Note: If the unit
has a redundant
1. Ensure that the surface onto which the
power supply, each
to be installed is clean, level, and stable and that
power cable should
there is at least
be connected to
a different power
2. Attach the provided
source. In this way,
FortiGate
if one power source
3. Place the unit in the designated location.
fails, the other may
4. Verify that the spacing around the
still be operational
conforms to requirements and that the unit is level.
and the unit will not
5. Using the provided
lose power.
into the rear of the unit, and then into a grounded
electrical outlet
1.5in
8
FortiGate unit
1.5 inches (3.8cm) of clearance on all
rubber feet to the bottom of the
unit.
FortiGate unit
power cable, plug the cable
or separate power source.
1.5in

SFP Transceivers

To install the SFP transceivers
Caution: SFP
transceivers are static
1. Ensure that you are properly grounded.
sensitive devices. Use
2. Remove the
an ESD wrist strap
front panel of the unit.
or similar grounding
device when handling
Transmit Optical Bore
transceivers.
Do not install
or remove SFP
transceivers while
still attached. This
can cause damage
to the cables, cable
Extraction Lever
connectors, and the
optical interfaces.
It may also prevent
the transceiver from
latching correctly into
the socket connector.
caps from the SFP cage sockets on the
Receive Optical Bore
SFP Cage Sockets
Socket Latch
