A s s e m b l y
G u i d e
X1400
AND
X1500
ELLIPTICAL TRAINERS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X1400 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vision Fitness X1400

Summary of Contents for Vision Fitness X1400

  • Page 1 A s s e m b l y G u i d e X1400 X1500 ELLIPTICAL TRAINERS...
  • Page 2 A s s e m b l y G u i d e X1400 AND X1500 ELLIPTICAL TRAINERS To avoid possible damage to this Elliptical Trainer, please follow these assembly steps in the correct order. Before proceeding, find your new Elliptical Trainer’s serial number located on the front axle tube, and enter here: Refer to this number when calling for service, and enter this serial number on your Warranty Card and in your own records.
  • Page 3 Right and Left Footplates Q235 Knuckle Pin Quantity: 2 Rear Stabilizers (located in parts box) Water Bottle and Cage Power Supply (X1500 only) Tension Knob and Bracket (X1400 only) Color Coded Hardware Bags Owners Manual Assembly Guide M8x40L Bolt Warranty Card...
  • Page 4 M8x15L Screw Quantity: 2 Quantity: 4 SS41 Link Joint Sleeve 25x34x2T Wavy Washer Quantity: 2 Quantity: 2 PINK BAG 5x10x1T Washer X1400 ONLY M8X15L Screws Quantity: 1 Quantity: 6 M8x45L Screw Quantity: 2 M4x12L Screw Quantity: 2 8x18x1T Arc Washer...
  • Page 5 ORANGE BAG STEP • Slide the stabilizer shaft through the plastic sleeves in the rear support tube. • Slide the stabilizer covers onto the stabilizer shaft and secure with (M8x15L) screws and (8x16x1T) flat washers. Tighten with the 5mm T-shaped wrench. •...
  • Page 6 BLUE BAG STEP • Slide a wavy washer (25x34x2T) on to the right rotation axle. Slide the knuckle joint of the pedal arm onto the right rotation axle. The pedal arm roller wheel should be placed into the groove of the guide rail. Secure the pedal arm to the rotation axle with a washer (8x38x2T) and screw (M8x20L).
  • Page 7 Console Knob mast over frame bracket. Mast NOTE: For the X1400 the tension cable should also run up through the console mast. Tension Knob • Slide a lock washer (SW8) fol- Bracket lowed by a flat washer (8x17x1T) Boot onto four of the screws (M8x15L).
  • Page 8 GREEN BAG STEP • Slide the knuckle pin (Q235) through the bushings of the knuckle. Slide the link arm over the knuckle so that the hole in the link arm lines up with the hole in the knuckle pin. Insert a bolt (M8x40L) through the hole in the link arm and knuckle pin and attach a washer (8x18x1T) and nylon...
  • Page 9 BLACK BAG STEP • Slide the dual-action axle cover into place over the console mast axle. Slide a wavy washer (25x34x2T) onto the console mast axle. Slide the right dual-action arm onto the axle. Fix in place with a washer (8x38x2T) and nylon nut (M8).
  • Page 10 500 South CP Avenue • P.O. Box 280 • Lake Mills. WI 53551 toll free 800.335.4348 • phone 920.648.4090 • fax 920.648.3373 www.visionfitness.com ©2005 Vision Fitness. All Rights Reserved. 12.05 AG18.34PRD REV3...

This manual is also suitable for:

X1500
