- Page 1 PB*4VI510FTB* (GB) INSTRUCTION MANUAL........2 IOAA-509 (10.2010/1...
-
Page 2: Basic Information
DEAR CUSTOMER, The plate is exceptionally easy to use and extremely efficient. After reading the instruction manual, operating the cooker will be easy. Before being packaged and leaving the manufacturer, the plate was thoroughly checked with regard to safety and functionality. Before using the appliance, please read the instruction manual carefully. -
Page 3: Table Of Contents
TABLE OF CONTENTS Basic information......................2 Safety instructions......................4 Saving energy........................5 Unpacking.........................6 Disposing of the device......................6 Description of the appliance....................7 Installation........................8 Connecting the plate to the electrical system..............10 Guidelines for the installer....................10 Operation........................12 Inductive hotplate – principles of operation................12 Pot detector ........................13 Selection of cookware for inductive hotplates ..............13 Control panel........................15 Turning on the cooktop.....................15... -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS • Be f o r e using the ceramic plate for the first time read the Operating Manual carefully as thus you can ensure safe operation and avoid damage to the plate. • If the ceramic plate is operated near a radio, TV set or other emitting device, please check whether the touch panel works correctly. • The ceramic plate should be installed by a qualified electrician. • Do not install the plate near refrigerating devices. • The furniture the plate is fitted in should be resistant to temperatures up to 100 C. The requirement applies to the veneer, plastic surfaces, glues and varnishes. • The plate can be used only after it has been fitted into furniture, as only thus you will be protected from accidental contact with live components. • Elec t ric appliances can be repaired only by qualified specialists. Unprofessional repairs may compromise the safety of the appliance. -
Page 5: Saving Energy
SAFETY INSTRUCTIONS • The heating surface of the ceramic plate is resistant to thermal shock. It is neither hot nor cold-sensitive. • Avo i d dropping objects on the plate. A point hit, for example a falling bottle with spices, may in unfavourable circumstances lead to cracks and splits appearing on your ceramic plate. • Bo i led over residuals of food may penetrate the damaged places and get to the live com- ponents of the ceramic plate. • Should cracks or splits appear on the surface of your ceramic plate immediately di s con n ect it from the mains. In order to do so, switch off the fuse or pull out the mains plug from the socket. Call the Customer Service. • Ple a se observe the maintenance and cleaning guidelines. Should you fail to proceed in compliance with the provided guidelines, you will lose your warranty rights. -
Page 6: Unpacking
UNPACKING DISPOSING OF THE DEVICE When disposing of the device, do The appliance is protected from damage during transpor- not bring it to regu lar municipal tation by its packaging. After waste con t ainers. Instead, bring unpacking please dispose it to elec trical and electronic of the packing materials in a waste recycling and reuse cen- manner creating no risk to the ter. -
Page 7: Description Of The Appliance
DESCRIPTION OF THE APPLIANCE Description of PB*4VI510FTB1 plate Inductive hotplate (rear right) Inductive hotplate (rear left) Inductive hotplate Booster (front left) Inductive hotplate (front right) Control panel 1. ON/OFF button 2. + button / field selector 3. Power indicator incl. decimal point 4. – button of the fields and the clock 5. Clock on/off button, + button of the clock 6. -
Page 8: Installation
INSTALLATION Installation of PB*4VI510FT* plate • prepare a place (an opening) in the table top according to di m en s ions specified on the installation drawing (Fig. A), • minimal clearance to be left between the appliance and the sides of the ne igh bo uring cupboards is 50 mm, • the installed plate is 50mm high, • if the cooking plate is separated from the support cupboard by means of a horizontal pro- tec t i v e plate, the clearance between the bottom of the enclosure of the cooking plate and the protective plate has to be at least 25 mm high to ensure free air flow. The minimal distance between the two plates should be 75 mm,... - Page 9 INSTALLATION Fig. B 25mm 80mm Fitted in the top of a carrying cupboard 500x10mm Minimum 10mm Fitted in a working top over an oven with ventilation 500x50mm 500x10mm Fig. C 1 - table top 2 - double-sided adhesive tape 3 - ceramic plate Fitting the plate over non-ventilated oven is prohibited...
-
Page 10: Connecting The Plate To The Electrical System
NSTALLATION Connecting the plate to the electrical system Note! The plate can be connected to the mains only by a qualified certified installer. Wilful adaptations or modifications to the electric system are prohibited. Guidelines for the installer The plate is provided with a terminal box enabling selection of proper connections for the given type of power supply. The terminal box enables the following types of connection: onephase 230 V twophase 400 V2N~ The plate can be connected to the appropriate power supply by adequate bridging on the connection strip, in accordance with the attached wiring diagram. The wiring diagram is also provided in the bottom part of the lower cover. The connection strip can be accessed once the cover on the terminal box is removed. Please remember to match the mains connection cable to the type of connection and the rated power of the plate. - Page 11 NSTALLATION DIAGRAM OF POSSIBLE CONNECTIONS Important! Heating elements voltage 230V Warning! In every type of connec- tion protective grounding has to be Recom- connected to terminal mended type of connector cable 1 For 230 V power supply single H05VVF phase connection with a neutral lead, 12 and 34 terminals are H05RRF shorted together, neutral lead 3X 4 mm...
-
Page 12: Operation
OPERATION Before first use • carefully clean the ceramic plate treating it as a glass surface, • when used for the first time the plate can give off a bit of a smell so switch on the ventilation system or open the window, • operate the plate observing the safety instructions. Inductive hotplate – principles of operation Electric generator supplies power to a coil located inside the appliance. As the coil generates magnetic field, in- duced currents permeable to a pot placed on the plate. The currents make the pot a true heat transmitter while the glass surface of the plate remains cold. The system provides for the usage of pots with bottoms susceptible to magnetic field. -
Page 13: Pot Detector
OPERATION Pot detector The pot detector is installed in plates equipped with the inductive field system. During opera- tion the pot detector automatically starts or stops the production of heat once a pot is put or removed from the plate, saving energy. • If appropriate pot is used there is a heat level indicated on the display. • Induction requires the use of wellmatched pots with bottoms made of magnetic material (see Table page 14). If a pot has not been put on the hotplate or improper pot has been used, the sign will be displayed. The hotplate will not switch on. If no pots are detected within 10 minutes, the switching on operation is cancelled. - Page 14 OPERATION Energy is well generated when the dimensions of a pot are equal to an induction cooktop. The shortest and longest diameters are presented in the table below and they depend on the quality of a dish. Induction cooktop Diameter of the bottom of a pot for induction cooking. Diameter (mm) Minimum (mm) Maximum (mm) While using smaller pots than the minimum diameters, the induction cooktop may not work.
-
Page 15: Control Panel
OPERATION Control panel • All the indicators will go on for a brief moment when the cooktop is connected to the mains. The appliance is ready to work. • The cooktop is equipped with an electronic touch button control panel. Press the suitable button for at least 1 second to activate the requested function. • A brief tone sounds each time a touch button is touched. Note: do not put any objects on the touch panels. Risk of triggering error alert. The touch panel should be maintained clean. Turning on the cooktop All the burners are cold and indicators are dead when the cooktop is in OFF mode. Touch the ON / OFF button (1) to turn the appliance on. -
Page 16: Turning Off The Cooktop
OPERATION Turning off the cooktop • The cooktop remains in ON mode as long as at least one of the burners is active. • Touch ON / OFF button to turn off the entire cooktop. For the burners which are still hot the residual heat indicator ‘H’ will show in the respective display (3). Turning off a burner. • A burner is active and the decimal point is blinking. • Reduce the burner’s heating power touch the burner’s ON / OFF button and reduce its heating power to ‘0’ to turn off a single burner with “-“ button (4). The burner will go off in about 3 seconds. Booster function Booster increases the power of the heating zones as follows: Φ210 from 2300 W to 3000 W. -
Page 17: Locking The Cooktop
OPERATION Locking the cooktop Touch the key button (8) to activate the lock. The lock is activated the moment the respective LED starts to blink. A brief tune sounds when the button is touched. “0” must be apparent in all the displays, or the heating power must be set for at least one of the burners in order to lock the cooktop. Unlocking the cooktop Touch the key button (8) to turn off the lock. -
Page 18: Limited Time Of Operation
OPERATION Limited time of operation To increase its reliability the plate is pro- Heating power Maximal time of vided with an operation time limiter for each level operation in hours hotplate. The maximal times of operation depend on the last selected heating power level. -
Page 19: Clock/Timer
OPERATION Clock / timer The programming clock can control all the heating elements, thereby making cooking easier. The clock can be also used as an alarm feature. Turning the clock on The clock makes cooking easier. It can be used to preset the duration of uptimes of the bur- ners. The clock can be also used as an alarm feature. • Select the required burner with burner selector (2). -
Page 20: Turning Off The Clock
OPERATION Turning the clock off A tune sounds after the preset requested cooking time has elapsed. That tune can be turned off by touching any button. Otherwise the alarm will go off automatically in 2 minutes. If it is necessary to turn the clock off before the preset time has been counted, proceed as follows: • Select the required burner with burner selector (2). The decimal point in the display starts blinking. • Press clock on / off button (5) to turn on the clock. • Press ““ (4) buttons to reduce the cooking time to “00”. The clock function will go off, while the burner remains active until it is manually switched off. Quick clock turn-off • Select the required burner with burner selector (2). -
Page 21: Cleaning And Routine Maintenance
CLEANING AND ROUTINE MAINTENANCE Daily cleaning and proper maintenance have crucial impact on the durability of your ce ra- mic plate. Clean the ceramic plate observing the same rules as for glass. Never use abrasive or aggressive clean- ing agents, scrubbing powders or scratching sponges. Also do not use steam cleaning devices. Removal of stains •... -
Page 22: Cleaning And Routine Maintenance
CLEANING AND ROUTINE MAINTENANCE Never apply cleaning agent on a hot hotplate. Attention! Leave the cleaning agent to dry and then wipe If from any reason you are not able it off with a damp cloth. Any residuals of clean- to control the switched on plate, ing agents should be wiped off with a damp switch off the main switch or screw cloth before the next heating as otherwise out the fuse and call the Customer... -
Page 23: Emergency Procedure
EMERGENCY PROCEDURE Every time when emergency situation occurs you should: • switch off the working assemblies of the plate • disconnect power supply • call in the service • as some minor faults can be removed by the user in accordance with the be l ow specified instructions, before calling the Customer Service please go thro u gh the Table checking every point. PROBLEM CAUSE ACTION 1.The appliance is not wor- - power supply failure -check the in-house electric king sys t em fuse, replace if ne ces sa ry 2. -
Page 24: Emergency Procedure
EMERGENCY PROCEDURE PROBLEM CAUSE ACTION 7.Residual temperature in di- - power supply fa i lu r e, the -the residual temperature in- ca tor is not lighted although ap plian ce has been di scon- di ca tor will work again after the hot pla tes are still hot nec ted from the mains swit ching the control panel... -
Page 25: Technical Data
TECHNICAL DATA Rated voltage 400V 2N~50 Hz Rated power: PB*4VI510FTB1 - inductive hotplate : Ø 145 mm 2 x 1400 W - inductive hotplate : Ø 180 mm 2300 W - inductive hotplate Booster: Ø 210 mm 2300/3000 W Dimensions 576 x 518 x 50; Weight ca.15 kg; Complies with EN 603351 and EN 6033526 European standards. WARRANTY Warranty Warranty services according to the warranty card.
