- Page 1 700-SE Multi-Fuel & Wood Burning Stove INSTALLATION & USER INSTRUCTIONS (TO BE LEFT WITH THE CUSTOMER) Australia & New Zealand Tested to AS/NZS 4012/4013 (2014)
-
Page 2: Table Of Contents
Avoid the use of aerosol sprays in the vicinity of the stove when it is in operation. This appliance must be installed as per these instructions and regulations complied with. No modifications or alterations of any kind are permitted. Page 2 700-SE-AUS-I02-130117... -
Page 3: Installation Instructions P
All local regulations, including those referring to National and European standards need to be complied with when installing the appliance. The Esse 700SE Free-Standing solid fuel appliance conforms to the requirements of Australian/New Zealand Standard 2918:2001, with respect to floor, ceiling, side wall and rear wall surface temperatures, when tested in the two test positions shown in figure 4c &... - Page 4 Fig.1 – Ideal Flue Connections Fig.2 – Chimney and Flue Performance Fig. 3 Wildcat default flue kit Page 4 700-SE-AUS-I02-130117...
- Page 5 Page 5 700-SE-AUS-I02-130117...
-
Page 6: Flue Draught P
Fit an air vent if the room is sealed. High flue draught symptoms: fire difficult to control, fuel will not last, stove too hot, stove damage, chimney fire. CAUSE REMEDY External wind conditions combined with Fit stabiliser cowl. chimney terminal Fit flue draught stabiliser. Page 6 700-SE-AUS-I02-130117... -
Page 7: Flue Stabiliser P
Fitted in the same room as the stove. The same size as the flue pipe. Fitted no closer than 700mm to the flue outlet of the appliance. DIMENSIONS & CLEARANCES Fig.4a – Stove Dimensions, Standard leg configuration. Page 7 700-SE-AUS-I02-130117... - Page 8 Fig.4b – Stove Dimensions, Log store configuration. Page 8 700-SE-AUS-I02-130117...
- Page 9 The Esse 700-SE was tested in two positions, conforming to Australian & New Zealand standard 2918:2001 Appendix B. The diagrams below show the tested clearances for this appliance. Fig.4c-Position A – Parallel position. Fig.4d-Position B – Corner position. Page 9...
-
Page 10: Commissioning Checklist P
Smoke test completed on installed appliance? Spillage test complete? Has the use of the appliance, operation and controls been explained? Clearance to combustible materials checked? Instruction book handed to the customer? CO Alarm fitted? Signature:……………………………………………….. Print Name:………………………………………………… Page 10 700-SE-AUS-I02-130117... -
Page 11: Installing The Stove P
On completing the installation, check that all the internal components of the stove are positioned correctly. Check - Ashpan, iron grate, baffle, side and back bricks. Leave the appliance operational and explain the operation of the stove to the customer. Leave all instructions and operating tools with the customer. Page 11 700-SE-AUS-I02-130117... -
Page 12: Operating Instructions P
Over firing will damage your stove. To maintain peak efficiency, your stove should burn approximately 2.2kg of well-seasoned wood per hour. Fig. 4 – Stove Controls Always use stove mitts when adjusting controls and opening or closing the door. Page 12 700-SE-AUS-I02-130117... - Page 13 If there are too few embers in the fire bed, add suitable kindling to prevent excessive smoke. FUEL OVERLOADING The maximum amount of fuel specified in this manual should not be exceeded, overloading can cause excess smoke. Page 13 700-SE-AUS-I02-130117...
-
Page 14: Wood Burning P
Page 14 700-SE-AUS-I02-130117... - Page 15 Resinous softwood burns well and gives a high output for short periods but is not as efficient and does not last as long as hardwood. Page 15 700-SE-AUS-I02-130117...
-
Page 16: Solid Fuel Burning P
The exact setting of the air controls depends on a number of variables including: the flue draught, the fuel used and the installation and so the best setting for your stove can only be learned by experience. Page 16 700-SE-AUS-I02-130117... -
Page 17: Technical Information P
(kW) (6/kg) Oven Dry Wood High Medium When tested the appliance particulate emissions factor was 1.0g/kg of Hardwood fuel that complies to AS/NZS4014.1 and the average efficiency of the appliance for all burn rates is 64%. MAINTENANCE Page 17 700-SE-AUS-I02-130117... -
Page 18: Maintenance P
Close the door and open the air inlets fully. This action will allow air circulation through the flue ways and help avoid corrosion and condensation. SERVICING Regular maintenance should be carried out by a competent engineer. Page 18 700-SE-AUS-I02-130117... -
Page 19: Guarantee P
Your ESSE is guaranteed against defects arising from faulty manufacture for 2 years when supplied by an ESSE Specialist. Upon registration of the warranty, ESSE will extend the guarantee period to 5 years from purchase. Your details must be registered with us by either returning the completed warranty card or by completing registration on-line at www.esse.com. - Page 20 ESSE Engineering Limited, Ouzledale Foundry, Long Ing, Barnoldswick, Lancashire BB18 6BJ United Kingdom Tel. +44 1282 813 235, Fax: +44 1282 816 876 Website and On-line Store http://www.esse.com Page 20 700-SE-AUS-I02-130117...
