BMG LABTECH
2 Overview
2.1 Front and Right Side of PHERAstar FS
Optic module door
Operating lamp
Plate carrier in/out button
Service lid for laser cartridge
Plate carrier door
Press the button on the
grip and the optic module
door can be slid aside.
Magnetic
Clamp
Needle
Holder
Waste
Container
Figure 3: Right side of the PHERAstar FS, showing the reagent injection system
2009-09-22
Figure 1: PHERAstar FS
Figure 2: Optic module door
0471B0001A
PHERAstar FS Operating Manual
Sliding Door
Reagent
Injectors
Holder for
Compound
Vessels
Priming
Buttons
7/26
