HOW TO FOLD AND STORE THE ROWER
The rower can be stored in a folded position to con-
serve space. Store the rower in a location where
children cannot tip it. Remove the batteries from the
console when storing the rower for extended periods of
time.
To store the rower, first slide the Seat (23) to the rear of
the Rail (2).
52
23
2
34
Next, hold and lift the Frame Handle (52) and the Rail
Handle (34), and tip the rower forward onto the Shields
(7, 8) and the Storage Feet (43).
Then, pull the Rail Handle (34) inward until the Folding
Clamp (35) engages the bar on the Stabilizer (3).
7, 8
43
41
3
To unfold the rower, first place your foot on a Stabilizer
Foot (41) and pull the Rail Handle (34) outward to dis-
engage the Folding Clamp (35).
Then, hold the Rail Handle (34) and the Frame Handle
(52), pull the Rail Handle outward, and lower the Rail
(2) to the floor.
9
52
2
34
35
3
41
