PHERAstar FS Operating Manual
2.2 Back of PHERAstar FS
USB connection to PC
Main power on/off switch
Miscellaneous labeling such as serial
Number, CE-marking, and voltage
information
USB connection to PC
RS-232 connection to Stacker
Main power on/off switch
8/26
Fan
Air inlet
Figure 4: Back of PHERAstar FS
Figure 5: Back of PHERAstar FS
0471B0001A
BMG LABTECH
2009-09-22
