This Quick Start Guide summarizes the basic steps needed to install, start-up and program the 1336
Frequency AC Drive. The information provided Does Not replace the User Manual and is intended for qualified drive service
personnel only. Refer to the 1336
considerations and related precautions.
Power Wiring – TB1
TE
Ground
TE
(L1)
(Not on all drives)
Required
Input Fusing
Circuit Disconnect
Conduit/4-Wire Cable
Nearest
Building Structure Steel
Digital Outputs – TB2
Important: On A Frame Drives, the power supply used for relay contact outputs requires a field installation of
Publication 1336 PLUS-5.9ML – June, 2003
Supersedes January, 2002
1336
PLUS
User Manual (publication 1336 PLUS-5.3) for details on other application
PLUS
II
AC Input
PE
to Drive
Ground
R
S
T
PE
PE
(L2)
(L3)
Required Branch
Important: Verify motor insulation system peak voltage
Diagram shows connections that are common for all drives.
CR1
CR2
CR3
10
11
12
13
Contacts Shown in Unpowered State
(or Powered State with Fault/Alarm Present)
Terminal
Signal
TE
True Earth - Shield Termination
10, 11
CR1 Programmable Contact
11, 12
CR2 Programmable Contact
13, 14
CR3 Programmable Contact
14, 15
16, 17
CR4 Programmable Contact
17, 18
A1, A2
Reserved for Future Use
transient voltage surge suppression with maximum clamping voltage of 2.5 kV on all control boards.
Quick Start Guide
II
Drive Output
to Motor
U
V
W
DC
(T1)
(T2)
(T3)
+
Common Mode Core*
Shield
* Optional
rating. For cable lengths greater than 6.1
meters (20 feet), consult the User Manual.
Refer to User Manual for Detailed Information.
CR3
CR4
CR4
14
15
16
17
18
Resistive Rating = 115V AC/30V DC, 5.0A
Inductive Rating = 115V AC/30V DC, 2.0A
Copyright © 2003 Rockwell Automation, Inc. All rights reserved. Printed in USA.
Adjustable
PLUS
II
Dynamic Brake
DC
BRK
–
–
(Not on all drives)
Motor
Terminator*
Motor Frame
PE
Ground per
Local Codes
Only Present
on B Frame
& Up Drives
A1
A2
Reserved for
Future Use
P/N 188747 (06)
