Multiple Monitors Connection
You can control multiple monitors by using RS-232C, REMOTE IN or LAN daisy-chain connection.
NOTE:
Multiple monitors that are daisy-chained have a limit to the connectable monitors.
When manually specify the ID number or control by the specifi ed ID number, please execute AUTO ID (see page 38)
previously.
Main Monitor
Connector
IN
RS-232C
REMOTE IN
LAN1
Connection
OUT
IN
LAN2
LAN1
Sub Monitors
Connector
OUT
LAN2
MultiSync
LAN1
LAN2
LAN Cable
English-46
MultiSync
LAN1
LAN2
LAN Cable
MultiSync
