  • Page 1 * at Output level of 2V across 4 ohm load © Copyright 2001 Philips Consumer Electronics B.V. Eindhoven, The Netherlands All rights reserved. No part of this publication may be reproduced, stored in a retrieval system or transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise without the prior permission of Philips.

  • Page 2: Dismantling Instructions

    www.freeservicemanuals.info DISMANTLING INSTRUCTIONS Dismantling the Grill Base & Speaker Driver 1. Place the Subwoofer Box upside down and remove the 2. Unscrew 4 screws C (see Picture 3) to remove the 4 Rubber Foot A (see Picture 1). Then unscrew 4 screws Speaker Driver (pos.
  • Page 3 www.freeservicemanuals.info DISMANTLING INSTRUCTIONS Dismantling the Rear Assembly 1. Unscrew 10 screws E (see Picture 7) to pull out the pc board assembly. Caution: Do not break the bundle of wires to the front. Picture 7 Service Position...

  • Page 4: Wiring Diagram

    www.freeservicemanuals.info WIRING DIAGRAM...

  • Page 5: Component Layout

    www.freeservicemanuals.info COMPONENT LAYOUT...
  • Page 6 www.freeservicemanuals.info ELECTRICAL PARTS LIST MISCELLANEOUS F901 4822 070 34002 Fuse T4A 250V C909 4822 124 40207 100µF 20% 25V F902 4822 070 34002 Fuse T4A 250V C910 4822 124 40207 100µF 20% 25V JK301 4822 267 41238 RCA Jack 1P C911 2038 554 00065 100nF +80/-20% 50V...

  • Page 7: Circuit Diagram

    www.freeservicemanuals.info CIRCUIT DIAGRAM Note : All capacitors are in µF unless otherwise specified. All resistors are 1/6W 5% unless otherwise specified. Some values may varies, see respective parts list for correct value. ELECTRICAL PARTS LIST DIODES D501 4822 130 31438 1N4001G LD401 4822 130 10236...

  • Page 8: Exploded View

    www.freeservicemanuals.info EXPLODED VIEW MECHANICAL PARTS LIST 9965 000 09698 Volume Knob 9965 000 08270 Bar Trim 9965 000 09699 Front Cabinet 9965 000 08272 Woox Speaker 9965 000 09700 Foot 9965 000 09701 Foot D30X35mm 9965 000 09702 Rubber Pad 4822 532 13065 Speaker Sponge 9965 000 08277...
  • Page 9 * at Output level of 2V across 4 ohm load © Copyright 2001 Philips Consumer Electronics B.V. Eindhoven, The Netherlands All rights reserved. No part of this publication may be reproduced, stored in a retrieval system or transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise without the prior permission of Philips.
  • Page 10 www.freeservicemanuals.info DISMANTLING INSTRUCTIONS Dismantling the Grill Base & Speaker Driver 1. Place the Subwoofer Box upside down and remove the 2. Unscrew 4 screws C (see Picture 3) to remove the 4 Rubber Foot A (see Picture 1). Then unscrew 4 screws Speaker Driver (pos.
  • Page 11 www.freeservicemanuals.info DISMANTLING INSTRUCTIONS Dismantling the Rear Assembly 1. Unscrew 10 screws E (see Picture 7) to pull out the pc board assembly. Caution: Do not break the bundle of wires to the front. Picture 7 Service Position...
  • Page 12 www.freeservicemanuals.info WIRING DIAGRAM...
  • Page 13 www.freeservicemanuals.info COMPONENT LAYOUT...
  • Page 14 www.freeservicemanuals.info ELECTRICAL PARTS LIST MISCELLANEOUS F901 4822 070 34002 Fuse T4A 250V C909 4822 124 40207 100µF 20% 25V F902 4822 070 34002 Fuse T4A 250V C910 4822 124 40207 100µF 20% 25V JK301 4822 267 41238 RCA Jack 1P C911 2038 554 00065 100nF +80/-20% 50V...
  • Page 15 www.freeservicemanuals.info CIRCUIT DIAGRAM Note : All capacitors are in µF unless otherwise specified. All resistors are 1/6W 5% unless otherwise specified. Some values may varies, see respective parts list for correct value. ELECTRICAL PARTS LIST DIODES D501 4822 130 31438 1N4001G LD401 4822 130 10236...
  • Page 16 www.freeservicemanuals.info EXPLODED VIEW MECHANICAL PARTS LIST 9965 000 09698 Volume Knob 9965 000 08270 Bar Trim 9965 000 09699 Front Cabinet 9965 000 08272 Woox Speaker 9965 000 09700 Foot 9965 000 09701 Foot D30X35mm 9965 000 09702 Rubber Pad 4822 532 13065 Speaker Sponge 9965 000 08277...
