14. USB PORT—Connects the scanner to a USB port on your computer by the
included USB cable.
15. POWER RECEPTOR—Connects the scanner to a standard AC power outlet
by the included AC adapter.
16. POWER SWITCH—Use this to turn the scanner ON or OFF.
LED I
NDICATOR
The Power/Power Saving LED and Warning LED indicate different scanner
status.
Warning LED Power / Power
Light Saving LED
Off
Off Orange
Red Blinking White The ADF cover is opened.
Blinking Red
Blinking Red
Off
Light
White The scanner is turned on, ready to scan images.
The scanner is in standby mode (sleep mode). It
will enter this mode if it is idle for 10 minutes.
White Paper jam.
Off An internal component of the scanner may have
malfunctioned.
Off The scanner is off, either because the power is not
turned on, or because the AC adapter is not
properly plugged into an AC power outlet.
Status
