F u j i t s u A m e r i c a , I n c .
Silicone Sleeve User's Guide
I N S T R U C T I O N S
This silicone sleeve is a rugged, lightweight case for protecting your
Slate PC.
Figure 1. Silicone Sleeve with System Installed
The silicone sleeve attaches snugly and securely to your computer.
Please read this manual before installing using the silicone sleeve.
Inserting the System into the Sleeve
The silicone sleeve is designed to provide a secure fit for the system.
In order to ensure your system is installed correctly, please perform
the following steps.
1.
Align the system above the sleeve so that the fingerprint sen-
sor and web camera opening are aligned with those features
on the back of the tablet
2.
Tuck one of the narrow ends of the system into the sleeve
under the flexible edge (Figure 3). Lay the other end of the
system atop the other end of the sleeve.
Elastic Strap
Pen
Holder
Card Holders/
Easel Stops
.
(Figure 2)

Advertisement

   Also See for Fujitsu silicone sleeve

   Related Manuals for Fujitsu silicone sleeve

   Summary of Contents for Fujitsu silicone sleeve

  • Page 1

    Please read this manual before installing using the silicone sleeve. Inserting the System into the Sleeve The silicone sleeve is designed to provide a secure fit for the system. In order to ensure your system is installed correctly, please perform the following steps.

  • Page 2

    Web Camera Fingerprint Pen Holder Opening Sensor Opening Threaded insert holes (for use with optional hand strap) Figure 2. Silicone Sleeve - Back Tuck one of the narrow Flexible ends under Edge the flexible edge Figure 3. Laying in System...

  • Page 3

    Figure 4. Securing Corners Pen Holder The silicone sleeve has a handy pen holder located at the top (Figure 2). It’s good practice to stow your pen when not in use in order to prevent damage to it.

  • Page 4

    Using the Optional Docking Cradle A system that is installed in the silicone sleeve can be used with the optional docking cradle. To attach it to the docking cradle, visually align the connector on the bottom of your slate with the connector on the docking cradle (Fig.
