2d: 24.0 / 0.1 007 Time *ENG sec/step] SM Appendix 8-21 G188/G189...
  • Page 434 Adjusts the time when the pressure roller moves from the pressing position to the no-pressing positon. 002 Feed Pressure: 1 *ENG Not used 003 Feed Pressure: 2 * ENG [0 to 700 / 0 / 1 msec/step] 004 Feed Pressure: 3 * ENG 005 SC Detection * ENG G188/G189 8-22 SM Appendix...
  • Page 435 [0 to 15 / 10 / 1 deg/step] 010 Reference Temp Correction b *ENG [0 to 15 / 0 / 1 deg/step] 011 High Temp Correction b *ENG [0 to 15 / 0 / 1 deg/step] SM Appendix 8-23 G188/G189...
  • Page 436 Specifies the idling time without the lamp on after job end. This idling prevents the heating roller overheating after job end. 1118 [Curl Temperature Correction] [0 or 1 / 0 / 1] 001 ON/OFF *ENG 0: OFF, 1: ON G188/G189 8-24 SM Appendix...
  • Page 437 008 Shift Time f *ENG [0 to 1200 /50 / 1 sec/step] 009 Shift Time g *ENG [0 to 1200 / 0 / 1 sec/step] 010 Shift Time h *ENG [0 to 1200 / 40 / 1 sec/step] SM Appendix 8-25 G188/G189...
  • Page 438 [1 to 240 / 5 / 1 K/step] Adjusts the execution interval for the fusing cleaning mode. 1K= 100 sheets 006 Count when operating *ENG [0 to 240,000 / - / 1 page/step] 1159 [Fusing Jam Detection] G188/G189 8-26 SM Appendix...
  • Page 439 [–4 to 4 / 0.0 / 0.1 %/step] 014 Duplex CW:Middle Thick:High *ENG 015 Duplex CW:Thick1:Low *ENG 016 Duplex CW:Thick1:Mid *ENG 017 Duplex CW:Thick2:Low *ENG 018 Duplex CW:Thick3:Low *ENG 019 Duplex CCW:Normal:High *ENG [–4 to 4 / 0.0 / 0.1 %/step] SM Appendix 8-27 G188/G189...
  • Page 440 041 Feed:Thick 2:Low *ENG [–2 to 2 / –1.1 / 0.1 %/step] 042 Feed:Thick 3:Low *ENG 043 Bridge Motor:Low *ENG [–4 to 4 / 0 / 0.1 %/step] 044 Bridge Motor:Mid *ENG 045 Bridge Motor:High *ENG G188/G189 8-28 SM Appendix...
  • Page 441 [–30 to 30 / 10 / 5 %/step] 079 Fusing Exit Motor: 1200 *ENG [–4 to 4 / 2.1 / 0.01 %/step] [0 or 1 / 1 / 1] Drum Adjust *ENG 0: Off, 1: On Enables or disables the drum amplitude adjustment. SM Appendix 8-29 G188/G189...
  • Page 442 [– 2 to 2 / -1.1 / 0.1 %/step] 127 Long:Regi:Thck2:L *ENG 128 Long:Regi:Thck3:L *ENG 129 Long:Fuse:Plain:H *ENG [– 2 to 2 / 1.9 / 0.01 %/step] 130 Long:Fuse:Plain:L *ENG [– 4 to 4 / 2.1 / 0.01 %/step] G188/G189 8-30 SM Appendix...
  • Page 443 0: Off, 1: On 1907 [Paper Feed Timing Adj.] DFU 002 Feed Solenoid ON: Plain *ENG [–10 to 40 / 0 / 2.5 mm/step] 003 Feed Clutch OFF: Plain *ENG [–10 to 10 / 0 / 1 mm/step] SM Appendix 8-31 G188/G189...
  • Page 444 *ENG [–10 to 10 / 0 / 1 mm/step] 013 1 Bin Junction Gate Sol-OFF *ENG 015 Junction Gate SOL1:ON:Plain *ENG 016 Junction Gate SOL1:ON:Thick *ENG 017 Junction Gate SOL1:OFF:Plain *ENG 018 Junction Gate SOL1:OFF:Thick *ENG G188/G189 8-32 SM Appendix...
  • Page 445 [0 to 50 / P2c: 0, P2d: 0 / 1 deg/step] 012 Offset: Plain: Standby *ENG [0 to 50 / 0 / 1 deg/step] Offset: Middle Thick: *ENG [0 to 50 / 20 / 1 deg/step] Ready SM Appendix 8-33 G188/G189...
  • Page 446 [0 to 100 / 25 / 1 deg/step] 033 D2: Plain: BW: Offset *ENG [0 to 100 / 27 / 1 deg/step] 034 D3: Plain: BW: Offset *ENG [0 to 100 / 30 / 1 deg/step] G188/G189 8-34 SM Appendix...
  • Page 447 [20 to 40 / P2c: 25 / 1 cpm/step] 049 D3: Plain :FC : CPM *ENG [20 to 50 / P2d: 35 / 1 cpm/step] 050 D1: Middle Thick: BW: *ENG [20 to 40 / P2c: 35 / 1 cpm/step] SM Appendix 8-35 G188/G189...
  • Page 448 068 D1: Paper Width1: CPM *ENG [10 to 50 / P2d: 20 / 5 cpm/step] [10 to 40 / P2c: 20/ 5 cpm/step] 069 D2: Paper Width1: CPM *ENG [10 to 50 / P2d: 20 / 5 cpm/step] G188/G189 8-36 SM Appendix...
  • Page 449 002 Specifies the limit sheets of outputs for initializing the home position of the ferrite roller. When the outputs are more than 500 sheets of paper, the machine starts to find the home position of the ferrite roller. SM Appendix 8-37 G188/G189...

  • Page 450: Sp2-Xxx (Drum)

    SP3-041-1, the values in these SP modes are used for printing. 001 Plain: Bk *ENG [0 to 1000 / 690 / 10 –V/step] 002 Plain: M *ENG 003 Plain: C *ENG 004 Plain: Y *ENG G188/G189 8-38 SM Appendix...
  • Page 451 (SP2-007-xxx to SP2-011-xxx). These SPs are activated only when SP2-012-1 is set to "1: manual control". 001 Plain: Bk *ENG [0 to 3 / 2.1 / 0.01 KV/step] 002 Plain: M *ENG 003 Plain: C *ENG 004 Plain: Y *ENG SM Appendix 8-39 G188/G189...
  • Page 452 Displays/sets the AC current target of the charge roller for ML environment (Meddle temperature and Low humidity). DFU 001 Environmental Target: Bk *ENG [0 to 3 / P2c: 1.49, P2d: 1.68 / 0.01 mA/step] 002 Environmental Target: M *ENG 003 Environmental Target: C *ENG G188/G189 8-40 SM Appendix...
  • Page 453 Displays/sets the AC current target of the charge roller for HH environment (High temperature and High humidity). DFU 001 Environmental Target: Bk *ENG [0 to 3 / P2c: 1. 66, P2d: 1.85 / 0.01 mA/step] 002 Environmental Target: M *ENG SM Appendix 8-41 G188/G189...
  • Page 454 LL and ML. Threshold 1 [0 to 100 / 4.3 / 0.01 g/m /step] Changes the humidity threshold Absolute Humidity: *ENG between ML and MM. Threshold 2 [0 to 100 / 11.3 / 0.01 g/m /step] G188/G189 8-42 SM Appendix...
  • Page 455 Specifies the charge AC control interval or thresholod for each condition. 001 Exec Interval: Power ON *ENG [0 to 2000 / 500 / 1 page/step] 002 Exec Interval: Print *ENG 003 Page Interval *ENG [0 to 500 / 10 / 5 page/step] SM Appendix 8-43 G188/G189...
  • Page 456 Housing Unit" in the "Replacement and Adjustment" section. The value should be provided with the new laser optics housing unit. 001 Main Dot: Bk *ENG [–512 to 511 / 0 / 1 dot/step] 002 Main Dot: M *ENG G188/G189 8-44 SM Appendix...
  • Page 457 Main Mag.: High Speed: *ENG Main Mag.: Medium *ENG Speed: M Main Mag.: Low Speed: *ENG Main Mag.: High Speed: *ENG Main Mag.: Medium *ENG Speed: C 009 Main Mag.: Low Speed: C *ENG Main Mag.: High Speed: *ENG SM Appendix 8-45 G188/G189...
  • Page 458 *ENG [0 to 4 / 0.8 / 0.1 mm/step] 013 Duplex Trail. S Size:Thick *ENG [0 to 4 / 0.6 / 0.1 mm/step] 014 Duplex Left Edge:Thick *ENG [0 to 1.5 / 0.3 / 0.1 mm/step] G188/G189 8-46 SM Appendix...
  • Page 459 011 Low Speed: C *ENG 012 Low Speed: Y *ENG 2106 [Polygon Rotation Time] Adjusts the time of the polygon motor rotation. DFU 001 Warming-Up *ENG [0 to 60 / 10 / 1 sec/step] 002 Job End *ENG SM Appendix 8-47 G188/G189...
  • Page 460 1: All colors, 2: Magenta, 3: Yellow, 4: Cyan 006 Density: Bk Specifies the color density for the test pattern. 007 Density: M [0 to 15 / 15 / 1 /step] 008 Density: C 0: Lightest density 15: Darkest density 009 Density: Y G188/G189 8-48 SM Appendix...
  • Page 461 SC285 occurs. For details, see "Laser Optics Housing Unit" in the "Replacement and Adjustment" section. 001 Pulse: M *ENG [–50 to 50 / 0 / 1 pulse/step] 002 Pulse: C *ENG 003 Pulse: Y *ENG SM Appendix 8-49 G188/G189...
  • Page 462 Bk, M, C, Y: ID sensors for the process control Front, Center, Rear: ID sensors for the automatic line position adjustment 001 Bk *ENG [0 to 1024 / 0 / 1/step] 002 M *ENG 003 C *ENG G188/G189 8-50 SM Appendix...
  • Page 463 Bk, M, C, Y: ID sensors for the process control Front, Center, Rear: ID sensors for the automatic line position adjustment 001 Maximum: Bk *ENG [0 to 5.5 / 0 / 0.01V/step] 002 Maximum: M *ENG 003 Maximum: C *ENG 004 Maximum: Y *ENG SM Appendix 8-51 G188/G189...
  • Page 464 Front, Center, Rear: ID sensors for the automatic line position adjustment 001 Maximum 2: Bk *ENG [0 to 5.5 / 0 / 0.01V/step] 002 Maximum 2: M *ENG 003 Maximum 2: C *ENG 004 Maximum 2: Y *ENG 005 Maximum 2: Front *ENG G188/G189 8-52 SM Appendix...
  • Page 465 *ENG [-256 to 255 / 0 / 1sub-dot/step] 028 Area1: Bk *ENG Adjusts the area magnification for LD 0. [–256 to 255 / 0 / 1 sub-dot/step ] 029 Area2: Bk *ENG 030 Area3: Bk *ENG SM Appendix 8-53 G188/G189...
  • Page 466 046 Area6: Bk *ENG 047 Area7: Bk *ENG 048 Area8: Bk *ENG 049 Area9: Bk *ENG 050 Area10: Bk *ENG Not used 051 Area11: Bk *ENG 052 Area12: Bk *ENG 079 Area0: M *ENG Not used G188/G189 8-54 SM Appendix...
  • Page 467 Adjusts the area magnification for LD 1. [–256 to 255 / 0 / 1 sub-dot/step] 097 Area5: Bk *ENG 098 Area6: Bk *ENG 099 Area7: Bk *ENG 100 Area8: Bk *ENG 101 Area9: Bk *ENG Not used 102 Area10: Bk *ENG SM Appendix 8-55 G188/G189...
  • Page 468 Adjusts the area magnification for LD 1. [–256 to 255 / 0 / 1 sub-dot/step] 146 Area2: C *ENG 147 Area3: C *ENG 148 Area4: C *ENG 149 Area5: C *ENG 150 Area6: C *ENG 151 Area7: C *ENG G188/G189 8-56 SM Appendix...
  • Page 469 196 Area0: Y *ENG Not used 197 Area1: Y *ENG Adjusts the area magnification for LD 1. [–256 to 255 / 0 / 1 sub-dot/step] 198 Area2: Y *ENG 199 Area3: Y *ENG 200 Area4: Y *ENG SM Appendix 8-57 G188/G189...
  • Page 470 [50 to 150 / 100 / 1 %/step] 003 Area 2: Bk *ENG 004 Area 3: Bk *ENG 005 Area 4: Bk *ENG 006 Area 5: Bk *ENG 007 Area 6: Bk *ENG 008 Area 7: Bk *ENG 009 Area 8: Bk *ENG G188/G189 8-58 SM Appendix...
  • Page 471 [50 to 150 / 100 / 1 %/step] 041 Area 8: M *ENG 042 Area 9: M *ENG 043 Area 10: M *ENG 044 Area 11: M *ENG 045 Area 12: M *ENG 046 Area 13: M *ENG 047 Area 14: M *ENG SM Appendix 8-59 G188/G189...
  • Page 472 [50 to 150 / 100 / 1 %/step] This is for the synchronizing detection 097 Area 0: Y *ENG board. [50 to 150 / 100 / 1 %/step] 098 Area 1: Y *ENG [50 to 150 / 100 / 1 %/step] G188/G189 8-60 SM Appendix...
  • Page 473 Adjusts the width of the vertical line. 001 600dpi:Bk *ENG [10 to 15 / 15 / 1 /step] 002 600dpi:Ma *ENG 003 600dpi:Cy *ENG 004 600dpi:Ye *ENG 005 1200dpi:Bk *ENG 006 1200dpi:Ma *ENG 007 1200dpi:Cy *ENG SM Appendix 8-61 G188/G189...
  • Page 474 [–5000 to 5000 / 0 / 0.001 um/step] 004 Bent: M *ENG 005 M. Scan Erro.: Left: M *ENG [–5000 to 5000 / 0 / 0.001 um/step] 006 M. Scan Erro.: Center: M *ENG 007 M. Scan Erro.: Right: M *ENG G188/G189 8-62 SM Appendix...
  • Page 475 *ENG 028 S. Scan Erro.: Right: C *ENG 029 M. Cor.: Dot: C *ENG [–512 to 511 / 0 / 1 dot/step] 030 M. Cor.: Subdot: C *ENG [–15 to 15 / 0 / 1 pulse/step] SM Appendix 8-63 G188/G189...
  • Page 476 [–32768 to 32767 / 0 / 1 pulse/step] 051 M. Left Mag.: Subdot: Y *ENG 052 M. Right Mag.: Subdot: Y *ENG 053 S. Cor.: 600 Line: Y *ENG [–16384 to 16383 / 0 / 1 line/step] G188/G189 8-64 SM Appendix...
  • Page 477 [-15 to 15 / 0 / 1 pulse/step] 012 M. Scan: Medium: Dot: C *ENG [-512 to 511 / 0 / 1 dot/step] 013 M. Scan: Medium: Subdot: C *ENG [-15 to 15 / 0 / 1 pulse/step] SM Appendix 8-65 G188/G189...
  • Page 478 [-16384 to 16383 / 0 / 1 line/step] 035 S. Scan: High: Subline: Y *ENG [–1 to 1 / 0 / 0.001 /line] 036 S. Scan: Medium: Line: Y *ENG [-16384 to 16383 / 0 / 1 line/step] G188/G189 8-66 SM Appendix...
  • Page 479 011 Execute: Medium: Y 012 Execute: Low: Y 2184 [Main Scan Length Detection Target] DFU 001 Execute: Bk 002 Execute: M Executes the target value for the main scan length detection. 003 Execute: C 004 Execute: Y SM Appendix 8-67 G188/G189...
  • Page 480 *ENG 002 Paper Int. Mag.: Subdot: M *ENG [0 or 1 / 1 / 1/step] 003 Paper Int. Mag.: Subdot: C *ENG 004 Paper Int. Mag.: Subdot: Y *ENG 005 M. Scan Mag.: Subdot: M *ENG G188/G189 8-68 SM Appendix...
  • Page 481 [–131071 to 131071 / 84 / 1 bit/step] 009 ch 0: Filter: Rear: b1 *ENG [–131071 to 131071 / 168 / 1 bit/step] 010 ch 0: Filter: Rear: b2 *ENG [–131071 to 131071 / 84 / 1 bit/step] SM Appendix 8-69 G188/G189...
  • Page 482 *ENG [0 to 3 / 3 / 1/step] [MUSIC Threshold Setting] Line Position Adjustment: Threshold Setting DFU 2192 ch 0: ID sensor at rear, ch 1: ID sensor at center, ch 2: ID sensor at front G188/G189 8-70 SM Appendix...
  • Page 483 Adjusts the threshold of the line position adjustment for color printing mode after job end. Page: Interrupt: BW+FC *ENG [0 to 999 / 200 / 1 page/step] Adjusts the threshold of the line position adjustment for BW and color printing SM Appendix 8-71 G188/G189...
  • Page 484 MUSIC, then MSUIC is done again. Temp. 2 *ENG [0 to 100 / 10 / 1deg/step] Adjust the temperature change threshold for the line position adjustment (Mode G188/G189 8-72 SM Appendix...
  • Page 485 [0 to 999999 / 0 / 1 times/step] 009 Number of Failure *ENG [0 to 999999 / 0 / 1 times/step] 010 Error Result: M *ENG [0 to 9 / 0 / 1 /step] 0: Not done 011 Error Result: C *ENG SM Appendix 8-73 G188/G189...
  • Page 486 These SPs are activated only when SP3-041-002 is set to "0". Plain: 205 (P2c)/230 (P2d) mm/sec, Thick 1: 154 mm/sec, Thick 2&Fine: 77 mm/sec 001 Plain: Bk *ENG [0 to 200 / 100 / 1%/step] Increasing this value makes the image 002 Plain: M *ENG G188/G189 8-74 SM Appendix...
  • Page 487 Plain: 205 (P2c)/230 (P2d) mm/sec, Thick 1: 154 mm/sec, Thick 2&Fine: 77 mm/sec 001 Plain: Bk *ENG [0 to 800 / 550 / 10 –V/step] 002 Plain: M *ENG 003 Plain: C *ENG 004 Plain: Y *ENG 005 Thick 1: Bk *ENG 006 Thick 1: M *ENG SM Appendix 8-75 G188/G189...
  • Page 488 [0 to 6 / 0 / 1 /step] 0: Automatic environment control 1: LL (Low temperature/ Low humidity) 002 Forced Setting *ENG 2: ML (Middle temperature/ Low humidity) 3: MM (Middle temperature/ Middle humidity) 4: MH (Middle temperature/ High humidity) G188/G189 8-76 SM Appendix...
  • Page 489 *ENG Paper is detected as "S3" size. [0 to 350 / 148 / 1 mm/step] Threshold 4 ≤ paper ≤ Threshold 3: 004 Threshold 4 *ENG Paper is detected as "S4" size. Paper ≤ Threshold 4: SM Appendix 8-77 G188/G189...
  • Page 490 Plain: 205 (P2c)/230 (P2d) mm/sec, Thick 1: 154 mm/sec, Thick 2&Fine: 77 2351 mm/sec [0 to 80 / P2c: 33, P2d: 37 / 1 μA] ITB unit: Plain *ENG Adjusts the current for the image transfer belt in B/W mode for plain paper. G188/G189 8-78 SM Appendix...
  • Page 491 Adjusts the current for the image transfer belt for Black in full color mode for thick 1 paper. [0 to 80 / 22 / 1 μA] ITB unit: Thick 1: M *ENG Adjusts the current for the image transfer belt for Magenta in full color mode for thick 1 paper. SM Appendix 8-79 G188/G189...
  • Page 492 002 ITB unit: Thick 1 *ENG 003 ITB unit: Thick 2 *ENG 004 ITB unit: Plain: Bk *ENG [1 to 60 / 13/ 1 /step] 005 ITB unit: Plain: M *ENG [1 to 60 / 2 / 1 /step] G188/G189 8-80 SM Appendix...
  • Page 493 [0 to 4000 / 2000 / 10 –V/step] Page Separation DC: 1200: 2nd *ENG [0 to 4000 / 3000 / 10 –V/step] side [Plain: Bias: BW] 2403 Adjusts the current for the paper transfer roller for plain paper in black-and-white mode. SM Appendix 8-81 G188/G189...
  • Page 494 Adjusts the size correction coefficient for the paper transfer roller current for 2411 each paper size. SP2403 and SP2407 are multiplied by these SP values. Plain: 205 (P2c)/230 (P2d) mm/sec, 1200: 77 mm/sec [100 to 600 / 100 / 5%/step] 001 Paper Transfer: Plain : *ENG G188/G189 8-82 SM Appendix...
  • Page 495 Paper Transfer: 2nd side: *ENG [100 to 600 / 300 / 5%/step] 1200: S3 Paper Transfer: Plain: 1st [100 to 600 / 115 / 5%/step] *ENG 210 mm ≥ S4 size ≥ 148 mm (Paper Side: S4 SM Appendix 8-83 G188/G189...
  • Page 496 Paper Transfer: Plain: *ENG [0 to 400 / 100 / 5%/step] 1st Side Paper Transfer: Plain: *ENG [0 to 400 / 100 / 5%/step] 2nd Side [0 to 400 / 100 / 5%/step] 003 Paper Transfer: 1200: *ENG G188/G189 8-84 SM Appendix...
  • Page 497 Plain: 205 (P2c)/230 (P2d) mm/sec, 1200: 77 mm/sec Paper Transfer: Plain: 1st [0 to 50 / 0 / 2 mm/step] *ENG Side Paper Transfer: Plain: *ENG 2nd Side Paper Transfer: 1200: 1st *ENG Side Paper Transfer: 1200: *ENG 2nd side SM Appendix 8-85 G188/G189...
  • Page 498 Paper Transfer: Plain: *ENG 2nd Side Paper Transfer: 1200: 1st *ENG Side Paper Transfer: 1200: *ENG 2nd side Separation DC: Plain: 1st *ENG Page Separation DC: Plain: *ENG 2nd Page 007 Separation DC: 1200: 1st *ENG G188/G189 8-86 SM Appendix...
  • Page 499 [1 to 60 / 11 / 1 /step] 005 Paper Transfer: FC: 1st Side *ENG [1 to 60 / 39 / 1 /step] 006 Paper Transfer: FC: 2nd Side *ENG [1 to 60 / 14 / 1 /step] SM Appendix 8-87 G188/G189...
  • Page 500 Adjusts the current for the paper transfer roller for thin paper in full color mode. Plain: 205 (P2c)/230 (P2d) mm/sec, 1200: 77 mm/sec [0 to 250 / P2c: 40, P2d: 45 / 1 001 Paper Transfer: Plain: 1st Side *ENG –μA /step] G188/G189 8-88 SM Appendix...
  • Page 501 The paper leading edge area can be adjusted with SP2472. 001 Paper Transfer: Plain: 1st Side *ENG [0 to 400 / 100 / 5%/step] 003 Paper Transfer: 1200: 1st Side *ENG 005 Separation DC: Plain: 1st Side *ENG SM Appendix 8-89 G188/G189...
  • Page 502 *ENG [0 to 400 / 100 / 5%/step] 005 Separation DC: Plain: 1st Side *ENG [0 to 400 / 100 / 5%/step] 007 Separation DC: 1200: 1st Page *ENG [0 to 400 / 100 / 5%/step] G188/G189 8-90 SM Appendix...
  • Page 503 [1 to 60 / 1 / 1 /step] Side 2481 [Glossy: Bias] Separation DC: Glossy: 1st *ENG [0 to 4000 / 2000 / 10 –V/step] Side Adjusts the DC voltage of the discharge plate for glossy paper. SM Appendix 8-91 G188/G189...
  • Page 504 [100 to 600 / 180 / 5%/step] Side: S5 2485 [Glossy: Leading Edge Correction] Paper Transfer: Glossy: 1st *ENG [10 to 400 / 100 / 5%/step] Side 005 Separation DC: Glossy: 1st *ENG [10 to 400 / 100 / 5%/step]] G188/G189 8-92 SM Appendix...
  • Page 505 [1 to 60 / 26 / 1 /step] Page 003 Paper Transfer: BW: 1st Side *ENG [1 to 60 / 11 / 1 /step] 005 Paper Transfer: BW: 2nd Side *ENG [1 to 60 / 1 / 1 /step] SM Appendix 8-93 G188/G189...
  • Page 506 Paper Transfer: Thick 1: 1st *ENG Side [0 to 250 / 30 / 1 –μA /step] Paper Transfer: Thick 1: 2nd *ENG Side 003 Separation DC: 1200: 1st Side *ENG [0 to 250 / 15 / –μA /step] G188/G189 8-94 SM Appendix...
  • Page 507 Paper Transfer: 1200: 1st Side: 275 mm ≥ S3 size ≥ 210 mm *ENG (Paper width) Paper Transfer: Thick 1: 1st [100 to 600 / 115 / 5%/step] *ENG 210 mm ≥ S4 size ≥ 148 mm Side: S4 SM Appendix 8-95 G188/G189...
  • Page 508 Side 003 Paper Transfer: 1200: 1st Side *ENG [0 to 400 / 100 / 5%/step] Separation DC: Thick 1: 1st *ENG Side [0 to 400 / 100 / 5%/step] Separation DC: Thick 1: 2nd *ENG Side G188/G189 8-96 SM Appendix...
  • Page 509 Thick 1: 154 mm/sec, 1200: 77 mm/sec The paper trailing edge area can be adjusted with SP2524. Paper Transfer: Thick 1: 1st [0 to 400 / 100 / 5%/step] *ENG Side Paper Transfer: Thick 1: 2nd *ENG Side SM Appendix 8-97 G188/G189...
  • Page 510 003 Paper Transfer: Thick 1: BW: 1st Side *ENG [1 to 60 / 11 / 1 /step] 004 Paper Transfer: Thick 1: BW:2nd Side *ENG 005 Paper Transfer: Thick 1: FC: 1st Side *ENG [1 to 60 / 1 / 1 /step] G188/G189 8-98 SM Appendix...
  • Page 511 Adjusts the size correction coefficient for the paper transfer roller current for each paper size. SP2553 and SP2558 are multiplied by these SP values. 001 Paper Transfer: 1st Side: S1 *ENG [100 to 600 / 100 / 5%/step] SM Appendix 8-99 G188/G189...
  • Page 512 SP2553 and SP2558 are multiplied by these SP values. The paper leading edge area can be adjusted with SP2572. 001 Paper Transfer: 1st Side *ENG [0 to 400 / 100 / 5%/step] G188/G189 8-100 SM Appendix...
  • Page 513 [0 to 400 / 100 / 5%/step] 002 Paper Transfer: 2nd Side *ENG 003 Separation DC: 1st Page *ENG [0 to 400 / 100 / 5%/step] 004 Separation DC: 2nd Page *ENG [0 to 400 / 100 / 5%/step] SM Appendix 8-101 G188/G189...
  • Page 514 [0 to 4000 / 1000 / 10 –V/step] [OHP: Bias: BW] 2603 Adjusts the current for the paper transfer roller for OHP in black-and-white mode. 001 Paper Transfer *ENG [0 to 250 / 12 / 1 –μA /step] G188/G189 8-102 SM Appendix...
  • Page 515 [0 to 400 / 100 / 5%/step] Adjusts the correction to the discharge plate current at the paper leading edge in each mode. SP2601 is multiplied by these SP values. 2621 The paper leading edge area can be adjusted with SP2622. SM Appendix 8-103 G188/G189...
  • Page 516 [0 to 50 / 0 / 2 mm/step] 2630 [OHP: Environment Correction] 001 Separation DC *ENG [1 to 60 / 22 / 1 /step] 002 Paper Transfer: BW *ENG [1 to 60 / 11 / 1 /step] G188/G189 8-104 SM Appendix...
  • Page 517 S1 size ≥ 297 mm (Paper 001 Paper Transfer: 1st Side: S1 *ENG width) [100 to 600 / 100 / 5%/step] 002 Paper Transfer: 1st Side: S2 *ENG 297 mm ≥ S2 size ≥ 275 mm SM Appendix 8-105 G188/G189...
  • Page 518 [Thick 3: Leading Edge Correction] Thick 3 Paper: Leading Edge Correction Adjusts the correction to the paper transfer roller current at the paper leading 2654 edge in each mode. SP2651 and SP2652 are multiplied by these SP values. G188/G189 8-106 SM Appendix...
  • Page 519 SP2651 and SP2652 are multiplied by these SP values. The paper trailing edge area can be adjusted with SP2657. 001 Paper Transfer: 1st Side *ENG [0 to 400 / 100 / 5%/step] 002 Paper Transfer: 2nd Side *ENG 003 Separation DC: 1st Page *ENG SM Appendix 8-107 G188/G189...
  • Page 520 [1 to 60 / 55 / 1 /step] 006 Paper Transfer: FC: 2st Side *ENG [1 to 60 / 11 / 1 /step] [Thick4: Bias] 2670 Adjusts the DC voltage of the discharge plate for thick paper 4. G188/G189 8-108 SM Appendix...
  • Page 521 007 PTR:TH4:1st:S2 *ENG width) 009 PTR:TH4:1st:S3 *ENG [100 to 600 / 140 / 5%/step] 275 mm ≥ S3 size ≥ 210 mm (Paper 011 PTR:TH4:1st:S3 *ENG width) 013 PTR:TH4:1st:S4 *ENG [100 to 600 / 160 / 5%/step] SM Appendix 8-109 G188/G189...
  • Page 522 [0 to 400 / 100 / 5%/step] 007 Sep DC:TH4:1st *ENG [Thick 4:LE:Timing] Adjusts the bias/ voltage switch timing of the paper transfer roller/ discharge 2675 plate at the paper leading edge between the erase margin area and the image area. G188/G189 8-110 SM Appendix...
  • Page 523 [0 to 50 / 0 / 1 mm/step] 005 Sep DC:TH4:1st *ENG 007 Sep DC:FINE:1st *ENG [Thick 4:Env Cor] Thick 4 Paper: MM Environment Coefficient Adjustment 2678 Adjusts the environment coefficient for each mode. When the environment is SM Appendix 8-111 G188/G189...
  • Page 524 [Thick5:Size Cor] 2693 Adjusts the size correction coefficient for the paper transfer roller current for each paper size. SP2691 and SP2692 are multiplied by these SP values. 001 PTR:1st:S1 *ENG [100 to 600 / 100 / 5%/step] G188/G189 8-112 SM Appendix...
  • Page 525 [0 to 400 / 100 / 5%/step] [Thick 5:LE:Timing] Adjusts the bias/ voltage switch timing of the paper transfer roller/ discharge 2695 plate at the paper leading edge between the erase margin area and the image area. SM Appendix 8-113 G188/G189...
  • Page 526 [1 to 60 / 11 / 1 /step] 005 PTR:TH5:FC:1st *ENG [1 to 60 / 1 / 1 /step] [Special1: Bias] 2751 Adjusts the DC voltage of the discharge plate for special paper 1. Plain: 205 (P2c)/230 (P2d) mm/sec, Fine: 77 mm/sec G188/G189 8-114 SM Appendix...
  • Page 527 [0 to 250 / 15 / 1 –μA /step] [Special1: Paper Size Correction] 2761 Adjusts the size correction coefficient for the paper transfer roller current for each paper size. SP2753 and SP2757 are multiplied by these SP values. SM Appendix 8-115 G188/G189...
  • Page 528 Adjusts the correction to the paper transfer roller current at the paper leading 2771 edge in each mode. SP2753 and SP2757 are multiplied by these SP values. Plain: 205 (P2c)/230 (P2d) mm/sec, 1200: 77 mm/sec The paper leading edge area can be adjusted with SP2772. G188/G189 8-116 SM Appendix...
  • Page 529 [Special 1: Trailing Edge Correction] Special 1 Paper: Trailing Edge Correction 2773 Adjusts the correction to the paper transfer roller current for the paper trailing edge in each mode. SP2753 and SP2757 are multiplied by these SP values. SM Appendix 8-117 G188/G189...
  • Page 530 Plain: 205 (P2c)/230 (P2d) mm/sec, 1200: 77 mm/sec 001 Separation DC: Plain: 1st Side *ENG [1 to 60 / 26 / 1 /step] 002 Separation DC: Plain: 2nd Side *ENG [1 to 60 / 32 / 1 /step] G188/G189 8-118 SM Appendix...
  • Page 531 003 Separation DC: 1200: 1st Side *ENG [0 to 200 / 11 / 1 –μA /step] [Special2: Bias: FC] 2807 Adjusts the current for the paper transfer roller for special paper 2 in full color mode. SM Appendix 8-119 G188/G189...
  • Page 532 Paper Transfer: Plain: 2nd Side: 275 mm ≥ S3 size ≥ 210 mm *ENG (Paper width) Paper Transfer: Plain: 1st Side: [100 to 600 / 160 / 5%/step] *ENG 210 mm ≥ S4 size ≥ 148 mm G188/G189 8-120 SM Appendix...
  • Page 533 The paper leading edge area can be adjusted with SP2822. 005 Separation DC: Plain: 1st Side *ENG [0 to 400 / 100 / 5%/step] 006 Separation DC: Plain: 2nd Side *ENG 007 Separation DC: 12001st Side *ENG 2822 [Special 2: Switch Timing: Lead. Edge] SM Appendix 8-121 G188/G189...
  • Page 534 005 Separation DC: Plain: 1st Side *ENG 006 Separation DC: Plain: 2nd Side *ENG 007 Separation DC: 1200: 1st Side *ENG [Special 2: Switch Timing: Trail. Edge] 2824 Adjusts the bias/voltage switch timing of the paper transfer roller/discharge G188/G189 8-122 SM Appendix...
  • Page 535 011 Paper Transfer: 1200: FC: 1st Side *ENG [1 to 60 / 1 / 1 /step] [Special 3: Bias] 2851 Adjusts the DC voltage of the discharge plate for special paper 3. Thick 1: 154 mm/sec, 1200: 77 mm/sec SM Appendix 8-123 G188/G189...
  • Page 536 [0 to 250 / 15 / 1 –μA /step] [Special 3: Paper Size Correction] 2861 Adjusts the size correction coefficient for the paper transfer roller current for each paper size. SP2852 and SP2857 are multiplied by these SP values. G188/G189 8-124 SM Appendix...
  • Page 537 Paper Transfer: Thick 1: 1st Side: 148 mm ≥ S5 size (Paper *ENG width) [100 to 600 / 180 / 5%/step] Paper Transfer: Thick 1: 2nd 148 mm ≥ S5 size (Paper *ENG Side: S5 width) SM Appendix 8-125 G188/G189...
  • Page 538 001 Paper Transfer: Thick 1: 1st Side *ENG [0 to 50 / 0 / 2 mm/step] 002 Paper Transfer: Thick 1: 2nd Side *ENG 003 Paper Transfer: 1200: 1st Side *ENG 005 Separation DC: Thick 1: 1st Side *ENG G188/G189 8-126 SM Appendix...
  • Page 539 [0 to 50 / 0 / 2 mm/step] 002 Paper Transfer: Thick 1: 2nd Side *ENG 003 Paper Transfer: 1200: 1st Side *ENG 005 Separation DC: Thick 1: 1st Side *ENG 006 Separation DC: Thick 1: 2nd Side *ENG SM Appendix 8-127 G188/G189...
  • Page 540 003 Thick 2 & FINE *ENG [OPC Drum Reverse Time] 2902 Adjusts the time for how long the OPC drum motor reverses after job end. DFU 001 All: BW *ENG [0 to 200 / 30 / 10 msec/step] G188/G189 8-128 SM Appendix...
  • Page 541 [0 to 359 / 0 / 1 deg/step] 003 M Drum *ENG 004 K Drum *ENG 2906 [Amplitude Setting] [0 to 100 / 0.0 / 0.1 μm/step] 006 Y Drum *ENG 007 C Drum *ENG 008 M Drum *ENG SM Appendix 8-129 G188/G189...
  • Page 542 002 C Drum *ENG [0 to 359 / 0 / 1 deg/step] 003 M Drum *ENG 004 K Drum *ENG 2912 [Offset Amplitude Setting] DFU [0 to 100 / 0.0 / 0.1 μm/step] 001 Y Drum *ENG G188/G189 8-130 SM Appendix...
  • Page 543 Adjusts the threshold between high resistance (division 1) and low resistance (division 2) at the paper transfer roller. This SP affects SP2931 to SP2939. 001 Voltage *ENG [0 to 7000 / 6000 / 10 –V/step] 2960 [Process Interval] SM Appendix 8-131 G188/G189...
  • Page 544 Executes the toner density adjustment 002 Density Adjustment manually. Executes the process control that is normally done before ACC. 003 Pre-ACC The type of process control is selected with SP3-041-004. 004 Full MUSIC Executes the process control that is G188/G189 8-132 SM Appendix...
  • Page 545 [1111 to 99999999 / 99999999 / 1/step] 006 Result: Latest 5 *ENG 007 Result: Latest 6 *ENG 008 Result: Latest 7 *ENG 009 Result: Latest 8 *ENG 010 Result: Latest 9 *ENG 3013 [T Sensor Initial Set: Execution] Developer Initialization Setting SM Appendix 8-133 G188/G189...
  • Page 546 001 Execution: ALL 002 Execution: COL 003 Execution: Bk Executes the manual toner supply to the development unit. 004 Execution: M 005 Execution: C 006 Execution: Y 3016 [Forced Toner Supply: Setting] Forced Toner Supply Setting ([Color]) G188/G189 8-134 SM Appendix...
  • Page 547 [0 to 99 / 0 / 1 times/step] 010 Lower Counter: Bk *ENG 011 Lower Counter: M *ENG 012 Lower Counter: C *ENG 013 Lower Counter: Y *ENG 3021 [TD Sensor Initial Set] Developer Initialization Setting SM Appendix 8-135 G188/G189...
  • Page 548 005-008 Sets the execution flag for the toner supply mode for each color. 005 Execution Flag: Bk *ENG [0 or 1 / 0 / 1/step] 0: Flag OFF, 1: Flag ON 006 Execution Flag: M *ENG G188/G189 8-136 SM Appendix...
  • Page 549 4: Repeat three times (No consumption mode) 5: Repeat three times (Toner is supplied only when the toner density is too low, and toner is consumed only when the toner density is too dark.) 6 to 9: Disabled SM Appendix 8-137 G188/G189...
  • Page 550 [0 to 9 / 4 / 1 time/step] Specifies the maximum number of repeats of the toner density adjustment at job end. 0: Disabled, 1 to 3: Repeat number, 4: Repeat three times (No consumption mode) G188/G189 8-138 SM Appendix...
  • Page 551 T2 Bias: M *ENG [0 to 80 / P2c: 22, P2d: 30/ 1 µA/step] Adjusts the image transfer belt bias for Magenta. 015 T3 Bias: C *ENG [0 to 80 / P2c: 25, P2d: 33/ 1 µA/step] SM Appendix 8-139 G188/G189...
  • Page 552 Adjusts the LD duty for the toner consumption mode at the toner density adjustment. In toner consumption mode, toner is discharged when the detected development gamma values (SP3611-004) exceed the target values (SP3611-008) by more than the specified thresholds (SP3239-009). G188/G189 8-140 SM Appendix...
  • Page 553 006 M Toner Consumption *ENG [0 to 3000 / 0 / 0.001 g/step] 007 C Toner Consumption *ENG 008 Y Toner Consumption *ENG 009-012 Displays the remaining amount of each color toner. These are calculated by SM Appendix 8-141 G188/G189...
  • Page 554 When both this SP and SP3-101-026 occur at same time, toner end is determined. Displays the total delta Vt (Vt-Vtref) value for each color.These are calculated 022-025 by pixel counting. 022 Delta Vt Sum: Bk *ENG [0 to 655 / 0 / 0.01 V/step] G188/G189 8-142 SM Appendix...
  • Page 555 038 End Threshold: C *ENG 039 End Threshold: Y *ENG 040-043 Displays the pixel M/A for each color. 040 Pixel M/A: Bk *ENG [0 to 1 / 0.4 / 0.001 mg/cm /step] 041 Pixel M/A: M *ENG SM Appendix 8-143 G188/G189...
  • Page 556 *ENG 002 Repeat: M *ENG [1 to 20 / 5 / 1 time/step] 003 Repeat: C *ENG 004 Repeat: Y *ENG [TE Count m: Display] 3131 Display the number of toner end detections for each color. G188/G189 8-144 SM Appendix...
  • Page 557 006 Thick 2 & FINE Shift: M *ENG [0 to 5 / P2c: 0.74, P2d: 0.85 / 0.01 V/step] 007 Thick 2 & FINE Shift: C *ENG 008 Thick 2 & FINE Shift: Y *ENG 3221 [Vtcnt: Display/Set] SM Appendix 8-145 G188/G189...
  • Page 558 Displays or adjusts the Vtref value for each color at developer initialization. 005-008 005 Initial: Bk *ENG 006 Initial: M *ENG [0 to 5.5 / 3 / 0.01 V/step] 007 Initial: C *ENG 008 Initial: Y *ENG G188/G189 8-146 SM Appendix...
  • Page 559 [1 to 15 / 9.5 / 0.1 wt%/step] Adjusts the lower limit of the toner 011 Lower: TC *ENG concentration. [1 to 15 / 4 / 0.1 wt%/step] Adjusts the upper limit of the TD sensor 012 Upper Sensitivity *ENG sensitivity. SM Appendix 8-147 G188/G189...
  • Page 560 [0 to 20 / 3 / 0.1 %/step] Adjusts the threshold of the 010 High Coverage: Threshold *ENG high coverage. [0 to 100 / 60 / 1 %/step] 011 TC Upper Limit Correction *ENG [0 to 5 / 0 / 0.1 wt%/step] G188/G189 8-148 SM Appendix...
  • Page 561 [0 to 2.55 / 0.47 / 0.01 /step] 007 Pixel Proportion: C *ENG 008 Pixel Proportion: Y *ENG 009 Vt Integral Control: Bk *ENG [0 to 2550 / 500 / 1 /step] 010 Vt Integral Control: M *ENG SM Appendix 8-149 G188/G189...
  • Page 562 002 Pixel Proportion 2: M *ENG [0 to 2.55 / 1 / 0.01 /step] 003 Pixel Proportion 2: C *ENG 004 Pixel Proportion 2: Y *ENG 005 Pixel Proportion 3: Bk *ENG [0.7 to 1.3 / 1 / 0.01 /step] G188/G189 8-150 SM Appendix...
  • Page 563 [0 to 200 / 5 / 1 sec/step] [Vt Target: Setting] 3238 Displays the Vt target value at developer initialization. DFU 001 Bk *ENG [0 to 5 / 2.5 / 0.01 V/step] 002 M *ENG 003 C *ENG SM Appendix 8-151 G188/G189...
  • Page 564 014 T Rank 2 Threshold *ENG [0 to 1 / 0.2 / 0.01 V/step] 3241 [Background Potential Setting] 001 Coefficient: Bk *ENG These are parameters for calculating the charge bias referring to the development 002 Coefficient: M *ENG G188/G189 8-152 SM Appendix...
  • Page 565 [-1000 to 1000 / 62 / 1 /step] 007 Offset: C *ENG 008 Offset: Y *ENG [Coverage] 3251 These (-001 to -016) are coefficients for SP3-222-009 to -012. 001 Latest: Bk *ENG Displays the latest coverage for each color. SM Appendix 8-153 G188/G189...
  • Page 566 013 Average L: Bk *ENG 014 Average L: M *ENG [0 to 100 / 5 / 0.01 %/step] 015 Average L: C *ENG 016 Average L: Y *ENG 017-019 Adjusts the threshold for SP3-251-005 to -016. G188/G189 8-154 SM Appendix...
  • Page 567 003 Voffset reg: C *ENG 004 Voffset reg: Y *ENG 005-007 Displays the ID sensor (diffusion) offset voltage for Vsg adjustments. 005 Voffset dif: M *ENG [0 to 5.5 / 0 / 0.01 V/step] 006 Voffset dif: C *ENG SM Appendix 8-155 G188/G189...
  • Page 568 007 Vsg dif: Y *ENG 008 Vsg TM (Front) *ENG 009 Vsg TM (Center) *ENG 010 Vsg TM (Rear) *ENG 3323 [Vsg Adjustment Result: Ifsg] DFU 001 Ifsg: Bk *ENG [0 to 50 / 0 / 0.1 mA/step] G188/G189 8-156 SM Appendix...
  • Page 569 3: Offset voltage error 2: Vsg adjustment value error 003 Result: Latest 2 *ENG 1: O.K 004 Result: Latest 3 *ENG 005 Result: Latest 4 *ENG 006 Result: Latest 5 *ENG 007 Result: Latest 6 *ENG SM Appendix 8-157 G188/G189...
  • Page 570 007 K5 Edit Point *ENG [0 to 1 / 0.15 / 0.01 /step] 008 K5 Target Voltage *ENG [0 to 5 / 1.63 / 0.01 V/step] 009 K5 Approximate Method *ENG [0 to 1 / 1 / 1 /step] G188/G189 8-158 SM Appendix...
  • Page 571 [0 to 2500 / 880 / 1 msec/step] Adjusts the processing timing for the pattern that is used for the line position 004 MUSIC Delay Time *ENG adjustment. [-2500 to 2500 / 300 / 1 msec/step] SM Appendix 8-159 G188/G189...
  • Page 572 004 Latest: Y *ENG 3421 [Toner Supply Range] 001 Upper Limit: Bk *ENG Adjusts the toner supply rate during printing. 002 Upper Limit: M *ENG [0 to 100 / 100 / 1%/step] 003 Upper Limit: C *ENG G188/G189 8-160 SM Appendix...
  • Page 573 [Process Control Target M/A] 3501 Adjusts the target M/A. 001 Maximum M/A: Bk *ENG 002 Maximum M/A: M *ENG [0 to 1 / 0.444 / 0.001 mg/cm /step] 003 Maximum M/A: C *ENG 004 Maximum M/A: Y *ENG SM Appendix 8-161 G188/G189...
  • Page 574 [0 to 2000 / 100 / 1 page/step] 007 Vsg Adj. Counter *ENG [0 to 2000 / 0 / 1 page/step] 008 Charge AC Control Counter *ENG 019 Environmental Correction *ENG [0 or 1 / 1 / 1 /step] G188/G189 8-162 SM Appendix...
  • Page 575 [0 to 1 / 1 / 0.01/step] Interrupt: FC Max. Number Correction *ENG [0 to 99 / 5 / 1/step] Threshold Max. Number Correction *ENG [0 to 255 / 0 / 1/step] Counter 3512 [Image Quality Adj.: Interval] SM Appendix 8-163 G188/G189...
  • Page 576 When the machine calculates the timing for process control, it uses a number of conditions. These are the results after considering all the conditions. 001 Job End: Potential *ENG [0 to 2000 / 500 / 1 page/step] G188/G189 8-164 SM Appendix...
  • Page 577 008 Pixel Coverage Sum: C *ENG 009 Pixel Coverage Sum: Y *ENG 010 Required Area: Bk *ENG [0 to 65535 / 0 / 1 cm /step] 011 Required Area: M *ENG 012 Required Area: C *ENG SM Appendix 8-165 G188/G189...
  • Page 578 If the temperature is above this value, toner is applied to the transfer belt at set intervals during the job to prevent the blade from flipping over. 001 Execution Temp. Threshold *ENG [0 to 50/ 40 / 1°C/step] G188/G189 8-166 SM Appendix...
  • Page 579 *ENG [0 or 1 / 1 / 1/step] 0: Permit (adjustment is done even toner 002 MUSIC *ENG near end condition) 1: Forbid (adjustment is not done at toner 003 TC Adj. *ENG near end condition) SM Appendix 8-167 G188/G189...
  • Page 580 [0 to 99 / 10 / 1°C/step] 004 Relative Humidity Range *ENG [0 to 99 / 50 / 1 %RH/step] 005 Absolute Humidity Range *ENG [0 to 99 / 6 / 1 g/m /step] 100 [Rapi_timer] G188/G189 8-168 SM Appendix...
  • Page 581 [0 to 5 / 0.85 / 0.01 mg/cm /kV /step] 007 C (Target Display) *ENG [0 to 5 / 0.8 / 0.01 mg/cm /kV /step] 008 Y (Target Display) *ENG [0 to 5 / 0.77 / 0.01 mg/cm /kV /step] SM Appendix 8-169 G188/G189...
  • Page 582 [1 to 99 / 15 / 1 g/m /step] 021 Y (Max Abs Hum) *ENG [Vk Display] 3612 Displays Vk for each color. 001 Bk *ENG 002 M *ENG [-300 to 300 / - / 1 V/step] 003 C *ENG 004 Y *ENG G188/G189 8-170 SM Appendix...
  • Page 583 Plain: 205 (P2c)/230 (P2d) mm/sec, Thick 1: 154 mm/sec, Thick 2 & FINE: 77 mm/sec 3631 Displays the charge DC voltage adjusted with the process control for each line speed and color. 001 Plain: Bk *ENG [0 to 2000 / 690 / 1 -V/step] 002 Plain: M *ENG SM Appendix 8-171 G188/G189...
  • Page 584 Plain: 205 (P2c)/230 (P2d) mm/sec, Thick 2 & FINE: 77 mm/sec 3651 Displays the LD power adjusted for each environment. 001 Plain: Bk *ENG [0 to 200 / 100 / 1 %/step] 002 Plain: M *ENG G188/G189 8-172 SM Appendix...
  • Page 585 [1.22 to 3.77 / 2.1 / 0.01 V/step] 004 Sensitivity: HM *ENG [0 to 2.55 / 1.05 / 0.01 V/step] 005 Sensitivity: ML *ENG 006 Set Detection *ENG [0 to 5 / 1 / 0.1 V/step] SM Appendix 8-173 G188/G189...
  • Page 586 [0 to 255 / - / 1 V/step] 010 Serial Number 2 *ENG 011 Adjustment: Vt *ENG [0 to 5 / 3 / 0.1 V/step] 012 Adjustment: Vtref *ENG [0 to 5 / 3 / 0.1 V/step] G188/G189 8-174 SM Appendix...
  • Page 587 [0 to 2.55 / 0 / 0.01 mg/cm /kV /step] 015 Adjustment: Vcnt Result *ENG [0 to 9 / 9 / 1 /step] [HST Concentration Control: Y] 3714 Displays the factory settings of the yellow PCU. SM Appendix 8-175 G188/G189...
  • Page 588 [0 to 50 / - / 1 /step] 003 Print Page After Near Full *CTL [0 to 1000 / 0 / 1 sheet/step] Pixel Count After Near *CTL [0 to 200000 / - / 1 cm /step] Full G188/G189 8-176 SM Appendix...
  • Page 589 [Toner Collection Bottle Full Detection] 3900 Turns toner collection bottle full detection on or off. [0 or 1 / 1 / - ] 001 ON/OFF Setting *ENG 0: OFF, 1: ON 3901 [New PCU Detection] SM Appendix 8-177 G188/G189...
  • Page 590 *ENG Do not use 3902-013 if you only change 015 Cleaning Unit *ENG the cleaning unit. 3902-015: This is for the image transfer 016 Paper Transfer Unit *ENG belt cleaning unit. 017 Toner Collection Bottle *ENG G188/G189 8-178 SM Appendix...
  • Page 591 Turns on or off the printed paper display on the LCD. [0 or 1 / 0 / - ] 001 - *CTL 0: OFF, 1: ON [TonerRefillDetectionDisplay] 5051 Enables or disables the toner refill detection display. SM Appendix 8-179 G188/G189...
  • Page 592 001 K Drum Unit *CTL [0 or 1 / 1 / - ] 0: Not display, 1: Display 002 M Drum Unit *CTL 003 C Drum Unit *CTL 004 Y Drum Unit *CTL 005 K Dev Unit *CTL G188/G189 8-180 SM Appendix...
  • Page 593 If the user service is selected, PM alart is displayed on the LCD. 001 PCU (Drum Unit):Bk *CTL 002 PCU (Drum Unit):M *CTL [0: Service] or [1: User] 003 PCU (Drum Unit):C *CTL 004 PCU (Drum Unit):Y *CTL SM Appendix 8-181 G188/G189...
  • Page 594 (Tray 2, and Optional paper tray unit trays 1 and 2) [0 or 1/ 0 / - ] 0: OFF 1: ON, If “1” is selected, the customer will be able to input a non-standard paper size using the UP mode. G188/G189 8-182 SM Appendix...
  • Page 595 This program updates the information on the optional counter. When you install or remove an optional counter, check the settings. 5121 [Counter Up Timing] *CTL [0: Feed/ 1: Exit] This program specifies when the counter goes up. The settings refer to “paper feed” and “paper exit” respectively. SM Appendix 8-183 G188/G189...
  • Page 596 Normally the paper length for sub scanning paper from the by-pass tray is limited to 600 mm, but this can be extended with this SP to 1260 mm. 5162 [App. Switch Method] *CTL [0: Soft Key Set/ 1: Hard Key Set] G188/G189 8-184 SM Appendix...
  • Page 597 [Size Adjust] 5181 Adjusts the paper size for each tray. 001 Paper TRAY 1 *ENG [0 to 3 / 0 (EU/ASIA), 1 (NA) / 1 /step] SM Appendix 8-185 G188/G189...
  • Page 598 [0 or 1 / 0 (EU/ASIA), 1 (NA) / - ] 014 TRAY 5: 1 *ENG 0: A4 LEF, 1: LT LEF 015 TRAY 5: 2 *ENG [0 or 1 / 0 (EU/ASIA), 1 (NA) / - ] G188/G189 8-186 SM Appendix...
  • Page 599 Displays the version number of the NVRAM on the controller board. 001 - 5191 [Mode Set] DFU [0 or 1 / 1 / -] *CTL 0: Off, 1: On Enables or disables the STR (Suspend to RAM) mode. SM Appendix 8-187 G188/G189...
  • Page 600 Adjusts the RTC (real time clock) time setting for the local time zone. Examples: For Japan (+9 GMT), enter 540 (9 hours x 60 min.) 5302 DOM: +540 (Tokyo) NA: -300 (New York) EU: + 60 (Paris) CH: +480 (Peking) G188/G189 8-188 SM Appendix...
  • Page 601 For example: 3500010 (EU default) The timer is advanced by 1 hour at am 0:00 on the 5th Sunday in March Rule Set (End) Specifies the end setting for the summer time mode. There are 8 digits in this SP. SM Appendix 8-189 G188/G189...
  • Page 602 220 SDK3 UniqueID *CTL SDK3 Certification *CTL Method 230 SDK certification device *CTL Detail Option *CTL - 240 Enalbes or disables the log out confirmation option. Bit 0: Log out confirmation option 0: Enable (default), 1: Disable G188/G189 8-190 SM Appendix...
  • Page 603 [1 to 10 / 5 / 1/step] Determines whether the system waits the prescribed time for input of a correct user 003 Cancellation On/Off *CTL ID and password after an account lockout has occurred. [0 or 1 / 0 / -] SM Appendix 8-191 G188/G189...
  • Page 604 [0 to 100 / 30 / 1 attempt/step] Sets the time limit to stop a password attack once such an attack has been 002 Detect Time *CTL detected. [1 to 10 / 5 / 1 sec./step] G188/G189 8-192 SM Appendix...
  • Page 605 [0 to 9 / 3 / 1 sec./step] Sets a limit on the number of requests received for certification in order to slow 004 Attack Max Num *CTL down the certification speed when an excessive number of access attempts have been detected. SM Appendix 8-193 G188/G189...
  • Page 606 [0 or 1/ 0 /1] 0: Off, 1: On Determines whether an error code appears on the operation panel after a user 002 Panel Disp *CTL authentication failure occurs. [0 or 1/ 1 /1] 1: On, 0: Off G188/G189 8-194 SM Appendix...
  • Page 607 0: Off, 1: On, DFU 002 Staple Supply Alarm 0: Off, 1: On, Japan only 003 Toner Supply Alarm 0: Off, 1: On, DFU 080 Toner Call Timing Changes the timing of the “Toner Supply Call” via SM Appendix 8-195 G188/G189...
  • Page 608 Sets the time a jam must remain before it becomes an “unattended paper jam”. This setting is enabled only when SP5508-004 is set to "1". 012* Jam Detection: Continuous [2 to 10 / 5 / 1 /step] G188/G189 8-196 SM Appendix...
  • Page 609 Non Genuine Tonner Alarm 1: On Supply Automatic Ordering Call Supply Management Report Call Jam/Door Open Call ⇒ 5801 [Memory Clear] (Refer to IMPORTANT NOTE in Sect. 5.4) 001 All Clear Resets all correction data for process control and SM Appendix 8-197 G188/G189...
  • Page 610 ID. All setting of Network Setup (User Menu) 011 NCS (NCS: Network Control Service) Initializes the DCS (Delivery Control Service) 014 Clear DCS Setting settings. 015 Clear UCS Setting Initializes the UCS (User Information Control G188/G189 8-198 SM Appendix...
  • Page 611 001 TRAY1: A4LEF: FC 002 TRAY2: A3: FC 003 TRAY2: A4SEF: FC See "Input Check Table" in this section. 5803 [Input Check] See "Output Check Table" in this section. 5804 [Output Check] 5805 [Anti-Condensation Heater] SM Appendix 8-199 G188/G189...
  • Page 612 Sets the fax or telephone number for a service representative. This number is printed on the Counter List. This can be up to 20 characters (both numbers and alphabetic characters can be input). 5816 [Remote Service] *CTL I/F Setting Selects the remote service setting. G188/G189 8-200 SM Appendix...
  • Page 613 [1 to 90 / 10 / 1 second /step] RCG Write Timeout Specifies the write timeout interval when calling the RCG. [1 to 100 / 60 / 1 second /step] RCG Read Timeout Specifies the read timeout interval when calling the RCG. SM Appendix 8-201 G188/G189...
  • Page 614 [0 or 1 / 0 / 1 /step 0: Internet connection 1: Dial-up connection Cert. Expire Timing DFU Proximity of the expiration of the certification. Use Proxy This SP setting determines if the proxy server is used when the machine G188/G189 8-202 SM Appendix...
  • Page 615 This SP sets the HTTP proxy certification password. The length of the password is limited to 31 characters. Any character beyond the 31st character is ignored. This name is customer information and is not printed in the SMC SM Appendix 8-203 G188/G189...
  • Page 616 The certification has been stored, and the GW URL is being notified of the successful completion of this event. The storing of the certification has failed, and the GW URL is being notified of the failure of this event. G188/G189 8-204 SM Appendix...
  • Page 617 084 Non-HDD Firm Up 0: Not allowed update 1: Allowed update This SP setting determines if the operator can 085 Firm Up User Check confirm the previous version of the firmware before the firmware update execution. If the SM Appendix 8-205 G188/G189...
  • Page 618 @Remote certification. CN = the following 30 092 CERT: Issuer bytes. Asteriskes () indicate that no @Remote certification exists. Displays the start time of the period for which the 093 CERT: Valid Start current @Remote certification is enabled. G188/G189 8-206 SM Appendix...
  • Page 619 Not used Outside Line/Outgoing Number Not used Dial Up User Name Not used Dial Up Password Not used Local Phone Number Not used Connection Timing Adjustment: Incoming Not used Access Point Not used Line Connecting Not used SM Appendix 8-207 G188/G189...
  • Page 620 Displays a number that indicates the result of the confirmation executed with SP5816-203. 0: Succeeded 1: Confirmation number error 2: Registration in progress 3: Proxy error (proxy enabled) 4: Proxy error (proxy disabled) 5: Proxy error (Illegal user name or password) 6: Communication error G188/G189 8-208 SM Appendix...
  • Page 621 Error Code Displays a number that describes the error code that was issued when either SP5816-204 or SP5816-207 was executed. Cause Code Meaning -11001 Chat parameter error Illegal Modem -11002 Chat execution error Parameter -11003 Unexpected error SM Appendix 8-209 G188/G189...
  • Page 622 -2387 Not supported at the Service Center -2389 Database out of service -2390 Program out of service -2391 Two registrations for same device -2392 Parameter error -2393 RCG device not managed G188/G189 8-210 SM Appendix...
  • Page 623 001 NV-RAM Data Upload [NV-RAM Data Download] 5825 Downloads the UP and SP mode data from an SD card to the NVRAM. For ⇒ details, see the "NVRAM Data Upload/Download" in Sect. 5.4). 001 NV-RAM Download SM Appendix 8-211 G188/G189...
  • Page 624 1: OFF (Automatically printed) Validates or invalidates the job spooling function for each protocol. 0: Validates 1: Invalidates bit0: LPR Job Spooling bit1: FTP (Protocol) bit2: IPP bit3: SMB bit4: BMLinkS bit5: DIPRINT bit6: sftp bit7: (Reserved) G188/G189 8-212 SM Appendix...
  • Page 625 8 blocks of 16 bits each. This SP is the IPv6 gateway address referenced on IPv6 Gateway the Ethernet or wireless LAN (802.11b). The IPv6 Address address consists of a total 128 bits configured in 8 blocks of 16 bits each. SM Appendix 8-213 G188/G189...
  • Page 626 236 Web Item visible bit0: Net RICOH bit1: Consumable Supplier bit2-15: Reserved (all) Displays or does not display the link to Net RICOH Web shopping link on the top page and link page of the web system. visible [0 to 1 / 1 / 1]...
  • Page 627 LAN. The number of channels available varies according to location. The default settings are set for the maximum end of the range for each area. Adjust the upper 4 bits to set the maximum number of channels. DFU Do not change the setting. SM Appendix 8-215 G188/G189...
  • Page 628 011 WEP key Select *CTL 01: Key #2 (Reserved) 10: Key #3 (Reserved) 11: Key #4 (Reserved) Adjusts the fragment threshold for the 042 Fragment Thresh *CTL IEEE802.11 card. [256 to 2346 / 2346 / 1] G188/G189 8-216 SM Appendix...
  • Page 629 Adjusts the debug program modesetting. Bit7: 5682 mmseg-log setting 0: Date/Hour/Minute/Second 002 Setting 2 *CTL 1: Minute/Second/Msec. 0 to 6: Not used 5844 [USB] 0x01: Full speed Transfer Rate *CTL 0x04: Auto Change Adjusts the USB transfer rate. SM Appendix 8-217 G188/G189...
  • Page 630 0: Disable, 1: Enable 5846 [UCS Settings] *CTL - LDAP Search Timeout [1 to 255 / 60 / 1 /step] Sets the length of the timeout for the search of the LDAP server. 041 Fill Addr Acl Info. G188/G189 8-218 SM Appendix...
  • Page 631 Clears the distribution address book information, Book except the user code. Initialize LDAP Addr Clears the LDAP address book information, except Book the user code. Clears all directory information managed by UCS, 050 Initialize All Addr Book including all user codes. SM Appendix 8-219 G188/G189...
  • Page 632 [0 to 32 / 0 / 1 /step] This SP does not normally require adjustment. This SP is enabled only after the system administrator has set up a group password policy to control access to the address book. G188/G189 8-220 SM Appendix...
  • Page 633 212 Setting: LogType: Access 213 Setting: Primary Srv Specifies the max size of the image data that 214 Setting: Secondary Srv the machine can download. [1 to 1024 / 1024 / 1 MB /step] 215 Setting: Start Time SM Appendix 8-221 G188/G189...
  • Page 634 0: Disable 1: Enable *CTL 5857 [Save Debug Log] On/Off (1:ON 0:OFF) 0: OFF, 1: ON Switches the debug log feature on and off. The debug log cannot be captured until this feature is switched on. G188/G189 8-222 SM Appendix...
  • Page 635 These SPs select the content of the debugging information to be saved to the 5858 destination selected by SP5857-002. SP5858-3 stores one SC specified by number. Refer to Section 4 for a list of SC error codes. SM Appendix 8-223 G188/G189...
  • Page 636 *CTL SMTP Svr Port No. [1 to 65535 / 25 / 1] This SP sets the number of the SMTP server port. [0 or 1 / 0 / -] 003 SMTP Authentication 0: Off, 1: On G188/G189 8-224 SM Appendix...
  • Page 637 [1 to 65535 / 110 / 1] This SP sets the number of the POP3 server port. IMAP4 Srv Port No [1 to 65535 / 143 / 1] This SP sets the number of the IMAP4 server port. SM Appendix 8-225 G188/G189...
  • Page 638 0: No. “From” item not switched. 1: Yes. “From item switched. SMTP Auth. Direct Setting [0 or 1 / 0 / – ] Selects the authentication method for SMPT. Bit switch: Bit 0: LOGIN Bit 1: PLAIN G188/G189 8-226 SM Appendix...
  • Page 639 5870 [Common Key Info Writing] Writes to flash ROM the common proof for 001 Writing *CTL validating the device for @Remote specifications. Initializes the data area of the common 003 Initialize *CTL proof for validating. SM Appendix 8-227 G188/G189...
  • Page 640 This SP sends a text file to an SD card inserted in SD card Slot 2 (lower slot). The 001 - *CTL operation stores. The file is stored in a folder created in the root directory of the SD card called SD_COUNTER. The file is G188/G189 8-228 SM Appendix...
  • Page 641 1: No authentication, Protected logs (only an administrator can see the logs) [SDK Application Counter] *CTL 5893 Displays the counter name of each SDK application. SDK-1 SDK-2 SDK-3 SDK-4 SDK-5 SDK-5 [External Charge Unit Setting] 5894 SM Appendix 8-229 G188/G189...
  • Page 642 Displays or does not display the end display for the fusing unit. This SP is 5930 016 Fusing Unit. *EGB activated only when the SP5930-001 is set to "1". [0 or 1 / 1 / -] G188/G189 8-230 SM Appendix...
  • Page 643 [0 or 1 / 0 / 1/step] 001 Normal/Enlarge *CTL 0: Normal, 1: Enlarge [Fusing Cont mode] Fusing Control Mode 5998 Turns the silent fusing warm-up mode on or off. 001 fast/silent *ENG [0 or 1 / 1 / - ] SM Appendix 8-231 G188/G189...
  • Page 644 003 3.Europe 4Hole *ENG 004 4.North Europe 4Hole *ENG 005 5.North Europe 2Hole *ENG [Skew Correction: Buckle Adj.] 6130 Adjusts the paper buckle for each paper size. 001 A3T *ENG [-5.0 to 5.0 / 0 / 0.25 mm/step] G188/G189 8-232 SM Appendix...
  • Page 645 [0 or 1 / 1 / 1/step] 0: No (No skew correction) 002 B4T *ENG 1: Roller Stop Skew Correction 003 A4T *ENG 004 A4Y *ENG 005 B5T *ENG 006 B5Y *ENG 007 DLT-T *ENG 008 LG-T *ENG 009 LT-T *ENG SM Appendix 8-233 G188/G189...
  • Page 646 *ENG 012 Other *ENG [Staple Position Adjustment] Adjusts the staple position for each finisher (B793/B805). 6133 + Value: Moves the staple position to the rear side. - Value: Moves the staple position to the front side. G188/G189 8-234 SM Appendix...
  • Page 647 001 A3T [-3.0 to 3.0 / 0 / 0.2 mm/step] + Value: Shifts staple position toward the crease. 002 B4T - Value: Shifts staple position away from the crease. 003 A4T 004 B5T 005 DLT-T 006 LG-T SM Appendix 8-235 G188/G189...
  • Page 648 Displays the signals received from sensors and switches of the booklet finisher. Input Check Table) 6139 [FIN (KIN) INPUT Check] Finisher (B408) Input Check Not used in this machine. 6140 [FIN (EUP) INPUT Check] Finisher (B805) Input Check G188/G189 8-236 SM Appendix...
  • Page 649 002 B4T jogger unit attached to the side of the machine jogs sheets as they exit the finisher. 003 A4T + Value: 004 A4Y Increases distance between jogger fences and the sides of the stack. 005 B5Y SM Appendix 8-237 G188/G189...
  • Page 650 (D386) ( "Input Check Table" in this section). [OUTPUT Check] 6151 Activates each device in the brisge unit (D386). ( "Output Check Table" in this section). [INPUT Check] 6152 Not used in this machine. 6153 [OUTPUT Check] G188/G189 8-238 SM Appendix...
  • Page 651 [SC History] Logs the SC codes detected. 7403 The 10 most recently detected SC Codes are not displayed on the screen, but can be seen on the SMC (logging) outputs. 001 Latest *CTL 002 Latest 1 SM Appendix 8-239 G188/G189...
  • Page 652 NOTE: The LCT is counted as the 3rd feed station. 001 At Power On *CTL For details, see "Jam Detection" in the "Appendix: Jam Detection" 003 Tray 1: ON *CTL section. 004 Tray 2: ON *CTL G188/G189 8-240 SM Appendix...
  • Page 653 027 Duplex Entrance: ON (Out) *CTL 051 Vertical Transport 1: Off *CTL 052 Vertical Transport 2: Off *CTL 053 Bank Transport 1: Off *CTL For details, see "Jam Detection" in the "Appendix: Jam Detection" 054 Bank Transport 2: Off *CTL SM Appendix 8-241 G188/G189...
  • Page 654 *CTL For details, see "Jam Detection" in the "Appendix: Jam Detection" 192 Finisher Proof Exit: EUP *CTL section. 193 Finisher Shift Tray Exit: EUP *CTL 194 Finisher Stapler Exit: EUP *CTL 195 Finisher Exit: EUP *CTL G188/G189 8-242 SM Appendix...
  • Page 655 Displays the number of jams according to the paper size. 005 A4 LEF *CTL [0 to 9999 / 0 / 1 sheet/step ] 006 A5 LEF 014 B5 LEF 038 LT LEF 044 HLT LEF 132 A3 SEF 133 A4 SEF 134 A5 SEF SM Appendix 8-243 G188/G189...
  • Page 656 004 Latest 3 005 Latest 4 *CTL 006 Latest 5 007 Latest 6 008 Latest 7 009 Latest 8 010 Latest 9 7801 [Memory/Version/PN] Displays all versions and ROM numbers 255 Engine *CTL in the machine. G188/G189 8-244 SM Appendix...
  • Page 657 007 Page: M Dev Unit 008 Page: C Dev Unit 009 Page: Y Dev Unit 010 Page: K Developer 011 Page: M Developer 012 Page: C Developer 013 Page: Y Developer 014 Page: ITB Unit 015 Page: Belt Cleaning Unit SM Appendix 8-245 G188/G189...
  • Page 658 037 Rotation: C Dev Unit 038 Rotation: Y Dev Unit 039 Rotation: K Developer 040 Rotation: M Developer 041 Rotation: C Developer 042 Rotation: Y Developer 043 Rotation: ITB Unit 044 Rotation: Cleaning Unit 045 Rotation: Fusing Unit G188/G189 8-246 SM Appendix...
  • Page 659 069 Rotation (%): K Developer 070 Rotation (%): M Developer 071 Rotation (%): C Developer 072 Rotation (%): Y Developer 073 Rotation (%): ITB Unit 074 Rotation (%): Cleaning Unit 075 Rotation (%): Fusing Unit 076 Rotation (%): PTR Unit SM Appendix 8-247 G188/G189...
  • Page 660 102 Page (%): Y Developer 103 Page (%): ITB Unit 104 Page (%): Cleaning Unit 105 Page (%): Fusing Unit 106 Page (%): PTR Unit 111 Yield(%):PCU:K *ENG [-999 to 999 / 100 / 1% / step] G188/G189 8-248 SM Appendix...
  • Page 661 005 PCU (Drum Unit): Y 006 PCU (Drum Unit): All 007 Development Unit: Bk 008 Development Unit: M 009 Development Unit: C 010 Development Unit: Y 011 Development Unit: All 012 Developer: Bk 013 Developer: M 014 Developer: C SM Appendix 8-249 G188/G189...
  • Page 662 *CTL - 7835 [ACC Counter] 001 Copy ACC *CTL Displays the ACC exectuion times for each mode. 002 Printer ACC *CTL Total Memory Size 7836 Displays the memory capacity of the controller system. 7855 [Coverage Range] G188/G189 8-250 SM Appendix...
  • Page 663 [Prev. Unit PM Counter] 7906 (Page or Rotations, Unit, [Color]), Dev.: Development Unit Displays the number of sheets printed with the previous maintenance units. 001 Page: K Drum Unit *ENG [0 to 9999999 / 0 / 1 page/step ] SM Appendix 8-251 G188/G189...
  • Page 664 031 Rotation: K Drum Unit *ENG [0 to 9999999 / 0 / 1 mm/step ] 032 Rotation: M Drum Unit 033 Rotation: C Drum Unit 034 Rotation: Y Drum Unit 035 Rotation: K Dev Unit 036 Rotation: M Dev Unit G188/G189 8-252 SM Appendix...
  • Page 665 064 Rotation (%): Y Drum Unit 065 Rotation (%): K Dev Unit 066 Rotation (%): M Dev Unit 067 Rotation (%): C Dev Unit 068 Rotation (%): Y Dev Unit 069 Rotation (%): K Developer 070 Rotation (%): M Developer SM Appendix 8-253 G188/G189...
  • Page 666 097 Page (%): C Dev Unit 098 Page (%): Y Dev Unit 099 Page (%): K Developer 100 Page (%): M Developer 101 Page (%): C Developer 102 Page (%): Y Developer 103 Page (%): ITB Unit G188/G189 8-254 SM Appendix...
  • Page 667 008 New Product Information 009 Recycle Counter 010 Date 011 Serial No. 012 Toner Remaining 013 EDP Code 014 End History 015 Refill Information 016 Attachment: Total Counter 017 Attachment: Color Counter 018 End: Total Counter SM Appendix 8-255 G188/G189...
  • Page 668 008 New Product Information 009 Recycle Counter 010 Date 011 Serial No. 012 Toner Remaining 013 EDP Code 014 End History 015 Refill Information 016 Attachment: Total Counter 017 Attachment: Color Counter 018 End: Total Counter G188/G189 8-256 SM Appendix...
  • Page 669 008 New Product Information 009 Recycle Counter 010 Date 011 Serial No. 012 Toner Remaining 013 EDP Code 014 End History 015 Refill Information 016 Attachment: Total Counter 017 Attachment: Color Counter 018 End: Total Counter SM Appendix 8-257 G188/G189...
  • Page 670 008 New Product Information 009 Recycle Counter 010 Date 011 Serial No. 012 Toner Remaining 013 EDP Code 014 End History 015 Refill Information 016 Attachment: Total Counter 017 Attachment: Color Counter 018 End: Total Counter G188/G189 8-258 SM Appendix...
  • Page 671 Displays the toner bottle *ENG information log 4 for Bk. 033 Attachment: Total Counter 034 Refill Information 041 Serial No. *ENG Displays the toner bottle information log 5 for Bk. 042 Attachment Date 043 Attachment: Total Counter SM Appendix 8-259 G188/G189...
  • Page 672 *ENG information log 4 for M. 033 Attachment: Total Counter 034 Refill Information 041 Serial No. 042 Attachment Date Displays the toner bottle *ENG information log 5 for M. 043 Attachment: Total Counter 044 Refill Information G188/G189 8-260 SM Appendix...
  • Page 673 041 Serial No. 042 Attachment Date Displays the toner bottle *ENG information log 5 for C. 043 Attachment: Total Counter 044 Refill Information 7938 [Toner Bottle Log 1: Y] 001 Serial No. *ENG Displays the toner bottle SM Appendix 8-261 G188/G189...
  • Page 674 Displays the toner bottle *ENG information log 5 for Y. 043 Attachment: Total Counter 044 Refill Information [Unit Replacement Date] 7950 Displays the replacement date of each PM unit. 001 Image Transfer Belt *ENG 002 Cleaning Unit G188/G189 8-262 SM Appendix...
  • Page 675 006 Page: M Dev Unit 007 Page: C Dev Unit 008 Page: Y Dev Unit 009 Page: K Developer 010 Page: M Developer 011 Page: C Developer 012 Page: Y Developer 013 Page: ITB Unit 014 Page: Cleaning Unit SM Appendix 8-263 G188/G189...
  • Page 676 045 Rotation: Fusing Unit 046 Rotation: PTR Unit Measurement: Toner Collection bottle [PM Yield Setting] 7952 Adjusts the unit yield of each PM unit. 001 Rotation: ITB Unit *CTL [0 to 999999999 / 256597000 / 1 mm/step] G188/G189 8-264 SM Appendix...
  • Page 677 028 Day: Y Dev Unit 029 Day: K Developer 030 Day: M Developer 031 Day: C Developer 032 Day: Y Developer 033 Day: ITB Unit 034 Day:Cleaning Unit 035 Day: Fusing Unit 036 Day: PTR Unit SM Appendix 8-265 G188/G189...
  • Page 678 048 Rotation: Developer: C 049 Rotation: Developer: Y Page: PCU (Drum Unit): 051 Page: PCU (Drum Unit): M [0 to 999999 / 0 / 1 sheet/step] 052 Page: PCU (Drum Unit): C 053 Page: PCU (Drum Unit): Y G188/G189 8-266 SM Appendix...
  • Page 679 T: Temperature (°C), H: Relative Humidity (%) 001 T<=0 *CTL [0 to 99999999 / - / 1 mm/step] 002 0<T<=5:0<=H<30 003 0<T<=5: 30<=H<70 004 0<T<=5: 70<=H<=100 005 5<T<15: 0<=H<30 006 5<T<15: 30<=H<55 007 5<T<15: 55<=H<80 008 5<T<15: 80<=H<=100 009 15<=T<25: 0<=H<30 SM Appendix 8-267 G188/G189...
  • Page 680 SP8211 to SP8216 The number of pages scanned to the document server. SP8401 to SP8406 The number of pages printed from the document server SP8691 to SP8696 The number of pages sent from the document server G188/G189 8-268 SM Appendix...
  • Page 681 Monitor. Utilities developed with the SDK (Software applications, for Development Kit) will also be counted with this example) group in the future. The Group 8 SP codes are limited to 17 characters, forced by the necessity of displaying SM Appendix 8-269 G188/G189...
  • Page 682 Print) used to store the job on the document server, for example. Dev Counter Development Count, no. of pages developed. Dup, Duplex Duplex, printing on both sides Emul Emulation Full Color Post-print processing, i.e. finishing (punching, stapling, etc.) G188/G189 8-270 SM Appendix...
  • Page 683 Personal Computer Pages. A page is the total scanned surface of the original. Duplex pages count as two pages, and A3 simplex count as two SM Appendix 8-271 G188/G189...
  • Page 684 SMC report. Server TonEnd Toner End TonSave Toner Save TXJob Send, Transmission Yellow, Magenta, Cyan YMCK Yellow, Magenta, Cyan, Black All of the Group 8 SPs are reset with SP5 801 1 Memory All Clear. G188/G189 8-272 SM Appendix...
  • Page 685 When an image received from Palm 2 is received and stored, the L: counter increments. When the customer prints a report (user code list, for example), the O: counter increments. However, for fax reports and reports executed from the fax application, the SM Appendix 8-273 G188/G189...
  • Page 686 When images stored on the document server by a network application (including Palm 2), are printed with another application, the O: counter increments. When a copy job stored on the document server is printed with a network application (Web Image Monitor, for example), the C: counter increments. G188/G189 8-274 SM Appendix...
  • Page 687 Number of jobs started in Booklet mode. If the machine is in 8 06x 4 Booklet staple mode, the Staple counter also increments. 8 06x 5 Z-Fold Number of jobs started In any mode other than the Booklet mode SM Appendix 8-275 G188/G189...
  • Page 688 Printing a fax report counts as a job and increments the F: counter (SP 8073). Interrupted jobs (paper jam, etc.) are counted, even though they do not finish. If a job is paused and re-started, it counts as one job. G188/G189 8-276 SM Appendix...
  • Page 689 - Error notification reports. - Partially printed pages as the result of a copier jam. LSize PrtPGS *CTL [0 to 9999999/ 0 / 1] 8 391 These SPs count pages printed on paper sizes A3/DLT and larger. SM Appendix 8-277 G188/G189...
  • Page 690 2 pages on 1 side (2-Up) 8 42x 7 4> 4 pages on 1 side (4-Up) 8 42x 8 6> 6 pages on 1 side (6-Up) 8 42x 9 8> 8 pages on 1 side (8-Up) G188/G189 8-278 SM Appendix...
  • Page 691 These SPs count the total number of pages output with the three features below, regardless of which application was used. P:PrtPGS/ImgEdt *CTL [0 to 9999999/ 0 / 1] 8 434 These SPs count the total number of pages output with the three features SM Appendix 8-279 G188/G189...
  • Page 692 8 447 These SPs count by print paper size the number of pages printed by Other applications. 8 44x 1 A3 8 44x 2 A4 8 44x 3 A5 8 44x 4 B4 8 44x 5 B5 G188/G189 8-280 SM Appendix...
  • Page 693 8 451 9 Tray 8 Currently not used. 8 451 10 Tray 9 Currently not used. T:PrtPGS/Ppr Type *CTL [0 to 9999999/ 0 / 1] 8 461 These SPs count by paper type the number pages printed by all SM Appendix 8-281 G188/G189...
  • Page 694 These SPs count by magnification rate the number of pages printed. 8 471 1 < 49% 8 471 2 50% to 99% 8 471 3 100% 8 471 4 101% to 200% 8 471 5 201% < G188/G189 8-282 SM Appendix...
  • Page 695 Color Mode by the print 8 504 *CTL Mode application. O:PrtPGS/Col 8 507 *CTL Mode 8 50x 1 B/W 8 50x 2 Mono Color 8 50x 3 Full Color 8 50x 4 Single Color SM Appendix 8-283 G188/G189...
  • Page 696 8 514 13 BM-Links Japan Only 8 514 14 Other SP8 511 and SP8 514 return the same results as they are both limited to the Print application. Print jobs output to the document server are not counted. G188/G189 8-284 SM Appendix...
  • Page 697 T:Counter *CTL [0 to 9999999 / 0 / 1] 8 581 These SPs count the total output broken down by color output, regardless of the application used. In addition to being displayed in the SMC Report, SM Appendix 8-285 G188/G189...
  • Page 698 8 581 17 Twin Colour Mode Print 8 581 18 Full Colour Print (Twin) 8 581 19 Mono Colour Print (Twin) 8 581 20 Full Colour Total (CV) 8 581 21 Mono Colour Total (CV) 8 581 22 Full Colour Print (CV) G188/G189 8-286 SM Appendix...
  • Page 699 8 601 1 B/W 8 601 2 Color 8 601 11 B/W Printing Pages 8 601 12 Color Printing Pages 8 601 21 Coverage Counter 1 8 601 22 Coverage Counter 2 SM Appendix 8-287 G188/G189...
  • Page 700 These SPs display the number of already replaced toner bottles. 8 781 NOTE: Currently, the data in SP7-833-011 through 014 and the data in SP8-781-001 through 004 are the same. 8 781 1 Toner: BK The number of black-toner bottles G188/G189 8-288 SM Appendix...
  • Page 701 8 851 22 3 to 4%: Y 8 851 42 8 to 10%: Y 8 851 23 3 to 4%: M 8 851 43 8 to 10%: M 8 851 24 3 to 4%: C 8 851 44 8 to 10%: C SM Appendix 8-289 G188/G189...
  • Page 702 These SPs display the number of scanned sheets on which the coverage of each color is 31% or higher. 8 881 1 BK 8 881 2 Y 8 881 3 M 8 881 4 C 8 891 Page/Toner Bottle *ENG [0 to 9999999/ 0 / 1] G188/G189 8-290 SM Appendix...
  • Page 703 8 911 1 BK 8 911 2 Y 8 911 3 M 8 911 4 C Cvr Cnt/Total *CTL [0 to 9999999/ 0 / 1] 8 921 Displays the total coverage and total printout number for each color. SM Appendix 8-291 G188/G189...
  • Page 704 8 941 4 Low Power Time Includes time while machine is performing background printing. Includes time while machine is performing 8 941 5 Off Mode Time background printing. Does not include time machine remains powered off with the power switches. G188/G189 8-292 SM Appendix...
  • Page 705 8 999 16 Coverage: Color Print Page (%) 8 999 17 Coverage: BW Print Page (%) SP9-XXX: Others Skew Origin Set *CTL 9511 001 M: Skew Motor These SPs reset the skew correction value (SP2-119-001 to -003) to "0". 002 C: Skew Motor SM Appendix 8-293 G188/G189...
  • Page 706 See table 3 following this table. 5803 12 Bypass Paper End Detection No paper Paper remaining 5803 13 Bypass Paper Length Detection See table 3 following this table. 5803 14 1st Paper Feed Sensor Paper detected Paper not G188/G189 8-294 SM Appendix...
  • Page 707 5803 30 Toner End Sensor: Bk Toner end Toner remaining 5803 31 Toner End Sensor: M Toner end Toner remaining 5803 32 Toner End Sensor: C Toner end Toner remaining 5803 33 Toner End Sensor: Y Toner end Toner remaining SM Appendix 8-295 G188/G189...
  • Page 708 5803 53 2nd Duct Fan: Lock Normal Lock 5803 54 3rd Duct Fan: Lock Normal Lock 5803 55 Paper Exit Fan:Lock Normal Lock 5803 56 Fusing Coil Fan: Lock Normal Lock 5803 57 IH Power Supply Cooling Fan: Lock Normal Lock G188/G189 8-296 SM Appendix...
  • Page 709 5803 85 Fusing Destination Detection: EU Not set 5803 86 Fusing Destination Detection: TWN Not set 5803 87 Fusing New Unit Detection Not new 5803 90 Zero-cross Signal Actuator not Actuator 5803 91 Fusing Rotation Sensor detected detected SM Appendix 8-297 G188/G189...
  • Page 710 Switch 1 is used for tray set detection. 0: Pushed, 1: Not pushed Models Switch Location North America Europe/Asia 4 (bit0) 3 (bit1) 2 (bit2) 11" x 17" SEF A3 SEF (A3 SEF) (11" x 17" SEF) G188/G189 8-298 SM Appendix...
  • Page 711 Table 3: Paper Size (By-pass Table) 0: ON, 1: OFF By-pass Paper Size Sensor Length EU/ASIA Sensor bit3 Bit2 Bit1 Bit0 HLT SEF A6 SEF HLT SEF A6 SEF HLT SEF A5 SEF HLT SEF A5 SEF SM Appendix 8-299 G188/G189...
  • Page 712 Home position (Stopper S HP Sensor) Exit Junction Gate HP Sensor Not home 6138 4 Home position (Stack Feed Out HP Sensor) position Jogger HP Sensor 6138 5 Not home position Home position (Jogger Fence HP Sensor) G188/G189 8-300 SM Appendix...
  • Page 713 (Shift Tray Paper Position Sensor) detected detected 6138 17 Shift Tray Full Full Nor full 6138 18 Shift Roller HP Sensor Not home position Home position Entrance Sensor Paper not 6138 20 Paper detected (Finisher Entrance Sensor) detected SM Appendix 8-301 G188/G189...
  • Page 714 6138 33 Not home position Home position Sensor Punch Moving HP Sensor 6138 34 Not home position Home position (Punch Movement HP Sensor) Punch HP Sensor Not home 6138 35 Home position (Punch HP Sensor) position G188/G189 8-302 SM Appendix...
  • Page 715 Paper not 6140 5 Staple Exit Sensor Paper detected detected 6140 6 Shift HP Sensor Not HP Paper not 6140 7 Shift Exit Sensor Paper detected detected 6140 8 Exit Guide Plate HP Sensor Not HP SM Appendix 8-303 G188/G189...
  • Page 716 Not HP 6140 24 Punch Registration HP Sensor Not HP Punch Registratioin Detection Paper not 6140 25 Paper detected Sensor detected 6140 26 Punch Chad Full Sensor Not Full Full 6140 27 Punch HP Not HP G188/G189 8-304 SM Appendix...
  • Page 717 Staple detected detected Saddle Stitch Leading Edge Staple not 6140 42 Staple detected Detection: Front detected Saddle Stitch Stapler 1 Rotation: 6140 43 Not HP Rear 6140 44 Saddle Stitch Detection: Rear Staple not Staple detected SM Appendix 8-305 G188/G189...
  • Page 718 (Booklet) Finisher". Mail Bin (G835) Reading 6142 Description Paper not 6142 1 Relay Sn 1 Paper detected detected Paper not 6142 2 Relay Sn 2 Paper detected detected 6142 3 Full Sn 4 Not Full Full G188/G189 8-306 SM Appendix...
  • Page 719 6150 1 Bridge: Exit Sensor Paper detected detected Paper not 6150 2 Bridge: Feed Sensor Paper detected detected 6150 3 Bridge:Set Detection Not set 6150 4 Bridge: Exit Cover Detection Closed Open 6150 5 Bridge: Feed Cover Detection Closed Open SM Appendix 8-307 G188/G189...

  • Page 720: Output Check Table

    6160 12 Bank: Palau: Slide Switch Closed Open 8.2.3 OUTPUT CHECK TABLE Printer 5804 Display Description Drum/Development Drive Motor-K: 230 5804 3 Drum/Dev Motor: K: 230mm/s mm/s Drum/Development Drive Motor-K: 205 5804 4 Drum/Dev Motor: K: 205mm/s mm/s G188/G189 8-308 SM Appendix...
  • Page 721 5804 24 Drum/Dev Motor: Y: 230mm/s mm/s Drum/Development Drive Motor-Y: 205 5804 25 Drum/Dev Motor: Y: 205mm/s mm/s Drum/Development Drive Motor-Y: 154 5804 26 Drum/Dev Motor: Y: 154mm/s mm/s Drum/Development Drive Motor-Y: 77 5804 28 Drum/Dev Motor: Y: 77mm/s mm/s SM Appendix 8-309 G188/G189...
  • Page 722 5804 61 Regist Motor: 205mm/s Registration Motor: 205 mm/s 5804 62 Regist Motor: 154mm/s Registration Motor: 154 mm/s 5804 64 Regist Motor: 77mm/s Registration Motor: 77 mm/s 5804 67 Duplex Feed M:CW:230mm/s Duplex/By-pass Motor: CW: 230 mm/s G188/G189 8-310 SM Appendix...
  • Page 723 Duplex Reverse Motor: CCW: Duplex Inverter Motor: CCW: 5804 90 154mm/s 154 mm/s Duplex Reverse Motor: CCW: Duplex Inverter Motor: CCW: 5804 92 77mm/s 77 mm/s 5804 95 ITB Contact Motor Image Transfer Belt Contact Motor SM Appendix 8-311 G188/G189...
  • Page 724 IH Power Supply Cooling Fan IH Inverter Fan 5804 126 Development Clutch: Bk Development Clutch-K 5804 127 Development Clutch: M Development Clutch-M 5804 128 Development Clutch: C Development Clutch-C 5804 129 Development Clutch: Y Development Clutch-Y G188/G189 8-312 SM Appendix...
  • Page 725 5804 146 2st Feed Pickup Solenoid 2nd Pickup Solenoid 5804 147 Duplex Junction Solenoid Duplex Junction Solenoid 5804 161 PCL: Bk 5804 162 PCL: M 5804 163 PCL: C 5804 164 PCL: Y 5804 166 HST Sensor:Bk TD Sensor:Bk SM Appendix 8-313 G188/G189...
  • Page 726 5804 183 Bank Motor 2: 205mm/s Paper Feed Unit) Paper Feed Motor 2: 215 mm/s (Optional 5804 184 Bank Motor 2: 215mm/s Paper Feed Unit) 5804 186 PP:Development:K 5804 187 PP:Development:M 5804 188 PP:Development:C 5804 189 PP:Development:Y G188/G189 8-314 SM Appendix...
  • Page 727 PP: Image Transfer Roller: K 5804 225 PP:ITB:M PP: Image Transfer Roller: M 5804 226 PP:ITB:C PP: Image Transfer Roller: C 5804 227 PP:ITB:Y PP: Image Transfer Roller: Y 5804 228 PP:PTR:+ PP: Paper Transfer Roller:+ SM Appendix 8-315 G188/G189...
  • Page 728 HVPS: ChargeAC: C: 154mm/s 5804 255 HVPS: ChargeAC: C: 77mm/s 1000-Sheet Booklet Finisher (B793) 6143 Display Description 6143 1 Shift Motor Shift Tray Motor 6143 2 Entrance Motor 6143 3 Staple Relay Motor Stapler Unit Motor G188/G189 8-316 SM Appendix...
  • Page 729 6143 19 Staple Moving Motor Staple Unit Driver Motor 6143 20 Jogger Motor Jogger Motor Punch Registration Moving 6143 21 Paper Position Sensor Slide Motor Motor 6143 22 Punch Motor 6143 23 Punch Moving Motor Punch Movement Motor SM Appendix 8-317 G188/G189...
  • Page 730 6145 17 Knock Solenoid Stapling Edge Pressure Plate Solenoid 6145 18 Trailing Edge Hold Solenoid Positioning Roller Solenoid 6145 19 Saddle Stitch Hold Solonoid Booklet Pressure Roller Solenoid Stack Junction Gate 6145 20 Stack Junction Gate Motor Open/Close Motor G188/G189 8-318 SM Appendix...
  • Page 731 Display Description 6147 1 Feed Motor 6147 2 Solenoid 1 Junction Gate Solenoid: 1 (Tray 1) 6147 3 Solenoid 2 Junction Gate Solenoid: 2 (Tray 2) 6147 6 Solenoid 3 Junction Gate Solenoid: 3 (Tray 3) SM Appendix 8-319 G188/G189...
  • Page 732 Feed Motor:300mm/s 6161 5 Bank1: Feed Motor:300mm/s (D351/ D352/D387) Feed Motor:265mm/s 6161 6 Bank1: Feed Motor:265mm/s (D351/ D352/D387) Feed Motor:230mm/s 6161 8 Bank1: Feed Motor:230mm/s (D351/ D352/D387) Feed Motor:215mm/s 6161 9 Bank1: Feed Motor:215mm/s (D351/ D352/D387) G188/G189 8-320 SM Appendix...
  • Page 733 Pick-up Solenoid (D351) 6161 32 Bank:Tray5: PU Solenoid Pick-up Solenoid (D353) 6161 35 Bank:Tray3: Feed Clutch Pick-up Solenoid (D351/ D352) 6161 36 Bank:Tray4: Feed Clutch Pick-up Solenoid (D351) 6161 37 Bank:Tray5: Feed Clutch Not used in this machine. SM Appendix 8-321 G188/G189...

  • Page 734: Test Pattern Printing

    10. Return the value of the setting in SP2-109-003 to "00" before completing this procedure. 11. Exit the SP mode. Pattern Pattern None Independent Pattern (1-dot) Vertial Line (1dot) Independent Pattern (2-dot) Vertial Line (2dot) Independent Pattern (4-dot) Horizontal Line (1dot) Triming Area Horizontal Line (2dot) Tooth Check (Horizontal) G188/G189 8-322 SM Appendix...
  • Page 735 Engine Service Mode Grid Vertical Line Band (Horizontal) Grid Horizontal Line Band (Vertical) Grid Pattern Small Checker Flag Pattern Grid Pattern Large Grayscale (Vertical Margin) Argyle Pattern Small Grayscale (Horizontal Margin) Argyle Pattern Large Full Dot Pattern SM Appendix 8-323 G188/G189...
  • Page 737 BOOKLET FINISHER B793...
  • Page 739 BOOKLET FINISHER B793 TABLE OF CONTENTS 1. REPLACEMENT AND ADJUSTMENT ..........1 1.1 COVERS......................1 1.1.1 FRONT/INNER/REAR COVERS ............1 1.1.2 UPPER COVERS .................2 1.2 MAIN BODY....................4 1.2.1 POSITIONING ROLLER ...............4 1.2.2 SHIFT TRAY POSITION SENSOR, UPPER LIMIT SWITCH ....4 1.2.3 PROOF TRAY EXIT / FULL SENSOR..........5 1.2.4 FINISHER ENTRANCE SENSOR ............6 1.2.5 SHIFT TRAY EXIT SENSOR..............7 1.2.6 STAPLE TRAY PAPER SENSOR ............8...
  • Page 740 2.3 PROOF TRAY....................40 2.4 SHIFT TRAY ....................41 2.4.1 UP/DOWN MOTION ................41 2.4.2 SIDE-TO-SIDE MOTION ..............42 2.5 BOOKLET TRAY ..................43 2.6 JOGGER UNIT ....................46 2.7 EXIT GUIDE PLATE, PAPER FEED OUT ...........47 2.8 STAPLER UNIT MOVEMENT..............48 2.9 STACKING FOR BOOKLET STAPLING............49 2.9.1 OVERVIEW ..................49 2.9.2 8.5 X 14 (LEGAL) OR SHORTER............49 2.9.3 LONGER THAN 8.5 X 14 INCHES .............50...
  • Page 741 Read This First Safety and Symbols Replacement Procedure Safety Turn off the main power switch and unplug the machine before beginning any of the replacement procedures in this manual. When taking apart the bridge unit, first take the unit out of the copier. Symbols Used in this Manual This manual uses the following symbols.

  • Page 743: Replacement And Adjustment

    Covers 1. REPLACEMENT AND ADJUSTMENT COVERS 1.1.1 FRONT/INNER/REAR COVERS Remove the front cover [A] ( x 1). Remove the inner cover [B] ( x 2). B793...

  • Page 744: Upper Covers

    Covers Remove the rear cover [C] ( x 2). 1.1.2 UPPER COVERS Remove the upper cover [A] ( x 1). Remove the proof tray [B] ( x 4). B793...
  • Page 745 Covers Remove the upper left cover [C]. B793...

  • Page 746: Main Body

    Main Body MAIN BODY 1.2.1 POSITIONING ROLLER Open the front cover. Remove the positioning roller [A] ( x 1). 1.2.2 SHIFT TRAY POSITION SENSOR, UPPER LIMIT SWITCH Remove the following items. Front Cover Inner Cover Rear Cover Proof Tray Upper Left Cover B793...

  • Page 747: Proof Tray Exit / Full Sensor

    Main Body Remove the lower guide unit [A] ( x 4, x 2). Remove the shift tray position sensor [B] ( x 1). Remove the upper limit switch [C] ( x 2). (Pull it out from the assembly.) 1.2.3 PROOF TRAY EXIT / FULL SENSOR Remove the front cover, rear cover and proof tray.

  • Page 748: Finisher Entrance Sensor

    Main Body Remove the vertical transport guide [A] ( x 4). Remove the exit sensor [B] ( x 1). Remove the tray full sensor [C] ( x 1). 1.2.4 FINISHER ENTRANCE SENSOR Remove the finisher entrance sensor with bracket [A] ( x 1).

  • Page 749: Shift Tray Exit Sensor

    Main Body 1.2.5 SHIFT TRAY EXIT SENSOR Remove the front cover and upper left cover. Remove the link [A] ( x 1). Remove the exit guide unit [B]. Remove the sensor [C] ( x 1). B793...

  • Page 750: Staple Tray Paper Sensor

    Main Body 1.2.6 STAPLE TRAY PAPER SENSOR Open the front cover. Pull out the staple/fold unit. Remove the staple tray paper sensor [A] ( x 1). 1.2.7 SHIFT TRAY MOTOR Remove the rear cover. Open the front cover, and then pull out the staple/fold unit. B793...

  • Page 751: Entrance Motor

    Main Body Remove the two gears [A], [B]. Remove the shift tray motor [C] ( x 2, x 1) 1.2.8 ENTRANCE MOTOR Remove the rear cover. Release the belt tension [A]. Remove the entrance motor [B] ( x 2, x 1). 1.2.9 UPPER TRANSPORT MOTOR Remove the rear cover.

  • Page 752: Lower Transport Motor

    Main Body Release the belt tension [A]. Remove the upper transport motor [B] ( x 2, x 1). 1.2.10 LOWER TRANSPORT MOTOR Remove the rear cover. Release the belt tension [A]. Remove the lower transport motor [B] ( x 2, x 1).

  • Page 753: Shift Motor

    Main Body 1.2.11 SHIFT MOTOR Remove the rear cover. Remove the shift motor with bracket [A] ( x 1, x 4) Remove the shift motor [B] ( x 1). B793...

  • Page 754: Folder

    Folder FOLDER 1.3.1 STAPLE FOLDER UNIT Remove the rear cover. Disconnect all connectors and release the harness [A] for the staple folder unit ( x 1, x 3). Open the front cover. B793...

  • Page 755: Folder Unit

    Folder Pull out and remove the staple folder unit [B] ( x 2). 1.3.2 FOLDER UNIT Remove the staple folder unit. Remove the knobs [A] ( x 1 each). Disconnect the connectors. Remove the folder unit [B] ( x 4). B793...

  • Page 756: Folder Unit Exit Sensor

    Folder 1.3.3 FOLDER UNIT EXIT SENSOR Remove the folder unit. Remove the folder unit upper cover [A] ( x 1). Remove the lower clamp roller unit [B] ( x 4). Remove the folder unit exit sensor [C] ( x 1, x 1).

  • Page 757: Folder Unit Entrance Sensor

    Folder 1.3.4 FOLDER UNIT ENTRANCE SENSOR Open the front cover. Pull out the staple folder unit. Remove the exit cover [A] ( x 2). Remove the entrance sensor [B] ( x 1, x 1). 1.3.5 STAPLER UNIT Remove the rear cover. Disconnect the connector [1] and release the harness ( x 2 [2]).
  • Page 758 Folder Open the front cover and pull out the staple folder unit [4]. Disconnect the connectors and release the harness. (4 connectors [5], 1 clamp [6]) B793...
  • Page 759 Folder Remove a connector [7]. Remove 2 screws [8]. B793...
  • Page 760 Folder Remove the staple tray [9]. Remove the guide [10]. (2 screws) B793...
  • Page 761 Folder 10. Move the stapler unit until its screw come to the hole [11] on the stay. 11. Remove the screw [12] that holds the front of the guide plate [13]. B793...
  • Page 762 Folder 12. Remove the screw [14] that holds the rear of the guide plate. Remove the rear side screw through the hole in the stay. B793...
  • Page 763 Folder 13. Remove the guide plate [13]. 14. Remove the staple folding unit [15] (3 screws, 2 connectors). B793...
  • Page 764 Folder 15. Remove the staple cartridge [16]. 16. Remove the stapler unit cover [17]. 17. Remove the stapler drive unit [18]. B793...
  • Page 765 Folder Reassembly Mount the stapler drive unit [1]. Mount the staple folder unit [2]. Do not tighten the screws [3] at this time. B793...
  • Page 766 Folder Set the special tool in the long hole [4] on both units. Secure the special tool [5] with the knob [6]. B793...
  • Page 767 Folder Tighten the screws [7] for the stapler folder unit. Reassemble the machine. B793...

  • Page 768: Others

    Others OTHERS 1.4.1 MAIN BOARD Remove the rear cover. Remove the main board [A] ( x 5). B793...

  • Page 769: Dip Switches

    DIP Switches DIP SWITCHES SW100: Adjust the staple position for booklet mode Function ON: 0.3 mm ON: 0.6 mm ON: 1.2 mm Direction OFF: Towards the trailing edge, ON: Towards the leading edge SW101: Adjust the fold position Function ON: 0.2 mm ON: 0.4 mm ON: 0.8 mm Direction...

  • Page 770: Detailed Section Descriptions

    Component Layout 2. DETAILED SECTION DESCRIPTIONS COMPONENT LAYOUT 2.1.1 MECHANICAL COMPONENT LAYOUT 1. Proof Tray 2. Shift Tray 3. Exit Guide Plate 4. Stack Feed Out Belt 5. Staple Unit 6. Booklet Tray 7. Proof Tray Exit Roller 8. Proof Tray Junction Gate 9.

  • Page 771: Component Layout

    Component Layout Drive Layout 1. Upper Transport Motor 2. Entrance Motor 3. Lower Transport Motor 4. Fold Plate Motor 5. Fold Roller Motor 6. Stack Feed-out Motor B793...

  • Page 772: Electrical Component Layout

    Component Layout 2.1.2 ELECTRICAL COMPONENT LAYOUT 1. Proof Tray Exit Sensor 2. Exit Guide Plate Motor 3. Shift Tray Exit Sensor 4. Upper Limit Switch 5. Shift Tray Position Sensor 6. Rear Booklet Tray Full Sensor 7. Front Booklet Tray Full Sensor 8.
  • Page 773 Component Layout 13. Proof Tray Gate Solenoid 14. Lower Transport Motor 15. Entrance Motor 16. Positioning Roller Solenoid 17. Main Board 18. Shift Tray Motor 19. Lower Limit Sensor 20. Upper Cover Sensor 21. Staple Tray Gate Solenoid 22. Upper Transport Motor 23.
  • Page 774 Component Layout 38. Fold Unit Exit Sensor 39. Lower Clamp Roller HP Sensor 40. Lower Retraction Motor 41. Fold Unit Entrance Sensor 42. Bottom Fence HP Sensor 43. Fold Cam HP Sensor 44. Fold Roller Motor 45. Fold Plate HP Sensor 46.
  • Page 775 Component Layout 48. Punch Motor 49. Punch Encoder Sensor 50. Punch HP Sensor 51. Punch Board 52. Paper Position Sensor Slide Motor 53. Paper Position Slide HP Sensor 54. Paper Position Sensor 55. Punch Movement HP Sensor 56. Punch Hopper Full Sensor 57.
  • Page 776 Component Layout Electrical Component Descriptions Boards Item Purpose Main Board Controls the finisher. Punch Board Controls the punch unit. Sensors Item Purpose Proof Tray Detects paper when it is fed out to the proof tray. Exit Sensor Shift Tray Detects paper when it is fed out to the shift tray. Exit Sensor Shift Tray Position...
  • Page 777 Component Layout Item Purpose Stopper S Detects when the ‘stopper S’ mechanism is at home position. HP Sensor Stack Feed Out HP Detects when the stack feed-out belt is at home position Sensor Staple Unit Detects when the side-to-side motion of the stapler unit is at home HP Sensor position Jogger HP...
  • Page 778 Component Layout Item Purpose Punch HP Detects when the hole-punch firing mechanism is at home position Sensor Paper Position Detects when the mechanism that measures the paper position in the punch unit is at home position Slide HP Sensor Paper Detects the side edge of the paper, to tell the machine where to put Position the punch holes.
  • Page 779 Component Layout Item Purpose Clamp Roller Motor Stapler Unit Moves the stapler from side to side. Motor Drives a large cam that alternately clamps and unclamps the lower clamp roller, which is the idle roller of the clamp roller pair. When these rollers are clamped, they are part of the paper feed path Lower and feed the stack toward the bottom fence of the fold unit.
  • Page 780 Component Layout Item Purpose Front Door Cuts dc power when the front door is opened. Safety Switch Others Item Purpose Staple Driver Unit Pushes the staples into the paper. Staple Folder Unit Folds the ends of the staples after stapling B793...

  • Page 781: Junction Gates

    Junction Gates JUNCTION GATES Two junction gates control the path of paper. Each junction gate is controlled by a solenoid. Junction gate operation is summarized in the following table. Mode Proof Shift Staple Paper Path Proof Tray Gate Solenoid Staple Tray Gate Solenoid B793...

  • Page 782: Proof Tray

    Proof Tray PROOF TRAY Proof Tray Junction Gate Control [A]: Proof Tray Gate Solenoid Roller Drive: Proof Tray Exit Roller [B], Proof Tray Transport Roller [C]: Controlled by the Upper Transport Motor Entrance Roller [D], Transport Roller [E]: Controlled by the Entrance Motor Jam Detection: Proof Tray Exit Sensor [F] Tray Full Detection: Proof Tray Full Sensor [G] B793...

  • Page 783: Shift Tray

    Shift Tray SHIFT TRAY 2.4.1 UP/DOWN MOTION The shift tray motor [A] moves the tray up and down. The upper limit switch [B] detects when the tray moves up too far, and cuts power to the shift tray motor. The shift tray position sensor [C] checks when the tray (or the top of the stack) is at the correct height to receive paper.

  • Page 784: Side-To-Side Motion

    Shift Tray 2.4.2 SIDE-TO-SIDE MOTION The shift motor [A] moves the shift roller [B] from side to side. The shift motor HP sensor [C] detects when the mechanism is at home position. The upper transport motor rotates the shift roller. When shift mode is used, the shift motor turns on after each page is fed out.

  • Page 785: Booklet Tray

    Booklet Tray BOOKLET TRAY The sensor actuator arm [A] rests on the top of the stack of stapled booklets as they are output to the lower tray. A flap depressor [B] keeps the open ends of the booklets down. The front booklet tray full sensor [C] and rear booklet tray full sensor [D] detect when the tray is full of booklets.
  • Page 786 Booklet Tray Condition Front Sensor Rear Sensor Ready Full 1 Full 2 Full 3 (or booklet tray not installed) In the tables below: "Sht" denotes "sheets in a stack". "Cnt" denotes "Count" (see below for an explanation). After a booklet is feed out, the fold roller motor stops the exit roller. The machine then monitors the tray full sensors every feed-out of a paper stack.
  • Page 787 Booklet Tray - Examples - After the copier makes a booklet with 1 sheet of 11 x 17 inch paper, the machine checks every feed-out of a paper stack for the ‘Full 1’ condition. If the Full 1 condition occurs 15 times (‘15 Cnt’...

  • Page 788: Jogger Unit

    Jogger Unit JOGGER UNIT The jogger is used in corner-staple mode and in booklet mode. For each sheet of paper when it arrives in the staple tray, the following is done. The jogger motor [A] drives the jogger fences [B]. The positioning roller solenoid moves the positioning roller [C] onto the top of the sheet.

  • Page 789: Exit Guide Plate, Paper Feed Out

    Exit Guide Plate, Paper Feed Out EXIT GUIDE PLATE, PAPER FEED OUT The exit guide plate [A] opens when a stapled stack is fed out. Also it opens every time a sheet is fed to the staple tray, to prevent the paper running into the exit roller during stacking.

  • Page 790: Stapler Unit Movement

    Stapler Unit Movement STAPLER UNIT MOVEMENT The machine has only one stapler [A]. It does stapling for booklets and for corner stapling. The stapler unit motor [B] moves the stapler from side to side. The stapler unit HP sensor [C] detects when the stapler unit is at home position. In corner staple mode, at the start of the job, the stapler moves to the position where the stapler will be inserted.

  • Page 791: Stacking For Booklet Stapling

    Stacking for Booklet Stapling STACKING FOR BOOKLET STAPLING 2.9.1 OVERVIEW There are two stoppers near the stapler unit. These stoppers hold the stack of paper in the correct position during stacking. The stoppers are called ‘stopper S’ and ‘stopper L’. Stopper S is used for legal size paper, or shorter than 8.5 x 14 inches.

  • Page 792: Longer Than 8.5 X 14 Inches

    Stacking for Booklet Stapling When the stack is complete, stopper S moves away [D], and the machine feeds the stack to the correct position for stapling. To do this, the upper clamp roller motor [E] rotates the upper clamp roller. 2.9.3 LONGER THAN 8.5 X 14 INCHES At the start of the set, the stapler moves to the center position.
  • Page 793 Stacking for Booklet Stapling previous section). When the stack is complete, the stapler moves to the rear-side position, and stopper L moves away. The machine feeds the stack to the correct position for stapling. B793...

  • Page 794: Moving The Stack To The Folding Position

    Moving the Stack to the Folding Position 2.10 MOVING THE STACK TO THE FOLDING POSITION First, the upper clamp roller feeds the stack down after the stack has been stapled. When the lower clamp roller [A] catches the stack, the upper clamp roller stops, and the lower clamp roller feeds the stack down.

  • Page 795: Folder

    Folder 2.11 FOLDER 2.11.1 OVERVIEW The fold plate pushes the stack into the nip between the fold rollers. The fold rollers feed out the stack, then reverse to feed it back in again. Then, the fold rollers feed the stack out of the folder, to the booklet tray.

  • Page 796: Fold Rollers

    Folder 2.11.3 FOLD ROLLERS [F]: Fold Roller Motor. Drives forward to feed out the stack at the fold, and then drives forward again to feed out the folded stack. This cycle can be repeated by changing the setting of SP6136. [G]: Fold Rollers.

  • Page 797: Punch Unit

    Punch Unit 2.12 PUNCH UNIT 2.12.1 OVERVIEW OF OPERATION Skew Correction Before Punching The finisher entrance roller corrects for paper skew and then the punch unit moves across to punch the holes at the correct position. Each sheet is punched one at a time. Paper feeds out of the copier.
  • Page 798 Punch Unit Punch Unit Position Correction These operations (skew correction before punching, and punch unit position correction) increase the accuracy of the punch alignment. The trailing edge of the sheet passes the finisher entrance sensor [A]. The paper position slide unit moves the paper position sensor [B] forward to the edge of the paper.

  • Page 799: Paper Position Detection

    Punch Unit These SP codes adjust the punch hole alignment: SP6128 Adjusts the punch positions in the direction of paper feed. SP6129 Adjusts the punch position perpendicular to the direction of feed. For more, see Section "5. Service Tables". 2.12.2 PAPER POSITION DETECTION The paper position sensor slide motor [A] extends and retracts the paper position slide that holds the paper position sensor [B].

  • Page 800: Punch Unit Movement

    Punch Unit 2.12.3 PUNCH UNIT MOVEMENT The punch movement motor [A] extends and retracts the punch unit to put it at the correct position for punching. The punch movement HP sensor [B] detects the position when it retracts, switches off the punch movement motor, and stops the punch unit at its home position.

  • Page 801: Punch Hopper Mechanism

    Punch Unit The timing for 2-hole punching [E] is different from 3-hole punching [F]. When the punch unit is at the punching position, the punch motor turns until the encoder detects the starting position for 2-hole or 3-hole punching. This is the ‘1’ position in the diagrams (the first diagram is for 2-hole punching, and the second diagram is for 3-hole punching).
  • Page 802 Punch Unit The punch hopper full sensor [B] does the following: Signals that the hopper is full when it detects the top of the stack of punchouts that have collected in the hopper. Detects when the punch hopper is set properly. B793...
  • Page 803 BOOKLET FINISHER & FINISHER SR3020/SR3030/SR4010/SR4020 B804/B805/D373/D374...
  • Page 805 BOOKLET FINISHER & FINISHER SR3020/SR3030/SR4010/SR4020 TABLE OF CONTENTS 1. REPLACEMENT AND ADJUSTMENT ..........1 1.1 COVERS......................1 1.1.1 EXTERIOR COVERS ................1 1.1.2 UPPER TRAY, END FENCE ..............2 1.2 MAIN UNIT.....................3 1.2.1 UPPER TRAY LIMIT SENSOR, LIMIT SWITCH ........3 1.2.2 POSITIONING ROLLER ...............4 1.2.3 PROOF TRAY EXIT SENSOR .............4 1.2.4 UPPER TRAY HEIGHT SENSORS 1, 2 ..........5 1.2.5 EXIT GUIDE PLATE, UPPER TRAY EXIT SENSOR ......5...
  • Page 806 2.1.1 GENERAL LAYOUT ................22 2.1.2 ELECTRICAL COMPONENTS ............24 2.1.3 SUMMARY OF ELECTRICAL COMPONENTS........28 2.1.4 DRIVE LAYOUT .................38 2.2 JUNCTION GATES..................40 2.2.1 PROOF MODE ...................40 2.2.2 SHIFT MODE..................40 2.2.3 STAPLE MODE ..................41 2.3 PRE-STACKING ..................42 2.4 TRAY MOVEMENT MECHANISM ...............44 2.4.1 UPPER TRAY ..................44 2.4.2 LOWER TRAY (B804 ONLY)..............46 2.5 CORNER STAPLING...................49 2.5.1 STACKING AND JOGGING ...............49...
  • Page 807 Read This First Safety and Symbols Replacement Procedure Safety Turn off the main power switch and unplug the machine before beginning any of the replacement procedures in this manual. Symbols Used in this Manual This manual uses the following symbols. : See or Refer to : Screws : Connector...

  • Page 809: Replacement And Adjustment

    Covers 1. REPLACEMENT AND ADJUSTMENT 1.1 COVERS 1.1.1 EXTERIOR COVERS Open the front door [D]. Small upper cover [A] ( x1) Upper cover [B] ( x2) Front door bracket [C] ( x1) Front door [D] Front left side cover [E] ( x2) Cover [F] Paper exit cover [G] (...

  • Page 810: Upper Tray, End Fence

    Covers 1.1.2 UPPER TRAY, END FENCE Remove the rear cover. (* "Exterior Covers") Support the tray [A] with your right hand. Pull gear [B] toward you to release. Slowly lower the tray until it stops. Front side cover [C] ( x1) Rear side cover [D] (...

  • Page 811: Main Unit

    Main Unit 1.2 MAIN UNIT 1.2.1 UPPER TRAY LIMIT SENSOR, LIMIT SWITCH Front door, front left side cover, rear cover, upper cover ( "Exterior Cover") End fence ( 1.1.2 "Upper Tray, End Fence") Upper tray exit mechanism [A] ( x4,  x3) Upper tray limit sensor [B] (...

  • Page 812: Positioning Roller

    Main Unit 1.2.2 POSITIONING ROLLER Open the front door [A]. Pull out the stapling unit [B]. Positioning roller [C] ( x1, timing belt x1) 1.2.3 PROOF TRAY EXIT SENSOR Small upper cover ( 1.1.1 "Exterior Cover") Proof tray exit sensor bracket [A] ( x1) B804/B805/D373/D374...

  • Page 813: Upper Tray Height Sensors 1, 2

    Main Unit Proof tray exit sensor [B] ( x1) 1.2.4 UPPER TRAY HEIGHT SENSORS 1, 2 Small upper cover, upper cover ( 1.1.1 "Exterior Cover") Upper tray paper height sensor bracket [A] ( x1) Upper tray paper height sensor [B] – staple mode (S08) ( x1) Upper tray paper height sensor [C] –...

  • Page 814: Proof Tray Full Sensor

    Main Unit Exit guide plate [B] ( x1, Link and spring,  x1,  x1) Upper tray exit sensor [C] (S6) ( x1) 1.2.6 PROOF TRAY FULL SENSOR Exit guide plate. ( 1.2.5 "Exit Guide Plate, Upper Tray Exit Sensor") Guide plate [A] (hook x 2) Sensor bracket [B] (...

  • Page 815: Finisher Entrance Sensor

    Main Unit 1.2.7 FINISHER ENTRANCE SENSOR Disconnect the finisher if it is connected to the copier. Sensor bracket [A] ( x1) Finisher entrance sensor [B] (S1) ( x1) 1.2.8 PRE-STACK TRAY EXIT SENSOR Disconnect the finisher if it is connected to the copier. Sensor bracket [A] Pre-stack tray exit sensor [B] (S2) B804/B805/D373/D374...

  • Page 816: Stapler Unit

    Stapler Unit 1.3 STAPLER UNIT 1.3.1 CORNER STAPLER Open the front door. Pull out the stapler unit. Inner cover [A] ( x3) Stapler unit holder [B] ( x1) Corner stapler [C] (M20) ( x1) B804/B805/D373/D374...

  • Page 817: Positioning Roller

    Stapler Unit 1.3.2 POSITIONING ROLLER Open the front door [A]. Pull out the stapling unit [B]. Positioning roller [C] ( x1, timing belt x1) B804/B805/D373/D374...

  • Page 818: Fold Unit

    Fold Unit 1.4 FOLD UNIT 1.4.1 FOLD UNIT Remove the back cover ( 1.1.1 "Exterior Covers"). Open the front door. The stapler unit is heavy. Ground cable [A] ( x1) Harness [B] ( x6,  x6) Stapler unit [C] ( x4) B804/B805/D373/D374...
  • Page 819 Fold Unit Support the fold unit with your hand to prevent it from falling. The fold unit is heavy. Folding unit [D] ( x4,  x2,  x6) If you have replaced the folding unit: Read the DIP SW settings on the decal [A] attached to the back of the new folding unit. Check the DIP SW settings on the main board [B] of the finisher.

  • Page 820: Fold Unit Entrance Sensor

    Fold Unit 1.4.2 FOLD UNIT ENTRANCE SENSOR Pull out the stapler unit ( 1.3.2 "Positioning Roller"). Fold unit entrance sensor bracket [A] ( x2) Fold unit entrance sensor [B] (S26) ( x1,  x1) 1.4.3 FOLD UNIT EXIT SENSOR Open the front door. Pull out the stapler unit ( 1.3.2 "Positioning Roller").

  • Page 821: Stack Present Sensor

    Fold Unit Fold unit upper cover [C] ( x1) Paper clamp mechanism [D] ( x4) Fold unit exit sensor bracket [E] ( x1) Fold unit exit sensor [F] (S31) ( x1) 1.4.4 STACK PRESENT SENSOR If you intend to correct the horizontal and vertical skew for the fold unit at the same time, do those adjustments first, then replace the sensor.

  • Page 822: Folding Horizontal Skew Adjustment (For B804 Only)

    Fold Unit Guide plate [A]. Stay [B] ( x4) Left plate [C] ( x4) Sensor bracket [D] ( x1) Stack present sensor [E] (S32) ( x1) 1.4.5 FOLDING HORIZONTAL SKEW ADJUSTMENT (FOR B804 ONLY) The fold unit is adjusted for optimum performance before the finisher is shipped from the factory.
  • Page 823 Fold Unit Open the front door and pull the stapler unit [A] out of the finisher. Open the guide plate [B]. Loosen the adjustment screw [C] and then tighten until it stops. (Do not over tighten.) Remove the lock screw [D]. Raise the tip [E] of the adjustment screw very slightly and allow it to descend under its own weight.
  • Page 824 Fold Unit 15. Open the front door of the finisher and pull the stapler unit [H] out. 16. Open the guide plate [I]. 17. Turn the adjustment screw [J] to correct the amount of skew you measured from the test sheet.

  • Page 825: Fold Vertical Skew Adjustment (For B804 Only)

    Fold Unit 1.4.6 FOLD VERTICAL SKEW ADJUSTMENT (FOR B804 ONLY) The fold unit is adjusted for optimum performance before the finisher is shipped from the factory. Do this adjustment only if the edges of folded booklets are not even. Switch the copier on. Do a folding test.
  • Page 826 Fold Unit B804/B805/D373/D374...

  • Page 827: Booklet Stapler Unit

    Booklet Stapler Unit 1.5 BOOKLET STAPLER UNIT 1.5.1 BOOKLET STAPLER Open the front door. Pull out the stapler unit ( 1.2.2 "Positioning Roller"). Harness cover [A] ( x2) Booklet stapler support stay [B] ( x4,  x2,  x4) Stapler [C] ( x4) 1.5.2 BOOKLET STAPLER MOTOR Open the front door.
  • Page 828 Booklet Stapler Unit Stay [A] ( x4). Left plate [B] ( x4) Harness cover [C] ( x2) Booklet stapler support stay [D] ( x4,  x2,  x4) Booklet stapler [E] ( x4) Booklet stapler motor [F] ( x2,  x1) To Reattach the Booklet Stapler Motor Reattach the booklet stapler motor.
  • Page 829 Booklet Stapler Unit Attach the special tool [A] and reattach the booklet stapler stay. This tool is included with the stapler spare part. Turn the gear [B] with your finger until it stops. Tighten the screws to attach to the booklet stapler motor. Remove the stay again and remove the special tool.

  • Page 830: Detailed Section Descriptions

    Component Layout 2. DETAILED SECTION DESCRIPTIONS 2.1 COMPONENT LAYOUT 2.1.1 GENERAL LAYOUT 1. Proof Tray Junction Gate 7. Lower Tray (Booklet)* 2. Punch Unit 8. Folder Rollers* 3. Stapler Junction Gate 9. Folder Plate* 4. Pre-Stack Junction Gate 10. Booklet Stapler* 5.
  • Page 831 Component Layout : B804 Only Paper direction The operation of the proof tray and stapler junction gates direct the flow of the paper once it enters the finisher: Proof Junction Gate Stapler Junction Gate Paper Feeds Closed Closed Paper feeds straight through Open Closed Paper feeds to the proof tray...

  • Page 832: Electrical Components

    Component Layout 2.1.2 ELECTRICAL COMPONENTS Upper Area B804/B805 1. Upper/Proof Exit Motor (M4) 10. Upper Tray Limit Switch (SW2) 2. Stapling Tray Junction Gate Solenoid 11. Stacking Roller HP Sensor (S13) (SOL2) 12. Stacking Sponge Roller Motor (M10) 3. Upper Transport Motor (M2) 13.
  • Page 833 Component Layout Lower Area B804/B805 8. Positioning Roller Motor (M14) 1. Upper Tray Lift Motor (M21) 9. Lower Tray Full Sensor – Front (S34)* 2. Lower Transport Motor (M3) 10. Lower Tray Full Sensor – Rear (S33)* 3. Entrance Motor (M1) 11.
  • Page 834 Component Layout Punch Unit B702 1. Punch Encoder Sensor (S24) 6. Paper Position Slide HP Sensor (S22) 2. Punch Drive Motor (M24) 7. Paper Position Sensor (S3) 3. Punch HP Sensor (S24) 8. Punch Hopper Full Sensor (S4) 4. Punch Unit Board (PCB3) 9.
  • Page 835 Component Layout Stacker/Stapler - B804/B805 7. Jogger Fence Motor (M15) 1. Stack Present Sensor (S32)* 8. Jogger Fence HP Sensor (S15) 2. Stack Junction Gate HP Sensor (S27)* 9. Corner Stapler Movement Motor (M6) 3. Stack Feed Out Belt HP Sensor (S16) 10.

  • Page 836: Summary Of Electrical Components

    Component Layout B804 Fold unit 1. Clamp Roller HP Sensor (S25) 6. Fold Cam HP Sensor (S30) 2. Fold Roller Motor (M12) 7. Fold Bottom Fence HP Sensor (S28) 3. Fold Plate Motor (M11) 8. Fold Unit Entrance Sensor (S26) 4.
  • Page 837 Component Layout Component Function Boards (PCB) PCB1 Main Board The main board that controls the finisher PCB2 Booklet Stapler Board A separate board that controls booklet finishing. PCB3 Punch Unit Board The board that controls the punch unit. Motors Finisher Entrance Drives 1) the finisher entrance rollers, 2) and the punch Motor waste transport belt of the punch unit.
  • Page 838 Component Layout Component Function are part of the paper feed path and feed the stack toward the bottom fence of the fold unit. When the idle roller is retracted, the stacks falls a very short distance (3 mm) onto the fold unit bottom fence below. These rollers remain unclamped while the bottom fence positions the stack for folding and while the stack is folded by the fold rollers.
  • Page 839 Component Layout Component Function lowers the stack 10 mm below the fold position, and then raises it to the fold position. Drives the large cam that operates the stack junction gate at the top of the stapling tray. When this gate is Stack Junction Gate open, it directs the ascending stack to the upper tray if it Motor...
  • Page 840 Component Layout Component Function Detects 1) paper fed from the pre-stack tray to the stapling tray, and detects 2) paper in the pre-stack when Pre-stack Tray Exit the copier is switched on. (This sensor performs no Sensor timing function. The entire flow of paper through the pre-stacking mechanism is controlled by motor pulse counts.) The photosensor that detects the edge of the paper and...
  • Page 841 Component Layout Component Function This is the upper sensor of the upper/lower paper height Upper Tray Paper sensor pair that controls the lift of the upper tray. This Height Sensor (Staple sensor detects the paper height of the stack in the upper Mode) tray when the copier is operating in the staple mode.
  • Page 842 Component Layout Component Function back against the end fence of the upper tray to keep the bottom of the stack aligned. A photo sensor that detects whether paper is in the Stapling Tray Paper stapling tray. When this sensor detects paper, the Sensor bottom fence motor raises or lowers the bottom fence to position the selected paper size for booklet stapling.
  • Page 843 Component Layout Component Function B804: This sensor is not used on the booklet finisher. There is only one upper tray full sensor (S18). Upper Tray Full B805: One of two upper tray full sensors. This is the Sensor (B805 only) lower tray full sensor for A4 and smaller paper.
  • Page 844 Component Layout Component Function Controls the movement of the bottom fence in the Fold Bottom Fence HP folding unit using pulse counts based on the size of the Sensor paper selected for the job to position the stack correctly for feeding. Along with the fold plate cam HP sensor (S30) this sensor controls the movement of the fold plate .
  • Page 845 Component Layout Component Function sensors are used to detect when the tray is full and stop the job. (The lower tray is stationary. At tray full, the job halts until booklets are removed from the lower tray.) This front sensor is the higher sensor of the lower tray full sensor pair.

  • Page 846: Drive Layout

    Component Layout Component Function Switches Front Door Safety The safety switch cuts the dc power when the front door Switch is opened. A micro-switch cuts the power to the upper tray lift motor when the upper tray reaches its upper limit. This switch Upper Tray Limit SW duplicates the function of the upper tray limit sensor (S12) and stops the upper tray if S12 fails.
  • Page 847 Component Layout 1. Upper Transport Motor (M2) 6. Folder Plate Motor* (M11) 2. Upper/Proof Exit Motor (M4) 7. Positioning Roller Motor (M14) 3. Upper Tray Lift Motor (M21) 8. Lower Transport Motor (M3) 4. Feed-Out Belt Motor (M5) 9. Entrance Motor (M1) 5.

  • Page 848: Junction Gates

    Junction Gates 2.2 JUNCTION GATES The positions of the proof tray and staple tray junction gates determine the direction of paper feed after paper enters the finisher. 2.2.1 PROOF MODE Proof tray junction gate [A] opens. Staple tray junction gate [B] remains closed. The proof tray junction gate directs paper to the proof tray above.

  • Page 849: Staple Mode

    Junction Gates 2.2.3 STAPLE MODE Proof tray junction gate [A] remains closed. Staple tray junction gate [B] opens The staple tray junction gate directs the paper to the staple tray below for jogging and stapling. B804/B805/D373/D374...

  • Page 850: Pre-Stacking

    Pre-Stacking 2.3 PRE-STACKING This example describes what happens to Set 2 during the feed and stapling cycle of sets that contain three pages. [A]: While the Set 1 is being stapled in the staple tray [1], the 1st sheet of Set 2 [2] feeds to the pre-stack tray, and the 2nd sheet of Set 2 [3] enters the finisher.
  • Page 851 Pre-Stacking In one-staple mode, one sheet goes to the pre-stacking tray. Then two sheets go to the stapler tray at the same time. In two-staple mode and booklet mode, three sheets go to the pre-stacking tray. Then four sheets go to the stapler tray at the same time. B804/B805/D373/D374...

  • Page 852: Tray Movement Mechanism

    Tray Movement Mechanism 2.4 TRAY MOVEMENT MECHANISM 2.4.1 UPPER TRAY [A]: Upper Tray Lift Motor [B]: Upper Feeler [C]: Upper Tray Paper Height Sensor 1 (Staple Mode) [D]: Upper Tray Paper Height Sensor 2 (Non-Staple Mode) [E]: Lower Feeler [F]: Upper Tray Limit Sensor [G]: Upper Tray Limit Switch [H]: Upper Tray Full Sensors The B804 (shown above) has only one upper tray full sensor (the higher sensor at...
  • Page 853 Tray Movement Mechanism A4, LT. Five sensors and one switch control the operation of the upper tray lift motor [A]. Upper Tray Raising and Lowering Sensors, Switch Action Operation Mode Stops the lift motor at the standby position when the actuator of the upper Standby feeler deactivates sensor [C] (when it is (Non-Staple...

  • Page 854: Lower Tray (B804 Only)

    Tray Movement Mechanism When the actuator on the tray activates the upper tray full sensor [H] the tray lift B804 motor [A] switches off. Operation resumes after some copies are removed from the tray. Upper Tray Capacity: 2,000 sheets (A4, LT) The operation of the upper tray full sensor is the same as the B804.
  • Page 855 Tray Movement Mechanism If the lower tray is not installed (this is detected if the front and rear sensors remain OFF), the machine will not operate in the booklet staple and fold mode. When booklet mode is selected, the tray full message appears on the operation panel. The combinations of the two actuators and two sensors as the actuator arm rises determines the number of booklets that the lower tray can hold before the job stops.
  • Page 856 Tray Movement Mechanism Lower Tray Full Condition Table A3 (DLT) 1 Sht 2 Sht 3 Sht 4 Sht 5 Sht 6 Sht 7 Sth 8 Sht 9 Sht … Full 1 3 Cnt — — — — — — — —...

  • Page 857: Corner Stapling

    Corner Stapling 2.5 CORNER STAPLING 2.5.1 STACKING AND JOGGING [A]: Jogger Fence Motor (M15) [B]: Jogger Fences [C]: Positioning Roller [D]: Jogger Fence HP Sensor (S15) [E]: Stapling Edge Pressure Plate Solenoid (SOL4) [F]: Pressure Plate At the beginning of the job, the jogger fence motor (M15) [A] switches on and moves the jogger fences [B] to the standby position (7.5 mm from the sides of the selected paper size).

  • Page 858: Stapler Movement

    Corner Stapling size. This pushes the positioning roller [C] onto the sheet and pushes it down onto bottom fence. This aligns the edge of the stack. Next, the jogger fence motor: Switches on again and moves the jogger fences to within 2.6 mm of the sides of the stack to align the sides of the stack.
  • Page 859 Corner Stapling The stapler performs horizontal and rotational movement in each of the four staple modes: Front 1 staple Rear 1 staple Rear diagonal staple Rear/Front 2 staples The stapler movement motor [A] drives a timing belt that moves stapler [B] left and right on its stainless steel rail.

  • Page 860: Corner Stapling

    Corner Stapling 2.5.3 CORNER STAPLING Staple firing is driven by the stapler motor [A] inside the stapler unit. The stapler hammer [B] fires the stapler [C]. The cartridge set sensor [D] detects the cartridge at the correct position. The staple end sensor [E] detects the staple end condition. B804/B805/D373/D374...

  • Page 861: Booklet Stapling (B804 Only)

    Booklet Stapling (B804 Only) 2.6 BOOKLET STAPLING (B804 ONLY) 2.6.1 BOOKLET PRESSURE MECHANISM [A]: Booklet Pressure Roller Solenoid (SOL5) [B]: Booklet Pressure Roller Arm [C]: Booklet Pressure Roller As soon as the edges are aligned by the positioning roller and the jogger fences, the stack feed out belt moves.

  • Page 862: Booklet Stapling And Folding

    Booklet Stapling (B804 Only) 2.6.2 BOOKLET STAPLING AND FOLDING Overview 1. Leading Edge Pressure Roller 13. Corner Stapler (M20) 2. Stack Present Sensor (S32) 14. Stapling Tray Paper Sensor (S14) 3. Feed Out Belt Pawl 1 15. Feed Out Belt 4.
  • Page 863 Booklet Stapling (B804 Only) The last sheet of the stack [1] enters the stapling tray. The jogger fences [2] jog the last sheet into position (based on the width of the selected paper size) and then retract and stop 1 mm away from the sides of the stack. The pressure plate [3] and booklet pressure roller [4] press down on the sheet.
  • Page 864 Booklet Stapling (B804 Only) The jogger fences remain 1 mm away from the sides of the stack. The feed out belt [1] raises the stack until the top of the stack is 10 mm past the leading edge pressure roller [2] and stops.
  • Page 865 Booklet Stapling (B804 Only) The bottom fence [1] raises the stack to the prescribed fold position [2]. The fold plate [3] moves to the left and advances 1/3 its maximum horizontal stroke and exerts 20 kg (44 lb.) of pressure at the fold rollers [4]. With the fold plate pushing the stack into nip of the fold rollers [5], the fold rollers begin to rotate and fold the stack as it feeds out.
  • Page 866 Booklet Stapling (B804 Only) When the fold rollers [1] feed the stack 10 mm past the nip, the fold plate retracts until it no longer touches the stack. The fold unit exit sensor [2] detects the folded edge of the stack and stops the fold rollers.
  • Page 867 Booklet Stapling (B804 Only) With the feed of the stack halted, the fold plate [1] retracts. The fold plate HP sensor (not shown) detects the fold plate and stops it at its home position. The fold rollers [2] and fold unit exit rollers [3] begin to rotate together and feed out the folded booklet to the lower tray.

  • Page 868: Booklet Stapling And Folding Mechanisms

    Booklet Stapling (B804 Only) 2.6.3 BOOKLET STAPLING AND FOLDING MECHANISMS Booklet Stapler [A]: Feed Out Belt Pawl. Raises the stack to stapling position. [B]: Booklet Stapler EH185R – Rear [C]: Booklet Stapler EH185R – Front Stack Junction Gate [D]: Stack Junction Gate Motor. Drives a timing belt and stack junction gate cam. [E]: Stack Junction Gate Cam.
  • Page 869 Booklet Stapling (B804 Only) Clamp Roller [A]: Fold Roller Motor. Drives the stationary clamp drive roller as well as the fold rollers (see next page). [B]: Clamp Rollers. Clamp Roller – Drive. Rotated by the fold roller motor, this stationary roller feeds the stack down with the retracting roller closed.
  • Page 870 Booklet Stapling (B804 Only) Fold Plate [A]: Bottom Fence Stack Stoppers. Catches the stack after it is released by the clamp rollers. [B]: Fold Plate Motor. Drives the timing belt and gears that move the fold plate. [C]: Fold Plate Cam. Controls the movement of the fold plate to the left (into the nip of the fold rollers) and right (toward the fold plate home position).

  • Page 871: Upper Tray Output

    Upper Tray Output 2.7 UPPER TRAY OUTPUT 2.7.1 FEED OUT [A]: Feed Out Belt Motor [B]: Stack Feed-Out Belt [C]: Pawl [D]: Exit Rollers [E]: Exit Guide Plate Motor [F]: Exit Guide Plate [G]: Exit Guide Plate HP Sensor [H]: Upper Tray After the stack is stapled, the feed out belt motor [A] switches on and drives the feed out belt [B].

  • Page 872: Feed Out Stacking

    Upper Tray Output The feed out belt motor stops 300 ms to prevent the stapled stack from rising too high. Next, the feed out belt motor switches on again, then the pawl actuates its home position sensor and switches off the motor. There are two output pawls on the feed out belt to improve the productivity of the feed out operation.

  • Page 873: Punch Unit B702 (For B804/B805)

    Punch Unit B702 (For B804/B805) 2.8 PUNCH UNIT B702 (FOR B804/B805) 2.8.1 OVERVIEW OF OPERATION Skew Correction before Punching This punch unit corrects for paper skew and then positions the punch unit to punch holes at the correct position. Each sheet is punched one at a time. Paper feeds out of the copier.
  • Page 874 Punch Unit B702 (For B804/B805) Punch Unit Position Correction These operations (skew correction before punching, and punch unit position correction) increase the accuracy of the punch alignment. The trailing edge of the sheet passes the finisher entrance sensor [A]. The paper position slide unit [B] moves the paper position sensor [C] forward to the edge of the paper.

  • Page 875: Punch Mechanisms

    Punch Unit B702 (For B804/B805) These SP codes adjust the punch hole alignment: SP6-128 Adjusts the punch positions in the direction of paper feed. SP6-129 Adjusts the punch position perpendicular to the direction of feed. For more, see Section "Service Tables". 2.8.2 PUNCH MECHANISMS Paper Position Detection B804/B805/D373/D374...
  • Page 876 Punch Unit B702 (For B804/B805) [A]: Finisher Entrance Motor (M1) [B]: Finisher Entrance Roller [C]: Finisher Entrance Sensor (S1) [D]: Paper Position Sensor Slide Motor (M7) [E]: Paper Position Sensor (S27) [F]: Paper Position Sensor Slide HP Sensor (S22) The finisher entrance motor (M1) [A] drives the finisher entrance rollers [B] that feed paper from the copier into the finisher.
  • Page 877 Punch Unit B702 (For B804/B805) [A]: Punch Movement Motor (M9) [B]: Punch Movement HP Sensor (S21) [C]: Punch Drive Motor (M24) The punch movement motor (M9) [A] extends and retracts the punch unit to position it at the correct position for punching. The punch movement HP sensor (S21) [B] detects the position when it retracts, switches off the punch position movement motor, and stops the punch unit at its home position.

  • Page 878: Punch Hopper Mechanism

    Punch Unit B702 (For B804/B805) The timing for 2-hole punching [E] is different from 3-hole punching [F]. When the punch unit is at the punching position, the punch motor turns until the encoder detects the starting position for 2-hole or 3-hole punching. This is the ‘1’...
  • Page 879 Punch Unit B702 (For B804/B805) [A]: Finisher Entrance Motor (M1) [B]: Punch Waste Belt [C]: Punch Waste Hopper [D]: Punch Hopper Full Sensor (S4) The finisher entrance motor (M1) [A] drives the timing belt and gears that rotate the punch waste belt [B].

  • Page 880: Finisher Jam Detection

    Finisher Jam Detection 2.9 FINISHER JAM DETECTION Display Mode What It Means Finisher After main machine exit sensor goes OFF, entrance finisher entrance sensor does not go ON even Proof sensor late after enough time to feed 450 mm. R1 to R3 Shift Finisher After finisher entrance sensor goes ON, it does...
  • Page 881 Finisher Jam Detection Display Mode What It Means After finisher entrance sensor goes ON, upper Upper tray exit tray exit sensor does not go ON even after sensor late enough time to feed 485 mm. Shift After finisher entrance sensor goes OFF, upper Upper tray exit tray exit sensor does not go OFF even after sensor lag...
  • Page 883 PAPER FEED UNIT PB3040 D351...
  • Page 885 PAPER FEED UNIT PB3040 (D351) TABLE OF CONTENTS 1. REPLACEMENT AND ADJUSTMENT ..........1 1.1 REAR COVER ....................1 1.2 MOTORS AND CLUTCHES ................2 1.2.1 LIFT MOTORS..................2 1.2.2 UPPER AND LOWER PAPER FEED CLUTCHES .......2 1.2.3 PAPER FEED MOTOR.................3 1.3 MAIN BOARD ....................4 1.4 LIFT, PAPER END, AND RELAY SENSORS ..........5 1.5 PAPER FEED UNIT ..................6 1.6 PICK-UP, PAPER FEED AND SEPARATION ROLLERS......7...
  • Page 887 Read This First Safety and Symbols Replacement Procedure Safety Turn off the main power switch and unplug the machine before beginning any of the replacement procedures in this manual. Symbols Used in this Manual This manual uses the following symbols. : See or Refer to : Screws : Connector...

  • Page 889: Replacement And Adjustment

    Rear Cover 1. REPLACEMENT AND ADJUSTMENT 1.1 REAR COVER Securing brackets [A] ( x 1 each) Rear cover [B] ( x 2) D351...

  • Page 890: Rear Cover

    Motors and Clutches 1.2 MOTORS AND CLUTCHES 1.2.1 LIFT MOTORS Rear cover ( "Rear Cover") Lift motors [A][B] ( x 2,  x 1 each) 1.2.2 UPPER AND LOWER PAPER FEED CLUTCHES Rear cover ( "Rear Cover") Upper paper feed gear unit [A] ( x 3,  x 1) Upper paper feed clutch bracket [B] (...

  • Page 891: Paper Feed Motor

    Motors and Clutches Lower paper feed clutch bracket [D] ( x 1, bushing x 1,  x 2) Lower paper feed clutch [E] ( x 1) 1.2.3 PAPER FEED MOTOR Rear cover ( "Rear Cover") Paper feed motor [A] ( x 1,  x 2) When installing the paper feed motor, make sure that the gear of the paper feed motor holds the timing belt [B].

  • Page 892: Main Board

    Main Board 1.3 MAIN BOARD Rear cover ( "Rear Cover") Main board [A] (All s,  x 2, snap pin x 2) D351...

  • Page 893: Lift, Paper End, And Relay Sensors

    Lift, Paper End, and Relay Sensors 1.4 LIFT, PAPER END, AND RELAY SENSORS Paper feed unit ( "Paper Feed Unit") Vertical transport sensor bracket [A] ( x 1) Vertical transport sensor [B] ( x 1) Paper feed sensor bracket [C] ( x 1) Paper feed sensor [D] (...

  • Page 894: Paper Feed Unit

    Paper Feed Unit 1.5 PAPER FEED UNIT Right cover [A] ( x 2) Vertical transport guide [B] of the paper feed unit Pull the tray 3 (or 4). Paper guide [C] Paper feed unit [D] ( x 2,  x 1,  x 2) When replacing the paper feed unit of tray 4, do the same.

  • Page 895: Pick-Up, Paper Feed And Separation Rollers

    Pick-up, Paper Feed and Separation Rollers 1.6 PICK-UP, PAPER FEED AND SEPARATION ROLLERS Paper feed unit ( "Paper Feed Unit) Roller holder [A] ( x 1) Pick-up roller [B] Paper feed roller [C] Separation roller [D] ( x 1) D351...

  • Page 896: Details

    Component Layout 2. DETAILS 2.1 COMPONENT LAYOUT 2.1.1 MECHANICAL COMPONENT LAYOUT 1. Upper tray 6. Separation roller 2. Paper size switch: Upper tray 7. Tray lift arm 3. Pick-up roller: Upper tray 8. Lift arm shaft 4. Paper feed roller 9.

  • Page 897: Electrical Component Layout

    Component Layout 2.1.2 ELECTRICAL COMPONENT LAYOUT 1. Main board 8. Lower paper feed clutch 2. Feed motor 9. Vertical transport guide switch 3. Upper tray lift motor 10. Paper end sensor 4. Lower tray lift motor 11. Vertical transport sensor 1 5.

  • Page 898: Paper Feed

    Paper Feed 2.2 PAPER FEED Paper Feed Mechanism: An FRR (feed and reverse roller) feed mechanism is used ( "Paper Feed Methods" in the Core Technology Manual). Drive Path: Tray 3 (upper tray) and tray 4 (lower tray) have identical paper feed systems. The feed motor [A] drives all the rollers in the unit.

  • Page 899: Paper Size Detection

    Paper Size Detection 2.3 PAPER SIZE DETECTION There are four paper size switches [A] working in combination. Switch 1 (right end) is for tray set detection. The other three switches detect the paper size as shown in the table below. The actuator [B] is moved by the end plate [C]. 0: Not pushed, 1: Pushed Models Switch Location...
  • Page 900 Paper Size Detection *3: Detects either LT LEF or A4 LEF, depending on the setting of SP5-181-6 or 10. *4: Detects either Exe LEF or B5 LEF, depending on the setting of SP5-181-9 or The machine disables paper feed from a tray if the paper size cannot be detected (if the paper size actuator is broken or no tray is installed).

  • Page 901: Reverse Roller And Pick-Up Roller Release

    Reverse Roller and Pick-Up Roller Release 2.4 REVERSE ROLLER AND PICK-UP ROLLER RELEASE The pick-up roller and separation roller release the paper when it is not being fed. This helps remove jammed paper easily. When the paper tray [A] is not in the machine, the separation roller [B] is away from the paper feed roller [C] and the pick-up roller stays in its upper position.

  • Page 902: Paper Height And End Detection

    Paper Height and End Detection 2.5 PAPER HEIGHT AND END DETECTION 2.5.1 PAPER HEIGHT DETECTION Two paper height sensors [A] [B] and actuator [C] are built into the paper tray lift motor. The paper height sensors, detect the amount of paper in the tray. The actuator [C] has two semicircles, and it is engaged with the lift arm shaft via gears.

  • Page 903: Paper End And Bottom Plate

    Paper Height and End Detection OFF: No actuator 2.5.2 PAPER END AND BOTTOM PLATE The paper stack raises the paper end feeler [A] and the paper end sensor [B] deactivates if there is some paper in the paper tray. When the paper tray runs out of paper, the paper end feeler [A] drops into the cutout in the tray bottom plate.

  • Page 904: Paper Lift

    Paper Lift 2.6 PAPER LIFT When the machine detects that a tray has been placed in the machine, the tray lift motor [A] rotates and the coupling gear [B] on the tray lift motor engages the pin [C] on the lift arm shaft [D].
  • Page 905 LCIT PB3050 D352...
  • Page 907 LCIT PB3050 (D352) TABLE OF CONTENTS 1. REPLACEMENT AND ADJUSTMENT ..........1 1.1 LEFT AND RIGHT TRAY ................1 1.2 SENSORS .....................2 1.2.1 PAPER HEIGHT SENSORS ON THE PAPER STORAGE SIDE ..2 1.2.2 END FENCE HP SENSOR/PAPER END SENSOR 2 ......2 1.3 CHANGING THE TRAY SIZE ................3 1.4 MAIN BOARD ....................4 1.5 CLUTCHES....................5...
  • Page 909 Read This First Safety and Symbols Replacement Procedure Safety Turn off the main power switch and unplug the machine before beginning any of the replacement procedures in this manual. Symbols Used in this Manual This manual uses the following symbols. : See or Refer to : Screws : Connector...

  • Page 911: Replacement And Adjustment

    Left and Right Tray 1. REPLACEMENT AND ADJUSTMENT 1.1 LEFT AND RIGHT TRAY Pull the LCT drawer. If the right tray comes up with the left tray, push the right tray into the LCT. Left tray [A] (x 2) Remove the right tray [B] while pressing down the stopper [C]. When reinstalling the tray, set the tray on the guide rail and carefully push the tray in, making sure to keep the tray level.

  • Page 912: Sensors

    Sensors 1.2 SENSORS 1.2.1 PAPER HEIGHT SENSORS ON THE PAPER STORAGE SIDE Tray ( "Left and Right Tray") Rear fence [A] ( x 1) Rear fence bracket [B] ( x 2) Paper height sensors [C] ( x 1 each) 1.2.2 END FENCE HP SENSOR/PAPER END SENSOR 2 Bottom cover [D] (...

  • Page 913: Changing The Tray Size

    Changing the Tray Size 1.3 CHANGING THE TRAY SIZE Remove the fence screws (x 5). Change the position of the fences. Before fastening the screws, set paper in the tray. D352...

  • Page 914: Main Board

    Main Board 1.4 MAIN BOARD Rear cover ( "Tray Lift Motor" ) Main board [A] (All s,  x 2, snap x 2) D352...

  • Page 915: Clutches

    Clutches 1.5 CLUTCHES 1.5.1 STACK TRANSPORT CLUTCH Rear cover ( "Tray Lift Motor") Stack transport clutch [A] ( x 1,  x 1) 1.5.2 PAPER FEED CLUTCH Rear cover ( "Tray Lift Motor") Paper feed gear unit [A] ( x 3,  x 1) Paper feed clutch bracket [B] (...

  • Page 916: Paper Feed Unit

    Paper Feed Unit 1.6 PAPER FEED UNIT Right cover [A] Open the vertical guide plate [B] Guide plate [C] Pull the LCT drawer [D]. Paper feed unit [E] ( x 2, x 1) D352...

  • Page 917: Motors

    Motors 1.7 MOTORS 1.7.1 TRAY LIFT MOTOR Securing brackets [A] ( x 1 each) Rear cover [B] ( x 2) Tray lift motor [C] ( x 1,  x 3) D352...

  • Page 918: Tray Motor

    Motors 1.7.2 TRAY MOTOR Rear cover ( "Tray Lift Motor") Tray motor [A] ( x 1,  x 2) When installing the tray motor, make sure that the gear of the tray motor holds the timing belt [B]. D352...

  • Page 919: Pick-Up, Feed And Separation Rollers

    Pick-up, Feed and Separation Rollers 1.8 PICK-UP, FEED AND SEPARATION ROLLERS Paper feed unit ( "Paper Feed Unit") Separation roller [A] ( x 1) Roller holder [B] ( x 1) Feed roller [C] and pick-up roller [D] D352...

  • Page 920: Paper Feed, Paper End, Lift And Relay Sensors

    Paper Feed, Paper End, Lift and Relay Sensors 1.9 PAPER FEED, PAPER END, LIFT AND RELAY SENSORS Paper feed unit ( "Paper Feed Unit") Vertical transport sensor bracket [A] ( x 1,  x 1) Relay sensor [B] Paper feed sensor bracket [C] Paper feed sensor [D] Paper end feeler [E] Paper end sensor holder [F] (hook x 3)

  • Page 921: Paper Feed

    Paper Feed 1.10 PAPER FEED This products uses an FRR type paper feed mechanism. The paper feed unit consists of the pick-up roller [A], paper feed roller [B], separation roller [C], and relay rollers. There is a torque limiter in the back of the separation roller (ferrite powder type). D352...

  • Page 922: Details

    Component Layout 2. DETAILS 2.1 COMPONENT LAYOUT 2.1.1 MECHANICAL COMPONENT LAYOUT 1. Pick-up Roller 6. Lower Limit Sensor 2. Paper Feed Roller 7. Paper End Sensor 2 3. Relay Sensor 8. End Fence HP Sensor 4. Separation Roller 9. Paper Height Sensors 4, 5 5.

  • Page 923: Electrical Component Layout

    Component Layout 2.1.2 ELECTRICAL COMPONENT LAYOUT 1. Main board 11. Paper feed sensors 2. Stack transport clutch 12. Side fence sensor 3. Tray motor 13. Tray lift motor 4. Paper feed clutch 14. Paper height sensor 1, 2, 3 5. Pick-up solenoid 15.

  • Page 924: Electrical Component Descriptions

    Component Layout 2.1.3 ELECTRICAL COMPONENT DESCRIPTIONS Symbol Name Function Index No. Motors Tray Drives all rollers. Tray Lift Drives the paper tray up or down. Sensors Paper Feed Detects whether the paper is jammed at Sensor LCT. Detects the copy paper coming to the Relay relay roller and checks for misfeeds.
  • Page 925 Component Layout Symbol Name Function Index No. left-tray paper stack is moving to the paper feed side.) Paper End 2 Informs the copier/printer when there is (paper storage no paper in the left side (paper storage side) side) of the tray. Detects the amount of paper remaining in Paper Height 4, 5 the left side of the tray.

  • Page 926: Separation Roller And Pick-Up Roller Release

    Separation Roller and Pick-Up Roller Release 2.2 SEPARATION ROLLER AND PICK-UP ROLLER RELEASE To prevent the paper from being torn when pulling out the paper feed tray, the separation and pick-up rollers release automatically. When the paper tray [A] is not inside the machine, the separation roller [B] is away from the paper feed roller [C], and the pick-up roller [D] stays in the upper position.

  • Page 927: Tray Lift

    Tray Lift 2.3 TRAY LIFT When the paper feed tray is put in the machine, the tray switch on the back turns on and the tray lift motor [A] starts. The base plate lift shaft [B] is coupled to the lift motor at the shaft [C], so the base plate [D] of the tray is lifted.

  • Page 928: Paper Amount Detection

    Paper Amount Detection 2.4 PAPER AMOUNT DETECTION The table lists the sensors that are used to detect the amount of remaining paper. Right Tray (Paper feed side) Paper end sensor 1 Paper height sensor 1 to 3 Left Tray (Paper storage side) Paper height sensor 4 and 5 Paper end sensor 2 Right Tray...

  • Page 929: Paper End Detection (Paper Feed Side)

    Paper End Detection (Paper Feed Side) 2.5 PAPER END DETECTION (PAPER FEED SIDE) The paper end sensor 1 [A] detects when copy paper in the paper feed side runs out. When there is paper in the tray, the paper pushes up the feeler [B] and the actuator enters the sensor.

  • Page 930: Paper Stack Transport

    Paper Stack Transport 2.6 PAPER STACK TRANSPORT When the paper in the paper feed side is used up, the tray motor [A] and stack transport clutch [B] turn on. Then the end fence [C] moves the stack of paper from the paper storage side to the paper feed side.
  • Page 931 BRIDGE UNIT BU3030 D386...
  • Page 933 BRIDGE UNIT BU3030 (D386) TABLE OF CONTENTS 1. REPLACEMENT AND ADJUSTMENT ..........1 1.1 BRIDGE UNIT CONTROL BOARD..............1 1.2 BRIDGE UNIT DRIVE MOTOR..............2 1.3 TRAY EXIT SENSOR ..................3 1.4 RELAY SENSOR ...................4 2. DETAILS ................... 5 2.1 MECHANICAL COMPONENT LAYOUT ............5 2.2 DRIVE LAYOUT.....................6 2.3 ELECTRICAL COMPONENT LAYOUT ............7 2.4 ELECTRICAL COMPONENT DESCRIPTION ..........8...
  • Page 935 Read This First Safety and Symbols Replacement Procedure Safety Turn off the main power switch and unplug the machine before beginning any of the replacement procedures in this manual. When taking apart the bridge unit, first take the unit out of the copier. Symbols Used in this Manual This manual uses the following symbols.

  • Page 937: Replacement And Adjustment

    Bridge Unit Control Board 1. REPLACEMENT AND ADJUSTMENT 1.1 BRIDGE UNIT CONTROL BOARD Bridge unit ( "Installation Procedure" in the base copier manual) Rear cover [A] ( x 2) Bridge unit control board [B] ( x 3,  x 4) D386...

  • Page 938: Bridge Unit Drive Motor

    Bridge Unit Drive Motor 1.2 BRIDGE UNIT DRIVE MOTOR Bridge unit ( "Installation Procedure" in the base copier manual) Rear cover ( "Bridge Unit Control Board") Bracket [A] ( x 3,  x 2) Bridge unit drive motor [B] ( x 4,  x 1) D386...

  • Page 939: Tray Exit Sensor

    Tray Exit Sensor 1.3 TRAY EXIT SENSOR Bridge unit ( "Installation Procedure" in the base copier manual) Rear cover ( "Bridge Unit Control Board") Paper tray [A] Exit guide [B] ( x 1) Tray exit sensor [C] ( x 1) D386...

  • Page 940: Relay Sensor

    Relay Sensor 1.4 RELAY SENSOR Bridge unit ( "Installation Procedure" in the base copier manual) Paper tray [A] Relay sensor [B] ( x 1) D386...

  • Page 941: Details

    Mechanical Component Layout 2. DETAILS 2.1 MECHANICAL COMPONENT LAYOUT 1. Upper Exit Roller 5. Relay Sensor 2. Tray Exit Sensor 6. 2nd Transport Roller 3. Junction Gate 7. Left Exit Roller 4. 1st Transport Roller 8. Paper Tray D386...

  • Page 942: Drive Layout

    Drive Layout 2.2 DRIVE LAYOUT Left Exit Roller 2nd Transport Roller 1st Transport Roller Upper Exit Roller Bridge Unit Drive Motor D386...

  • Page 943: Electrical Component Layout

    Electrical Component Layout 2.3 ELECTRICAL COMPONENT LAYOUT Left Guide Switch Right Guide Switch Junction Gate Solenoid Tray Exit Sensor Bridge Unit Control Board Bridge Unit Drive Motor Relay Sensor D386...

  • Page 944: Electrical Component Description

    Electrical Component Description 2.4 ELECTRICAL COMPONENT DESCRIPTION Symbol Name Function Index No. Motors Drive Motor Drives the bridge unit. Sensors Tray Exit Checks for misfeeds. Relay Checks for misfeeds. Switches Right Guide Detects when the right guide is opened. Left Guide Detects when the left guide is opened.

  • Page 945: Junction Gate Mechanism

    Junction Gate Mechanism 2.5 JUNCTION GATE MECHANISM The junction gate [A] directs any paper reaching the bridge unit to either the upper tray (on top of the bridge unit) or to the finisher, depending on which has been selected. If the junction gate solenoid has been activated, the junction gate [A] points downward and directs the paper to the upper tray [B] (dotted line path in illustration).
  • Page 947 PAPER FEED UNIT PB3080 (D387)
  • Page 949 PAPER FEED UNIT PB3080 (D387) TABLE OF CONTENTS 1. REPLACEMENT AND ADJUSTMENT ..........1 1.1 REAR COVER ....................1 1.2 MOTORS, CLUTCH AND MAIN BOARD............2 1.2.1 LIFT MOTOR ..................2 1.2.2 PAPER FEED CLUTCH................3 1.2.3 PAPER FEED MOTOR.................3 1.2.4 MAIN BOARD ..................4 1.3 PAPER FEED UNIT ..................5 1.4 ROLLERS AND SENSORS ................6 1.4.1 PICK-UP, PAPER FEED AND SEPARATION ROLLERS ....6...

  • Page 951: Symbols Used In This Manual

    Read This First Safety and Symbols Replacement Procedure Safety Turn off the main power switch and unplug the machine before beginning any of the replacement procedures in this manual. Symbols Used in this Manual This manual uses the following symbols. : See or Refer to : Screws : Connector...

  • Page 953: Replacement And Adjustment

    Rear Cover 1. REPLACEMENT AND ADJUSTMENT 1.1 REAR COVER Securing brackets [A] ( x 1 each) Rear cover [B] ( x 2) D387...

  • Page 954: Motors, Clutch And Main Board

    Motors, Clutch and Main Board 1.2 MOTORS, CLUTCH AND MAIN BOARD 1.2.1 LIFT MOTOR Rear cover ( p.1 "Rear Cover") Lift motor [A] ( x 2,  x 1) D387...

  • Page 955: Paper Feed Clutch

    Motors, Clutch and Main Board 1.2.2 PAPER FEED CLUTCH Rear cover ( p.1 "Rear Cover") Remove the tray end cover [A]. Paper feed gear unit [B] ( x 3,  x 1) Paper feed clutch bracket [C] ( x 1,  x 2, bushing x 1) Paper feed clutch [D] 1.2.3 PAPER FEED MOTOR Rear cover (...

  • Page 956: Main Board

    Motors, Clutch and Main Board 1.2.4 MAIN BOARD Rear cover ( p.1 "Rear Cover") Main board [A] (All s,  x 2, snap pin x 2) D387...

  • Page 957: Paper Feed Unit

    Paper Feed Unit 1.3 PAPER FEED UNIT Right cover [A] ( x 2) Stopper [B] ( x 1) Vertical transport guide [C] of the paper feed unit Pull tray 3. Paper guide [A] Paper feed unit [B] ( x 2,  x 1,  x 2) D387...

  • Page 958: Rollers And Sensors

    Rollers and Sensors 1.4 ROLLERS AND SENSORS 1.4.1 PICK-UP, PAPER FEED AND SEPARATION ROLLERS Paper feed unit ( p.5 "Paper Feed Unit") Roller holder [A] ( x 1) Pick-up roller [B] Paper feed roller [C] Separation roller [D] ( x 1) D387...

  • Page 959: Lift, Paper End, And Relay Sensors

    Rollers and Sensors 1.4.2 LIFT, PAPER END, AND RELAY SENSORS Paper feed unit ( p.5 "Paper Feed Unit") Vertical transport sensor bracket [A] ( x 1) Vertical transport sensor [B] ( x 1) Paper feed sensor bracket [C] ( x 1) Paper feed sensor [D] (...
  • Page 961 MAIL BIN TYPE C820 G835...
  • Page 963 MAIL BIN TYPE C820 G835 TABLE OF CONTENTS 1. REPLACEMENT AND ADJUSTMENT ..........1 1.1 EXTERIOR COVERS..................1 1.1.1 TOP, REAR AND FRONT COVERS............ 1 1.2 MOTOR AND SENSORS................2 1.2.1 MAIL BIN DOOR OPEN SENSOR AND OVERFLOW SENSOR 4..2 1.2.2 MAIN BOARD AND TRANSPORT MOTOR ........
  • Page 965 Read This First Safety and Symbols Replacement Procedure Safety Turn off the main power switch and unplug the machine before beginning any of the replacement procedures in this manual. Symbols Used in this Manual This manual uses the following symbols. See or Refer to Clip ring Screw...

  • Page 967: Replacement And Adjustment

    Exterior Covers 1. REPLACEMENT AND ADJUSTMENT 1.1 EXTERIOR COVERS 1.1.1 TOP, REAR AND FRONT COVERS Four bin trays [A] Front cover [B] ( x 1, x 2, x all) Rear cover [C] ( x 1) Top cover [D] G835...

  • Page 968: Motor And Sensors

    Motor and Sensors 1.2 MOTOR AND SENSORS 1.2.1 MAIL BIN DOOR OPEN SENSOR AND OVERFLOW SENSOR 4 Rear cover ( p.1) Top cover ( p.1) Overflow sensor 4 [A] (hooks, x 1) Open the mail bin door [B]. Mail bin door open sensor [C] ( x 1) 1.2.2 MAIN BOARD AND TRANSPORT MOTOR Rear cover (...

  • Page 969: Tray Paper And Overflow Sensors

    Motor and Sensors Transport motor bracket [B] ( x 2, x 1) Transport motor [C] ( x 2) 1.2.3 TRAY PAPER AND OVERFLOW SENSORS Remove all bin trays. Bin cover [A] (hook x 4) Overflow sensor [A] (hooks, x 1) Tray paper sensor [B] (hooks, x 1) The overflow sensor 1 is located at the second bin.
  • Page 970 Motor and Sensors First bin cover or second bin cover [A] (hook x 4) Remove the first bin cover to access the vertical transport sensor 1. Remove the third bin cover to access the vertical transport sensor 2. Vertical transport sensor [A] The vertical transport sensor 1 is located at the first bin.

This manual is also suitable for:

G189

Table of Contents
