- Page 1 RX Series Video Recording Server RX324v3 / RX328v3 / RX3216v3 RX364v3 / RX368v3 / RX3616v3 Quick Start Guide Version 1.04...
-
Page 3: Table Of Contents
This manual is copyrighted. All rights are reserved. This manual should not be copied, reproduced or translated in whole or part without prior consent from Signal Communications Limited. TeleEye is a trademark of Signal Communications Limited and is registered in China, European Communities, Hong Kong, US and other countries. - Page 4 Copyright (c) 2010 Signal Communications Limited (A member of TeleEye Group). All rights reserved. Release Version 1.04 Limits of Liability and Disclaimer of Warranty Signal Communications Limited has taken care in preparation of this manual, but makes no expressed or implied warranty of any kind and assume no responsibility for errors or omissions.
-
Page 5: Introduction
PC, video recording, email notification, etc. can be performed. TeleEye RX can also keep a comprehensive log of the events for audit trail. TeleEye RX is designed to fully comply with the British Standard BS 8418:2003, providing professional remote monitoring and visual alarm verification solution to central monitoring station. -
Page 6: Hardware Features
Quick Start Guide PAGE 2 Package contents Description Package contents Description Warranty Card HDD Screws (Only for RX324v3, RX328v3, RX3216v3) Software CD Straight-through Ethernet Cable Power Adaptor Resistors (1.2kΩ x 20, 6kΩ x 20) Alarm Port Connector Remote Control and... - Page 7 Quick Start Guide PAGE 3 1. Notification LEDs 2. Main control buttons only for RX328v3, RX368v3, RX3216v3 and RX3616v3 only for RX3216v3 and RX3616v3 3.Menu control / Local playback control / PTZ control buttons Buttons Menu Mode Playback Mode PTZ Mode Cursor Up Pause Tilt Up...
-
Page 8: Back View
Quick Start Guide PAGE 4 1.2.2.Back View 1.Alarm / switch Port 2.VGA output 3.Audio In/Out Port, PA 4.NC (Not available for use) 5.Video Input Connectors 6.Power on / off 7.Power input (12V DC) RX3216v3 Model 8.RS 485 In/Out Port 9.USB Port 10.Ethernet Socket (10/100 Base-T) 11.Video Output Connector RX3616v3 Model... -
Page 9: Functional Features
Data retention Mobile monitoring 1.4.Hard Disk Installation 1.Put the hard disk into the RXv3 video recording server and connect it to the cables. For RX324v3, RX328v3 and RX3216v3 1.1 Take out the screws. 1.2 Pull up the cover. Hard Disk Installation... - Page 10 Quick Start Guide PAGE 6 1.3 Put the HDD into the RXv3 1.4 Mount the HDD to holders with attached screws. 1.5 Insert the SATA cable to the HDD Hard Disk Installation...
- Page 11 Quick Start Guide PAGE 7 For RX364v3, RX368v3, RX3616v3, TeleEye RXv3 video recording server supports SATA standard hard disk. Hard Disk Front Panel Description 1. Key lock 2. Spring lock 3. LED indicator (for Power & Access) Key Lock Description...
-
Page 12: Installation Procedure
Quick Start Guide PAGE 8 Installation Procedure RX MUST be shut down before installing / uninstalling hard disk 1.Press “Menu” button, select [SHUT DOWN] option and press “Enter” button. 2.[SHUT DOWN] menu will pop up and select [SHUT DOWN] option and press “Enter” button. - Page 13 Quick Start Guide PAGE 9 7.Place the HDD into the cartridge with the hard drive label (printed) side up and be sure the HDD connector side is properly inserted into the cartridge. 8.Close the front door. 9.Insert the bundled key provided into the keyhole and turn the key anti-clockwise (position A).
-
Page 14: Local Operation (Cctv / Vga Monitor)
2.1.Setup for Local CCTV Monitor When you observe video from CCTV monitor or VGA monitor, icons may be shown on the video Connection Topology Equipment TeleEye RXv3 Video recording server Cameras Video Cables (RG-59) with BNC Header CCTV Monitor Setup for Local CCTV Monitor... -
Page 15: Setup Procedure
2.Connect CCTV monitor to TeleEye RXv3 {Video Output} with RG59 cable and BNC connector. 3.Install and use the bundled key to lock the {Hard Disk Rack} with hard disk to the TeleEye RXv3. Note: If there is no hard disk installed, Recording and Playback are not functional 4.Plug in the power adapter (12V DC) to TeleEye RXv3. -
Page 16: Icons Description (Osd)
Quick Start Guide PAGE 12 2.2.Icons Description (OSD) When you observe video from CCTV monitor or VGA monitor, icons may be shown on the video. Each of the icons has special meaning. Please find their meanings from the table summary in next page. - Page 17 Quick Start Guide PAGE 13 •IP Filtering Scan / Format Disk 1.Scan Disk 2.Format Disk 7.Event Handler 3.Format USB Flash •ARM / DISARM Server Information •Security Switch 1.Server Name •Alarm 2.Server IP •Motion 3.Model No. •Video Loss 4.Serial No. •System Tamper 5.Version •Power Failure 6.Security Mode...
-
Page 18: View Live Video (Osd)
Quick Start Guide PAGE 14 2.4.View Live Video (OSD) 1.Turn on your RXv3 video recording server and cameras 2.Turn on your monitor 3.Select screen mode and cameras by using main control panel buttons on RXv3 video recording server or number pads and screen mode buttons on remote controller FULL QUAD 3x3*... -
Page 19: Playback (Osd)
Quick Start Guide PAGE 15 5.Select [APPLY] 6.Press [Rec] button on front panel 7.Select [START SCHEDULE RECORDING] 8.During schedule recording, press [Rec] button again for stopping it 2.6.Playback (OSD) 1.Press [Search] button to pop up [RECORDING LOG] 2.Search log for playback (by 2.1 or 2.2) 2.1.View by log 2.1.1.Select [VIEW LOG] 2.1.2.Select a log by using [↑... -
Page 20: Remote Operation (Network)
Quick Start Guide PAGE 16 3.Remote Operation (Network) 3.1.Network Configuration (Network) PC Requirements: CPU: Intel Pentium Dual-Core 2.2GHz or above Memory: 1GB or above OS: Windows XP or Windows Vista Home/Business Other Requirements: Java: Sun Microsystems Java 2 runtime Version 1.5.0 or above IE: Windows Internet Explorer Version 6 or above There are Ethernet and 3G networks. - Page 21 Quick Start Guide PAGE 17 Icons Description Camera selection panel Event status panel 1.Alarm event 2.Video loss event 3.Motion event 4.Disc event 5.Clear event 6.Power Failure Event 7.Alarm Tamper Event 8.System Temper Event 9.Siren off 10.Armed / Disarmed Menu panel 1.Setting 2.Audio 3.PTZ...
- Page 22 Quick Start Guide PAGE 18 Icons Description Icons on PTZ panel 1.Tilt up 2.Pan left 3.Tilt down 4.Pan right 5.Zoom in 6.Zoom out 7.Focus near 8.Focus far 9.Open iris 10.Close iris 11.Washer 12.Wiper 13.Expand panel 14.Shrink panel Icons on audio panel 1.Mute 2.Audio level –...
-
Page 23: Menu Overview (Network)
3.Wait for the system to save the setting or exit from [MAIN MENU] to save the settings 3.4.2.By IP Setup Utility 1.Install TeleEye IP Setup Utility software by the software CD. .NET framework is needed for IP Setup Utility operation. You can find .NET framework installer in the software CD. -
Page 24: View Live Video (Network)
Quick Start Guide PAGE 20 3.5.View Live Video (Network) 1.Enter IP address plus port number in this format http://IPAddress:PortNumber (e.g. http://192.168.0.1:1024) or sureLINK address in web browser address bar 2.Enter password. Default password can be found in the given registration code sheet. 3.Press [Connect] button 4.Use screen mode selection panel and/or camera selection panel to view video View Live Video (Network) -
Page 25: Recording (Network)
Quick Start Guide PAGE 21 Remarks: If the cross logo is shown at the top left hand corner of the web page, it implies the Java JVM is not installed in the computer. Please follow method 1 or method 2 to install it. Method 1: Install the Java JVM through the software CD in the package Method 2: Download the Java JVM through http://www.java.com... -
Page 26: Playback (Network)
Quick Start Guide PAGE 22 3.7.Playback (Network) 1.Press [Playback] button 2.Choose a log entry or enter date and time on the bottom of the panel 3.Click on [Play] button to start playback 4.Use playback control panel, camera selection panel and screen mode selection panel to control playback process 3.8.Footage Extraction (Network) 1.Go to [Menu]...
