F u j i t s u
C o m p u t e r
S y s t e m s
Bump Case User's Guide
FPCCC47
I N S T R U C T I O N S
These instructions provide details on using the
FPCCC47 Bump Case. This case is designed for
use with your Tablet PC. The bump case provides
added protection when transporting, using, or
storing the Tablet PC.
We strongly recommend that you read these
instructions prior to using the bump case with
your computer.

Advertisement

   Related Manuals for Fujitsu FPCCC47

   Summary of Contents for Fujitsu FPCCC47

  • Page 1

    I N S T R U C T I O N S These instructions provide details on using the FPCCC47 Bump Case. This case is designed for use with your Tablet PC. The bump case provides added protection when transporting, using, or storing the Tablet PC.

  • Page 2

    DC-In access LAN/Modem access External Monitor port access USB 2.0/IEEE 1394/ microphone/ headphone jack access Transparent security strap Pen holder Figure 1. Bump case - Front...

  • Page 3

    Installing the Tablet PC Prior to installing the Tablet PC into the bump case, remove the pen. Once the system is installed, you will not be able to remove the pen. Store the pen in the pen holder. (Figure 1) Battery Release Latch access Velcro Strips...

  • Page 4

    To install your Tablet PC into the bump case, position the case face down as shown in Figure 3. Open the side flap of the case. The flap is secured by a long strip of Velcro® that is attached to the back of the bump case. Note that the left side of the case is open for port access, but the system cannot be inserted or removed from that side.

  • Page 5

    System with the main battery installed: Slide the system all the way into the bump case until it meets the opposite end of the case (see Figure 3). Pull the battery strap down tightly and tuck it under the battery so that it is snug against the side of the battery. (See Figure 4).

  • Page 6

    Attaching a Shoulder Strap The ends of the elasticized handstraps have D-rings to which you can attach the shoulder strap. To secure the shoulder strap, attach the strap clips to two of the D-rings. The bump case can be carried vertically, horizontally, or diagonally, depending on how you orient the clips.

  • Page 8

    For technical support call: 1-800-8fujitsu (1-800-838-5487) or e-mail us at: 8fujitsu@us.fujitsu.com Fujitsu and the Fujitsu logo are registered trademarks of Fujitsu, Ltd. All other trademarks mentioned herein are the property of their respective owners. Product description data represents Fujitsu design objectives and is provided for comparative purposes;...
