NEC MultiSync P404 User Manual page 42

CHANGE PASSWORD Allows the security password to be changed.
The factory preset password is 0000.
SECURITY
PASSWORD Insert a security password.
SECURE MODE
OFF Security password is not required when the monitor power is on.
START-UP LOCK Security password is required when the monitor power is on.
CONTROL LOCK Security password is required when the remote control button or control button on the monitor is pressed.
BOTH LOCK Security password is required when the monitor power is on, or the remote control button or control button on the
monitor is pressed.
IR LOCK SETTINGS
Prevents the monitor from being controlled by the wireless remote control.
When ACTIVATE is selected, all the settings are activated.
NOTE: IR LOCK SETTINGS is a function intended only to the wireless remote control buttons. This function does
not lock out access to all buttons at the back of the monitor. To return to normal operation, press the "DISPLAY"
button on the remote control then hold it down for more than 5 seconds.
MODE SELECT Selects the mode UNLOCK, ALL LOCK or CUSTOM LOCK.
UNLOCK All buttons on the remote control are available for normal operations.
ALL LOCK
Locks all remote control buttons.
CUSTOM LOCK
Selects which buttons to be locked from POWER, VOLUME, and INPUT button.
Except for CUSTOM LOCK settings, other buttons on the remote control are locked.
POWER:
VOLUME: When UNLOCK is selected, sets minimum and maximum volume between VOL.0 to VOL.100.
INPUT:
CHANNEL: To lock channel buttons on the remote control, select it to LOCK then press ACTIVE, channel
KEY LOCK SETTINGS Prevents the monitor from being controlled by buttons at the back of the monitor.
When ACTIVATE is selected, all the settings are activated.
NOTE: KEY LOCK SETTINGS is a function intended only for the buttons on the back of the monitor. This
function does not lock out access to all buttons on the remote control. To activate the control key lock function,
press the UP button ( ) and the DOWN button ( ) and hold down simultaneously for more than 3 seconds.
To resume user mode, press the UP button ( ) and the DOWN button ( ) and hold simultaneously for more
than 3 seconds.
MODE SELECT
Selects the mode UNLOCK, ALL LOCK or CUSTOM LOCK.
UNLOCK
All buttons are available for normal operations.
ALL LOCK Locks all remote control buttons.
CUSTOM LOCK Selects which buttons to be locked from POWER, VOLUME, and INPUT button.
Except for CUSTOM LOCK settings, other buttons on the remote control are locked.
POWER:
VOLUME: When UNLOCK is selected, sets minimum and maximum volume between VOL.0 to VOL.100.
INPUT:
CHANNEL: To lock channel buttons on the remote control, select it to LOCK then press ACTIVE,
DDC/CI ENABLE/DISABLE: Turns ON or OFF the two way communication and control of the monitor.
PING Confi rm the response by communicating to the preset IP address.
IP ADDRESS Set an IP ADDRESS for sending PING.
EXECUTE Checks a reply can be sent to the monitor or not from the IP ADDRESS by sending PING.
IP ADDRESS RESET Resets IP ADDRESS SETTINGS back to factory settings.
When LOCK is selected, POWER button is locked.
VOLUME (+) button and VOLUME (-) buttons are only available from the minimum volume to the
maximum volume you set.
When LOCK is selected, VOLUME (+) button and VOLUME (-) buttons are locked.
When UNLOCK is selected, choose up to three buttons from DVI, HDMI1, HDMI2, DisplayPort1,
DisplayPort2, VGA (RGB/YPbPr), VIDEO, MEDIA PLAYER, OPTION which you prefer to be
unlocked.
The unselected buttons are locked. When LOCK is selected, all INPUT buttons are locked.
CH/ZOOM (+) button and (-) button are locked.
When LOCK is selected, POWER button is locked.
The PLUS button (+) and the MINUS button (-) are only available from the minimum volume to the
maximum volume you set.
When LOCK is selected, the PLUS button (+) and the MINUS button (-) are locked.
When UNLOCK is selected, the INPUT/SET button is unlocked.
the UP button ( ) and the DOWN button ( ) are locked.
English-40
