PHERAstar FS Operating Manual
Reagent Injectors
Gain control
Height adjustment
Temperature Control
Plate Carrier
Shaking
Computer interface
Power requirements
Fuses
Dimensions and weight
Ambient conditions
Instrument conformity
Robotic capabilities
The fluorescence ratio associated with the HTRF
covered by the US patent 5,527,684 and its foreign equivalents, for which Cisbio international has granted a license to
BMG LABTECH. Its application is strictly limited to the use of HTRF® reagents and technology, excluding any other TR-
FRET technologies.
* Limit of detection < 100 amol of biotinylated and phosphorylated polypeptide (P-Tyr-100 assay kit, PerkinElmer, #6760620C),
measured in white 384 small volume microplates (17 µL/well).
AlphaScreen, DELFIA, and LANCE are registered trademarks of Perkin Elmer, Inc.
HTRF is a registered trademark of Cisbio international.
LanthaScreen is a registered trademark of Invitrogen Corp.
Transcreener is a registered trademark of BellBrook Labs
Specifications are subject to change without notice.
6/26
10 flashes: 38 s (384)
10 flashes: 1 min 52 s (1536)
50 flashes: 1 min 29 s (384)
50 flashes: 5 min 18 s (1536)
Up to two built-in reagent injectors
Injection at measurement position (6 to 384-well)
Individual injection volumes for each well (3 to 350 µL)
Variable injection speed (100 to 420 µL/s with a 500 µL syringe)
Up to four injection events per well
Reagent back flushing
- Software selectable gain for F, FP, L, and AS.
- Automatic Z-adjustment with curve monitoring
- Incubation range from 5°C above ambient to 45°C
- Temperature monitoring (with and without incubation)
- Auto lock microplate carrier
All microplate formats up to 1536-well in all detection modes
Microplates should adhere to the SBS specification and non-SBS formats
should fit: (lxwxh) (mm) max: 128x86x20; min: length 124
- Double orbital, orbital and linear shaking
- Programmable shake time and diameter
- USB 2.0, compatible to USB 1.1
- 100 or 115 or 230 V, 50/60 Hz, auto ranging
- Consumption: max. 300 VA
- T 5A/250V for main power 100 - 240 V
(use original type Wickmann only)
- Height: 46 cm, width: 46 cm and depth 51 cm. Weight 50 kg max
- Operating temperature: 15°C to 35°C
- Storage temperature: -10°C to 50°C
- Humidity of atmosphere: 20 % to 80 %
- Non-condensing environment.
- Over voltage category II; contamination class II; protection class I;
Laser class I and IIIB
- Easy to integrate into all existing robotic systems
For medium level throughput, an optional BMG LABTECH
Stacker with magazines for 50 microplates is available
®
readout is a correction method developed by Cisbio international and
0471B0001A
BMG LABTECH
2009-09-22
