Summary of Contents for Esse Ironheart EW
- Page 1 Ironheart Models EW & EWB Wood Fired Cooking Stove THIS APPLIANCE MUST BE COMMISSIONED BY A HETAS REGISTERED ENGINEER THE WARRANTY CARD MUST BE RETURNED TO ENSURE GUARANTEE VALIDITY...
-
Page 2: Table Of Contents
Table of Contents OPERATING INSTRUCTIONS ................3 INTRODUCTION ....................3 BEFORE USING YOUR COOKING STOVE ............3 YOUR COOKING STOVE .................. 4 LIGHTING AND CONTROLLING THE FIRE ............6 NOTES ON WOODBURNING ................. 10 LONG TERM SHUTDOWN ................11 FIREWOOD AND THE WOODBURNING PROCESS.......... 11 COOKING WITH THE COOK STOVE ............... -
Page 3: Operating Instructions
Ironheart OPERATING INSTRUCTIONS INTRODUCTION Thank you for choosing an ESSE cooking stove. Please read these instructions carefully to ensure your safety and enjoyment whilst using this product. Correctly installed and operated, your ESSE cooking stove will provide faithful service indefinitely. We feel certain that like countless ESSE owners since 1854, you will be truly satisfied by the warmth and comfort it will provide and the taste of your food cooked within its oven. -
Page 4: Your Cooking Stove
YOUR COOKING STOVE Figure 1 Ironheart Cooking Stove Figure 1 show the cooking stove and it’s controls. The fire is loaded, refuelled, and emptied through the large glass fire door. A flue damper is fitted in the bottom of the flue box and is in the open position when lever is pointing to rear of cooker. - Page 5 Included inside your cooking stove is a multi-purpose Operating Tool – for adjusting the air supply and operating the door. A glove is also provided to protect the user’s hand. (Figure 2) WARNING Do not place towels on the handrail, keep pets and children away and ensure that any curtains near the appliance cannot ignite even when displaced.
-
Page 6: Lighting And Controlling The Fire
LIGHTING AND CONTROLLING THE FIRE Figure 3 Multi-fuel Grate Firebox Parts Figure 4 Wood Burning Firebox Parts Page 6 EW-I02-070319... - Page 7 Before lighting the fire ensure that all parts are in the correct position. For multi fuel use see Figure 3. The Ironheart may be configured to a wood burning only specification by removing the grate and ashpan and substituting a steel wood burning box (see Figure 4).
- Page 8 Place a firelighter in the space and surround with a small amount of kindling. Figure 6 Fire Lighter and Kindling in Place Lay a third log over the top of the space perpendicular to the other logs. Figure 7 Final Log in Position When you are ready to light the fire all that needs to be done is light the firelighter.
- Page 9 Figure 8 Oven Damper Controls Once the fire has been established the oven damper control may be used to regulate the oven temperatures along with the burning rate of the cookstove. WARNING When the cooking stove is running ALL HANDLES become hot and the operating tool or glove provided should be used to open or close the doors (Figure 2) The burning rate of the stove can now be regulated by the rate at which fuel is...
-
Page 10: Notes On Woodburning
When refuelling the cook stove it is recommended that the logs are placed running front to back as in Figure 5 as this leads to the cleanest combustion. Before lighting a full fire in the cook stove for the first time it is recommended that 3 smaller fires are lit first to ensure that any moisture is driven out. -
Page 11: Long Term Shutdown
Above 260 Too hot. Heat will be wasted up the chimney. Excess heat may damage the cooking stove or ignite an existing accumulation of tar resulting in a chimney fire. In the event of a fire, close the air controls on the appliance and call the fire brigade for assistance. - Page 12 Wood is composed of bundles of microscopic tubes that were used to transport water from the roots of the tree to the leaves. These tubes will stay full of water for years even after a tree is dead. This is why it is so important to have your firewood cut to length for 6 months or more before you burn it, it gives this water a chance to evaporate since the tube ends are finally open and the water only has to migrate a small distance to escape.
- Page 13 some deciduous trees. Birch, for example, is not very hard at all. So we should understand that there is a whole range of densities amongst our tree species, including medium dense woods, which cannot be satisfactorily classed as hard or soft. Firewood tends to be sold by volume rather than weight.
- Page 14 There is also the matter of seasoning to be considered. When you buy wood, it will usually have been cut in the winter of the year you buy it. Hard woods tend to take longer than softwoods to fully dry out. Softwoods cut in the previous winter should, with proper storage, be ready to burn the next autumn, whereas many hardwoods may take a bit longer than that.
- Page 15 breath on a colder window or mirror. So when the by-products of combustion (smoke in the form of gases) exit the cooker, and flow up into the relatively cooler chimney, condensation occurs. The resulting residue that sticks to the inner walls of the chimney is called creosote.
-
Page 16: Cooking With The Cook Stove
are still warm. They should not be put into a plastic receptacle or anything that might melt in contact with heat. Always use the Operating Tool to open the ash door and remove the ash pan. Use the Operating Tool to securely lock the door and ensure the door is closed properly. - Page 17 to hold a smaller amount of fuel at the rear of the firebox. This also has the advantage of reducing the heat radiated through the window, making life easier for the cook. Also the fire guard can be slid in front of the fire door in order to reduce the heat through the glass and protect the operator whilst cooking.
-
Page 18: Extended Woodburning
EXTENDED WOODBURNING This appliance has not been certified as a slow combustion stove. Loading a large amount of wood into the cooking stove all at once will reduce the temperature inside. If the temperature is too low, the gases given off from the wood will be too low to combust, resulting in a lot of smoke which will cover the inside of the cooking stove, including the glass, with soot. -
Page 19: Cleaning And Maintainance
CLEANING AND MAINTAINANCE The successful operation of your cook stove is entirely dependent on the adequate performance (pull) of the chimney or flue to which it is connected. The following maintenance guidelines will be pointless unless the flue is also maintained and cleaned regularly. - Page 20 High temperature resistant cooking stove paints are available in aerosol form from your cooking stove dealer, or from www.esse.com/spareparts/. Do not use this paint until the cooking stove is completely cold and always follow the instructions on the container before starting to paint.
-
Page 21: Conditions Of Guarantee
Your ESSE is guaranteed against defects arising from faulty manufacture for 2 years when supplied by an ESSE Specialist. Upon registration of the warranty, ESSE will extend the guarantee period to 5 years from purchase. Your details must be registered with us by either returning the completed warranty card or by completing registration on-line at www.esse.com. -
Page 22: Customer Care
Should you have cause for dissatisfaction with your cooker, you should contact your ESSE dealer, who will, in most instances, be able to offer you immediate assistance. You will be required to give the following details. o Your name, address and postcode. - Page 23 ventilate the room. Let the fire burn out or eject and safely dispose of fuel from the appliance. Once the fire is cold, check the flue and chimney for blockages and clean if required. Do not attempt to relight the fire until the cause of the fume emission has been identified and corrected.
-
Page 24: Installation Instructions
Ironheart INSTALLATION INSTRUCTIONS GENERAL SAFETY INFORMATION In the UK, the installer has a responsibility under the Health and Safety at Work Act 1974 to provide for the safety of persons carrying out the installation. Attention is drawn to the fact that fire cement is caustic and hands must be washed thoroughly after use. -
Page 25: The Clean Air Act 1993 And Smoke Controlled Areas
THE CLEAN AIR ACT 1993 AND SMOKE CONTROLLED AREAS Under the Clean Air Act local authorities may declare the whole or part of the district of the authority to be a smoke control area. It is an offence to emit smoke from a chimney of a building, from a furnace or from any fixed boiler if located in a designated smoke control area. -
Page 26: Dimensions And Clearances
Clean Air Act requirements “The ESSE Ironheart Cooking Stove has been recommended as suitable for use in smoke control areas when burning dry wood logs”... - Page 27 Figure 12 Boiler Tapping Locations & Minimum Clearances to None Combustibles Clearances From Combustibles Sides Back Any adjacent combustible material should be far enough away from the cooking stove so as not to rise 60°C above the room temperature when the cooking stove is in operation.
-
Page 28: Chimney And Flue Information
CHIMNEY AND FLUE INFORMATION The successful operation of the cooking appliance relies on the adequate performance of the chimney to which it is connected. The following chimney guidelines must be followed: o It should have an internal cross section of no less than 320cm2 (200mm dia.) (If a flue liner is used, it should be 150mm (6’’) diameter and be made of suitable material for burning wood). - Page 29 NOTE The chimney/flue to which this appliance is being connected must be swept and examined for soundness prior to installation. Remedial action should be taken if required, seeking expert advice if necessary. Where the chimney is believed to have served an open fire installation it is possible that a higher flue gas temperature from a closed appliance may loosen deposits that were firmly adhered, with the consequent risk of flue blockage.
- Page 30 as the appliance and be the same size as the flue pipe. Consult building regulations regarding additional ventilation. A fan flue booster can also be fitted if the flue draught is poor. This should be fitted according to the instructions supplied with the booster. An electrical supply will be needed.
-
Page 31: Installing The Appliance
Figure 13 Chimney Location and Flue Performance INSTALLING THE APPLIANCE Flue Connection The flue pipe used to connect the appliance to the chimney is 6’’ (150mm) in diameter. (The flue connection is on the top of the appliance, in the centre at the back.) Important Installation Notes o The installation must allow access for adequate chimney sweeping and... - Page 32 o All flue sockets must face upwards. On completing the installation of the appliance, the chimney, hearth and walls adjacent to the cooker must conform to local or national regulations currently in force. In the United Kingdom, the appropriate sections of the Building Regulations must be conformed to.
-
Page 33: Hot Water System (Ewb Models Only)
HOT WATER SYSTEM (EWB MODELS ONLY) There are two connections, both 1" BSP Female on the left hand side. Follow general notes below: The EWB or DE-LUXE boiler is plain mild steel and capable of running a radiator in addition to domestic hot water. General Notes on Water System:- o The cooking stove will produce hot water at differing rates depending on how it is operated. - Page 34 Figure 14 Typical DHW Gravity System Page 34 EW-I02-070319...
-
Page 35: Commissioning The Appliance
Measure and record flue draught o Check ventilation o If applicable check plumbing circuit o Check no extractor fan, other appliance or other flue interferes o Complete commissioning card and return to ESSE to validate warranty Page 35 EW-I02-070319... -
Page 36: Replacement Parts
REPLACEMENT PARTS WCKLIDSET- 1. Upper Door Handles EW-062 23. Bolster Lid Assembly 2. Lower Door Handles ES-006 24. Hinge Assembly CENT-022 3. Magnet Catch EW-042 25. Flue Damper EW-048 4. Ash Door EW-005 26. Cast Iron Flue Box EW-036 5. Flue Access Door EW-009 27. - Page 37 Page 37 EW-I02-070319...
-
Page 38: Commissioning Checklist
COMMISSIONING CHECKLIST To assist with any potential guarantee claim please complete the following information:- To be completed by the installer. Dealer the appliance was purchased from: Name: Address: Telephone No: ESSENTIAL information: Date Installed Model Description: Serial No: Installation Engineer: Company Name: Address: Telephone No:... -
Page 39: Technical Information
TECHNICAL INFORMATION Nominal Heat Output (kW) 10.5 Boiler Heat Output (kW) Combustion Air Requirements (m Air Vent Size (cm Weight of Appliance (kg) Minimum Chimney Draught (Pa) Mean Flue Gas Temperature ( Flue Gas Mass Flow (g/s) 18.5 13.7 Page 39 EW-I02-070319... - Page 40 ESSE Engineering Limited, Ouzledale Foundry, Long Ing, Barnoldswick, Lancashire BB18 6BJ Tel. 01282 813 235, Fax: 01282 816 876 Website and On-line Store http://www.esse.com...
