Installation

The FortiGate unit
(48.3 cm) rack unit with the provided rack-mount brackets
To install the FortiGate unit into a rack
1. Ensure that the FortiGate unit is placed on a stable surface prior to rack-mount
installation.
2. Attach the provided rack-mount brackets
screws.
Caution: Electrostatic
discharge (ESD) can
damage your Fortinet
equipment.
POE devices only:
This equipment is to
be used in a Network
Environment 0 per
IECTR 62101. This
product is connected
only to PoE networks
without routing to the
outside plant.
6
and screws.
to the sides of the unit using the provided
3. Position the FortiGate unit in the rack. Ensure there is enough room around the unit to
Caution: To avoid
personal injury or
damage to the unit, it
is recommended that
two or more people
install the unit into the
rack.
4. Line up the rack-mount bracket holes to the holes on the rack and ensure that the
FortiGate unit is level.
5. Finger tighten four rack-mount screws to attach the unit to the rack.
6. Verify that the spacing around the FortiGate unit
unit is level, then tighten the rack-mount screws
7. Using the provided power cable, plug the cable into the rear of the unit, and then into a
grounded electrical outlet or separate power source.
conforms to requirements and that the
with an appropriate screwdriver.
