Harness Wiring Diagram - Western tornado Owner's Manual

To Vehicle Switched Accessory
To Vehicle CHMSL Signal
Spreader
Module
BAT MOT GND
8 ga Black
8 ga Red
12 Volt DC, .56 kW Motor
Lit. No. 95748/95749, Rev. 03

HARNESS WIRING DIAGRAM

18 ga Red
6 ga Red 100 Amp Fuse
+
Vehicle
Spreader
Motor
16 ga Tan and White Twisted Pair
Motor Specification
Cab Control
4-Way Connector
Connector
18 ga Shielded Twisted-Pair Cable
6 ga Red
18 ga Black
6 ga Black
Wiring Harness
Wiring Harness
CHMSL
Assembly
20
6 ga Red
6 ga Black
September 15, 2009
