TURBO HD
H1T Series Turret Camera
User Manual
UD03835B
User Manual
Thank you for purchasing our product. If there are any
questions, or requests, do not hesitate to contact the
dealer.
This manual applies to the models below:
Type
Type I
Camera
Type II
Camera
This manual may contain technical incorrect places or
printing errors, and the content is subject to change
without notice. The updates will be added to the new
version of this manual. We will readily improve or
update the products or procedures described in the
manual.
Model
DS-2CE56H1T-IT1
DS-2CE56H1T-IT3
DS-2CE56H1T-ITM
0100001061127

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H1T Series and is the answer not in the manual?

Questions and answers

Related Manuals for HIKVISION H1T Series

Summary of Contents for HIKVISION H1T Series

  • Page 1 TURBO HD H1T Series Turret Camera User Manual UD03835B User Manual Thank you for purchasing our product. If there are any questions, or requests, do not hesitate to contact the dealer. This manual applies to the models below: Type Model...
  • Page 2 Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
  • Page 3 Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions” Warnings: Serious injury or death may occur if any of the warnings are neglected.

  • Page 4: Product Features

     The sensor may be burned out by a laser beam, so when any laser equipment is in using, make sure that the surface of sensor will not be exposed to the laser beam.  Do not place the camera in extremely hot, cold, dusty or damp locations, and do not expose it to high electromagnetic radiation.

  • Page 5: Installation

    2 Installation Before you start:  Make sure that the device in the package is in good condition and all the assembly parts are included.  Make sure that all the related equipment is power-off during the installation.  Check the specification of the products for the installation environment.
  • Page 6 Figure 2-3 Attach the Mounting Base to the Ceiling Note: In the supplied screw package, both self-tapping  screws and expansion bolts are contained. For cement ceiling/wall, expansion bolts are  required to fix the camera. For wooden ceiling/wall, self-tapping screws are required. 6.
  • Page 7 Figure 2-6 The Drill Template 3. Disassemble the inclined base by the screw driver. 4. Install the turret camera’s mounting base on the inclined base cover with three PM4 screws. Figure 2-7 Install Turret Camera’s Mounting Base 5. Install the inclined base’s body on the ceiling/wall with four PA4×25 screws, as shown in Figure 2-8.
  • Page 8 Clip Plate Notch Figure 2-10 Disassemble the Camera 2. Pry the mounting base to remove the mounting base from the camera body. 3. Paste the drill template (supplied) to the place where you want to install the camera. 4. Drill the screw holes according to the drill template, and the cable hole (optional) on the ceiling.
  • Page 9 3). Rotate the camera body to adjust the rotation position [0° to 360°]. Pan Position Range [0° to 360°] Tilt Position Range Rotation Position Range [0°to75°] [0° to 360°] Figure 2-14 3-axis Adjustment 2.3 Installation of Type I and Type II Camera 2.3.1 Ceiling/Wall Mounting with JunctionBox Steps: 1.

  • Page 10: Menu Description

    2. Install the bracket to the wall by aligning the four screw holes of the bracket with expansion screws on the wall. 3. Secure the bracket with four hex nuts and washers. Figure 2-17 Install the Pendent Bracket 4. Install the mounting base of the turret camera to the wall mounting bracket and secure them with supplied screws.

  • Page 11: Output Mode

    RESOLUTION OUTPUT FRAME RATE MODE VIDEO OUT RETURN SHUTTER FLICKER MODE EXPOSURE BRIGHTNESS D-WDR RETURN MAIN MENU BACKLIGHT WHITE AWC- SET MANUAL COLOR DAY & NIGHT AUTO MIRROR SPECIAL LANGUAGE RETURN SHARPNESS ADJUST MONITOR RETURN SAVE & END EXIT RESET NOT SAVE Figure 3-2 Main Menu Overview 3.1 OUTPUT MODE...
  • Page 12 3.2 EXPOSURE Exposure describes the brightness-related parameters. You can adjust the image brightness by the SHUTTER FLICKER MODE, AGC, BRIGHTNESS, and D-WDR in different light conditions. EXPOSURE AUTO SHUTTER FLICKER MOD BRIGHTNESS AUTO D-WDR RETURN Figure 3-4 EXPOSURE SHUTTER Shutter denotes the speed of the shutter. PAL: AUTO, 1/25 s, 1/50 s, FLK, 1/200 s, 1/400 s, 1/1k s, 1/2k s, 1/5k s, 1/10k s, and 1/50k s are selectable.

  • Page 13: Day & Night

    3.4 WB (White Balance) White balance is the white rendition function of the camera to adjust the color temperature according to the environment. It can remove the unrealistic color casts in the image. MANUAL, ATW (Auto-Tracking White Balance), AWC→SET are selectable. Manual You can set the R GAIN/B GAIN value from 0 to 255 to adjust the shades of red/blue color of the image.
  • Page 14 WHITE DPC: White DPC is the pixel on CCD or CMOS sensor that appear completely white. Move the cursor to the white DPC, and press Iris+ to enter the white DPC configuration interface. BLACK DPC: Black DPC is the pixel on CCD or CMOS sensor that appear completely black.
