Summary of Contents for Sencore cm2125
- Page 72 Intensity Pin 13 Pin 5, Pin 6 , Pin 7, Pin 8 Pin 10 Pin 14 V Sync Pin 14 Pin 15 +5 mode CM2125 Settings (Recall 6 or 7) Type Format Horiz Vert Freq (Hz) Horiz Pix Vert Pix...
- Page 73 Freq(kHz) VGA2 720x400/70Hz 31.5 70.1 VGA3 640x480/60Hz 31.5 60.0 Using the CM2125 Computer Monitor Analyzer To test Ceronix 1490 and 1492 monitors Ceronix 1490 / 1492 CM2125 Intensity Pin 4 Intensity Pin 5 Comp Sync Pin 7 Intensity Pin 12...
- Page 74 Pin 8 No Connection Pin 9 AC (White) Pin 10 AC (Black) Pin 11 Ground Pin 12 No Connection Pin 13 No Connection Pin 14 No Connection Pin 15 No Connection Pin 16 No Connection Pin 17 No Connection Pin 18 No Connection Pin 19 No Connection...
- Page 75 The number of cycles displayed on the digital display and continually updated. Sync Timing: The CM2125 recognizes common computer monitor formats and automatically adjusts General: for the correct sync, back porch, and front porch timing. Digital meters: 3 ½ digit, LCD readout Digital display: LCD readout Guaranteed operating temperature: 15-35 degrees C Sync timing parameters can be changed through the front panel.
