  • Page 1 UICK TART UIDE Cisco Service Control Engine 2000 4xGBE Q UICK TART UIDE 3.8. ELEASE Preparing for Installation Rack-Mounting the SCE 2000 Chassis Connecting Power Supply Units Connecting Management Interfaces and Performing Initial System Configuration Cabling Line Ports Completing the Installation...
  • Page 2: Preparing For Installation

    Do not work on the system or connect or disconnect cables during periods of lightning activity. Warning Before you begin the installation of the SCE 2000 platform, read the Regulatory Compliance and Safety Information for the Cisco Service Control Engines (SCE) document. Site Preparation • Print out and have accessible the “Cisco SCE 2000 GBE Installation...
  • Page 3: Tools And Parts

    When you unpack the Cisco SCE 2000, do not discard the shipping container. Flatten the shipping cartons and store them with the pallet. You may need these containers if you move or ship the Cisco SCE 2000 in the future.
  • Page 4 Remove the adhesive strips from the four rubber feet and affix the feet onto the four marked locations on the bottom Step 1 panel of the unit Place the SCE 2000 platform on the tabletop or workbench. Step 2...
  • Page 5: Sce 2000 Mounting Brackets

    Warning Before you install, operate, or service the system, read the Regulatory Compliance and Safety Information for the Cisco Service Control Engines (SCE). This guide contains important safety information you should know before working with the system. SCE 2000 Mounting Brackets There are two standard types of equipment racks, and the appropriate brackets for each are provided in the enclosed kit.
  • Page 6: Attaching Brackets To The Sce 2000

    Attaching Brackets to the SCE 2000 Before installing the SCE 2000 in the rack, you must first install an appropriate rack-mount bracket on each side of the front of the SCE 2000, as illustrated in the following figures. Figure 4 Attaching the Mounting Brackets (4-post) PW R A PW R B...
  • Page 7: Installing The Crossrail Supports (Four-Post Rack Only)

    Installing the Crossrail Supports (Four-post rack only) This section provides information for assembling the crossrail supports and attaching them to the rack. When mounting in a rack with four posts (front and back) the two crossrail supports are mounted one on each side of the rack. The SCE 2000 then slides into these crossrails, which support the weight of the unit.
  • Page 8: Mounting The System To The Rack

    Slide the SCE 2000 into the rack, pushing it back until the brackets (installed at the front of the unit) meet the mounting Step 1 strips or posts on both sides of the rack. Figure 8 Sliding the SCE Platform into the Rack PWR A PWR B STATUS BYPASS Cisco SCE MNG 1 MNG 2 2000 LINK/ 10/100/ CONSOLE LINK RX 4xGBE...
  • Page 9 While keeping the brackets flush against the posts or mounting strips, align the holes in the brackets with the holes on Step 2 the rack or mounting strip. Insert and tighten two appropriate screws to the rack for each bracket. Figure 9 Securing the SCE Platform to the Rack PW R A...
  • Page 10: Connecting Chassis Ground

    Connecting Power Supply Units The SCE 2000 platform is shipped with the power supplies (AC or DC) already installed. This section provides information for grounding the SCE 2000 platform and connecting the AC or DC power supply units. Connecting Chassis Ground Figure 10 Grounding the Unit (AC) BY PA SS...
  • Page 11: Connecting Power

    When installing the unit, the chassis ground connection must always be made first and disconnected last. Step 1 Attach the grounding cable (green and yellow cable) to the chassis grounding connector located on the rear panel of the SCE 2000, firmly fastening the (enclosed) hex nuts and spring washers with a #¼” hex wrench (refer to the appropriate figure above for an AC- or DC-powered SCE 2000 platform).
  • Page 12: Connecting Ac-Input Power Supply Unit

    Step 3 Insert one receptacle screw into the hex or loop connector on one power line input, insert the screw with the connector into the corresponding lead receptacle and tighten the receptacle screw using the number 2 Phillips. Repeat for the remaining power line input lead.
  • Page 13: Connecting The Local Console

    • No flow control The above Cisco SCE 2000 port parameters are fixed and are not configurable. Plug the RS-232 serial cable provided with the Cisco SCE 2000 into the Con port on the front panel of the SCE 2000 Step 1 (#2 in Figure 14).
  • Page 14: Setting Up Initial Parameters

    Note For further information regarding any configuration step or specific parameter, refer to the relevant section in the Cisco SCE 2000 and SCE 1000 Software Configuration Guide Table 1...
  • Page 15 Table 1 Setup Command Parameters (continued) Parameter Definition Access Control List number How many ACLs will be necessary? What IP addresses will be permitted/denied access for each management interface? You may want ACLs for the following: Any IP access Telnet access SNMP GET access SNMP SET access list entries (maximum 20 per list)
  • Page 16: Connecting The Management Interface

    Connecting the Management Interface Figure 15 Cabling the Management Port PW R A PW R B STA TU S BY PAS S MN G 1 C is co S MN G 2 C E 2 0 0 0 CO NS OL Se rie s AU X LIN K RX...
  • Page 17: Sce 2000 Connectivity Summary

    Cabling Line Ports This chapter describes cabling the Gigabit Ethernet ports for both one and two SCE 2000 topologies, and for configuring Gigabit Ethernet (GBE) interface parameters. In a topology utilizing two SCE 2000s (cascade), this includes the cascade ports as well as the line ports.
  • Page 18: Cabling Gbe Line Interface Ports

    SCE 2000 are the same, either 850nm Multimode OR 1310nm Single Mode. SCE Model Transceiver Transmit Power Receive Power Typical (Max.) Distance SCE 2000 4xGBE MM 850nm –9.5 to –3 dBm –17 to 0 dBm 750m for 50µm Core Diameter MMF Multimode 400m for 62.5µm Core Diameter MMF...
  • Page 19: Configuring Gigabitethernet Auto-Negotiation

    Configuring GigabitEthernet Auto-Negotiation By default, the SCE 2000 GBE line interface ports are configured with auto-negotiation disabled. Auto-negotiation must be disabled when the SCE 2000 is deployed using an external optical splitter (receive-only Note topology) Note If you change any parameters, you must save the new configuration settings. Use the copy running-config startup-config CLI command.
  • Page 20: Completing The Installation

    Completing the Installation This module explains how to verify link connectivity and how to install a Cisco service control application. Examining the LEDs • The GBE Link LED should be green. This indicates that an active connection exists. • The GBE RX and TX LEDs (if flashing green) indicate that traffic is being received or transmitted by the SCE 2000 platform, respectively.
  • Page 21: Viewing User Log Counters

    For information on system and interface configuration, refer to the following documents: Cisco SCE 2000 and SCE 1000 Software Configuration Guide • Cisco SCE 2000 and SCE 1000 CLI Command Reference Guide • Viewing Configurations When you enter configuration commands, this action immediately affects the SCE platform operation and configuration. The configuration, referred to as the running-config, is saved in the SCE platform volatile memory and is effective while the SCE platform is up.
  • Page 22 After configuring the SCE platform, you may query for the running configuration using the command show running-config. Step 1 At the SCE# prompt, type show running-config. The system shows the running configuration. SCE#show running-config #This is a general configuration file (running-config). #Created on 13:39:29 July 2009...
  • Page 23: Saving Or Changing Configuration Settings

    line vty 0 4 timeout 180 exit interface Mng 0/1 exit interface Mng 0/2 exit aaa authentication login default local management-agent property "" "Install" management-agent property "" "3.5.5 build 127" management-agent property "" "SCA BB" management-agent property "" "Tue Jun 04 20:57:48 GMT+00:00 2009"...
  • Page 24: Installing A Service Control Application

    The Service Control solution requires that the Service Control application be installed on the SCE platform. This is a pqi file that is installed and configured using the Cisco Service Control Application for Broadband (SCA BB) console. For an explanation of how to install the pqi file, s ee “Installing the Application and Protocol Pack on the SCE...
  • Page 25: Troubleshooting

    Troubleshooting the Cisco SCE 2000 Operational Status Table 5 lists the operational states of the Cisco SCE 2000. The Status LED on the service control module reflects current Cisco SCE 2000 operational status. To show operational status, enter the command show system operation-status. Table 6 lists the LED status explanations.
  • Page 26: Identifying Startup Issues

    Status LED is flashing orange, indicating a warning state, check the user log: • At the prompt, enter more user log If any of the following warning messages appear, turn off the Cisco SCE 2000 platform and call technical support. Voltage problem –...
  • Page 27: Obtaining Documentation And Submitting A Service Request

    Subscribe to the What’s New in Cisco Product Documentation as a Really Simple Syndication (RSS) feed and set content to be delivered directly to your desktop using a reader application. The RSS feeds are a free service and Cisco currently supports...
  • Page 28 Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its affiliates in the U.S. and other countries. To view a list of Cisco trademarks, go to this URL: Third-party trademarks mentioned are the property of their respective owners. The use of the word partner does not imply a partnership relationship between Cisco and any other company.
