MECHANICAL & ACCESSORIES PARTS LIST - MAIN UINT
A1
9965 000 15982
FRONT PANEL ASSY
/00S/02S/15S
A1
9965 000 14650
FRONT PANEL ASSY
A1
9965 000 14648
FRONT PANEL ASSY
A2
9965 000 14651
CLOTH FRAME ASSY
/00S/02S/17
A2
9965 000 14649
CLOTH FRAME ASSY
/15S/17S
8
9965 000 12979
MAINS TRANSFO 120V
/17/17S
!
8
9965 000 15970
MAINS TRANSFO 230V
/00S/02S/15S
!
29
9965 000 12818
MAINS CORD FIXED
/17/17S
!
29
9965 000 15980
MAINS CORD DETACHABLE AUST. /00S
!
29
9965 000 15983
MAINS CORD DETACHABLE
!
30
9965 000 07092
BUSHING, FIXED CORD
/15S/17/17S
38
4822 532 13065
WASHER
39
9965 000 08278
SPEAKER DRIVER 100W 6,5" 4OHM
44
9965 000 12981
RUBBER FOOT
48
9965 000 12443
Mains Socket
/00S/02S
Note:
Only the parts mentioned in this list are normal service spare
parts.
6-2
SCREW LIST - MAIN UINT
4
D3 x 10
/17
5
D3 x 6
/17S
6
M4 x 25
14
M3 x 8
26
M2 x 6
27
D3 x 10
28
D3,5 x 14
31
M3 x 22
36
M3 x 14
/02S
49
M3 x 12
6-2
