ADVANCED
Some video formats may require different scanning modes in order to best display the image.
OVER SCAN
HDMI1, HDMI2, VGA (YPbPr), VIDEO, MP,
OPTION* 1 inputs only
ON Image size is larger than what can be displayed. The image edge will appear cropped.
Approximately 95% of the image will be shown on the screen.
OFF Image size stays within the display area. The whole image is displayed on the screen.
NOTE: When you use a computer with HDMI out, please set "OFF".
AUTO Image size is set automatically.
NOTE: This function is not available if input signal is VGA (YPbPr), VIDEO or MP.
Selects the IP (Interlace to Progressive) conversion function.
DEINTERLACE
NOTE: IMAGE FLIP is not available. When SUPER is selected in INPUT CHANGE and displayed, this function
cannot be changed.
ON Converts interlaced signals to progressive. This is the default setting.
OFF Disables IP conversion. This setting is best suited for motion pictures, but increases the risk of image retention.
NOISE REDUCTION Adjusts the amount of noise reduction. Press + or - to adjust.
VIDEO input only
TELECINE Automatically senses the sources frame rate for optimal picture quality.
HDMI1, HDMI2, VIDEO, VGA (YPbPr),
NOTE: Set DEINTERLACE ON if TELECINE is AUTO.
MP inputs only
ADAPTIVE Sets the level of adjustment for dynamic contrast.
2
CONTRAST* If HIGH is set, the image is displayed clearly but it makes brightness unstable due to the wide gap of contrast
HDMI1, HDMI2, VIDEO, VGA (YPbPr),
variation.
MP inputs only
ROTATION Display the inverse image right-left, up-down or rotation.
Press + or - to select.
NOTE: This function is not available when MOTION in SCREEN SAVER is "ON".
IMAGE FLIP NOTE: When the ASPECT is DYNAMIC, the image will be changed to FULL image before ROTATE, then start to
ROTATE.
When selecting IMAGE FLIP is set except for NONE, the following functions are released: MULTI PICTURE
MODE, TEXT TICKER, STILL, POINT ZOOM and TILE MATRIX.
When input signal is Interlace, the image may be disturbed.
NONE
Normal mode.
H FLIP
The image inverts right-left.
V FLIP
The image inverts up-down.
180° ROTATE
The image rotates 180 degrees.
OSD FLIP Determines the OSD display direction.
If "ON" is selected, OSD will invert depending on the image.
SPECTRAVIEW ENGINE Select "ON" to activate SPECTRAVIEW ENGINE (see page 27).
RESET Resets "PICTURE" settings back to factory settings except for SPECTRAVIEW ENGINE and PICTURE MODE.

AUDIO

VOLUME Increases or decreases output volume level.
BALANCE
BALANCE Select "STEREO" or "MONO" of audio output.
If you select "STEREO", adjust the balance of L/R volume.
Press + button to move the stereo sound image to right.
Press - button to move the stereo sound image to left.
NOTE: BALANCE is not available if MONO is set at STEREO/MONO.
SURROUND Artifi cial surround sound.
NOTE: LINE OUT is disabled when this function is set to "ON".
*1: This function depends on which option board you use.
*2: If SPECTRAVIEW ENGINE is ON, this function is grayed out.
English-33
